Blodgett BCM Technical Document

BLODGETT COMBI
www.blodgett.com
44 Lakeside Avenue, Burlington, Vermont 05401 U A Telephone (802) 658Ć6600 Fax: (802) 864Ć0183
PN60740 Rev E (8/11)
E 2011 - G. . Blodgett Corporation
BCM and BLCM
INSTALLATION - OPERATION - MAINTENANCE
BCM et BLCM
MANUEL D'INSTALLATION - FONCTIONNEMENT - ENTRETIEN

A PERSONAL WORD FROM BLODGETT COMBI
QUELQUES MOTS DE BLODGETT COMBI
Congratulations on your purchase of a BLODGETT Combi appliance. We
firmly believe that your choice has been a wise one, and trust you will reĆ
ceive many years of excellent service from your new Combi.
You will find that cooking with Combi appliances saves time, labor and
extensive cleaning of both the kitchen and the unit.
With Combi appliances the quality, taste, consistency, and look of your
food are improved, thus endorsing the policy to which we've always adĆ
hered: For Better Cooking!"
Once you've had a chance to use your Combi, please tell us, your dealer
and colleagues about any creative and interesting applications you have
discovered; exchange ideas with other users. Be sure to advise us or
your dealer immediately should any mechanical or technical problems
be encountered (...we're here to help!) and above all Enjoy Cooking the
BLODGETT Combi Way!
For information on cooking, please refer to our separate cooking guide.
Toutes nos félicitations sur votre achat d'appareil de Blodgett Combi.
Nous croyons fermement que votre choix est un choix raisonnable et
nous sommes certains que vous obtiendrez de nombreuses années
d'excellent service de votre nouveau four multiĆusages.
Vous allez découvrir que la cuisson dans les appareils Combi économise
le temps, le travail et le degré de nettoyage de l'appareil aussi bien que
de la cuisine.
Avec les appareil de Combi, la qualité, le goût, la consistence et l'apparĆ
ence des aliments sont améliorés, s'accordant, de ce fait, avec notre
politique "Pour une meilleure cuisson !"
Une fois que vous aurez eu la chance d'utiliser notre Combi, informez
nous, votre concessionnaire et vos collègues, de toutes les applications
nouvelles et intéressantes que vous avez découvertes ; échangez vos
idées avec d'autres utilisateurs. N'hésitez pas à nous prévenir, ou votre
concessionnaire, de tout problème mécanique ou technique que vous
pourriez rencontrer (... nous sommes ici pour vous aider) et parĆdessus
tout RégalezĆvous à cuisiner à la façon BLODGETT Combi!
Pour obtenir de plus amples informations sur l'art culinaire, veuillez conĆ
sulter notre livre de cuisine séparé.

IMPORTANT
FOR YOUR SAFETY
Do not sto e o use gasoline o othe flammable vapo s o liquids in the vicinity
of this o any othe appliance.
AVERTISSEMENT
Ne pas ent epose ni utilise de l'essence ni d'aut es vapeu s ou liquides inflamĆ
mables dans le voisinage de cet appa iel, ni de tout aut e appa eil.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT
AVERTISSEMENT: UNE INSTALLATION, UN AJUSTEMENT, UNE ALTÉRATION, UN
SERVICE OU UN ENTRETIEN NON CONFORME AUX NORMES PEUT CAUSER DES
DOMMAGES À LA PROPRIÉTE, DES BLESSURES OU LA MORT. LISEZ ATTENTIVEĆ
MENT LES DIRECTIVES D'INSTALLATION, D'OPÉRATION ET D'ENTRETIEN AVANT
DE FAIRE L'INSTALLATION OU L'ENTRETIEN DE CET ÉQUIPEMENT.
The info mation contained in this manual is impo tant fo the p ope installation,
use, and maintenance of this oven. Adhe ence to these p ocedu es and inst ucĆ
tions will esult in satisfacto y baking esults and long, t ouble f ee se vice.
Please ead this manual ca efully and etain it fo futu e efe ence.
Les info mations données dans le p ésent manuel sont impo tantes pou installe ,
utilise et ent eteni co ectement ce fou . Le espect de ces inst uctions et p océĆ
du es pe mett a d'obteni de bons ésultats de cuisson et une longue du ée de se Ć
vice sans p oblèmes. Veuillez li e le p ésent manuel et le conse ve pou pouvoi
vous y epo te à l'aveni .
E o s: Desc iptive, typog aphic o picto ial e o s a e subject to co ection. SpecificaĆ
tions a e subject to change without notice.
E eu s:Les e eu s de desc iption, de typog aphie ou d'illust ation font l'objet de
co ections. Les ca acté istiques sont sujettes à modifications sans p éavis.

