Blodgett MT2136 Series Installation and operating manual

MT2136 SERIES
CONVEYOR OVEN
SERVICE AND REPAIR MANUAL
BLODGETT OVEN COMPANY
www.blodgettcorp.com
50 Lakeside Avenue, Box 586, Burlington, ermont 05402 USA Telephone (802) 658Ć6600 Fax: (802)864Ć0183
PN M9884 A (6/01)
 1999 - G.S. Blodgett Corporation All rights reserved.
Duplication of the information in this manual is prohibited without the consent of the Blodgett Service Department.

TABLE OF CONTENTS
i
1. INTRODUCTION
Oven Specifications 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
entilation Requirements 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Specifications 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas Specifications 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illustrated Parts Lists 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. ASSEMBLY
Oven Assembly Procedures 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nozzles 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conveyor Supports 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive Chain 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wire Conveyor Belt 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Plates 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conveyor Tunnel Extensions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conveyor Belt Tensioners 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Crumb Pans 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mount remote control 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. OPERATION
Standard Control Options 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
U.E. Temperature Controller with Open Loop DC Drive System 3-1. . . . . . . . . . . . . . . . . . . . .
Athena Temperature Controller with Open Loop DC Drive System 3-2. . . . . . . . . . . . . . . . . . .
Computer Controller 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sequence of Operation 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MT2136E Domestic with Athena controls - M2190 Rev H 3-5. . . . . . . . . . . . . . . . . . . . . . . . . .
MT2136E General Export with Athena controls - M2341 Rev F 3-7. . . . . . . . . . . . . . . . . . . . .
MT2136G Australian Unit with Athena Control - M2847 Rev C 3-9. . . . . . . . . . . . . . . . . . . . . .
MT2136G CE with Athena Control - M3163 Rev C 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MT2136G Domestic with Remote Computer control - M3476 Rev b 3-13. . . . . . . . . . . . . . . . .
MT2136G Domestic with Open Loop Computer Control - M3717 Rev B 3-15. . . . . . . . . . . . .
MT2136G Domestic with Closed Loop Computer Control - M7287 Rev A 3-17. . . . . . . . . . . .
MT2136E CE with Closed Loop Computer Control - M6476 Rev B 3-19. . . . . . . . . . . . . . . . . .
MT2136G CE with Computer Control - M7290 Rev E 3-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MT2136G General Export - M7295 Rev B 3-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oven Adjustments for Cooking 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conveyor Speed Time vs. Temperature 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Flow Adjustments 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS
ii
4. CALIBRATION AND ADJUSTMENT
Convection Blower Motors 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Regulated Gas Pressure 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Standard Controller Configuration 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Belt Speed Calibration - Open Loop 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Calibration - United Electric Controller 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Calibration - Athena Controller 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Computer Controller Configuration 4-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Computer Controls 4-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Calibration 4-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Belt Speed Calibration 4-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Motor Control Board Adjustment 4-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rerating the Appliance 4-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Firing Rate 4-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. TROUBLESHOOTING
DC Drive System 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convection System 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heating System 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Computer Control System 5-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6. TECHNICAL APPENDIX
Intermittent Ignition System 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Principles of Operation 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Procedures 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooking Computer - Temperature vs Resistance 6-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermoelectric oltage in Absoluter Millivolts - Type J Thermocouple 6-5. . . . . . . . . . . . . . . . . .
Conversion Factors 6-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure Conversion 6-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INTRODUCTION
CHAPTER 1

