Blaupunkt Arrifana 12 User manual

Instruction manual
Bedienungsanleitung
Instrukcja obsługi
Arrifana 12
BAC-PO-0012-E06D

A12
2
www.blaupunkt.com
CONTENTS
IMPORTANT SAFEGUARD....................................................................................................................................4
DESCRIPTION..............................................................................................................................................................7
IMPORTANT SAFEGUARD....................................................................................................................................9
DESCRIPTION OF THE DISPLAY SCREEN..................................................................................................10
OPERATING FROM THE CONTROL PANEL..............................................................................................10
SELF-DIAGNOSIS ...................................................................................................................................................15
TIPS FOR CORRECT USE ....................................................................................................................................16
WATER DRAINAGE METHOD..........................................................................................................................16
CLEANING..................................................................................................................................................................18
START-END OF SEASON OPERATIONS......................................................................................................20
TECHNICAL DETAILS ...........................................................................................................................................21
TROUBLESHOOTING ...........................................................................................................................................22
Instruction Manual for Remote Control .................................................................................................24
INHALTSVERZEICHNIS
SICHERHEITSHINWEISE......................................................................................................................................36
PRODUKTBESCHREIBUNG ...............................................................................................................................43
INBETRIEBNAHME.................................................................................................................................................44
BEDIENFELD - Funktionstasten.....................................................................................................................45
BETRIEB MIT DEM BEDIENFELD....................................................................................................................45
SELBSTDIAGNOSE.................................................................................................................................................51
ANWEISUNGEN ZUR RICHTIGEN BENUTZUNG DES KLIMAGERÄTES.....................................52
ENTWÄSSERUNGSMETHODEN.....................................................................................................................53
REINIGUNG ...............................................................................................................................................................55
ANFANG UND ENDE DES JAHRESZEITBETRIEBS.................................................................................57
TECHNISCHE SPEZIFIKATIONS.......................................................................................................................58
FEHLERBEHEBUNG...............................................................................................................................................59
SPIS TREŚCI
PRZEPISY I ZASADY BEZPIECZEŃSTWA...................................................................................................63
OPIS URZĄDZENIA...............................................................................................................................................67

A12
3
www.blaupunkt.com
PRZYGOTOWANIE.................................................................................................................................................69
EKRAN WYŚWIETLACZA....................................................................................................................................70
OBSŁUGA PANELU KONTROLNEGO...........................................................................................................70
AUTO DIAGNOZA .................................................................................................................................................75
PORADY DOTYCZĄCE WŁAŚCIWEGO UŻYTKOWANIA..................................................................76
USUWANIE WODY................................................................................................................................................76
CZYSZCZENIE..........................................................................................................................................................78
CZYNNOŚCI NA POCZĄTEK I KONIEC SEZONU..................................................................................80
SPECYFIKACJA TECHNICZNA.........................................................................................................................80
USUWANIE PROBLEMÓW ................................................................................................................................81
Instrukcja obsługi dla pilota...........................................................................................................................83
CONTENUTI
MISURE DI SICUREZZA.......................................................................................................................................95
DESCRIPTION...........................................................................................................................................................98
PREDISPOSIZIONE ALL’USO............................................................................................................................99
DESCRIZZIONE DEL SCERMO .....................................................................................................................100
FUNZIONAMENTO DA PANELLO DI CONTROLLO..........................................................................100
AUTODIAGNOSI..................................................................................................................................................105
CONSIGLI PER UN UTILIZZO CORRETTO..............................................................................................106
METODO DI DRENAGGIO DELL’ACQUA................................................................................................106
PULIZIA.....................................................................................................................................................................109
OPERAZIONI DI INIZIO E FINE STAGIONE ............................................................................................110
CARATTERISTICHE TECNICHE......................................................................................................................111
SE QUALCOSA NON FUNZIONA...............................................................................................................112
TABLE DES MATIÈRES
PRÉCAUTIONS IMPORTANTES....................................................................................................................116
DESCRIPTION........................................................................................................................................................119
PRÉPARATION POUR L'UTILISATION ........................................................................................................120
DESCRIPTION DU PANNEAU DE COMMANDE .................................................................................121
FONCTIONNEMENT DEPUIS LE PANNEAU DE COMMANDE ...................................................121

