This manual contains information to help with the installation and
operation of Black Box Corporation’s TotalSwitch line of modular
10 Mbps Ethernet multi-port switches.
TotalSwitch 6 10-Mbps Module
Installation Guide and
Users Reference Manual
Document Number 56-80326BB-00 A0 September 1998
LB6010-TP8 LB6011-FO LB6011-FOSC LB6010-BNC4
LB6012-FO LB6012-FOSC LB6013-FO LB6013-FOSC
LB6013P-FO LB6013P-FOSC LB6014-TPFO LB6014-TPFOSC
LB6015-TP-FO LB6015-TPFOSC LB6016-TPFO LB6016-TPFOSC
LB6016P-TPFO LB6016P-TPFOSC

Disclaimer
Black Box Corporation makes no warranties with respect to this document and disclaims any
implied warranties of merchantability or fitness for a particular purpose. Black Box Corporation
assumes no responsibility for any errors that may appear in this document or for incidental
consequential damages in connection with the performance or use of this material.
This document contains proprietary information which is protected by copyright. No part may
be reproduced in any way without prior consent of Black Box Corporation.
Copyright
© 1998 Black Box Corporation. All rights reserved.
Trademarks
Brands or product names may be trademarks and are the properties of their respective
companies.

Contents
Chapter 1 Introduction
About TotalSwitch 6 10-Mbps Modules . . . . . . . . . . . . . . . . . . .1.1
Chapter 2 Hardware Installation
Jumper Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.1
FiberAlert Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.3
Half-Duplex/Full-Duplex Jumpers . . . . . . . . . . . . . . . . . . .2.4
Factory Test Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.4
Installing TotalSwitch Modules in Modular Concentrator Hubs . .2.4
Installing TotalSwitch Modules in TotalSwitch 6 . . . . . . . . . . . . .2.5
BNC Port Termination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.6
LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.6
LEDs on Twisted Pair Ports . . . . . . . . . . . . . . . . . . . . . . . .2.7
LEDs on Fiber Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.7
LEDs on Thin Coaxial Ports . . . . . . . . . . . . . . . . . . . . . . . .2.8
Chapter 3 User Guidelines
TotalSwitch Installation Examples . . . . . . . . . . . . . . . . . . . . . . .3.1
Chapter 4 Technical Specifications
Fiber Optic Power Specifications . . . . . . . . . . . . . . . . . . . . . . . .4.1
Fiber Optic Cleaning Guidelines . . . . . . . . . . . . . . . . . . . .4.1
Electrostatic Discharge Precautions . . . . . . . . . . . . . . . . . .4.2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.3
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.3
Chapter 5 General Information
Customer Service Information . . . . . . . . . . . . . . . . . . . . . . . . . .5.1
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.1
Federal Communications Commission Radio Frequency
Interference Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.1
Safety Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.2

Chapter 1
Introduction
TotalSwitch 6 10-Mbps Modules™ are IEEE 802.3 multi-port
switchs that provide eight 10Base-T (Half- or Full-Duplex), four
10Base-2 (Half-Duplex), four 10Base-FL (Half- or Full-Duplex) or four
10Base-T (Half- or Full-Duplex) and two 10Base-FL (Half- or Full-
Duplex) switched segments.
TotalSwitch 6 10-Mbps Modules use non-blocking switching
architecture, provide wire speed switching (14,880 pps) for each
segment and ensure extremely low latency.
Each TotalSwitch 6 10-Mbps Module features Store-and-Forward
switching, a self-learning mechanism with advanced address
recognition that holds eight thousand addresses and includes a 1MB
packet buffer for high performance.
About TotalSwitch 6 10-Mbps Modules
TotalSwitch 6 10-Mbps Modules are
designed to be installed in any TotalSwitch
6™ or Modular Concentrator™hub.
Figure 1.1 TotalSwitch 6 TP/8 Module
The following versions of TotalSwitch 6 10-Mbps Modules are
available:
TotalSwitch 6 10-Mbps Module, TP/8 —(LB6010-TP8)
includes eight RJ-45 connectors; Half- or Full-Duplex
on each port
TotalSwitch 6 10-Mbps Module, BNC/4 —(LB6010-BNC4)
includes four BNC connectors; Half-Duplex
TotalSwitch 6 10-Mbps Module, FO/4 —includes four pair ST
(LB6011-FO) or SC (LB6011-FOSC) connectors; 850
nm multi-mode; Half- or Full-Duplex on each port
1.1

