Black Line BLK-HD360 User manual

HD CCTV
Digital Video
Panoramic View Camera
OPER ATION MANUAL
Thank you for choosing our high quality camera.
Before attempting to connect operate this unit, please read and follow these instructions.
M159-HDV120F-001

These servicing instructions are for use by qualied service personnel only.
To reduce the risk of electric shock do not perform any servicing other than
that contained in the operating instructions unless you are qualied to do so.
Use Class 2 Power Supply Only
CAUTION
2
CONTENTS
1. CAUTIONS
2. IMPORTANT SAFETY INSTRUCTIONS
3. FEATURES
4. EQUIPMENT AND ACCESSORIES
5. CAMERA COMPONENT DESCRIPTIONS
6. INSTALLATION
7. DIMENSIONS
8. SPECIFICATIONS
9. OSD MANUAL
• Menu Structure
• Function Description

1. CAUTIONS
3
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Note
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
WARNING
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Caution
Any changes or modications in construction of this devices which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
1. A regulated DC12V 1A power supply is recommended for use with
this camera for the best picture and the most stable operation.
An unregulated power supply can cause damage to the camera.
When an unregulated power supply is applied, the product warranty will
be void.
2. It is recommended that the camera be used with a monitor that has a CCTV
quality 75 video impedance level. If your monitor is switched to high impedance
then please adjust accordingly.
3. Do not attempt to disassemble the camera to gain access to the internal
components. Refer servicing to your dealer.
4. Never face the camera towards the sun or any bright or reective light, which
may cause smears on the picture and possible damage to the image sensor.
5. Do not remove the serial sticker for the warranty service.
6. Do not expose the camera to rain or other types of liquid.
7. The apparatus must be connected to a main socket-outlet with a protective
earth connection.

1. CAUTIONS
4
WEEE
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that it
should not be disposed with other household wastes at the end of its
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly
to promote the sustainable reuse of material resources. Household
users should contact either the retailer where they purchased this
product, or their local government office, for details of where and
how they can take item for environmentally safe recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for
disposal.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
This symbol is intended to alert the user to the presence
of un-insulated “dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude to constitute a
risk of electric shock.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.

2. IMPORTANT SAFETY INSTRUCTION
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specied by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualied service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
5

3. FEATURES
• High Resolution.
SONY 1 / 3” Progressive Color CMOS Image Sensor. ( 3 Mega Pixel ).
• Support Various Digital Video Output.
1080p30, 1080p25
• Video Outputs.
Primary HD-SDI (BNC)
Test/Setup TV Out (Test Point-adapter to BNC included),
NTSC/PAL selectable
• 360° Panorama HD-SDI Camera.
- Four PTZ Views - Two 180° Panorama Views
- One 360° Panorama View with PAN
• OSD menu for setup and configuration.
• Support RS485 Communucation Protocol for
Camera Configuration Remote Control.
- PELCO-D , PELCO-P
• Lens Control
Fisheye Lens Focal Length ( 1.25 mm )
• Power Source : DC 12V / AC24V
• IP66 Weather Resistant.
6

4. EQUIPMENT AND ACCESSORIES
Camera
Template Manual
Screws / Plastic anchors / Wrench Service Video Output Test Cable
7
When using
Wall Mount Bracket

5. CAMERA COMPONENT DESCRIPTIONS
8
• CONTROL FUNCTION
(OSD JOYSTICK)
LEFT
UP
RIGHT
DOWN
MENU
*PRESS INWARD FOR MENU
OSD Joystick
Service Video Connector

6. INSTALLATION
9
Cover Screws(3ea):
are “captive and will
normally be retained in
cover. They are shown
here for illustration
purposes.
Screws(3ea)
Plastic Anchors(3ea)
Template

6. INSTALLATION
• MONITOR CONNECTION
10
When you install the camera, please glue up the end of cable to
keep it stable in order to protect the camera from the humidity problems.
View of the most appropriate angle can be set.
Using the 1-axis 360° rotation function.
HD SDI IN
RS485(+)
RS485(-)
DC12V / AC24V REGULATED
POWER SUPPLY
VIDEO IN
HANDHELD
MONITOR
Service Video
Connector
OPEN
COVER
TEST CABLE

