Polymer wool cartridge
The polymer wool pad may be washed a limited number of times before it
starts to lose efficiency and blocks rapidly.
Replacement packs of polymer wool are available from your retailer and are
quick and easy to replace.
See page 10 on how to remove the cartridge easily from the Inpond.
Removing LED Lamp
Replacing or removing the lamp
can be easily done by unscrewing
part 23 from the lamp holder
(part 19) then part 22 will be able
to be removed. Allowing the lamp
to be disconnected (part 21).
MAINTENANCE & CLEANING
14 15
Polymer wool pad
Polymer wool cartridge
Active hinge
IMPORTANT - Ensure that the mains supply is switched off and the power
isolated before removing the lamp cover.
23
22
21
20
19
Pump
LED Automatic Photo Sensor - detects when light levels are low/dusk
The LED automatic sensor is positioned
on top of the motor body between the
outlet and the lamp. Ensure this is kept
clean from dirt and algae as it needs
sufficient light to activate correctly.
This extremely efficient lamp uses less
than 1 watt of electricity which
automatically turns on at dusk and
off at dawn.
Annual maintenance of the filter
Check for wear. Once a year you should dismantle your Inpond. Dismantle
the filter examining all the parts for wear or damage, replacing any parts
showing obvious signs of wear and/or damage (see getting to know your filter
for replacement codes and parts descriptions on page 2 & 3).
Annual maintenance of the pump
Once a year you should service your pump.
Dismantle pump and examine all parts for wear or damage, replacing any
parts that show obvious wear and/or damage (see getting to know your
Inpond for parts/description and replacement parts codes). Particular care
should be taken to examine the cable entry points.
Annual maintenance of the UVC
Check for wear. Once a year you should dismantle your Inpond UVC section.
Dismantle the UVC containing all the parts for wear and damage, replacing any
parts that show obvious signs of wear or damage (see getting to know your
Inpond filter for replacement codes and parts descriptions on pages 2 & 3).
Winter Storage
The Inpond filter and pump can be run in the pond during the winter but care
should be taken to ensure that it is fully immersed and cannot freeze solid. If
the pump is not used during the winter follow the annual maintenance
procedure and store frost-free in the house or garage until spring.
MAINTENANCE & CLEANING
1/2“ hose fitting
Automatic LED spot light
Ball joint
LED automatic sensor
Pump
If the LED light is not
required you can
permanently remove the
lamp (see removing lamp
section page 14).