MT2136
1-1
OVEN SPECIFICATIONS
VENTILATION RE UIREMENTS
The hood should completely cover the unit with an
overhang of at least 6" (15 cm) on all sides not adjaĆ
cent to a wall. The distance from the floor to the
lower edge of the hood should not exceed 7' (2.1
m). The ventilation system should replace 80% of
the exhaust volume with fresh make up air.
TABLE 1 should be used as a guideline.
Single Double Triple
CFM 500Ć600 1000Ć1200 1500Ć1800
M3/min 14 Ć 17 28Ć34 42Ć51
TABLE 1
ELECTRICAL SPECIFICATIONS
NOTE: Three Phase hookup is ot permitted o
gas models.
WARNING: DO NOT INSTALL A HIGH LEG" TO
ANY CONVEYOR OVEN!
Installations within the U.S.
MT2136G ovens require a 15 amp, 60HZ, 1F,
120/208Ć240 AC, 4 wire service consisting of L1,
L2 neutral and ground. See FIGURE 1. Use 90C
wire and size to National Electric or local codes.
MT2136E ovens are available in either 1F or 3F opĆ
tions. Single phase models require a 15 amp, 60
HZ, 208Ć240 AC 3 wire service consisting of L1, L2
and ground. Three phase units require a 15 amp,
60 HZ, 208Ć240 AC 4 wire service consisting of L1,
L2, L3, and ground. See FIGURE 1. Use 90C wire
and size to National Electric or local codes.
MT2136G - U.S. Installations
MT2136E - Single Phase U.S. Installations MT2136E - Th ee Phase U.S. Installations
L1
L2
OvenSupply L3
208Ć240
L1
L2 208Ć240 OvenSupply
L1
N120 OvenSupply
L2 120
208Ć240
FIGURE 1

INTRODUCTION
1-2
Installations outside the U.S.
MT2136G ovens require a 15 amp, 50HZ, 1F,
220Ć240 AC, 3 wire service consisting of L1, neuĆ
tral and ground. See FIGURE 2. Use 90C wire and
size to National Electric or local codes.
MT2136E ovens are available in either 1F or 3F opĆ
tions. Single phase units require a 15 amp, 50 HZ,
240 AC 3 wire service consisting of L1, L2 and
ground. Three phase units require a 15 amp, 50
HZ, 220Ć240 AC 4 wire service consisting of L1,
L2, L3 and ground. See FIGURE 1. Use 90C wire
and size to National Electric or local codes.
CE approved installations
The MT2136G requires a 15 amp 50Hz, 1F, 230
AC, 3 wire service consisting of L1, neutral and
ground. Connect exhaust fan connector 1 and 2.
See FIGURE 2. Use 90C wire and size according
to local codes.
NOTE: If the phase a d eutral are switched the
co trol locks out.
The MT2136E requires a 15 amp, 50Hz, 3F, 230
AC, 5 wire service consisting of L1, L2, L3, neutral
and ground. See FIGURE 2. Use 90C wire and
size according to local codes.
240
É
É
s
Connector 1
2
L3
L2
L1
N
Fan
N
L
Blodgett
Connector
2Ć4Ć92
A2
A1
2
1
Relay A
2
1
Air Pressure Regulator
Burner Control Solenoid
MT2136G CE App oved Installations
L1
N230 OvenSupply
MT2136G - Expo t Installations
L1
N220Ć240 OvenSupply
MT2136E - Single Phase Expo t Installations
MT2136E - Th ee Phase Expo t Installations
L1
L2
L3 230 OvenSupply
N
400
400 400
MT2136E - CE App oved Installations
L1
240
OvenSupply L2
L1
L2
L3 OvenSupply
FIGURE 2