Your ervice Agency's Address:
Adresse de votre agence de service:
Model/Modèl:
erial Number/Numéro de série:
Your appliance was installed by/
Installateur de votre four:
Your oven's installation was checked by/
Contrôleur de l'installation de votre four:

Table of Contents/Table des Matières
Introduction
The Blodgett CombiĆOven/Steamer 2. . . . .
Description of the CombiĆOven/Steamer 3.
Installation
gency pprovals 4. . . . . . . . . . . . . . . . . . . .
Utility Specifications 5. . . . . . . . . . . . . . . . . . .
Unpacking the Oven 7. . . . . . . . . . . . . . . . . .
Oven Location and Leveling 8. . . . . . . . . . . .
Plumbing Connections 9. . . . . . . . . . . . . . . .
Electrical Connection and Ventilation 11. . . .
Gas Connections 12. . . . . . . . . . . . . . . . . . . . .
Gas Hose Restraint 14. . . . . . . . . . . . . . . . . . .
Final Check Lists 15. . . . . . . . . . . . . . . . . . . . .
Operation
Manual Control Description 16. . . . . . . . . . . .
Manual Cooking 17. . . . . . . . . . . . . . . . . . . . . .
Core Probe Cooking 17. . . . . . . . . . . . . . . . .
Programmed Cooking 18. . . . . . . . . . . . . . . . .
Programming the Control 18. . . . . . . . . . . .
Cooking with a Program 18. . . . . . . . . . . . .
Cooking Tips 19. . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance
Cleaning & Preventative Maintenance 20. . .
Introduction
Le fourĆétuveur Combi de Blodgett 22. . . . . .
Description du fourĆétuveur Combi 23. . . . . .
Installation
Certifications 24. . . . . . . . . . . . . . . . . . . . . . . . .
Caractéristiques techniques relatives
aux services publics 25. . . . . . . . . . . . . . . . . .
Déballage du four 27. . . . . . . . . . . . . . . . . . . .
Choix de l'emplacement et nivellement
du four 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Robinetterie 29. . . . . . . . . . . . . . . . . . . . . . . . . .
Raccordement à l'électricité et Ventilation 31
Raccordement au gaz 32. . . . . . . . . . . . . . . . .
Câble d'immobilisation du tuyau à gaz 34. .
Liste de vérification finale 35. . . . . . . . . . . . . .
Fonctionnement
Description de la commande manuelle 36. .
Cuisson manuelle 37. . . . . . . . . . . . . . . . . . . .
Cuisson Manuelle 37. . . . . . . . . . . . . . . . . . .
Cuisson a la Sonde 38. . . . . . . . . . . . . . . . . .
Cuisson programmée 39. . . . . . . . . . . . . . . . .
Programmation de la Commande 39. . . . .
Cuisson Selon un Programme 40. . . . . . . .
Trucs et suggestions en matière de
cuisson 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Entretien
Nettoyage et entretien préventif 42. . . . . . . .

