Black Box VT-101 User manual

IENGLISHI
1
Verification tool for use with EVEMS240-100 & EVEMS240-200
Usage Instructions:
The device must be turned on and the cable plugged into it before plugging it into to the
energy manager. To start testing unplug one of the current monitoring devices from the energy
manager’s control board and plug in the tool to that location. The display will read the
percentage of load the tool is simulating for the control device. Rotating the adjustment nob
clockwise will simulate more current and counter-clockwise for less current. If you want the
energy manager to respond quickly to your adjustment nob movements, you must put the
energy manager into test mode by rotating the time adjustment dial on the energy manager
control board all the way counter-clockwise. This must be adjusted back to its original position
after testing to restore the normal operation of the energy manager. The device is autosensing
between an EVEMS240-100 device and an EVEMS240-200 model so no adjustments are needed
to change between devices. See the chart below for the corresponding display percentage
current and actual current simulated respective to each device. This tool is for verification
purposes only as calibration is done in the factory before energy managers are shipped.
Charging: Always keep the device in a state of charge, especially when stored at a cold temperature. Charge it by plugging the micro-USB cable into the appropriate connection
point on the device and the other end into a USB charger while the battery switch is in the ON position. Switch it to the OFF position when storing the device in a safe place
while not in use. The LED on the front labeled battery will be green when the switch is ON and the battery is fully charged. This color will change progressively to red when the
battery is getting low and is needed to recharge
EVEMS240-200
READING %
AMPS
100
200
90
180
80
160
70
140
60
120
50
100
40
80
30
60
10
20
0
0
EVEMS240-100
READING %
AMPS
100
100
90
90
80
80
70
70
60
60
50
50
40
40
30
30
10
10
0
0
Please read & save these instructions
VT-101 INSTRUCTION MANUAL

2
INFORMATION
This document contains important
instructions which must be followed
during the use of this device.
Notes
It is the installer’s responsibility to verify that
this device is charged in a responsible manor
with the appropriate power source.
Do not use any solvents to clean this device.
Do not paint or apply exterior finishing to this
device.
Cautions
Do not use this device with other products. Do
not connect it to power sources other then
what is described in this document.
Warning
Read all documentation provided by the
device manufacturer before using this
product and follow the installation and setup
procedures. Always disconnect any and all
sources of power before starting work in a
device that uses electricity.
Do not modify, repair, or dismantle the
device.
Never introduce water or any other liquids to
the area around or on this device.
Do not install or charge the device near
flammable materials, explosives or fuels,
chemical products, and vapors.
Do not install this device in a hazardous or
wet environment or location
Disconnect this device immediately if
defective or damaged in any way and
contact the manufacturer.
Any improper use of the device could result
in serious injuries, death, or damage to
property.
Any improper use of the device can cause
damage which will void the warranty.
The devices must be always kept free of
frost and water vapor.
Feedback
We are always happy to hear your
feedback on our products of this
manual. We look forward to hearing
from you. Please email all comments
to
[e-mail].
You can also contact us by clicking on
the message us button on our website
at www.blackbox-in.com.
Limited warranty
1 Black Box Innovations Inc. warranties this
device against any defects for a period of one
year from the date of shipping. The warranty is
limited to the components and equipment
supplied by Black Box Innovations Inc.
2Black Box Innovations Inc. may undertake
repair or replacement, at the site or the
manufacturing location, at its option, of the
defective material only after an evaluation has
been made by its representative.
3If, in the opinion of Black Box Innovations Inc.
installation has been done incorrectly, or the
device is used inappropriately, or repairs have
been done by unauthorized personnel other
than representatives of Black Box Innovations
Inc., the warranty will be automatically void.
4Black Box Innovations Inc. will not be held
liable for damages or delays and will not be
required to pay the transport cost of the
charge controller claimed to be defective.
5Prior written consent must be made by Black
Box Innovations Inc. before repairs,
replacement, or modifications for
compensation to be made.
6Black Box Innovations Inc. shall not be liable for
any charging equipment used to charge this
device or direct or indirect damage that results
from the charging of this device.
7Black Box Innovations Inc. shall not be liable
for any indirect damages or delays caused by
inadequate workmanship, or materials with
device usage. This also applies if not used in
accordance with the manufacturer’s
instruction, local electrical codes, as well as
specifications of devices connected to this
device.
8Black Box Innovations Inc. shall not be
liable for any direct or indirect damages or
delays for any devices that are connected to
this device that can not tolerate having
supplied power switched off for any time
period specified by the device or when the
device is in need of repair or maintenance.
9Any repairs made at the Black Box
Innovations Inc. factory are warrantied for 30
days from the date of repairs.
10 Any components supplied for repairs are
warrantied for the remaining of the warranty
on the original product or 90 days whichever is
longer.
