BluDot Modu-licious #4 User manual

WWW.BLUDOT.COM MODULICIOUS 4 rev02 - PAGE 1 OF 7
HARDWARE
PARTS LIST
Top Panel Side Panel Center Panel
Drawer Slide
Bottom Panel
Back Panel Drawer
Foot
Stretcher
Panel
has notched
edge on
both sides.
Panel has
pre-drilled
holes on
both sides.
x2
x1 x1
x2
x2
x1
x8
x1
x4
x24
5002
x24
5001
x16
1023
x4
4005
MODULICIOUS
ASSEMBLY INSTRUCTIONS
#4
modular and stylish,
who knew?
ANTI-TIP
HARDWARE
x1
8043
x1
1201
x2
3009
CONSULT YOUR
LOCAL HARDWARE
PROFESSIONAL TO
DETERMINE THE
HARDWARE BEST
SUITED FOR YOUR
TYPE OF WALL..
*
not
included
*
x24
5005

WWW.BLUDOT.COM MODULICIOUS 4 rev02 - PAGE 2 OF 7
32 5
4
Turn cam clockwise
½ turn
HOW TO USE CAM
LOCK HARDWARE
Note direction of
arrow on cam
Note direction of
arrow on cam
1

WWW.BLUDOT.COM MODULICIOUS 4 rev02 - PAGE 3 OF 7
1 2
ASSEMBLE ON
CARPET OR
PROTECTIVE MAT
x4x4
5001 5002
See page 2:
HOW TO USE CAM
LOCK HARDWARE
Finished edge
Finished edge
x2 x4x2
5001 5002 4005

WWW.BLUDOT.COM MODULICIOUS 4 rev02 - PAGE 4 OF 7
34
Start screw
here first.
REPEAT THIS
STEP FOR SECOND
SIDE PANEL
x16
5002
Center panel
Make sure notched
edge and drawer
slides are in
alignment.
x6
5001 x6 50025005
x8

WWW.BLUDOT.COM MODULICIOUS 4 rev02 - PAGE 5 OF 7
56
x4
8018
Add 2 rubber
grommets to each
back panel
Make sure back
panels fit into top
and bottom panel
notched grooves.
x12
5001 x12
50025005
x16

WWW.BLUDOT.COM MODULICIOUS 4 rev02 - PAGE 6 OF 7
SAFETY
Serious or fatal crushing
injuries can occur from
furniture tip-over. Install
the provided anti-tip
hardware as shown. The
use of such hardware
may only reduce, but
not eliminate, the risk of
tip-over.
8
Attach anti-tip strap to
wall using recommended
hardware as shown. For
best results, attach anti-
tip strap to a wall stud.
x1
8043
x1
1201
x1
3009 x1
3009
**
TOP PANEL
WALL
BACK PANEL
TOP PANEL
Install anti-tip hardware to
product as shown. hardware
must be installed to top
panel versus back panel. In
order to prevent cracking,
it is recommended to mark
hole locations and drill pilot
holes using a 3/32” drill bit.
CONSULT YOUR LOCAL
HARDWARE PROFESSIONAL TO
DETERMINE THE HARDWARE
BEST SUITED FOR YOUR TYPE
OF WALL..
*
*
7
not
included

WWW.BLUDOT.COM MODULICIOUS 4 rev02 - PAGE 7 OF 7
9NOTES
To remove drawers
pull lever up on the
right side and push
down on the left side
of the drawer slide.
Drawer fronts can
be adjusted if
drawer gaps
are inconsistent.
Loosen the acorn
nuts, shift the drawer
front into place and
ask a friend to hold the
drawer front in place
while you re-tighten the
nuts (but don’t
over tighten).
Extend ball
drawer slides out
from cabinet body,
align with drawer
slides and slide
drawer in.
CARE
Clean with a slightly damp,
soft cloth. To remove dirt
and fingerprints, use a
quality cleaner formulated
for wood furniture. Wipe
completely dry with a soft
cloth in the direction of the
wood grain.