MT2136
1-3
GAS SPECIFICATIONS
GAS CONNECTIONS
Domestic and General Export installations
The gas line should be large enough to accommoĆ
date the peak demand of all the gas appliances.
TABLE 2 reflects a straight line, 50 foot run with no
coupling restrictions and no other appliances
drawing service. Gas line installations MUST conĆ
form to National Fuel Gas Code NFPA 54/ANSI
Z223.1 Sec. 1.4 (Latest Edition). TABLE 2 should
be used as a guideline only.
NOTE: For a y pipe ru s over 50 feet (15 m), co Ć
sult the factory.
CE approved installations
1. Connect the oven to the gas line with the propĆ
er type of gas according to Local and National
Installation Standards. See TABLE 2.
GAS RE UIREMENTS
The firing rate for the MT2136G is 55,000 BTU/Hr.
(16 kW/Hr.)
NOTE: For atural gas meter sizi g, co sult your
local gas compa y to e sure that your meĆ
ter will provide the proper supply.
Installations within the U.S.
1. Add the total BTU's/hr of all the gas
appliances.
2. Convert BTU's to cubic ft/hr using the formula
Cu Ft/Hr = 1000 BTU/Hr for natural gas.
3. Size the meter accordingly.
Installations outside the U.S.
1. Add the total M3/min of all the appliances.
2. Size the meter accordingly.
DOMESTIC AND GENERAL EXPORT
Natural Gas Propane Gas
Gas Line Sizing
Single
Double
Triple
3/4" line
3/4" line
1" line
3/4" line
3/4" line
3/4" line
Orifice Size #1 #29
Incoming Gas Pressure W.C. kPa mbar W.C. kPa mbar
Static
Operational
7"
5.5"
1.74
1.36
17.4
13.7
12.5"
11"
3.11
2.73
31.1
27.4
CE APPROVED UNITS
Type of
Gas
Inlet
Pressure
mbars
Burner Pressure
mbars
Injector
Diameter
mm
Air
Opening
mm
Pilot
Injector
mm
Standard
Delivery
Value kW (HS)
G25 25 12 3,30 2 x 16 2 x 0,63 16,3 Nat. Gas
G20 20 8 3,30 2 x 16 2 x 0,63 16,3 Nat. Gas
G20/G25 20/25 Totally Inscrewed
Pressure Regulator
2,90 2 x 16 2 x 0,63 16,3 Nat. Gas
G31 30/37/50 24 2,10 2 x 16 2 x 0,30 16,3 Propane
TABLE 2

INTRODUCTION
1-4
ILLUSTRATED PARTS LISTS
CONVEYOR COMPONENTS
NOTE:  = ASAP Distributor Required Stocki g Parts
Ref.
No.
Part
No. Description
Ref.
No.
Part
No. Description
M2740 Belt, Wire S/S 21" SB (Per Foot)
(Total 11 FT)
39 M6336 Belt, Wire S/S 10" TB (Per Foot)
(Total 21 FT)
M2388 Tensioner Assy., Belt
22 M2379 Speed Control Board, Bodine
M3301 Capacitor, Speed Control
Board, 200W DC
M3145 Potentiometer, Bodine, 10K
23 M2316 Fuse, Armature, Bodine Board,
200 MA, 250
7M2254 Fuse, Line, Bodine Board, 5
AMP, 125
M5770 Conversion Kit, Digital Time
(Open Loop) to MicroĆDrive
(Closed Loop)
M7202 Conversion Kit, Open Loop to
Closed Loop (Computerized)
M3146 Time Display, Digital
M3147 PickĆUp, P Ć10 (For M3146)
M0200 Lock, Speed Control PotentiomĆ
eter
M0201 Dial, Speed Control PotentiomeĆ
ter
21169 Knob, Speed Control PotentiomĆ
eter
M2378 Motor, Conveyor Drive, Bodine
130
M2500 Brush Set, Bodine
M2738 Chain, Drive
M2011 Conveyor Assy., Drive Side SB
M2012 Conveyor Assy., Idle Side SB
M2207 Conveyor Assy., Drive Side TB
M2208 Conveyor Assy., Idle Side TB
M0109 Sprocket, Motor Drive, 12 Tooth
SB/TB
M0108 Sprocket, Conveyor Belt, 11
Tooth SB/TB (Bore Diameter
3/4" ) (Qty 1)
M0110 Sprocket, Conveyor Drive, 15
Tooth SB/TB (Bore Diameter
3/4")
M1865 Sprocket, Conveyor Drive, 15
Tooth TB (Bore Diameter 1/2")
M0112 Masterlink, Drive Chain
M0122 Bearing, Conveyor Drive