A12
4
www.blaupunkt.com
AUTO-DIAGNOSTIC ..........................................................................................................................................125
CONSEILS POUR L'UTILISATION CORRECTE........................................................................................127
MÉTHODE DE DRAINAGE DE L'EAU........................................................................................................127
NETTOYAGE................................................................................... Błąd! Nie zdefiniowano zakładki.
OPÉRATIONS DE DEBUT/FIN DE SAISON.............................................................................................131
DÉPANNAGE..........................................................................................................................................................133
WEE SIGN................................................................................................................................................................140
NOMENCLATURE................................................................................................................................................140
IMPORTANT SAFEGUARD
•Use this appliance only as described in this instruction manual. As with all
electrical equipment, whilst the instructions aim to cover many eventualities as
possible, caution and common sense should be applied when operating and
installing this appliance.
•This appliance is designed for home air conditioning and must not be used for
other purposes.
•It is dangerous to modify or alter the characteristics of the appliance in any way.
•The appliance must be installed in conformity with national legislation
regulating electrical equipment and installations.
•If the appliance requires repair, contact Service Centre authorized by the
manufacturer only. Repairs carried out by unauthorized personnel may be
dangerous.
•This appliance must be used exclusively by adults.
•The appliance must be connected to an efficient earth system. Have your
electrical circuit checked by a qualified electrician.
•Do not use extension cables.
Before cleaning or maintenance, always unplug the appliance from the mains
socket.

A12
5
www.blaupunkt.com
•Never unplug the appliance by pulling on the power cable.
•Do not install the appliance in rooms containing gas, oil or sulphur. Do not install
near sources of heat.
•Keep the appliance at least 50 cm away from flammable substances (alcohol etc.)
or pressurized containers (eg. aerosol cans).
•Do not rest heavy or hot objects on top of the appliance.
•Clean the air filter at least once a week.
•Avoid using heating appliances near the air conditioner.
•Always transport the appliance upright or resting on one side. Before moving,
the appliance, empty the internal circuit completely of water. After moving the
appliance, wait at least 1 hour before starting it.
•When putting the appliance away, do not cover with plastic bags.
•The materials used for packaging can be recycled. You are therefore
recommended to dispose of them in special differentiated waste collection
containers.
•At the end of its working life, consign the appliance to a specialist collection
centre.
•If the power cable is damaged, it must be replaced by the manufacturer or an
authorized technical service centre in order to avoid all risk.
•This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance (based on IEC60335-2-40)

A12
6
www.blaupunkt.com
This product contains fluorinated greenhouse gases covered by the Kyoto Protocol.
Do not vent gases into the atmosphere. Refrigerant type: R290. GWP (Global
Warming Potential) with value: 3.
ELECTRICAL CONNECTIONS
Before plugging the appliance into the mains socket, check that:
•The mains power supply corresponds to the value indicated on the rating plate
on the back of the appliance.
•The power socket and electrical circuit are adequate for the appliance.
•The mains socket matches the plug. If this is not the case, have the plug
replaced.
•The mains socket is adequately earthed. Failure to follow these important safety
instructions absolves the manufacturer of all liability.
Important information for correct disposal of the product in accordance with
EC Directive 2012/19/EU.
At the end of its working life, the product must not be
disposed of as urban waste. It must be taken to a special
local authority differentiated waste collection centre or to
a dealer providing the service. Disposing of a household
appliance separately avoids possible negative
consequences for the environment and health deriving
from inappropriate disposal and enables the constituent
materials to be recovered to obtain significant savings in
energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is
marked with a crossed-out wheeled dustbin.