TotalSwitch 6 10-Mbps Modules, FO/4-1300 —includes four
pair ST (LB6012-FO) or SC (LB6012-FOSC)
connectors; 1300 nm multi-mode; Half- or Full-
Duplex on each port
TotalSwitch 6 10-Mbps Modules, FO/4-SingleMode —
includes four pair ST (LB6013-FO) or SC (LB6013-
FOSC) connectors; 1300 nm single-mode fiber;
Half- or Full-Duplex on each port
TotalSwitch 6 10-Mbps Modules, FO/4-SingleMode/PLUS —
as above except supports longer distances; includes
four pair ST (LB6013P-FO) or SC (LB6013P-FOSC)
connectors
TotalSwitch 6 10-Mbps Modules, TP4+FO2 —includes four
RJ-45 connectors and two pair ST (LB6014-TPFO) or
SC (LB6014-TPFOSC) connectors; Half- or Full-
Duplex on each port; 850 nm multi-mode fiber
TotalSwitch 6 10-Mbps Modules, TP4+FO2 —includes four
RJ-45 connectors and two pair ST (LB6015-TPFO) or
SC (LB6015-TPFOSC) connectors; Half- or Full-
Duplex on each port; 1300 nm multi-mode fiber
TotalSwitch 6 10-Mbps Modules, TP4+FO2-SingleMode —
includes four RJ-45 connectors and two pair ST
(LB6016-TPFO) or SC (LB6016-TPFOSC) connectors;
Half- or Full-Duplex on each port; single-mode fiber
TotalSwitch 6 10-Mbps Modules, TP4+FO2-SingleMode/
PLUS —includes four RJ-45 connectors and two pair
ST (LB6016P-TPFO) or SC (LB6016P-TPFOSC)
connectors; Half- or Full-Duplex on each port; single-
mode fiber; supports longer distances
Please contact Black Box Corporation for further details and
ordering information on TotalSwitch 6 chassis and Modular
Concentrator hubs.
1.2

Chapter 2
Hardware Installation
This chapter provides configuration and installation information for
TotalSwitch 6 10-Mbps Modules (referred to as Total Switch Modules
throughout the rest of this manual).
Jumper Settings
TotalSwitch TP/8, TotalSwitch FO/4 and TotalSwitch TP/4+FO/2
have several jumpers that may need to be configured. It is necessary
to power down the unit before adjusting the jumper settings.
NOTE: To change the settings once a TotalSwitch Module is
installed, it is necessary to remove the PCB from the chassis. To do
this, loosen the thumbscrews on the face of the chassis, then slide
the PCB out of the chassis. After configuration is complete, slide
the PCB back into the chassis and tighten the thumbscrews.
The following diagrams show the jumper locations and default
settings on the various TotalSwitch Modules.
NOTE: Ports are labeled on the PCB as well as on the front of the
module. The HDX/FDX jumpers at JA1 on TotalSwitch TP/8 are
numbered in reverse order (i.e jumper 1 corresponds to Port 8,
jumper 2 corresponds to Port 7, etc. Refer to the diagram of
TotalSwitch TP/8)
2.1

Figure 2.1 Jumper Locations and Default Settings for
TotalSwitch TP/8
Figure 2.2 Jumper Locations and Default Settings for
TotalSwitch FO/4
2.2

Figure 2.3 Jumper Locations and Default Settings for
TotalSwitch TP/4+FO/2
FiberAlert Jumpers
TotalSwitch FO/4 Modules (board revisions -20 and higher) and
TotalSwitch TP/4+FO/2 Modules feature FiberAlert. When a fiber
optic receive fault is detected, FiberAlert makes the link LED for the
opposite end of the fiber conversion pulse, signifying there is a
problem and thus eliminating “silent failures.”
FiberAlert is enabled/disabled on each fiber port of a TotalSwitch
Module by repositioning the shunts on the 3-pin, FiberAlert jumper
blocks on the PCB. TotalSwitch Modules are shipped from the factory
with FiberAlert disabled on each port.
The FiberAlert jumper blocks on TotalSwitch TP/4+FO/2 Modules
are located at positions JP15 (Port 1) and JP16 (Port 2). The FiberAlert
jumper blocks on TotalSwitch FO/4 Mdoules are located at positions
JP12 for Port 1 (labeled Port 0 on the PCB), JP11 for Port 2 (labeled
Port 1 on the PCB), JP10 for Port 3 (labeled Port 2 on the PCB) and
JP9 for Port 4 (labeled Port 3 on the PCB).
Enable FiberAlert by positioning the shunt over the top and center
pins. Disable FiberAlert (factory default) by positioning the shunt over
the center and bottom pins.
2.3