Introduction
2
The Blodgett CombiĆOven/Steamer
The Blodgett CombiĆOven/Steamer offers a comĆ
pletely new method of cooking With the Oven/
Steamer you have the choice of two cooking proĆ
cesses: Steam and Hot ir, either
DSeparately
DCombined, or
DIn Sequence
And for easy operation you can choose from three
primary cooking modes:
In the Steam mode you can:
steam reheat reconstitute
stew thaw simmer
blanch preserve braise
poach
In the Hot ir mode you can:
roast bake
grill gratinate
broil
In the two Combi modes you can:
defrost roast rethermalize
reheat bake forced steaming
There are four additional specialized modes to
help you make the most of your time:
Retherm - for perfect reheating
Proofing - Proof and bake all in the same oven
Preheat - in this mode the oven will preheat to
575_F (300_C) for 15 minutes The oven will then
automatically lower to 480_F (249_C) to protect
the advanced electronic components
Cool Down - allows the oven cavity to cool down
rapidly with the door opened
You āācan also āāuse āātwo āāor āthree functions in seĆ
quence during one cooking process We call this:
DcombiĆsteaming
DcombiĆroasting
DcombiĆbaking
The combination of circulating hot air and steam
in the space saving, high performance CombiĆ
Oven/Steamer leads to improvements in the folĆ
lowing areas:
Dincreased productivity in the kitchen
Da reduction in capital expenditures for multiple
equipment replacement
Da wider range of menu choices
Da simplified cleaning process
The work process is simplified since products are
prepared on or in steam table āpans āand trays
Food can be cooked, stored, and transported with
āthe āsame āāpans āSmall āamounts of product can be
processed efficiently; preĆcooked and conveĆ
nience foods can be reheated within minutes
āMany frozen foods can be processed without preĆ
thawing This flexibility in preparation reduces the
need for kettles and steam tables since there is no
need for large amounts of food to be kept warm for
long periods of time
Today the improvement of food quality is more imĆ
portant than ever Vegetables are cooked in the
Blodgett CombiĆOven/Steamer without water at
the optimal temperature of just under 212_F
(100_C), maintaining valuable vitamins, minerals,
nutrients and trace elements Cooking meat in the
Combi results in less shrinkage and a firmer, juicier
product The Blodgett CombiĆOven/Steamer is
being used more and more for baking Steam and
Hot āAir āmodes āmake āit āa āgeneral āpurpose baking
appliance

Introduction
3
Description of the CombiĆOven/Steamer
BOUT THE OVEN/STE MER
Blodgett CombiĆOven/Steamers are quality proĆ
duced using highĆgrade stainless steel with first
class workmanship
The multiple speed fan, which is guarded against
accidental finger contact, is driven by a quiet and
powerful motor The condenser draws out excess
steam from the appliance Condensation and
waste water, which result during steaming and
cleaning, are continuously drained
The use of high quality insulation impedes excesĆ
sive heat radiation and saves energy
The BCM/BLCM makes it possible to enjoy all of
the advantages of a high quality steamer at the
flick of a switch Fresh steam enters the oven cavĆ
ity without pressure and is circulated at high
speed This process enables quick and gentle
cooking and ensures high quality food while proĆ
viding convenient working methods The steam
generator is completely automatic and protected
from running dry
OVEN/STE MER OPER TION
The practical oven door, with a viewing window,
has a wide swing radius and handle which can be
operated easily, even with wet or greasy hands
Ease of operation is guaranteed through the simĆ
ple to use control With graphical symbols and
storage for 10 product recipes the BCM/BLCM is
easy for even inexperienced kitchen staff to operĆ
ate
Cleaning is kept to a minimum thanks to the autoĆ
matic Combi Wash system

Installation
4
Agency Approvals
THE INSTALLATION INSTRUCTIONS CONĆ
TAINED HEREIN ARE FOR THE USE OF QUALIĆ
FIED INSTALLATION AND SERVICE PERSONNEL
ONLY. INSTALLATION OR SERVICE BY OTHER
THAN QUALIFIED PERSONNEL MAY RESULT IN
DAMAGE TO THE OVEN AND/OR INJURY TO
THE OPERATOR.
Qual f ed nstallat on personnel are nd v duals, a
f rm, a corporat on, or a company wh ch e ther n
person or through a representat ve are engaged
n, and are respons ble for:
DThe nstallat on or replacement of gas p p ng.
The connect on, nstallat on, repa r or serv c ng
of equ pment.
DThe nstallat on of electr cal w r ng from the elecĆ
tr c meter, ma n control box or serv ce outlet to
the electr c appl ance.
Qual f ed nstallat on personnel must be exper Ć
enced n such work, be fam l ar w th all precauĆ
t ons requ red and have compl ed w th all requ reĆ
ments of state or local author t es hav ng
jur sd ct on.
U.S. and Canadian Installations
Installat on must conform w th local codes, or n
the absence of local codes, w th the National Fuel
Gas Code, NFPA54/ANSI Z223.1-Latest dition,
the Natural Gas Installation Code CAN/CGAĆ
B149.1 or the Propane Installation Code, CAN/
CGAĆB149.2 as appl cable.
Reference: National lectrical Code, ANSI/NFPA
70-Latest dition and/or Canadian lectrical
Code CSA C22.1 as appl cable.
Th s equ pment s to be nstalled n compl ance
w th the Basic Plumbing Code of the Building OffiĆ
cials and Code Administrators International Inc.
(BOCA) and the Food Service Sanitation Manual of
the Food and Drug Administration (FDA).
Appl ance s to be nstalled w th backflow prevenĆ
t on n accordance w th appl cable federal, provĆ
nce and local codes.
General Export Installations
Installat on must conform w th Local and Nat onal
nstallat on standards. Local nstallat on codes and/
or requ rements may vary. If you have any quest ons
regard ng the proper nstallat on and/or operat on of
your appl ance, please contact your local d str butor.
If you do not have a local d str butor, please call
Blodgett Comb at 0011Ć802Ć860Ć3700.

