blueLOGIC BMW01 User manual

Version12.07.2012,fromSW2.0.04
blueLOGiC®hands-freekit
BMW01
forBMWwithfibreoptics(MOST®)
Bluetooth®-hands-free phonekitfullyintegratedinthevehicleinfotainment
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page2
Contents
1. Priortoinstallation
1.1.Deliverycontents
1.2.Checkingthecompatibilityofvehicleandaccessories
2. Installation
2.1.Removalofthenavigationcomputer/radio
2.1.1.RemovalnavigationcomputerfromBMWE60/E61/63/64withProfessional
Navigation
2.1.2.RemovalnavigationcomputerfromBMWE70/71 withProfessionalNavigation
2.1.3.RemovalnavigationcomputerfromBMWE90/91/92/93withProfessional
Navigation
2.2.Connections
2.3.Activationoftheinterface
3. Interface operation
3.1.PairingtheblueLOGiC®Interface withamobilephone
3.2.Loadingofphonebook
3.3.Setup,factorydefaults,update
3.4.A2DPaudiostreamingthroughCD-changeremulation
4. Specifications
5. Technicalsupport
Information
Changesofthevehiclesoftwarecancausemalfunctionsoftheinterface.Weofferfree
software-updatesforinterfacesforoneyearafterpurchase.Toreceiveafreeupdate,the
interface mustbesentinatowncost.Laborcostforand otherexpensesinvolvedwiththe
software-updateswillnotberefunded.
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page3
Productfeatures
Integrationinandcontrolsthroughthetelephoneportofthefactoryinfotainment
UpdatableParrotchipsetwithbestaudioqualityand highphonecompatibility
Automaticradiomute
Calleraudiothroughvehiclesound-system
Externalmicrophonewithamplificationadjustment throughinfotainment
A2DPaudiostreamingthroughCD-changeremulation(requirement:mobilephone
supportsfunction,factoryCD-changercodedbutnofactoryCD/DVD-changer
installed)
up to10mobilephonescanbepairedsimultaneously
Useoffactory/vehiclebuttonstocontrolphonefunctions
Mobilephonebookintegration(about1000call numbers)
Audioadjustment andsettings throughvehicleinfotainment
SMSreadingandwritingifsupportedbymobilephone
1. Priorto installation
Readthemanualpriortoinstallation.Technicalknowledgeisnecessaryforinstallation.The
place ofinstallationmustbefreeofmoistureandawayfromheatsources.
1.1. Deliverycontents
HW________ SW________
TakedowntheSW-versionand HW-versionoftheinterfaceand store thismanual
forsupport purposes.
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page4
Requirements
VehicleBMW vehicles withiDriveand fibre optics,Mini
Navigation/RadioProfessionalNavigation
Business Navigation
ProfessionalRadio
ChampMP3Radio
MiniRadioBoost
Limitations
Vehiclenot 7series (E65/66)andFxx
FactorytelephonekitMust beremoved ifinstalled.
Factory-CD/DVD-changer Must becoded butinstalled ifA2DPshall beused.
Factory-comboxThephonefunctionofthefactory-comboxmustbe uncoded if
installed.
1.2. Checkingthecompatibilityofvehicleand accessories
2. Installation
Switch off ignition and disconnect the vehicle’s battery! Theinterface needsapermanent
12Vsource.Ifaccordingtofactoryrulesdisconnectingthebatteryistobeavoided,itis
usuallysufficienttoputthevehicleissleep-mode.Incase thesleep-modedoes notshow
success,disconnectthebatterywitharesistorlead.
Ifpowersource isnottakendirectlyfromthebattery,theconnectionhastobechecked
forbeingstart-up provenand permanent.
2.1. Removal ofthenavigationcomputer/radio
Theinterface isinstalledonthebacksideofthenavigationcomputerorradiounit.
Thefollowingchaptersshowsome exemplaryremovalsofnavigationcomputers.
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page5
2.1.1.Removal navigationcomputerBMW E60/E61/63/64 withProfessional Navigation
Removethecover
Unscrewthetwoscrewsatthesideends
Removelowerplastic
Unscrewthe4screwsandpull out
thenavigationcomputer.
Continuefromchapter2.2.Connections.
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page6
2.1.2.Removal navigationcomputerBMW E70/71withProfessional Navigation
Removethemiddleairvents.
Unscrewthetwoscrewsatthesideends
Unscrewthe4Torxscrews
Continuefromchapter2.2.Connections.