Half-Duplex/Full-Duplex Jumpers
Each twisted pair and fiber optic port on a TotalSwitch Module can
operate in either Half-Duplex (HDX) or Full-Duplex (FDX) mode.
TotalSwitch Modules are shipped from the factory with HDX selected
on each port. HDX/FDX is selected on TotalSwitch Modules by
repositioning the shunts on the 3-pin, HDX/FDX jumper blocks on
the PCB.
The HDX/FDX jumper blocks on TotalSwitch TP/8 Modules are
located at position JA1 and labeled 1 - 8. The HDX/FDX jumper
blocks on TotalSwitch TP/4+FO/2 Modules are located at positions
JP5-10 (and labeled with the corresponding port). The HDX/FDX
jumper blocks on TotalSwitch FO/4 Modules are located at positions
JP4 for Port 1 (labeled Port 0 on the PCB), JP5 for Port 2 (labeled
Port 1 on the PCB), JP6 for Port 3 (labeled Port 2 on the PCB) and JP7
for Port 4 (labeled Port 3 on the PCB).
Select FDX by positioning the shunt over the top and center pins.
Select HDX (factory default) by positioning the shunt over the center
and bottom pins.
Factory Test Jumpers
The jumper blocks located at position JP1 on TotalSwitch
TP/4+FO/2 Modules and at position JP8 on TotalSwitch FO/4 Modules
are for factory test purposes only. These jumpers are configured at the
factory and should not be changed. The default setting is with the
shunt positioned on the top two pins.
Installing TotalSwitch Modules in Modular Concentrator
Hubs
TotalSwitch Modules can be installed into any available slot in any
collision domain on any Modular Concentrator hub (e.g.: Modular
Concentrator/12, Modular Concentrator/5 and Modular
Concentrator/2). For specific installation and operation information
on Modular Concentrator hubs, please refer to the manual included
with the hub.
NOTE: TotalSwitch Modules are not capable of being managed
even when installed in a Modular Concentrator hub using SNMP
managment.
2.4

To install a TotalSwitch Module, remove the blank bracket covering
the slot where the module is to be installed by removing the two
screws located closest to the outside edge of the bracket.
NOTE: TotalSwitch Modules cannot be installed in Slot 1; this
disables SNMP for the Modular Concentrator’s NMS.
Next, slide the module into the chassis until it is seated securely in
the connector on the backplane. Secure the module to the chassis by
tightening the thumbscrews.
Figure 2.4 Installing a TotalSwitch Module in a Modular Concentrator
Hub
To complete the installation of a Modular Concentrator hub, refer
to the manual included with the hub for more information.
Installing TotalSwitch Modules in TotalSwitch 6
TotalSwitch Modules can be installed into any available slot in any
modular TotalSwitch 6. Before installing a TotalSwitch Module in a
TotalSwitch 6 chassis, the resistor packs on the module must be
removed from the sockets on the rear of the PCB (lift the resistor pack
from the socket). Refer to the diagrams of the modules earlier in the
chapter for socket location.
NOTE: The sockets are located in the same general location on
TotalSwitch BNC/4.
To install a TotalSwitch Module, remove the blank bracket covering
the slot where the module is to be installed by removing the two
screws located closest to the outside edge of the bracket.
Next, slide the module into the chassis until it is seated securely in
the connector on the backplane. Secure the module to the chassis by
tightening the thumbscrews.
2.5