Installation
5
Utility Specifications
PLUMBI G SPECIFICATIO S
WATER
Water Pressure 36.26 PSI (250 kPa, 2.5 bar) dur ng Comb Wash
21.76 PSI (150 kPa, 1.5 bar) when Comb Wash s not act ve
87 PSI (600 kPa, 6 bar) max mum
Water Connect on 3/4" garden hose cold water
M n mum Requ rements TDS - less than 100 parts per m ll on
Total Hardness - 80Ć120 parts per m ll on
Chlor des - less than 30 parts per m ll on
pH Factor - 7.0Ć8.0
Chlor ne - 0 parts per m ll on
DRAI AGE
Dra n Type Atmospher c Vented Dra n
Dra n Connect on 2.00" (50.8mm) Copper
Avg Water Dra n Temp. Approx mately 140_F (60_C)
RATI GS - GAS OVE S
Model Gas Type Input Voltage Phase Amps
BLCMĆ61G Natural 40,900 BTU 120 1 11
Propane 40,900 BTU 120 1 11
BLCMĆ101G Natural 71,500 BTU 120 1 11
Propane 71,500 BTU 120 1 11
BLCMĆ102G Natural 125,000 BTU 120 1 22
Propane 125,000 BTU 120 1 22
BLCMĆ202G Natural 184,000 BTU 120 1 22
Propane 184,000 BTU 120 1 22

Installation
6
Utility Specifications
ELECTRICAL RATI GS
Model Voltage kW Hz Phase Max Load (amps)
208 5.4 60 3 26
BLCMĆ23E 240 5.9 60 3 25
BLCM 23E
480 6.4 60 3 14
208 6.9 60 3 34
BLMPĆ6E 240 7.5 60 3 32
BLMP 6E
480 8.2 60 3 18
240 10.4 60 3 29
BLCMĆ10E 240 11.3 60 3 28
BLCM 10E
480 12.3 60 3 26
BCMĆ61E
BLCM 61E
208 9 60 3 26
BLCMĆ61E 240 9 60 3 26
480 9 60 3 13
BCMĆ101E
BLCM 101E
208 18 60 3 52
BLCMĆ101E 240 18 60 3 52
480 18 60 3 25
BCMĆ102E
BLCM 102E
240 27 60 3 80
BLCMĆ102E 240 27 60 3 80
480 27 60 3 36
BCMĆ202E
BLCM 202E
240 60 60 3 175
BLCMĆ202E 240 60 60 3 175
480 60 60 3 80

Installation
7
Unpacking the Oven
The oven s best handled wh le st ll n ts wrapp ng.
Wherever poss ble, use a roll ng l ft.
1. Roll the l ft under the lower cross tube of the
stand Place a couple of wooden blocks beĆ
tween the cross tube and the l ft.
NOT : To achieve the best possible balance,
roll the lift from the front of the oven or
from the motor side.
NOT : If necessary, the oven can also be
lifted off the stand.
2. Remove the or g nal packag ng from the oven.
Do not remove the v nyl that covers the sta nĆ
less steel surface unt l the oven has been
nstalled. Once the v nyl has been removed,
the surfaces are vulnerable to sharp objects
such as tools.
3. Remove all packag ng mater al that secures
the racks n the oven chamber.
Figure 1

