Blodgett 900 SERIES Guide

900 SERIES
ROASTING, BAKING AND PIZZA OVEN
INSTALLATION - OPERATION - MAINTENANCE
LA SÉRIE 900
DU FOUR À RÔTIR, À CUIRE ET À PIZZA
MANUEL D'INSTALLATION - UTILISATION - ENTRETIEN
BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, Vermont 05401 U A Telephone: (802) 658Ć6600 Fax: (802)864Ć0183
PN 11356 Rev H (10/09)
E 2009 - G. . Blodgett Corporation

IMPORTANT
FOR YOUR SAFETY
D n t st re r use gas line r ther flammable vap rs r liquids in the vicinity
f this r any ther appliance.
AVERTISSEMENT
Ne pas entrep ser ni utiliser de l'essence ni d'autres vapeurs u liquides inflamĆ
mables dans le v isinage de cet appariel, ni de t ut autre appareil.
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT THE USER SMELLS GAS
MUST BE POSTED IN A PROMINENT LOCATION. THIS INFORMATION MAY BE
OBTAINED BY CONTACTING YOUR LOCAL GAS SUPPLIER.
LES INSTRUCTIONS À RESPECTER AU CAS OÙ L'UTILISATEUR PERÇOIT UNE
ODEUR DE GAZ DOIVENT ÊTRE AFFICHÉES DANS UN ENDROIT BIEN VISIBLE.
VOUS POUVEZ VOUS LES PROCURER AUPRÈS DE VOTRE FOURNISSEUR DE
GAZ LOCAL.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT
AVERTISSEMENT: UNE INSTALLATION, UN AJUSTEMENT, UNE ALTÉRATION, UN
SERVICE OU UN ENTRETIEN NON CONFORME AUX NORMES PEUT CAUSER DES
DOMMAGES À LA PROPRIÉTE, DES BLESSURES OU LA MORT. LISEZ ATTENTIVEĆ
MENT LES DIRECTIVES D'INSTALLATION, D'OPÉRATION ET D'ENTRETIEN AVANT
DE FAIRE L'INSTALLATION OU L'ENTRETIEN DE CET ÉQUIPEMENT.
The inf rmati n c ntained in this manual is imp rtant f r the pr per installati n,
use, and maintenance f this ven. Adherence t these pr cedures and instrucĆ
ti ns will result in satisfact ry baking results and l ng, tr uble free service.
Please read this manual carefully and retain it f r future reference.
Les inf rmati ns d nnées dans le présent manuel s nt imp rtantes p ur installer,
utiliser et entretenir c rrectement ce f ur. Le respect de ces instructi ns et pr céĆ
dures permettra d' btenir de b ns résultats de cuiss n et une l ngue durée de serĆ
vice sans pr blèmes. Veuillez lire le présent manuel et le c nserver p ur p uv ir
v us y rep rter à l'avenir.
Err rs: Descriptive, typ graphic r pict rial err rs are subject t c rrecti n. SpecificaĆ
ti ns are subject t change with ut n tice.
Erreurs:Les erreurs de descripti n, de typ graphie u d'illustrati n f nt l' bjet de
c rrecti ns. Les caractéristiques s nt sujettes à m dificati ns sans préavis.

THE REPUTATION YOU CAN COUNT ON
UNE RÉPUTATION SUR LAQUELLE VOUS POUVEZ COMPTER
For over a century and a half, The Blodgett Oven Company has been building
ovens and nothing but ovens. We've set the industry's quality standard for all
kinds of ovens for every foodservice operation regardless of size, application
or budget. In fact, no one offers more models, sizes, and oven applications
than Blodgett; gas and electric, fullĆsize, halfĆsize, countertop and deck, conĆ
vection, Cook'n Hold, CombiĆOvens and the industry's highest quality Pizza
Oven line. For more information on the full line of Blodgett ovens contact your
Blodgett representative.
Cela fait maintenant dessus un siècle et demi que Blodgett se spécialise dans
la fabrication de fours. Nous avons établi les normes de qualité qui s'appliĆ
quent dans l'industrie à tous les types de fours utilisés dans les services aliĆ
mentaires, quel qu'en soit la taille, l'exploitation ou le budget. En fait, ni n'offre
plus de modèles, de tailles et d'applications de fours que Blodgett. À gaz et
électriques. De tailles différentes, sur plan de travail et superposables. Qu'il
s'agisse de fours à convection, des modèles Cook'n Hold et CombiĆOven, ou
de la gamme de fours à pizzas de la plus haute qualité offerte sur le marché.
Pour de plus amples informations sur la gamme complète de fours Blodgett,
veuillez contacter votre représentant Blodgett.