To complete the installation of a TotalSwitch 6, refer to the
TotalSwitch 6 Installation Guide included with the chassis.
BNC Port Termination
When using the BNC port, the port termination may need setting.
TotalSwitch BNC/4 features
a 2-position switch next to
each BNC connector that
allows a thin coaxial
segment to be terminated
at the hub/chassis without
an additional ‘T’ connector
and terminator. Figure 2.5 BNC Termination Switch
If the TotalSwitch Module is attached
to the mid-point of a thin Ethernet
segment, attach a ‘T’ connector to the
BNC port. Termination must be OFF
(disabled – factory default). Termination
is disabled when the toggle is in the
down position.
Figure 2.6 BNC Termination
If a thin Ethernet segment is to be terminated at the TotalSwitch
Module, attach the cable directly to the BNC connector and set the
termination switch to ON (enabled) by moving the toggle to the up
position.
NOTE: When the BNC port is not being used, Black Box
recommends the toggle be set to ON and a 50
Ω terminator be
connected to the port.
LEDs
TotalSwitch Modules feature diagnostic LEDs per port. The
following diagrams show the LEDs on TotalSwitch TP/8, BNC/4 and
FO/4 Modules. Refer to the sections “LEDs on Twisted Pair Ports” and
“LEDs on Fiber Ports” for LED information on TotalSwitch TP/4+FO/2
Modules.
2.6

LEDs on Twisted Pair Ports
The LED functions for twisted pair ports are as follows:
Figure 2.7 LEDs on TotalSwitch TP/8 Module
FDX Glows amber when Full-Duplex is selected on the port
LNK This LED provides three port status functions:
• Glows green constantly in normal operation
• Blinks green once every few seconds when there is a
Link failure
• Blinks green twice every few seconds if the port has
been partitioned
LEDs on Fiber Ports
The LED functions for fiber optic ports are as follows:
Figure 2.8 LEDs on TotalSwitch F0/4 Module
RCV Flickers amber when port is receiving data
XMT Flickers green when port is transmitting data
FDX Glows amber when Full-Duplex is selected on the port
LNK This LED provides three port status functions:
• Glows green constantly in normal operation
• Blinks green once every few seconds when there is a
Link failure
• Blinks green twice every few seconds if the port has
been partitioned
2.7

LEDs on Thin Coaxial Ports
The LED functions for thin coaxial ports are as follows:
Figure 2.9 LEDs on TotalSwitch BNC/4 Module
ACT Flickers green in normal operation indicating
activity (traffic) on the BNC segment
COL Flickers red in normal operation indicating
normal collisions are being detected on the
BNC segment
2.8

Chapter 3
User Guidelines
As stated earlier, TotalSwitch Modules are 10 Mbps Ethernet, multi-
port switchs that provide eight 10Base-T (Half- or Full-Duplex in any
combination), four 10Base-2 (Half-Duplex) or four 10Base-FL (Half-
or Full-Duplex in any combination) or four 10Base-T (Half- or Full-
Duplex) and two 10Base-FL (Half- or Full-Duplex) switched
segments. This chapter discusses how to use a TotalSwitch Module in
a network.
TotalSwitch Installation Examples
PROBLEM 1: Your network performance is suffering because you
have too many nodes creating too much traffic.
SOLUTION: By installing a TotalSwitch Module, as illustrated in
Figure 3.1, you will decrease traffic congestion and, at
the same time, increase your network’s performance.
Figure 3.1
PROBLEM 2: You need to connect two 10 Mbps Ethernet
networks located in different buildings. The buildings
are farther apart than the IEEE 802.3 specification allows
(e.g.: maximum distance is 2 km on a fiber optic link
segment).
SOLUTION: In order to make a connection beyond the IEEE
802.3 specification, you need to eliminate the collisions
that are inherent in Ethernet. This can be done by using
Full-Duplex. Each UTP port on TotalSwitch TP/8 Module
3.1

can operate in either Half- or Full-Duplex. By placing a
TotalSwitch TP/8 Module in each building, selecting FDX
on one of the TP ports, and attaching this link segment
to a Media Converter TP/FO, you can make long
distance (up to 40+ km in the case of TP/FO Single-
Mode/PLUS), Full-Duplex, 10 Mbps Ethernet fiber
connections between buildings, as illustrated in Figure
3.2.
Figure 3.2
PROBLEM 3: You have the same situation as Problem 2, but you
have four buildings you need to connect.
SOLUTION: As in the solution to Problem 2, using a
combination of a TotalSwitch Module and Media
Converter TP/FO, you can make multiple long distance
fiber runs from one central point. Simply install a
TotalSwitch FO/4 in one building and place a Media
Converter TP/FO on each link segment, as illustrated in
Figure 3.3.
Figure 3.3
3.2

