BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
MODEL 961/961P
Deck Oven
EXTERIOR CONSTRUCTION
Full angle iron frame
Stainless steel front, top, sides and back
Counterbalanced doors with concealed hinges
Heavy chrome plated tubular steel door handle
27-1/2" (699mm) black powder coated legs (for single units)
19" (483mm) black powder coated legs (for double units)
7" (178mm) black powder coated legs (for triple units)
Burner doors open easily for ignition, cleaning or adjustment, without
removal of any fastenings
Vitreous fiber insulation at top, back, sides, bottom and doors
INTERIOR CONSTRUCTION
42" x 32" x 7" (1067mm x 813mm x 178mm) oven compartment interior
Aluminized steel baking compartment liner
Aluminized steel combustion chamber
Steel deck supported by an angle iron frame
12 gauge (3.02mm) press-formed, reinforced and flanged aluminized steel
deck
OPERATION
Free-floating, easily removable duplex-tube burner
Removable fixed orifices on main and pilot burner
Main gas valve, temperature control valve and safety pilot valve fully within
section body and are accessible through a covered and ventilated compart-
ment in front.
Air mixers with adjustable air shutters and locking device
961 - Liquid pressure thermostat with temperature control range of
200°F(93°C) to 500°F (288°C)
961P - Liquid pressure thermostat with temperature control range of
300°F (149°C) to 650°F (343°C)
STANDARD FEATURES
961 - Fahrenheit dial 200° to 500°
961P - Fahrenheit dial 300° to 650°
961- Steel oven deck
961P - Ultra Rokite deck
Two year oven parts and one year labor warranty*
Five year limited oven door warranty*
* For all international markets, contact your local distributor.
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Legs:
7" (178mm) stainless steel legs
19" (483mm) stainless steel legs
27-1/2" (699mm) stainless steel legs
Flexible gas hose with quick disconnect and
restraining device:
36" (914 mm)
48" (1219mm)
Casters
Stainless steel crown angle trim
Vent kit
Double or triple connector for stacking
Ultra Rokite shelves, 1-1/2" (38.1mm) thick
(pizza type shelf)
Steam jets
OPTIONS AND ACCESSORIES
(AT NO ADDITIONAL CHARGE)
961 - FDTH 300°F (149°C) to 650°F (343°C)
temperature thermostat
Centigrade dial, 100°C to 300°C
961/961P - Single/Double/Triple
Project
Item No.
Quantity
Ovens consist of basic sections and are a complete and separate unit
capable of operating alone or in combination.
All data is shown per oven section, unless otherwise indicated.
Refer to operator manual specification chart for listed model name.

BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
MODEL 961/961P
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior
notice
TOP VIEW
2-1/2”
(64) 6” (152) Diameter flue pipe
28-1/8”
(714)
38-1/2”
(978)
31-7/8”
(810)
60” (1524)
GAS 3/4 IPS
(FEMALE)
2-13/16” (71)
5”
(127)
3”
(76)
961 & 961P Single
6” (152) dia.
Flue Pipe
DRAFTHOOD
7”
(178)
13-1/4”
(337)
38” (965)
26-1/8” (664) 45-7/8”
(1165)
GAS 3/4 IPS
(FEMALE)
DRAFT
DIVERTER
6” (152)
48-1/4” (1226)
961 & 961P Double
7”
(178)
13-1/4”
(337)
17-5/8” (448)
60-9/16” (1538)
50-3/16” (1275)
29-1/2” (749)
58-1/16”
(1475)
37-3/8”
(949)
GAS 3/4 IPS
(FEMALE)
6” (152) dia.
Flue Pipe
DRAFTHOOD
DRAFT
DIVERTER
6” (152)
7”
(178)
13-1/4”
(337)
6” (152)
69-5/8” (1768)
59-1/4” (1505)
38-9/16” (979)
67-1/8”
(1705)
47-7/16”
(1180)
GAS 3/4 IPS
(FEMALE)
6” (152) dia.
Flue Pipe
DRAFTHOOD
DRAFT
DIVERTER
6” (152)
961 only Triple
25-3/4”
(654)
17-7/8” (454)
APPROVAL/STAMP
P/N 35029 Rev P (4/08)
SHORT FORM SPECIFICATIONS
Provide Blodgett (single/double/triple) deck oven, model 961. Construction shall be welded stainless steel front, top, back and sides, and shall be fully insulated on all sides. Oven shall
be supported by formed adjustable legs. Door(s) shall be counterbalanced (no springs) with concealed hinges and chrome plated tubular steel handles. Separate burner door provided
for ignition, cleaning and adjustment. Each baking compartment shall be 42" W x 7" H x 32" D and shall be lined with aluminized steel. Deck shall be 11 gauge press-formed, reinforced
and flanged steel. Unit shall be gas heated by a free-floating, easily removable, duplex-type burner controlled by a liquid pressure thermostat with range of 200°F to 500°F (961) or 300°F
to 650°F (961P). Each compartment provided with flue vent. Provide with two year limited parts and one year labor warranty. Provide with options and accessories as indicated.
DIMENSIONS: Single Double Triple
Number of sections: 1 2 3
Number of controls: 12 3
Number of compartments: 12 3
Size of compartment: 42" (1067mm) W x 7" (178mm) H x 32" (813mm) D
Area of each compartment: 9.34 sq. ft. (0.87m2)
Total area of oven: 9.34 sq. ft. (0.87m2) 18.68sq. ft. (1.74m2) 28.02sq. ft. (2.60m2)
Clearance below oven: 26-1/8" (664mm) 17-5/8" (448mm) 6" (152mm)
Floor space: 60" (1524mm) wide x 40" (1016mm) deep
Product clearance: 6" from combustible and non-combustible construction
PAN CAPACITIES: Single Double Triple
10" (254mm) pie tins: 12 24 36
18" x 26" (457mm x 660mm) bun pans: 246
9-1/2" x 5" (241mm x 127mm) bread pans: 24 48 72
9" x 7" (228mm x 178mm) roll pans: 16 32 48
19" x 4" (483mm x 102mm) pullman pans: 14 28 42
13" x 16-1/2" (330mm x 419mm) cup tins: 91827
20" x 28" (508mm x 711mm) roast pans: 246
No. 200 pans (324mm x 527mm): 4812
Bean pots #1: 35 70 105
#3: 20 40 60
#6: 12 24 36
GAS SUPPLY:
3/4" IPS connection at rear of oven
Manifold Pressure:
• Natural – 5" W.C • Propane – 10" W.C.
Inlet Pressure:
• Natural – 7.0" W.C. min. – 10.5" W.C. max.
• Propane – 11.0" W.C. min. – 13.0" W.C. max.
MAXIMUM INPUT:
961 961P
Single 37,000 BTU/hr 50,000 BTU/hr
Double 74,000 BTU/hr 100,000 BTU/hr
Triple 111,000 BTU/hr N/A
MINIMUM ENTRY CLEARANCE:
Uncrated 23-1/4" (591mm)
Crated 27" (686mm)
SHIPPING INFORMATION:
Approx. Weight:
Single: 540 lbs. (245kg)
Double: 1085 lbs. (492kg)
Triple: 1625 lbs. (737kg)
Crate sizes:
65" (1651mm) x 46" (1168mm) x 27" (686mm)