Your ervice Agency's Address:
Adresse de votre agence de service:
Model/Modèl:
erial Number/Numéro de série:
Your oven was installed by/
Installateur de votre four:
Your oven's installation was checked by/
Contrôleur de l'installation de votre four:

Table f C ntents/Table des Matières
Intr ducti n
Oven Description and pecifications 2. . . .
Oven Components 3. . . . . . . . . . . . . . . . . . . .
Installati n
Delivery and Location 4. . . . . . . . . . . . . . . . .
Oven Assembly 5. . . . . . . . . . . . . . . . . . . . . .
Packaging 5. . . . . . . . . . . . . . . . . . . . . . . . . .
Leg Attachment 5. . . . . . . . . . . . . . . . . . . . .
Caster ATtachment 5. . . . . . . . . . . . . . . . . .
Double ection Assembly 6. . . . . . . . . . . .
Ultra Rokite Deck 6. . . . . . . . . . . . . . . . . . .
team Injection 7. . . . . . . . . . . . . . . . . . . . .
Ventilation 8. . . . . . . . . . . . . . . . . . . . . . . . . . .
Canopy Type Exhaust Hood 8. . . . . . . . . .
Direct Flue Arrangement 9. . . . . . . . . . . . .
Venting Problems 9. . . . . . . . . . . . . . . . . . .
Utility Connections -
tandards and Codes 10. . . . . . . . . . . . . . . . .
Gas Connection 11. . . . . . . . . . . . . . . . . . . . . .
Initial tartup 14. . . . . . . . . . . . . . . . . . . . . . . . .
Operati n
afety Information 15. . . . . . . . . . . . . . . . . . . .
Oven Control 16. . . . . . . . . . . . . . . . . . . . . . . . .
uggested Times and Temperatures 17. . . .
Maintenance
Cleaning and Preventative Maintenance 19.
Troubleshooting Guide 20. . . . . . . . . . . . . . . .
Intr ducti n
Description et pécifications du Four 22. . . .
Éléments du Four 23. . . . . . . . . . . . . . . . . . . . .
Installati n
Livraison et Implantation 24. . . . . . . . . . . . . . .
Montage du Four 25. . . . . . . . . . . . . . . . . . . . .
Emballage 25. . . . . . . . . . . . . . . . . . . . . . . . .
Assemblage des Pieds 25. . . . . . . . . . . . . . .
Fixation des Roulettes 25. . . . . . . . . . . . . . .
Double ection Assembly 26. . . . . . . . . . . .
Des Plaques en Rokite 26. . . . . . . . . . . . . . .
Injection de Vapeur 27. . . . . . . . . . . . . . . . . .
Ventilation 28. . . . . . . . . . . . . . . . . . . . . . . . . . .
Hotte D'évacuation Type Voûte 28. . . . . . .
En Prise Directe 29. . . . . . . . . . . . . . . . . . . . .
Problêmes de la Ventilation 29. . . . . . . . . . .
Branchements de ervice -
Normes et Codes 30. . . . . . . . . . . . . . . . . . . . .
Branchement de Gaz 31. . . . . . . . . . . . . . . . .
L'Installation Initiale 34. . . . . . . . . . . . . . . . . . .
Utilisati n
Information de écurité 35. . . . . . . . . . . . . . . .
Oven Control 36. . . . . . . . . . . . . . . . . . . . . . . . .
Durées et Températures uggérées 37. . . . .
Entretien
Nettoyage et Entretien Préventif 39. . . . . . . .
Guide de Détection des Pannes 40. . . . . . . .