MT2136
1-5
TEMPERATURE CONTROLS
Computer solid state co trols for ove s ma ufactured after mid sept., 1993
NOTE:  = ASAP Distributor Required Stocki g Parts
Ref.
No.
Part
No. Description
Ref.
No.
Part
No. Description
M3149 Controller, Digital Temperature
M3439 Relay, Digital Temp. Controller,
10 AMP, 250
M3150 Control Board, Temperature HiĆ
Lo Limit
M3151 Thermocouple, Dual Lead
M3152 Thermocouple, Single Lead
M6474 Computer Control Kit, Closed
Loop SB
FW525 Computer Control Kit, Closed
Loop SB (Reconditioned)
M5635 Computer Control Kit, Open
Loop TB
M7427 Probe, Temperature RTD, 500
OHMS
M3347 Cable, Computer Control, 25
Pin, 10 Foot
M3348 Cable, Computer Control, 9 Pin,
10 Foot
M3490 Cable, Computer Control, 25
Pin, 50 Foot
M3491 Cable, Computer Control, 9 Pin,
50 Foot
M3314 Bracket, Computer Wall
M5661 Bracket Assy., Cable Clamp
19 22672 Relay, Control (Ice Cube) (Qty 4)
18 M3295 Thermostat, High Limit (Manual
Reset)
M0152 Contact, Emergency Stop
Switch
M3296 Activator, Emergency Stop
Switch (Mushroom Shape)
M3297 Nameplate, Emergency Stop
20 M3136 Breaker, 7 AMP Circuit (Qty 2)
(Before AB er.)
21 M2772 Breaker, 4 AMP Circuit (Qty 2)
(Before AB er.)
26 M3352 Transformer, 120 to 24 (Qty 1)
M3349 Harness, InterĆConnecting DC
Drive, 3 Wire (For 9 Pin)
M3353 Harness, Relay Board (Open
Loop) (Qty 1) (For 25 Pin)
M7237 Harness, Relay Board (Closed
Loop) (Qty 1) (For 25 Pin)

INTRODUCTION
1-6
GAS BURNER COMPONENTS
NOTE:  = ASAP Distributor Required Stocki g Parts
Ref.
No.
Part
No. Description
Ref.
No.
Part
No. Description
20287 alve, Single Solenoid 110/120
M0282 alve, Manual Gas
3M0767 Blower Motor, Combustion w/
Control Box
4M2383 Blower Motor, Combustion
1M2381 Transformer, 120 to 24
2M2385 Relay, Time Delay
5M6397 Pilot Burner & Igniter Assy.,
Natural
5M6398 Pilot Burner & Igniter Assy., LP
6 M0248 Tube, Pilot Aluminum 1/4"
7 22258 Burner Assy., Complete
8M0415 Flame Sensor
9M0697 Orifice, Pilot Natural
9M2690 Orifice, Pilot LP
10 M3203 Orifice, Main Burner, Natural
(MTD 29)
10 M1491 Orifice, Main Burner, LP (MTD
45)
M2140 Flame Tube Assy.
16 M1054 Spark Box, 24
11 M5495 Dual Solenoid/Pressure RegulaĆ
tor, Nat. 24
11 22190 Dual Solenoid/Pressure RegulaĆ
tor, LP 24
M3434 Conversion Kit, Natural to LP
(MTD 45)
M3435 Conversion Kit, LP to Natural
(MTD 29)
18612 Spring, Solenoid alve, Natural
to LP
23007 Spring, Solenoid alve, LP to
Natural
12 M0279 Union, 1/2 Inch Black
13 1949 Nipple, Pipe 1/2 x 1Ć3/16 Close
M0590 Nipple, Pipe 1/2 x 2Ć1/2
14 M0317 Elbow, 1/2 Inch Street 90 Deg.
15 597 Ell, Black 90 Degree
17874 Ell, Black 1/2 x 3/4