7. DIMENSIONS
Unit(mm)
11
Ø112.8
Ø151
Ø107
123.4
71.5
Ø124

8. SPECIFICATIONS
Image Device SONY 1 / 3” Progressive Color CMOS Image Sensor
( 3 Mega Pixel , 15 fps )
Effective Pixels 2096 (H) x 1561 (V)
Unit cell size(um) 2.5um (H) x 2.5um (V)
Video output mode HD-SDI: 1080p30, 1080p25
TV Out: NTSC / PAL selectable
Output Mode
360° Panorama View / Four PTZ Views
Two 180° Panorama Views /
One 360° Panorama View with PAN
Minimum illumination 0.1 Lux
S/N Ratio Max 50dB
Video output HD-SDI / 1.0 Vp-p Composite (75Ω)
Lens Fisheye Lens Focal Length ( 1.25 mm )
View Angle
360° ( H ) / 185° ( V ) ( Original Views / Four PTZ Views )
360° ( H ) / 65° ( V ) (360° Panorama Views )
180° ( H ) / 65° ( V ) x 2 ( 180° Panorama Views )
PTZ Digital
D-ZOOM 1X ~ 10X
Shutter speed Auto / Manual selectable
Manual shutter speed 1/10000 sec
Flickerless OFF / ON ( 60Hz / 50Hz ) selectable
White Balance ATW / Manual / Specific Color / Push
BLC On / Off (by OSD)
OSD Menu Yes
Power Consumption DC 12V (±10%), Max.540mA
AC 24V (±10%), Max.6.5W
Dimension 151(Ø) x 123.4(mm)
Weight 950g
Conformity CE, FCC
IP Rating IP66 (Weatherproof)
Temperature / Humidity
(no condensing)
Operation : 14°F ~ 112°F ( -10~50 / 20~80% )
Storage : -4°F ~ 158°F ( 20~70 / 20~95% )
Specifications and designs are subject to change for improving the
functionality of this product without notice.
12

9. OSD MANUAL
• Menu structure
- Panorama Mode Select
Main Sub Menu Sub Menu
PANORAMA
MODE
SELECT
180° PANORAMA
360° PANORAMA
WINDOW SELECT 1 ~ 2
FILP ON / OFF
MIRROR ON / OFF
POSITION INITIALIZE
1 REGION
1:ORIGINAL / 3:PTZ
4PTZ
WINDOW SELECT 1 ~ 4
FILP ON / OFF
MIRROR ON / OFF
PTZ & ZOOM CONTROL PAN & ZOOM CONTROL
ZOOM IN / ZOOM OUT
POSITION INITIALIZE
- Camera setting
Main Sub Menu
CAMERA
SETTING
EXPOSURE
WHITE BALANCE
DAY & NIGHT
SYSTEM
RESET DATA
- EXPOSURE Menu
Main Sub Menu Sub Menu
EXPOSURE
SHUTTER SHUTTER
MODE
NORMAL
AE
AE
PRIORITY
NORMAL
GAIN
GAIN LEVEL:
0DB / 1.2DB / 3.31DB /
5.12DB / 6.92DB / 9.33DB
11.14DB / 12.94DB /
15.34DB / 17.16DB /
18.96DB / 21.37DB
/ 23.18DB / 25DB /
27.09DB / 29.2DB
SHUTTER SUTTER LEVEL:
1 ~ 160
MANUAL
USER MODE 1 ~ 4
GAIN LEVEL 1 ~ 150
SHUTTER LEVEL 1 ~ 160
AE HOLD
FLICKERLESS OFF / 50HZ / 60HZ
BRIGHTNESS 0 ~ 255
AGC 0 ~ 186
BLC ON / OFF
WDR ON / OFF
13

9. OSD MANUAL
- WHITE BALANCE Menu
Main Sub Menu Sub Menu
WHITE
BALANCE WB MODE
ATW ATW MODE INDOOR / OUTDOOR
MANUAL R GAIN 0 ~ 255
B GAIN 0 ~ 255
SPECIFIC
COLOR TARGET TEMP
1500K / 1567K / 1641K / 1721K / 1810K /
1909K / 2019K / 2143K / 2283K / 2242K /
2625K / 2838K / 3088K / 3387K / 3705K /
4200K / 4773K / 5526K / 6563K / 8077K /
10500K / 15000K
PUSH
- DAY & NIGHT Menu
Main Sub Menu Sub Menu
DAY &
NIGHT DAY & NIGHT
AUTO
DELY TIME 0 ~ 10
DAY THRESHOLD 0 ~ 255
NIGHT THRESHOLD 0 ~ 255
BW
COLOR
- IMAGE Menu
Main Sub Menu Sub Menu
GAMMA Y GAMMA PRESET 0 ~ PRESET 3
C GAMMA PRESET 0 ~ PRESET 3
SHARPNESS 0 ~ 31
CONTRAST 0 ~ 31
SATURATION 0 ~ 31
DNR OFF / LOW / MIDDLE / HIGH
- SYSTEM Menu
Main Sub Menu Sub Menu
SYSTEM
FIRMWARE VER
COMMUNICATION
CAMERA ID GROUP 1 ~ GROUP 51
BAUD RATE 2.4K / 4.8K / 9.6K / 19.2K / 38.4K / 57.6K
COMM APPLY
SDI FRAME RATE 30HZ / 25HZ
CVBS FORMAT NTSC / PAL
FACTORY RESET
14