A12
7
www.blaupunkt.com
SPECIFIC INFORMATION REGARDING APPLIANCES WITH R290 REFRIGERANT GAS
•Thoroughly read all of the warnings.
•When defrosting and cleaning the appliance, do not use any tools other than those
recommended by the manufacturing company.
•The appliance must be placed in an area without any continuous sources of ignition (for example:
open flames, gas or electrical appliances in operation).
•Do not puncture and do not burn.
•Refrigerant gases can be odourless.
•The appliance must be installed, used and stored in an area that is greater than 13 m2.
•R290 is a refrigerant gas that complies with the European directives on the environment. Do not
puncture any part of the refrigerant circuit.
•If the appliance is installed, operated or stored in a non-ventilated area, the room must be
designed to prevent the accumulation of refrigerant leaks resulting in a risk of fire or explosion
due to ignition of the refrigerant caused by electric heaters, stoves, or other sources of ignition.
•The appliance must be stored in such a way as to prevent mechanical failure.
•Individuals who operate or work on the refrigerant circuit must have the appropriate certification
issued by an accredited organization that ensures competence in handling refrigerants according
to a specific evaluation recognized by associations in the industry.
•Repairs must be performed based on the recommendations from the manufacturing company.
•Maintenance and repairs that require the assistance of other qualified personnel must be
performed under the supervision of an individual specified in the use of flammable refrigerants.

A12
8
www.blaupunkt.com
DESCRIPTION
1. Deflector
2. Air outlet grille
3. Display screen
4. Handle
5. Intake grille
6. Castors
7. Control panel
8. Intake grille
9. Air exhaust hose housing
10. Condenser drain
11. Power cable
12. Air Exhaust hose
13. Hose Outlet
14. Stopper or Castor Locks
15. Suckers
16. Window Slider
17. Drain pan
18. Drain Hose
19. Remote Control

A12
9
www.blaupunkt.com
IMPORTANT SAFEGUARD
The instructions below will enable you to prepare your air
conditioner for operation as efficiently as possible.
Before use, make sure the air intake and outlet grilles are
unobstructed.
AIR-CONDITIONING WITHOUT INSTALLATION
Just a few simple steps and your comfort is ensured with
your appliance:
•Fit the air exhaust hose in the housing at the back of
the appliance (fig. A).
•Fit the window outlet to the end of the hose.
Place the air conditioner near a window or French
window.
Adjust the length of the hose to reach the window.
•Make sure the air exhaust hose is unobstructed.
•Open the window or French window slightly and
position the outlet (fig. B).
•If you have a sash window, place the bracket on the
window still, extend the bracket fully within the
window frame fix the bracket by using the pin, then
lower the window onto the bracket. Insert the
window outlet of the exhaust hose into the Slot, then
connect the hose to the air conditioner(fig. C).
•If you have a double window, use the sucker provided
to hold the two parts of the window together (fig. D).
Keep the air hose as short and free of curves as possible to avoid
bottlenecks.

A12
10
www.blaupunkt.com
DESCRIPTION OF THE DISPLAY SCREEN
1. COOL symbol
2. HEAT symbol
3. FAN speed indicator
4. TIMER symbol
5. Temperature symbol
6. Temperature indicator
OPERATING FROM THE CONTROL PANEL
The control panel is on the top of the appliance, enables you to manage part
functions without remote controller, but to fully exploit its potential, you must use
the remote controller.
1. ON/OFF button 4. INCREASE button

A12
11
www.blaupunkt.com
2. MODE button
3. FAN button
5. DECREASE button
TURNING THE APPLIANCE ON
Plug into the mains socket, then the appliance is standby.
Press the button to make the appliance turn on. The last function active when it
was turned off will appear.
COOL MODE
Ideal for hot muggy weather when you need to cooling
and dehumidify the room.
To set this mode correctly:
•Press the Mbutton a number of times until the
symbol appears.
•Select the target temperature 18~32ºC (64~90ºF) by
pressing the or button until the corresponding value is displayed.
•Select the required fan speed by pressing the button.
Three speeds are available:
Maximum speed: to achieve the target temperature as rapidly as
possible.
Medium speed: reduces noise levels but still maintains a good level of
comfort.
Low speed: for silent operation.
Never turn the air conditioner off by unplugging from the mains.
Always press the button
, then wait for a few minutes before
unplugging. This allows the appliance to perform a cycle of checks to
verify operation.