MT2136
1-7
ELECTRICAL COMPONENTS
NOTE:  = ASAP Distributor Required Stocki g Parts
Ref.
No.
Part
No. Description
Ref.
No.
Part
No. Description
M2571 Element Assy., 208 , 3 PH, 15
KW (Qty 1)
M2697 Element Assy., 208 , 1 PH, 15
KW (Qty 1)
M2572 Element Assy., 240 , 3 PH, 15
KW (Qty 1)
M2698 Element Assy., 240 , 1 PH, 15
KW (Qty 1)
M6891 Element, Individual, 208 (Qty 6)
M6892 Element, Individual, 220 (Qty 6)
M6893 Element, Individual, 240 (Qty 6)
20162 Fuse, 10 AMP, 300 , SCĆ10 (Qty
2) (After...)
M1821 Fuse, 4 AMP, 300 , SCĆ4 (Qty 2)
(Before...)
M0156 Fuse, 10 AMP, 250 , FMNĆ10
M3389 Fuse, 4 AMP, Ceramic, MDAĆ4
M0158 Fuse Holder for SCĆ10 & SCĆ4
Fuses (Qty 2)
M0702 Fuse Block for FMNĆ10 Fuse
M3390 Fuse Holder, 20 AMP for MDAĆ4
Fuse
M2453 Snap Disc, L140Ć20F, 3 Pole
SPDT
M1362 Snap Disc, L140Ć20F, 2 Pole
SPST
M0635 Snap Disc, F110Ć20F, 2 Pole
SPST
M2734 Snap Disc, L165Ć30F, 2 Pole
M0593 Terminal Block, 2 Pole (Neutrals)
w/ Push On Terminals
M3714 Terminal Block, 3 Pole (Power)
MT2136E w/ Allen Head Screws
25 M0708 Contactor, Mechanical, 16 AMP,
3 Pole,120 Coil (Motor)
M2483 Contactor, Mercury, 60 AMP, 3
Pole, 120 Coil (Heat)
M2720 Contactor, Mercury, 100 AMP, 2
Pole, 120 Coil (Heat)
M7170 Transformer, 240 to 115
M2469 Fan, Axial 110 CFM 4Ć1/2" (Qty
3) or (AB Qty 4)
M0571 Guard & Hardware, Fan (Qty 3)
or (AB Qty 4)
M0572 Cord Set, Axial Fan (Qty 3) or (AB
Qty 4)
M0152 Selector Switch, Heat & ConveyĆ
or
M0153 Selector Switch, Blower
M0151 Knob, Selector Switch (Heat/
Conveyor/Blower)
M1694 Cord Set & Plug Assy., 10 Foot
M0772 Receptacle, Twist Lock
4168 Lug, Grounding
CONVECTION COMPONENTS
Ref.
No.
Part
No. Description
M2871 Motor & Blower Assy., 60 HZ,
CW (Qty 1)
M2870 Motor & Blower Assy., 60 HZ,
CCW (Qty 1)
36 M2100 Nozzle Assy. (Aluminum) (Qty 5)
36 M3456 Nozzle Assy. (S/S) (Qty 5)
M2741 Plate Assy., Air (Aluminum) (LH
& RH)
37 M7490 Air Plate, LH (Aluminum)
38 M7493 Air Plate, RH (Aluminum)
M7492 Plate Assy., Block Off
M3125 Upgrade Kit, Cooling Fan (DoĆ
mestic)

INTRODUCTION
1-8
EXTERIOR COMPONENTS
NOTE:  = ASAP Distributor Required Stocki g Parts
 = Doors Are Not Retur able
Ref.
No.
Part
No. Description
Ref.
No.
Part
No. Description
M2085 Decal, Control Panel, SB, Red
M2087 Decal, Control Panel, TB, Red
M2524 Decal, Racing Strip, Red
M2722 Decal, Control Panel, SB, Black
M2723 Decal, Black
M2769 Decal, Control Panel, TB, Black
28 M4306 Crumb Pan, Idle (Remote & InĆ
tergal)
27 M4372 Crumb Pan, Drive w/ Remote
27 M4305 Crumb Pan, Drive w/ Intergal
M4309 Stop, Product
29 M3121 Extension Assy., Product 6"
29 M3122 Extension Assy., Product 12"
26 M2059 Drip Pan (Aluminum)
26 M5008 Drip Pan (S/S)
30 M2450 Access Panel, Combustion
Compartment (Manual) Element
Assy., 240 , 3 PH, 15 KW (Qty 1)
30 M3376 Access Panel, Combustion
Compartment
(Computer Controls)
30 M3553 Access Panel, Control Box
(Integral)
31 M4580 Access Panel, Front w/ Door
M2072 Access Panel, Front w/o Door
M2514 Bolt, Front Access Panel (Allen
Head Decoration)
M3420 Gasket Assy., Front Access PanĆ
el
M3574 Retainer, Gasket Top/Bottom w/
Door
M3575 Retainer, Gasket LH/RH w/ Door
M2731 Retainer, Gasket Top/Bottom
w/o Door
M2732 Retainer, Gasket LH/RH w/o
Door
M2801 Hinge Pin & Plate Assy.
16470 Nameplate, Blodgett 10"
32 M4587 Door Assy., Sandwich
M2188 Handle Assy., Sandwich Door
M6035 Latch, Sandwich Door
33 M4581 Plate, Pivot RH Slotted
34 M4582 Plate, Pivot LH Slotted
M6970 Retrofit Kit, Sandwich Door
(To Add Sandwich Door)
M2515 Allen Key
21826 Installation Hose, 36"
21242 Installation Hose, 48"
M7273 Body Top w/ Hardware
M2678 Body Back
M2361 Pin, Stacking
M2486 Stacking Rails
M2439 Stacking, 24" Stand & Caster
Assy.
M3123 Stacking, Single to Double
M3124 Stacking, Double to Triple
M2532 Triple Base w/ Casters
M3998 Heat Shield Kit
35 M2075 Tunnel Extension