15
9. OSD MANUAL
• Function Description
MAIN MENU
- PANORAMA MODE SELECT
: Panorama Mode Select.
- WHITE BALANCE
: Basic CAMERA FUNCTION Setting.
PANORAMA MODE SELECT
- 180 Panorama:
Use the SET button to select Fisheye Corrected Mode With 180° Panorama.
- 360° PANORAMA:
Use the SET button to select Fisheye Corrected Image Mode.
- 1 REGION:
Use the SET button to select 1 Region Image.
- 1 : ORIGINAL / 3 : PTZ:
Use the SET button to select 1 Windows : Original Image + 3 Region Window Image
- 4 PTZ: Use the SET button to select 4 Region Image.
MAIN MENU
+ PANORAMA MODE SELCET
+ CAMERA SETTING
* EXIT
PANORAMA MODE
+ 180 PANORAMA
+ 360 PANORAMA
+ 1 REGION
+ 1: ORIGINAL / 3 : REGION
+ 4 PTZ
* EXIT

9. OSD MANUAL
PTZ & ZOOM MODE (Sub Menu)
- WINDOW SELECT: Use the LEFT/RIGHT button to select the PTZ Control Window.
Control Available Window
Mode Window Number.
1 Region 1
4 Region 1 ~ 4
1 : ORG / 3 Region 2 ~ 4
180 Panorama 1 ~ 2
360 Panorama 1
- FLIP: Use the LEFT/RIGHT button to select ON/OFF the H-Flip Control
- MIRROR: Use the LEFT/RIGHT button to select ON/OFF the MIRROR Control
- PAN&TILT CONTROL: Use the SET button to go to the PAN & TILT CONTROL sub menu.
(only in the 1 : ORG / 3 Region , 4 Region , 1 Region Mode ).
- POSITION INITIALIZE: Use the SET button to action start of Current Mode Data Reset.
PAN & TILT CONTROL (Sub Menu)
- PAN & TILT CONTROL: Use the OSD Joystick button to action of PAN & TILT Control.
- ZOOM CONTROL: Use the SET button to action of ZOOM IN / OUT.
Zoom Ratio : 1X ~ 10X
16
PTZ & ZOOM MODE
* WINDOW SELECT:
+ FLIP
+ MIRROR
+ PAN & TILT CONTROL
+ POSITION INITIALIZE
* ESC
* EXIT
PTZ & ZOOM CONTROL MODE
ZOOM IN ZOOM OUT
* ESC
* EXIT

17
9. OSD MANUAL
• Function Description
CAMERA SETTING
- EXPOSURE: Adjust exposure control
- WHITE BALANCE: Adjust white balance control
- DAY & NIGHT: Day & Night control
- IMAGE: Apply image processing effects
- SYSTEM: System information & setting
- RESET DATA: Reset camera’s all feature data to default value.
- EXIT: Close OSD menu.
EXPOSURE
- SHUTTER: Use the SET button to go to the SHUTTER sub menu.
- FLICKERLESS: Use the LEFT/RIGHT button to select the flickerless control setting
- OFF, 60Hz, 50Hz
- BRIGHTNESS: Use the LEFT/RIGHT button to adjust the brightness reference level
- AGC: Use the LEFT/RIGHT button to adjust the AGC max value.
- BLC: Use the LEFT/RIGHT button to select ON/OFF the Back-Light Compensation control
- WDR: Use the LEFT/RIGHT button to select ON/OFF the Wide Dynamic Range effect control
CAMERA SETTING
+ EXPOSURE
+ WHITE BAMANCE
+ DAY & NIGHT
+ IMAGE
+ SYSTEM
+ RESET DATA
* ESC
* EXIT
EXPOUSE
+ SHUTTER
+ FLICKERLESS OFF
+ BRIGHTNESS 30
+ AGC 140
+ BLC OFF
+ WDR OFF
* ESC
* EXIT