Installation
8
Oven Location and Leveling
The well planned and proper placement of your
oven w ll result n long term operator conven ence
and sat sfactory performance.
Certa n m n mum clearances must be ma nta ned
between the oven and any combust ble or nonĆ
combust ble construct on.
MI IMUM REQUIRED CLEARA CES
Size Sides Back Top
Electric Ovens
61, 101,
102 & 202 2.75" (7cm) 2" (50mm) n/a
23, 6 & 10 2.75"
(69.9mm) 2.75" (69.9mm) 19.5" (49.5cm)
Gas Ovens
61, 101,
102 & 202 2.75" (70mm) 2" (50mm) n/a
Strong sources of heat such as hotplates, t lt ng
fry ng pans, deep fat fryers, etc. should not be
placed near the oven, espec ally near ts r ght s de.
An opt onal s de heat sh eld s ava lable.
In add t on, the follow ng clearances are recomĆ
mended for serv c ng.
DOven body s des - 12" (30cm)
DOven body back - 12" (30cm)
To ensure that the oven functions correctly
when installed, it should be placed upright and
level (horizontally). This is measured at the
front and side edge of the roof. The oven can be
levelled using the adjusting screws on the
stand or on the legs of table models. The height
of the oven should also be adjusted to fit the
trolley for rack.
CORRECT I STALLATIO
I CORRECT I STALLATIO
Figure 2

Installation
9
Plumbing Connections
WATER CO ECTIO
Blodgett BCM/BLCM ovens have two water conĆ
nect ons. Both are located at the back of the un t.
D1 connect on for raw water for the condensat on
jet.
D1 connect on for steam generat on and the
Comb Wash jet n the oven chamber. Must
meet the requ rements apply ng to water supĆ
pl ed to household appl ances.
Quench Steam
Figure 3
WAR I G!!
If the water temperature exceeds 70°F
(21°C), problems with regard to Combi
Optima calibration and cooling of the
oven may occur.
The water connection must be carried out
by an authorized plumber in accordance
with existing local codes.
Clogged up water filters and dirt in the soĆ
lenoid valves are not covered by the warĆ
ranty.
To fac l tate clean ng and serv c ng, the oven
should be connected w th an approved flex ble
3/4" hose. Permanent nstallat ons should be f tted
w th a stopĆtap and a nonĆreturn valve.
If the feeder s connected to the water d str but on
system w th a flex ble hose, th s hose should be VA
approved.
Before connect ng the oven to water, flush the
tubes thoroughly. Connect the oven.
DRAI CO ECTIO
Blodgett ovens are equ pped w th a dra n system
that removes surplus water from the oven chamĆ
ber. Th s may be condensed water from the prodĆ
ucts, or t may occur when the oven chamber s
cooled down w th cold water, or when the oven
chamber s cleaned.
WAR I G!!
Connection must be carried out by an auĆ
thorised plumber, to an open or closed
drain. The drain must never end directly
beneath the oven.
The dra n must be of sta nless steel or an equally
temperatureĆres stant mater al, have a d ameter of
at least 2" (49 mm) and a fall of at least 3° or 5%.
Figure 4

Installation
10
Plumbing Connections
CLEA I G & DELIMI G CHEMICAL
1. BCP/BLCPĆ61, 101, 102 and 202 ovens
only. The oven s suppl ed w th a chem cal
bottle holder. The holder can be aff xed to e Ć
ther s de of the oven. Place t on the stand
crossmember. See F gure 5.
Figure 5
2. Connect the suppl ed detergent tubes (red
and blue) to the unders de of the oven near the
rear. Connect the blue hose to the f tt ng w th
the blue st cker and the red hose to the f tt ng
w th the red st cker. See F gure 6.
Red Tube
Blue Tube
Red St cker Blue St cker
Figure 6
3. Insert the blue and red hoses nto the proper
bottles. Red s for detergent, blue s for r nse
a d.
4. BCM only - The last l ne s for the del mer.
Th s s the tan colored tube protrod ng from
the bottom of the oven. Cut the tub ng to the
proper length, f needed, and place the tub ng
nto the del me bottle.
NOT : If the tube is cut to length, remove the
stainless steel weight from the end of
the tube and reinsert.