MT2136
1-9
EXCLUSIVE TO VERSION AB
Serial umber model ide tificatio code of BK=MT2136G or FB=MT2136E.
NOTE:  = ASAP Distributor Required Stocki g Parts
Ref.
No.
Part
No. Description
Ref.
No.
Part
No. Description
1 M5070 Conveyor Assy., Drive Side SB
M5066 Conveyor Assy., Idle Side SB
M5069 Conveyor Assy., Drive Side TB
M5067 Conveyor Assy., Idle Side TB
M6044 Snap Disc, L110Ć20F, 3 Pole
M5302 Nozzle Assy. (Aluminum) (Qty 5)
M5288 Nozzle Assy. (S/S) (Qty 5)
M2741 Plate Assy., Air (Aluminum) (LH
& RH)
M7490 Air Plate, LH (Aluminum)
M7493 Air Plate, RH (Aluminum)
M4674 Air Plate, LH (S/S)
M4675 Air Plate, RH (S/S)
M4163 Plate Assy., Block Off
(Aluminum)
M4673 Plate Assy., Block Off (S/S)
M5071 Crumb Pan, Idle (Remote & inteĆ
gral) (Bottom Section)
M5335 Crumb Pan, Drive w/ Remote
(Bottom Section)
M5068 Crumb Pan, Drive w/ Integral
(Bottom Section)
M6996 Crumb Pan, Idle (Remote & InteĆ
gral) (Top & Middle Section Ć
ented)
M6995 Crumb Pan, Drive w/ Remote
(Top & Middle Section Ć ented)
M5068 Crumb Pan, Drive w/ Intergal
(Top & Middle Section)
M7002 Extension Assy., Product 6"
M6997 Extension Assy., Product 12"
M7000 False Front w/o Door
M7001 False Front w/ Door
M6213 Access Panel, Combustion
Compartment
M6035 Latch, Combustion Compartment
Access Panel
M4580 Access Panel, Front w/ Door
M6389 Access Panel, Front w/o Door
M2733 Bolt, Front Access Panel
M2599 Gasket, Front Access Panel
M3574 Retainer, Gasket Top/Bottom w/
Door
M3575 Retainer, Gasket LH/RH w/ Door
M6383 Retainer, Gasket w/o Door
M2801 Hinge Pin & Plate Assy.
16470 Nameplate, Blodgett 10"
M4587 Door Assy., Sandwich
M2188 Handle Assy., Sandwich Door
M6035 Latch, Sandwich Door
M4581 Plate, Pivot RH Slotted
M4582 Plate, Pivot LH Slotted
M7274 Body Top w/ Hardware
M6220 Body Back
21390 Legs, 17Ć1/4" w/ Casters
(Double Oven)
21391 Legs, 23Ć1/4" w/ Casters
(Single Oven)
M3828 Pin, Stacking
M5537 Triple Base w/ Casters
NOTE: MT2136 AB versio is o ly available with
legs (Part #'s 21390 & 21391). There is o
sta d available for this ove .