18
9. OSD MANUAL
SHUTTER (Sub Menu)
- SHUTTER MODE: Use the LEFT/RIGHT button to select shutter & gain control mode
- NORMAL AE, AE HOLD, MANUAL
- AE PRIORITY: This menu can be accessed when the SHUTTER MODE is set to NORMAL AE.
Use the LEFT/RIGHT button to select the AE control priority setting.
- NORMAL, GAIN, SHUTTER
- USER MODE: This menu can be accessed when the SHUTTER MODE is set to MANUAL.
Use the LEFT/RIGHT button to select the user mode(1~4) to save setting.
- GAIN LEVEL: In GAIN priority mode at NORMAL AE mode. this menu can be accessed when
the SHUTTER MODE is set to NORMAL AE and AE PRIORITY is set to GAIN.
Use the LEFT/RIGHT button to select the Gain value setting.
- GAIN LEVEL: In MANUAL mode. This menu can be accessed when the SHUTTER MODE
is set to MANUAL. Use the LEFT/RIGHT button to select the Gain level setting.
- SHUTTER LEVEL: This menu can be accessed when the SHUTTER MODE is set to MANUAL.
Use the LEFT/RIGHT button to select the Shutter level setting.
SHUTTER
+ SHUTTER MODE NORMAL AE
+ AE PRIORITY NORMAL
* ESC
* EXIT
SHUTTER
+ SHUTTER MODE NORMAL AE
+ AE PRIORITY SHUTTER
+ SHUTTER LEVEL 25
* ESC
* EXIT
SHUTTER
+ SHUTTER MODE NORMAL
+ USER MODE 1
+ GAIN LEVEL 20
+ SHUTTER LEVEL 50
* ESC
* EXIT
SHUTTER
+ SHUTTER MODE NORMAL AE
+ AE PRIORITY GAIN
+ GAIN LEVEL 0 DB
* ESC
* EXIT
SHUTTER
+ SHUTTER MODE AE HOLD
* ESC
* EXIT

19
9. OSD MANUAL
WHITE BALANCE
- WB MODE : Use the LEFT/RIGHT button to select White balance modes
– ATW, MANUAL, SPECIFIC COLOR, PUSH
ATW Auto trace white balance mode
MANUAL Manual white balance mode
SPECIFIC COLOR Manual setting with target color temperature
PUSH White Balance Push mode to Auto AWB
- ATW MODE : This menu can be accessed when the WB MODE is set to ATW.
Use the LEFT/RIGHT button to select environment setting.
- INDOOR, OUTDOOR
- TARGET TEMP : This menu can be accessed when the WB MODE is set to SPECIFIC COLOR.
Use the LEFT/RIGHT button to select target color temperature.
- R GAIN : This menu can be accessed when the WB MODE is set to MANUAL.
Use the LEFT/RIGHT button to adjust the Red Gain.
- B GAINL : This menu can be accessed when the WB MODE is set to MANUAL.
Use the LEFT/RIGHT button to adjust the Red Gain.
WHITE BALANCE
+ WB MODE ATW
+ ATW MODE INDOOR
* ESC
* EXIT
WHITE BALANCE
+ WB MODE MANUAL
+ R GAIN 48
+ B GAIN 64
* ESC
* EXIT
WHITE BALANCE
+ WB MODE SPECIFIC COLOR
+ TARGET TEMP 3387K
* ESC
* EXIT
WHITE BALANCE
+ WB MODE PUSH
* ESC
* EXIT

20
9. OSD MANUAL
DAY & NIGHT
- DAY & NIGHT : Use the LEFT / RIGHT button to select Day & Night modes
– AUTO, COLOR, BW
AUTO Auto controlled by AGC level in the processor.
COLOR Fixed Day State. Color Image.
BW Fixed Night State. BW Image.
- DELAY TIME : This menu can be accessed when the DAY & NIGHT is set to AUTO.
Use the LEFT/RIGHT button to select state change delay time.
- DAY THRESHOLD : This menu can be accessed when the DAY & NIGHT is set to AUTO.
Use the LEFT/RIGHT button to select threshold value of change from night
state to day state.
- NIGHT
THRESHOLD
: This menu can be accessed when the DAY & NIGHT is set to AUTO.
Use the LEFT/RIGHT button to select threshold value of change from day state
to night state.
DAY & NIGHT
+ DAY & NIGHT AUTO
+ DELAY TIME 3 SEC
+ DAY THRESHOLD 101
+ NIGHT THRESHOLD 188
* ESC
* EXIT
DAY & NIGHT
+ DAY & NIGHT COLOR
* ESC
* EXIT
DAY & NIGHT
+ DAY & NIGHT BW
* ESC
* EXIT