Intr ducti n
2
Oven Descripti n and Specificati ns
The 900 eries enjoys the distinction of having the
longest continuous production run of any oven
manufactured by the G. . Blodgett Company since
its founding in 1848. The first 900 oven was marĆ
keted in 1940 and while advancements in metallurĆ
gy and more convenient and reliable controls have
been incorporated over the years, the basic design
of this unit has remained unchanged since its incepĆ
tion.
In establishing this record, the 900 eries has set
industry wide standards for excellence in baking
characteristics, performance, and reliability. In its
primary applications, it remains unsurpassed for
product quality. implicity of design and quality
construction throughout assure years of troubleĆ
free service if equipment is installed properly and
given minimal periodic maintenance.
GAS SPECIFICATIONS
Natural Gas Pr pane Gas
US Units SI Units US Units SI Units
Heating Value 1000 BTU/hr 37.3 MJ/m32550 BTU/hr 95.0 MJ/m3
pecific Gravity (air=1.0) 0.63 0.63 1.53 1.53
Gas Manifold Pressure 5.0" W.C. 1.25 kPa 10.0" W.C. 2.49 kPa
Oven Input
901
911
911P
951
961
961P, 966, 981
22,000 BTU
20,000 BTU
27,000 BTU
38,000 BTU
37,000 BTU
50,000 BTU
6.4 KW
5.9 KW
7.9 KW
11.1 KW
10.8 KW
14.6 KW
22,000 BTU
20,000 BTU
27,000 BTU
38,000 BTU
37,000 BTU
50,000 BTU
6.4 KW
5.9 KW
7.9 KW
11.1 KW
10.8 KW
14.6 KW
Main Burner Orifice ize
901
911
911P
951
961
961P, 966, 981
45 MTD*
46 MTD*
42 MTD*
34 MTD*
34 MTD*
30 MTD*
2.08 mm
2.05 mm
2.35 mm
2.8 mm
2.8 mm
3.25 mm
54 MTD*
55 MTD*
53 MTD*
49 MTD*
49 MTD*
45 MTD*
1.39 mm
1.3 mm
1.5 mm
1.85 mm
1.85 mm
2.1 mm
Pilot Burner Orifice ize 0.18" .45 mm .010" .25 mm
NOTE: * Multiple Twist Drill
NOTE: Orifice sizes given are at sea level.

Intr ducti n
3
Oven C mp nents
Ultra R kite Deck - stone deck that absorbs heat
from below to cook the bottom of the product.
Deck Supp rts - hold the oven decks.
C ntr l Panel - contains components to control
the oven operation.
Burner C mpartment - located beneath the
cooking chamber. The burner compartment conĆ
tains the combustion burners.
C mbusti n Burners - provide heat to the bakĆ
ing chamber and the decks.
Deflect r - diverts some of the heat from the
combustion burners to the flue plates.
Flue Plates - located on the interior side walls of
the cooking chamber. The flue plates conduct
heat from the burners to the oven cavity. The heat
cooks the top of the product before being vented
from the oven.
7" High C mpartment
911 Ć 33" x 22"
911ĆP Ć 33" x 22"
961 Ć 42" x 32"
961ĆP Ć 42" x 32"
Tw 7" High C mpartments
981 Ć 42" x 32"
12" High C mpartment
901 Ć 33" x 22"
951 Ć 42" x 32"
16" High C mpartment
966 Ć 42" x 32"
Figure 1