A12
12
www.blaupunkt.com
The most suitable temperature for the room during the summer varies from 24ºC to
27ºC. You are recommended, however, not to set a temperature much below the
outdoor temperature.
HEAT MODE (option)
•Press the Mbutton a number of times until the
symbol appears.
•Select the target temperature 13~27ºC (55~81ºF) by
pressing the or button until the
corresponding value is displayed.
•Select the required fan speed by pressing the
button.
Three speeds are available:
Maximum speed: to achieve the target temperature as rapidly as
possible.
Medium speed: reduces noise levels but still maintains a good level of
comfort.
Low speed: for silent operation.
•Water is removed from the air and collected in the tank.
•When the tank is full, the appliance shuts down and “ ” (full tank) appears on
the display.
The tank cap must be extracted and emptied. Run off all water left into a basin.
When all the water has been drained, put the cap back in place.
•When the tank has been emptied, the appliance starts up again.
N.B. When operating in very cold rooms, the appliance defreeze automatically,
momentarily interrupting normal operation. “ ” appears on the display. During this
operation, it is normal for the noise made by the appliance to change.

A12
13
www.blaupunkt.com
- In this mode, you may have to wait for a few minutes before the appliance starts
giving out hot air.
- In this mode, the fan may operate for short periods, even though the set
temperature has already been reached.
FAN MODE
When using the appliance in this mode, the air hose
does not need to be attached.
To set this mode correctly:
•Press the Mbutton a number of times until the
symbol appears.
•Select the required fan speed by pressing the
button.
Three speeds are available:
Maximum speed: to achieve the target temperature as rapidly as
possible.
Medium speed: reduces noise levels but still maintains a good level of
comfort.
Low speed: for silent operation.
DRY MODE
Ideal to reduce room humidity (spring and autumn,
damp rooms, rainy periods etc.).
In dry mode, the appliance should be prepared in the
same way as for cool mode, with the air exhaust hose
attached to enable the moisture to be discharged
outside.
To set this mode correctly:

A12
14
www.blaupunkt.com
•Press the Mbutton a number of times until the symbol appears.
•Select the required fan speed by pressing the button.
Three speeds are available:
Maximum speed: to achieve the target temperature as rapidly as
possible.
Medium speed: reduces noise levels but still maintains a good level of
comfort.
Low speed: for silent operation.
Switch the unit of temperature
When the appliance is standby, press the M button 20 seconds, then you can
change the unit of temperature.
For example:
Before change, in cool mode, the screen display like fig E.
After change, in cool mode, the screen display like fig F.

A12
15
www.blaupunkt.com
SELF-DIAGNOSIS
The appliance has a self diagnosis system to identify a number of malfunctions.
Error messages are displayed on the appliance display.
IF IS DISPLAYED WHAT SHOULD I DO?
The appliance is fitted with a Frost protection device
to avoid excessive formation of ice.
The appliance starts up again automatically when
the defrosting process is completed.
LOW TEMPERATURE
(frost prevention)
If this is displayed, contact your local authorized
service centre.
PROBE FAILURE
(sensor damaged)
Empty the internal safety tank,
following the
instructions in the “End of season operations”
paragraph.
FULL TANK
(safety tank full)

