BluDot Modu-licious Bedside Table Quick start guide

Modu-licious Bedside Table
DESIGNED IN 1999
ASSEMBLY NOTES | REV 00
NEED A HAND?
Contact us at [e-mail]
844.425.8368for assistance.
KEEP THE STUFFYOU LIKE AND S TO RE I T WELL .
Drawers and doors are your canvas with the award-winning
Modu-licious series.

1 | 8 4 4 . 4 2 5 . 8 3 6 8 MODU-LICIO U S BED S I D E T A BLE
Foot
2QTY
Drawer Slide
2QTY
Stretcher
1QTY
Shelf Panel
1QTY
Side Panel
2QTY
Drawer
1QTY
Bottom Panel
1QTY
Top Panel
1QTY
Back Panel
1QTY
Parts & Hardware

S E RVIC E @ B L U DOT . C O M | 2A S SEM B L Y NOTES
Pt. 5001
18QTY
Pt. 1023
4QTY
Pt. 4005
QTY
Pt. 8018
1QTY4
Pt. 5002
18QTY
Pt. 5005
22QTY
Parts & Hardware

3 | 8 4 4 . 4 2 5 . 8 3 6 8 MODU-LICIO U S BED S I D E T A BLE
354
1 2
How to use the cam lock system
Note direction of cam arrow. Turn cam clockwise 1/2 turn or until tight. Note direction of cam arrow.

S E RVIC E @ B L U DOT . C O M | 4A S SEM B L Y NOTES
PT. 5001 x 2 PT. 5002x 2 PT. 4005x 4
Finished Edge
Step 01
ASSEMBLE BASE .
Using the stretcher and feet assemble the
base as shown. Refer to Page 3 on how to use
the cam lock system.

5 | 8 4 4 . 4 2 5 . 8 3 6 8 MODU-LICIO U S BED S I D E T A BLE
PT. 5001 X 4 PT. 5002 X 4
Bottom Panel
Step 02
AT TACH B O T T O M PANEL .
Attach the bottom panel to the base using
the provided hardware as shown. Refer to
page 3 on how to use the cam lock system.

S E RVIC E @ B L U DOT . C O M | 6A S SEM B L Y NOTES
PT. 1023 X 4
Right Side Panel
Step 03
AT TACH DRAWER SLIDES.
Attach drawer slides to side panel as shown
using the provided hardware. Repeat for left
side panel.

7 | 8 4 4 . 4 2 5 . 8 3 6 8 MODU-LICIO U S BED S I D E T A BLE
Side Panel
PT. 5005 X 6
Shelf Panel
Step 04
BEGIN ASSEMBLING C A S E .
Attach side panels to shelf panel as shown
using the provided hardware. Be sure to align
grooves on side panels. Refer to page 3 on
how to use the cam lock system.

S E RVIC E @ B L U DOT . C O M | 8A S SEM B L Y NOTES
PT. 5001 x 6 PT. 5002x 6 PT. 5005 x 8
Step 05
AT TACH BAS E .
Attach the base as shown using the provided
hardware. Refer to page 3 on how to use the
cam lock system.

9 | 8 4 4 . 4 2 5 . 8 3 6 8 MODU-LICIO U S BED S I D E T A BLE
PT. 8018 X 1
Step 06
INSERT THE BACK PANEL .
Add rubber grommet to back panel as
shown. Insert back panel into grooves
in case.

S E RVIC E @ B L U DOT . C O M | 10A S SEM B L Y NOTES
PT. 5001 x 6 PT. 5002x 6 PT. 5005 x 8
To install the drawer extend drawer slides out
from case, align with drawer slides as shown,
and slide drawer in. Be sure to push until
drawer is completely closed and engaged.
Step 07
FINISH ASSEMBLING C A S E .
Finish assembling the case by attaching
the top panel as shown using the provided
hardware. Refer to page 3 on how to use the
cam lock system.

B L U DOT DESIGN & MANUFACTURING,INC. DESIGNED IN MINNEAPOLIS,M N
Additional Information
TO REMOVE DR AWERS
Pull lever up on the right side and push down on the left side
of the drawer slide. With levers engaged pull drawer out.
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use a quality cleaner formulate
for wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain.
TO ADJUST DRAWER FR ONTS
Loosen the acorn nuts, adjust drawer
front, re-tighten acorn nuts.