Installati n
4
Delivery and L cati n
DELIVERY AND INSPECTION
All Blodgett ovens are shipped in containers to
prevent damage. Upon delivery of your new oven:
DInspect the shipping container for external damĆ
age. Any evidence of damage should be noted
on the delivery receipt which must be signed by
the driver.
DUncrate the oven and check for internal damĆ
age. Carriers will accept claims for concealed
damage if notified within fifteen days of delivery
and the shipping container is retained for inĆ
spection.
The Bl dgett Oven C mpany cann t assume
resp nsibility f r l ss r damage suffered in
transit. The carrier assumed full resp nsibility
f r delivery in g d rder when the shipment
was accepted. We are, h wever, prepared t
assist y u if filing a claim is necessary.
OVEN LOCATION
The well planned and proper placement of your
oven will result in long term operator convenience
and satisfactory performance.
The following clearances must be maintained beĆ
tween the oven and any combustible or nonĆcomĆ
bustible construction.
DOven body right side - 6" (15cm)
DOven body left side - 6" (15cm)
DOven body back - 6" (15cm)
DOven body bottom - 6" (15cm)
Area must be accessible for proper servicing.
NOTE: On gas models, routine servicing can usu
ally be accomplished within the limited
movement provided by the gas hose re
straint. If the oven needs to be moved fur
ther from the wall, the gas must first be
turned off and disconnected from the oven
before removing the restraint. Reconnect
the restraint after the oven has been re
turned to its normal position.
It is essential that an adequate air supply to the
oven be maintained to provide a sufficient flow of
combustion and ventilation air.
DPlace the oven in an area that is free of drafts.
DKeep the oven area free and clear of all combusĆ
tibles such as paper, cardboard, and flammable
liquids and solvents.
DDo not place the oven on a curb base or seal to
a wall. Either condition will restrict the proper
flow of combustion and ventilation air resulting
in damage to the oven.

Installati n
5
Oven Assembly
PACKAGING
Before beginning assembly of the oven, check for
all necessary components. In addition to the oven
itself, legs, a proper vent, and/or other accessoĆ
ries may be required.
900 eries ovens are packaged as follows:
Single Secti n Ovens
The following are packed in the oven:
DA set of 27Ć1/2" (70 cm) legs with attaching
hardware.
DEither a canopy or direct vent as specified
DEither a natural gas or propane gas pressure
regulator as required.
Multiple Secti n Ovens
The following are packed inside the bottom secĆ
tion:
DA set of legs of the appropriate length
DEither a canopy or direct vent as specified
DA back pipe of appropriate length with either a
natural gas or propane gas regulator attached
Additi nal Packaging
DUltra Rokite decks for all 900 eries are packed
in a separate crate.
DThe top section of multiple section ovens will alĆ
ways have the crown angle in position.
LEG ATTACHMENT
1. Put the oven onto a lift with the bottom of the
oven down.
2. Each leg is attached by three bolts to the unĆ
derside of the oven base frame.
Figure 2
CASTER ATTACHMENT
1. Bolt supports to oven with 1/2-13 hex head
bolts (casters with brakes should be facing
front of oven.)
2. Carefully place oven onto the casters. (It will
be necessary to have several persons lift oven
off the pallet and set it onto the casters). EnĆ
gage brakes on front casters.
NOTE: A fixed restraint must be provided if cast
ers are used in conjunction with a flexible
connector for movable appliances. This
restraint must secure the oven to a non
movable surface to eliminate stress on the
connector. If the oven is moved, the re
straint must be reconnected after the oven
is returned to it's normal position.
Restraint Cable
Bracket
Figure 3

Installati n
6
Oven Assembly
DOUBLE SECTION ASSEMBLY
1. Place lower section in predetermined place of
installation.
2. Attach the legs (and casters if applicable) as
previously described.
3. Using two 1" boards, place one near the edge
of the oven and the other at the far side of the
flue collar.
4. Lift the upper section and place on the boards.
Push the top section across until the sections
are even.
5. Remove the board from one side by placing a
2" x 4" approximately four feet long under the
angle frame. Lift to remove the board.
6. Remove the other board in the same manner
as above, allowing the upper section to come
gently to rest in the proper position.
7. Install gas backĆpipes and pressure regulator.
8. Install the canopy or direct type vent as approĆ
priate.
9. Remove all tags.
10. Level the ovens side to side and front to back
by placing a spirit level on the base frame of
the lower section and screwing the adjustable
leg feet in or out as appropriate.
ULTRA ROKITE DECK
1. lide the Ultra Rokite shelf through the door
opening. Rest the shelf on the deflector and
slide to the rear of the oven until it drops into
the shelf support.
2. Refer to preĆheating instructions supplied with
Ultra Rokite.
NOTE: Because of the weight of the Ultra Rokite
shelves, take care to avoid injury to your
self or damage to the shelves when sliding
sections into the oven.
NOTE: For model 981, Ultra Rokite is only avail
able as a bottom deck. DO NOT install the
Ultra Rokite in the top baking compart
ment of a 981.
D uble Secti n Assembly
Figure 4