A12
16
www.blaupunkt.com
TIPS FOR CORRECT USE
To get the best from your air conditioner, follow these
recommendations:
•Close the windows and doors in the room to be air
conditioned (fig. 1). When installing the air
conditioner semi-permanently, you should leave a
door slightly open (as little as 1cm) to guarantee
correct ventilation.
•Protect the room from direct exposure to the sun by
partially closing curtains and/or blinds to make the
appliance much more economical to run (fig. 2).
•Never rest objects of any kind on the air conditioner.
•Do not obstruct the air intake and outlet (fig. 3). Leave
the grilles free.
•Make sure there are no heat sources in the room.
•Never use the appliance in very damp rooms
(laundries for example).
•Never use the appliance outdoors.
•Make sure the air conditioner is standing on a level
surface. If necessary, place the castor locks under the
front wheels.
WATER DRAINAGE METHOD
This air conditioner is equipped with the very last MIST technology which means
the water tank nearly never fills, hence, water drainage will generally only be
required at the end of the season (see START-END OF SEASON OPERATIONS).
However, the MIST technology does not operate when the unit is in HEAT mode.
Thus, the tank may still require emptying in HEAT mode.

A12
17
www.blaupunkt.com
NOTE
As a safety measure, to positively prevent water spillage, the air conditioner is
equipped with a fail safe device, if, the water tank fills. The unit will completely stop,
the control panel displays “ ” (FULL TANK as mentioned in SELF-DIAGNOSIS), the
compressor and fan will nor restart until the tank has been drained.
INTERMITTENT DRAINAGE (fig. 4 and fig. 5)
•Turn the air conditioner off, then drain the water tank by unplugging the drain
cap and allowing the water to flow onto the drain pan. The drain pan will not
hold the full contents of water tank. A number of fills of the drain pan are
required. It may be easier (after 3 or 4 pans have been drained in order to avoid
accidental spillage when moving the air conditioner) to wheel the unit outside,
remove the drain cap and drain the water onto the ground freely.
•The water tank is considered sufficiently when no more water flows from the
drain outlet to completely drain all water from the water tank, tilt the unit by
lifting it slightly upwards from the front until no more water drains from the
outlet.
•Restart the air conditioner by pressing the ON/OFF button. Ensure that the unit is
in COOL, DRY or HEAT mode. The compressor will start approximately 3 minutes
after the unit is switched on.

A12
18
www.blaupunkt.com
CONTINUOUS DRAINAGE (fig. 6 and fig. 7)
When operating in HEAT mode, continuous drain method can also be used to avoid
the trouble of manual drainage.
•Empty the water tank completely.
•Connect one end of the drain hose on the drain outlet, and lead the other end to
outdoor or and place where can be drained freely.
•Turn on the appliance and select HEAT mode.
When continuous drainage method adopted in HEAT mode, the water removed
from the air flows out through the drain hose continuously.
NOTE
Please be sure that the height of and section of the drain hose should not be higher
than that of the drain outlet, or the water tank may not be drained.
CLEANING
Before cleaning or maintenance, turn the appliance off by pressing button on
the control panel or remote control, wait for a few minutes then unplug from the
mains socket.
CLEANING THE CABINET

A12
19
www.blaupunkt.com
You should clean the appliance with a slightly damp cloth then dry with a dry cloth.
Never wash the air conditioner with water. It could be dangerous.
Never use petrol, alcohol or solvents to clean the appliance
Never spray insecticide liquids or similar.
CLEANING THE AIR FILTERS
To keep your air conditioner working efficiently, you should clean the filter every
week of operation.
The evaporator filter can take out like fig. 8.
The condenser filters are two pieces.
Step 1: Take out one filter like fig. 9.
Step 2: Take out other filter like fig. 10-11.
Use vacuum cleaner to remove dust accumulations from the filter. If it is very dirty,
immerse in warm water and rinse a number of times. The water should never be
hotter than 40ºC. After washing, leave the filter to dry then attach the intake grille to
the appliance.

A12
20
www.blaupunkt.com
START-END OF SEASON OPERATIONS
START OF SEASON CHECKS
Make sure the power cable and plug are
undamaged and the earth system is efficient. Follow
the installation instructions precisely.
END OF SEASON OPERATIONS
To empty the internal circuit completely of water,
remove the cap (fig. 12). Run off all water left into a
basin. When all the water has been drained, put the
cap back in place. Clean the filter and dry thoroughly before putting back.