Chapter 4
Technical Specifications
Fiber Optic Power Specifications
The maximum distance between any two fiber optic devices is
determined by a number of factors, including the TotalSwitch
Modules used in the configuration. The following table shows the
specifications for each of the available TotalSwitch Modules and will
assist in determining which TotalSwitch Module is best for your
installation.
1Distances listed are estimates and can vary with application. Distance limitations are determined by a
combination of fiber characteristics, number of splices and other physical parameters. Subtract 3 dB
from Power Loss Budget for 50/125µmulti-mode fiber.
2Values are averages and have been determined under factory conditions. Actual field application
values may vary.
3Half-Duplex (HDX) distances are limited by IEEE specifications.
Fiber Optic Cleaning Guidelines
Fiber Optic transmitters and receivers are extremely susceptible to
contamination by particles of dirt or dust, which can obstruct the
optic path and cause performance degradation. Good system
performance requires clean optics and connector ferrules.
1) Use fiber patch cords (or connectors, if you terminate your own
fiber) only from a reputable supplier; low quality components can
cause many hard-to-diagnose problems in an installation.
2) Dust caps are installed at the factory to ensure factory-clean
optical devices. These protective caps should not be removed
until the moment of connecting the fiber cable to the device.
Assure that the fiber is properly terminated, polished and free of
4.1

any dust or dirt and that the location is as free from dust and dirt
as possible.
3) Store spare caps in a dust free environment such as a sealed
plastic bag or box so that when reinstalled they do not introduce
any contamination to the optics.
4) Should it be necessary to disconnect the fiber device, reinstall the
protective dust caps.
5) If you suspect that the optics have been contaminated, alternate
between blasting with clean dry compressed air and flushing with
methanol to remove particles of dirt.
Electrostatic Discharge Precautions
Electrostatic discharge (ESD) can cause damage to your add-in
modules. Always observe the following precautions when installing or
handling an add-in module or any board assembly.
1) Do not remove unit from its protective packaging until you are
ready to install it.
2) Wear an ESD wrist grounding strap before handling any module
or component. If you do not have a wrist strap, maintain
grounded contact with the system unit throughout any procedure
requiring ESD protection.
WARNING! Integrated circuits and fiber optic components are
extremely susceptible to electrostatic discharge damage. Do not
handle these components directly unless you are a qualified service
technician and use tools and techniques that conform to accepted
industry practices.
3) Hold boards by the edges only; do not touch the electronic
components or gold connectors.
4) After removal, always place the boards on a grounded, static free
surface, ESD pad or in a proper ESD bag. Do not slide the board
over any surface.
4.2

Specifications
Environmental
Operating Temperature: 32° - 122° F (0° - 40° C)
Storage Temperature: 22° - 160° F (-6° - 71° C)
Humidity: 5 - 95% non-condensing
4.3

Chapter 5
General Information
Customer Service Information
Call: [phone] Phone orders 24 hours a day, 7:00 AM
Monday to midnight Friday; 8:00 AM to 4:00 PM
Saturday (EST)
Fax: [phone] or in North America 1-800-321-0746
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence,
PA 15055-1018
Technical Support and fax orders 24 hours a day
Warranty
Contact Black Box Corporation for warranty information.
Federal Communications Commission Radio Frequency
Interference Statement
This equipment has been tested and found to comply with the
limits for a Class A computing device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
chassis the user will be required to correct the interference at his own
expense.
Any changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the
equipment.
The use of non-shielded I/O cables may not guarantee compliance
with FCC RFI limits.
5.1

Safety Certifications
UL: Listed to UL1950 and CSA 22.2, No. 950, Safety of
Information Technology Equipment, Including
Electrical Business Equipment.
TUV/GS: Certified to EN 60 950, Safety of Information
Technology Equipment, Including Electrical Business
Equipment.
CE: The products described herein comply with the
Council Directive on Electromagnetic Compatibility
(89/336/EEC) and the Council Directive on Electrical
Equipment Designed for use within Certain Voltage
Limits (73/23/EEC). For further details, contact Black
Box Corporation.
NOTE: Modules are FCC approved and UL, TUV/GS
and CE certified when installed in a Black Box chassis
only.
5.2