INTRODUCTION
1-10
EXCLUSIVE TO EXPORT 50 HZ (ZA VERSION)
NOTE:  = ASAP Distributor Required Stocki g Parts
Ref.
No.
Part
No. Description
Ref.
No.
Part
No. Description
M2246 Burner Assy., Complete
M2386 Blower Motor, Combustion
M2384 Transformer (Burner Assy.)
M2245 alve, Single Solenoid, 240 AC
M2573 Element Assy., 220/380 , 3 PH,
15 KW
M2699 Element Assy., 220/380 , 1 PH,
15 KW
M2574 Element Assy., 240/415 , 3 PH,
15 KW
M2698 Element Assy., 240/415 , 1 PH,
15 KW
M6892 Element, Individual, 220/380
M6893 Element, Individual, 240/415
M2630 Fuse, Bodine Speed Control, 5
AMP, 250
23034 Axial Fan, 230 (Qty 3)
M2247 Contactor, Mechanical, 16 AMP,
3 Pole, 250 (Motor) 50 HZ
R1530 Contactor, Mercury, 60 AMP, 3
Pole (Heat)
M2591 Contactor, Mercury, 100 AMP, 1
Pole (Heat)
M7170 Transformer, 208/460Ć120 ,
300 A (Step Down)
M2873 Motor & Blower Assy., 50 HZ,
CW
M2872 Motor & Blower Assy., 50 HZ,
CCW
M3154 Time Display, Digital 50 HZ
M3126 Upgrade Kit, Cooling Fan (ExĆ
port)
M3153 Speed Control Board, Digital
180 DC
M3128 Motor, Conveyor Drive, 180 DC
M3155 Controller, Temperature C§/50
HZ
M2819 Switch, Air Pressure Differential
(in W.C) (Qty 1) (Australia)
M7880 Computer Control Kit, Closed
Loop SB (CE)
M3237 Burner Assy. (CE)
16 M7334 Pilot Burner & Igniter Assy., NatĆ
ural (CE)
16 M7333 Pilot Burner & Igniter Assy., LP
(CE)
M2497 Switch, Push Button (CE)
M2498 Switch, Contact (CE)
M0595 Switch, Air Pressure SPDT (CE)
40 M3172 Timer, Fixed, 2 Second (CE)
41 M3173 Timer, Fixed, 10 Second (CE)
M3166 Fuse, 4 Amp., 250 (CE)
M3167 Fuse Holder (CE)
M2549 Strip, Terminal (CE)
43 M3168 Spark Box, 240 (Landis & Gyr)
(CE)
R1586 Terminal Block, Power (CE)
R0166 Terminal Block, Ground (CE)
R1580 Stop, End (CE)
16037 Indicator Light, 250 , Red,
Round (CE & Australia)
90250 Relay, 240 3PDT (CE)
42 16775 Relay, 240 SPST, 30 AMP (CE)
17 M6000 Dual Solenoid/Pressure RegulaĆ
tor, Nat. (CE)
17 M6001 Dual Solenoid/Pressure RegulaĆ
tor, LP (CE)
M3330 Switch, Air Pressure Differential
(mbr) (CE)
M6649 Noise Filter (G&E)
M6648 Noise Filter (E Only)
M7282 Relay Board (All CE ComputerĆ
ized Ovens)
M6025 Fuse, 250 80 MA (For M7282)

MT2136
1-11
35
30
35
29
39
28
38
33
3431
37
36
26
27
32
EXTERIOR COMPONENTS
FIGURE 3

INTRODUCTION
1-12
DOMESTIC GAS BURNER COMPONENTS
(Control Box not Shown)
2
1
3
4
5
7
8
9
10
6
15
14
11
12
13
13
13
FIGURE 4

MT2136
1-13
CE GAS BURNER COMPONENTS
(Control Box not Shown)
16
17
FIGURE 5

INTRODUCTION
1-14
CONTROL PLATE ASSEMBLY
18
25
16
26
21
19
20
24
23
22
EXCLUSIVE TO CE
40
41
42 43
FIGURE 6

MT2136
1-15
This page i te tio ally left bla k.

ASSEMBLY
CHAPTER 2