Installation
11
Electrical Connection and Ventilation
ELECTRICAL CO ECTIO
NOT : lectrical connections must be performed
by a qualified installer only.
Before mak ng any electr cal connect ons to these
appl ances, check that the power supply s adeĆ
quate for the voltage, amperage, and phase reĆ
qu rements stated on the rat ng name plate
mounted on the appl ance.
1. The rat ng plate s located on the r ght s de of
the oven.
An approved plug outlet or a safety cutout must be
located close to the oven so that the oven can be
d sconnected dur ng nstallat on and repa r. The
safety cutout must be able to cut off all poles w th
a total d stance of break of at least 3 mm.
All appl ances must be nstalled n accordance
w th Local or Nat onal Electr cal codes.
The w r ng d agram s located n the motor
compartment.
NOT : Disconnect the power supply to the apĆ
pliance before servicing.
WAR I G!!
Improper installation may invalidate your
warranty.
Electric Models
A stra n rel ef for the power supply cord s prov ded.
The nstaller must supply a cord that meets all Local
and Nat onal nstallat on standards.
Gas Models
U.S. and Canadian Installations
A power cord (115V un ts only) s suppl ed w th a
plug attached. Plug the power cord nto the deĆ
s red receptacle.
WAR I G!!
If the supply cord is damaged, it must be
replaced by a special cord or assembly
available from the manufacturer or its serĆ
vice agent.
VE TILATIO
Blodgett BCM/BLCM ovens are equ pped w th an
open/d rect exhaust system that removes surplus
hum d ty from the oven chamber. The exhaust sysĆ
tem has an electr cally operated damper.
The vent lat on motor can be controlled d rectly
from the oven. Th s means that the vent lat on
starts when a program s started and runs for 10
m nutes after the program s completed.
The exhaust tube can be connected to a vent laĆ
t on system. In that case, a spec al extract on funĆ
nel s f tted to avo d suct on d rectly from the oven
chamber. Th s extract on funnel can be ordered
from Blodgett.
If an extract on hood s nstalled n the ce l ng
above the oven, t should project 20" (50 cm) over
the front of the oven.
Figure 7

Installation
12
Gas Connections
GAS PIPI G
A properly s zed gas supply system s essent al for
max mum oven performance. P p ng should be
s zed to prov de a supply of gas suff c ent to meet
the max mum demand of all appl ances on the l ne
w thout loss of pressure at the equ pment.
Example:
NOT : BTU values in the following example are
for natural gas.
You purchase a BCXĆ14G to add to your ex st ng
cook l ne.
1. Add the BTU rat ng of your current appl ances.
P tco Fryer 120,000 BTU
6 Burner Range 60,000 BTU
Deck Oven 50,000 BTU
Total 230,000 BTU
2. Add the BTU rat ng of the new oven to the toĆ
tal.
Prev ous Total 230,000 BTU
BLCMĆ61G 40,900 BTU
New Total 270,900 BTU
3. Measure the d stance from the gas meter to
the cook l ne. Th s s the p pe length. Let's say
the p pe length s 30' (9 m) and the p pe s ze
s 1" (2.54 cm).
4. Use the appropr ate table to determ ne the toĆ
tal capac ty of your current gas p p ng.
The total capac ty for th s example s 270,900
BTU. S nce the total requ red gas pressure,
270,900 BTU s less than 375,000 BTU, the
current gas p p ng w ll not have to be nĆ
creased.
NOT : The BTU capacities given in the tables are
for straight pipe lengths only. Any elbows
or other fittings will decrease pipe capaciĆ
ties. For example: a schedule 40 1Ć1/2" ell
fitting has an equivalent capacity of 4.2"
(10.2 cm) of straight pipe. Contact your loĆ
cal gas supplier if you have any questions.
Maximum Capacity of Iron Pipe in Cubic Feet
of atural Gas Per Hour
(Pressure drop of 0.5 Inch W.C.)
Pipe
Length
ominal Size, Inches
L
eng
th
(ft) 3/4" 1" 1Ć1/4" 1Ć1/2" 2"
10 360 680 1400 2100 3950
20 250 465 950 1460 2750
30 200 375 770 1180 2200
40 170 320 660 990 1900
50 151 285 580 900 1680
60 138 260 530 810 1520
70 125 240 490 750 1400
80 118 220 460 690 1300
90 110 205 430 650 1220
100 103 195 400 620 1150
From the National Fuel Gas Code Part 10 Table 10Ć2
Maximum Capacity of Pipe in Thousands of
BTU/hr of Undiluted P.P. Gas at 11" W.C.
(Pressure drop of 0.5 Inch W.C.)
Pipe Length
(ft)
Inside Diameter, Inches
pg
(ft) 3/4" 1" 1Ć1/2"
10 608 1146 3525
20 418 788 2423
30 336 632 1946
40 287 541 1665
50 255 480 1476
60 231 435 1337
70 215 404 1241
80 198 372 1144
90 187 351 1079
100 175 330 1014
From the National Fuel Gas Code Part 10 Table 10Ć15

Installation
13
Gas Connections
PRESSURE REGULATIO A D TESTI G
The gas pressure to the appl ance must be rated
for each appl ance wh le the burners are on. A sufĆ
f c ent gas pressure must be present at the nlet to
sat sfy these cond t ons. Refer to the table below
for correct gas pressure.
Each appl ance has been adjusted at the factory
to operate w th the type of gas spec f ed on the ratĆ
ng plate.
Each oven s suppl ed w th a regulator to ma nta n
the proper gas pressure. The regulator is essenĆ
tial to the proper operation of the oven and
should not be removed.
DO NOT INSTALL AN ADDITIONAL REGULATOR
WHERE THE UNIT CONNECTS TO THE GAS
SUPPLY UNLESS THE INLET PRESSURE IS
GREATER THAN 14" W.C. (1/2 PSI) (37mbar).
The oven and ts nd v dual shutoff valve must be
d sconnected from the gas supply p p ng system
dur ng any pressure test ng of that system at test
pressures n excess of 1/2 ps g (3.45kPa).
The oven must be solated from the gas supply
p p ng system by clos ng ts nd v dual manual
shutoff valve dur ng any pressure test ng of the
gas p p ng system at test pressures equal or less
than 1/2 ps g (3.45kPa).
Pr or to connect ng the appl ance, gas l nes
should be thoroughly purged of all metal f l ngs,
shav ngs, p pe dope, and other debr s. After conĆ
nect on, the appl ance must be checked for corĆ
rect gas pressure.
U.S. and Canadian Installations
Installat on must conform w th local codes, or n
the absence of local codes, w th the National Fuel
Gas Code, NFPA54/ANSI Z223.1-Latest dition,
the Natural Gas Installation Code CAN/CGAĆ
B149.1 or the Propane Installation Code, CAN/
CGAĆB149.2 as appl cable.
General Export Installations
Installat on must conform w th Local and Nat onal
nstallat on standards. Local nstallat on codes and/
or requ rements may vary. If you have any quest ons
regard ng the proper nstallat on and/or operat on of
your appl ance, please contact your local d str butor.
If you do not have a local d str butor, please call
Blodgett Comb at 0011Ć802Ć860Ć3700.
GAS PRESSURE
Model Gas Type Inlet Pressure
BLCMĆ61G Natural 7.0" W.C.
Propane 11.0" W.C.
BLCMĆ101G Natural 7.0" W.C.
Propane 11.0" W.C.
BLCMĆ102G Natural 7.0Ć14.0" W.C.
Propane 12.0Ć14.0" W.C.
BLCMĆ202G Natural 7"Ć14" W.C.
Propane 12.0Ć14.0" W.C.

Installation
14
Gas Hose Restraint
If the appl ance s mounted on casters, a commerĆ
c al flex ble connector w th a m n mum of 3/4" (1.9
cm) ns de d ameter must be used along w th a
qu ck connect dev ce.
A restra nt must be used to l m t the movement of
the appl ance so that no stra n s placed upon the
flex ble connector. The restra nt should be fasĆ
tened to the base frame of the oven as close to the
flex ble connector as poss ble. It should be short
enough to prevent any stra n on the connector.
W th the restra nt fully stretched the connector
should be easy to nstall and qu ck connect.
The restra nt ( e: heavy gauge cable) should be atĆ
tached w thout damag ng the bu ld ng. DO NOT
use the gas p p ng or electr cal condu t for the atĆ
tachment of the permanent end of the restra nt!
Use anchor bolts n concrete or cement block. On
wooden walls, dr ve h test wood lag screws nto
the studs of the wall.
WAR I G!!
If the restraint is disconnected for any reaĆ
son it must be reconnected when the apĆ
pliance is returned to its original position.
U.S. and Canadian installations
The connector must comply w th the Standard for
Connectors for Movable Gas Appliances, ANSI
Z21.69 or Connectors For Moveable Gas ApĆ
pliances CAN/CGAĆ6.16 and a qu ck d sconnect
dev ce that compl es w th the Standard for QuickĆ
Disconnect Devices for Use With Gas Fuel, ANSI
Z21.41 or Quick Disconnect For Use With Gas Fuel
CAN 1Ć6.9. Adequate means must be prov ded to
l m t the movement of the appl ance w thout deĆ
pend ng on the connect on and the qu ck d sconĆ
nect dev ce or ts assoc ated p p ng.
A dr p leg must be used at each appl ance. Refer
to NFPA54/ANSI Z223.1 Ć Latest dition (Nat onal
Fuel Gas Code) for proper dr p leg nstallat on.
General export installations
Installat on must conform w th Local and Nat onal
nstallat on standards. Local nstallat on codes and/
or requ rements may vary. If you have any quest ons
regard ng the proper nstallat on and/or operat on of
your appl ance, please contact your local d str butor.
If you do not have a local d str butor, please call
Blodgett Comb at 0011Ć802Ć860Ć3700.
Gas Supply L ne
Gas Hose
Qu ck Connect
Installation of Gas Hose and Restraint
(S ngle Sect on Shown)
Attachment Plate
(secure w th leg mount bolt)
IMPORTANT: Cable restra nt should
be fastened as close as poss ble to the
flex ble connector and short enough to
prevent any stra n on the flex ble conĆ
nector.
At max mum stretch of shortened reĆ
stra nt, the flex ble connector should
be easy to nstall and qu ck to connect.
Restra nt
Figure 8

Installation
15
Final Check Lists
WAR I G!!
Final check list must be performed by a
qualified installer only.
OVE EXTERIOR
jCheck that the oven has not been damaged
n trans t (dents, scratches, etc.)
jCheck/adjust the he ght and check that the
oven s placed level (hor zontally)
jCheck/adjust oven door
CO ECTIO S
jCheck for correct water connect on
jTurn on water supply
jCheck for leaks
jTurn off water supply
jCheck and clean d rt f lter
jTurn on water supply aga n
jCheck hand shower
jCheck for correct electr cal connect on
jCheck for correct gas connect on ( f appl caĆ
ble)
jCheck connect on to dr p tray
jCheck for correct mount ng of dr p tray
jCheck for correct fall of hose from dr p tray,
and check for leaks
jCheck for correct exhaust and dra n connecĆ
t on
jClean the oven
jApply steel o l
OVE I TERIOR
jCheck that f lter hous ng s mounted correctly
jCheck nter or l ght
jClean the oven
CO TROL
jCheck and adjust, f necessary, each of the
preset values
jHeat up the oven at 480° F (249°C) for approxĆ
mately 5 m nutes.

Operation
16
Manual Control Description
1. MAIN POWER SWITCH - controls power to
the oven
. TEMPERATURE KEY - press to set the cook
temperature
3. TIME KEY - press to set the cook time
4. PROBE KEY - press to activate core probe
5. PROGRAM KEY - press access and program
product recipes. Control stores up to 10 recĆ
ipe programs with 3 cooking stages each.
6. STAGE KEY - use to enter stage information
during product programming
7. ALARM KEY - press to silence alarms
8. HOT AIR KEY - press to select Hot Air mode
9. COMBI KEY - press to select Combi 1, Combi
or Retherm mode
10. STEAM KEY - press to select Steam mode
11. VENT KEY - press to open or close the vent
1 . FAN KEY - press to change the fan speed.
The fan is reversible with 9 speeds for optiĆ
mum baking and roasting results
13. SELECTION DIAL - turn to enter data into
control
14. START/STOP KEY - press to begin or cancel
a cook cycle
1
3
4
5
6
7
8
9
10
11
1
13
14
Figure 9