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page7
2.1.3.Removal navigationcomputerBMW E90/91/92/93 withProfessional Navigation
Removethe airconditioncontrolpanel;itis
onlyfitted,notfixedintoplace.
Removethecover
Unscrewthe6screws
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page8
2.2. Connections
UnplugtheQuadlocksocketfromthebacksideofthe
navigationcomputer.
Unplugthecompartment withthefibreopticsfromthe
Quadlocksocket.
Exchange the shells of the vehicle harness’ fibre optical
connector and interface harness’ fibre optical
connectoragainsteachother.
Connect the vehicle harness’ fibre optical
connectortothefibreopticalsocketofthe
interface harness.
Connect the interface harness’ fibre optical
connectortotheQuadlocksocketofthe
vehicleharness.
PlugtheQuadlocksocketbackintothe
navigationcomputer.
Vehicleswithoutfibreopticalcomponents,whichmeanswithoutCDC,withoutphoneor
otherfibreopticalcomponentshaveopticalwiresatthenavigationcomputer,butitcanbe
possiblethattheringisnotconnectedtodiagnosticconnectorintheglovecompartment.In
thiscaseaconnectorbridgeforopticalwiresisnecessary.
Connectredand blackwiretopermanent+12V
source.Connectblueto+12VtoenableCD-
changeremulationforA2DP.A2DP
requirementisthatthenavigationsystem is
codedtoCD-changerbutfactoryCD-changer
mustNOTbeinstalled.
Installthemicrophoneclosetothedriver.Connectthemicrophones2PinAMPjacktothe
2PinAMPjackbushoftheblueLOGiC®harness.
Wirecolor
Definition
●Black
Ground
●Red
+12VDC(permanent)
●Blue
to +12V=CDC-emuon
Interface
Connector
Vehicle
Connector
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page9
2.3. ActivationoftheInterface
Afterfirstinstallationthevehiclemustgointosleep-modeinordertorecognizethenewly
attachedhardware.Afterre-connectingthebattery,lockthevehicleandwaitfor5-10
minutes.
Onsome vehicles,itmayhappenthattheblueLOGiC®interfaceisnot
recognizedbytheheadunit.Ifthephoneoptionisnotavailable,afterthe
activationasdescribedabove,takethefollowingsteps:
1. Switchonignition
2. Aftersystem start,connectpin7for2secondsto+12V
3. Switchoffignition,lockthevehicleand waitfor5-10 minutes
3. Interfaceoperation
Theinterfaceenablesthe telephonebusofthefactorynavigation/radiosystem.Thereforein
principal,theoperationisanalogueasdescribedinthemanualofthecorresponding
navigation/radiosystem.
NavigationProfessional(CCC)
NavigationProfessional(CIC)
BusinessNavigation
+12Vfor 2 sec.
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page10
3.1. PairingtheblueLOGiC®Interface withamobilephone
Upto10mobilephonescansimultaneouslybepairedwiththeblueLOGiC®interface.Ifa
11th phoneispaired,theoldestentryisautomaticallydeleted.Insome cases,itbecomes
necessarytoputthevehicleinsleepmodetoenablecorrectfunctionofthe11th phone.
Forpairing,enablethepairingmodeofthemobilephone(seemanualofthemobilephone).
Search with the mobile phone for „blueLOGiC“or„CK5050N“ andconnectwithactivation
code „1234“.Some mobilephonestrytoconnecttotheblueLOGiC®interface withanother
functionas"handsfree".Checkthisattitudeandswitchtheadjustment to"handsfree"if
necessary(seemanualofthemobilephone).
IfamobilephonehadbeenpairedtotheblueLOGiC®interface (requirementisanoccurred
pairingwithamobilephone,seeabove),aconnectionwillbeautomaticallyestablishedas
soonasthemobilephoneisinreach.Ifmultiplepairedmobilephonesaresimultaneouslyin
reach,theblueLOGiC®interface willbeconnectedtothefirstphone.
Ifyouhaveconnectionproblemsbetweenmobilephoneand theblueLOGIC,first check at
theparrotwebsitewhetheranupdatefortheparrotchipisavailable.Thepartnumberof
theparrotchipcanbefound inthespecificationsattheend ofthemanual.
3.2. Loadingofphonebook
Aftereachestablishment ofconnectiontothemobilephone,thephonebookofthemobile
phonewillbeloadedtothevehicleinfotainment.
Depending on the mobile phone either it will be loaded from the phone’s memory or the
SIMcard.Thisprocesscantakeafewminutes.Ifthephonebookisnoornotcompletely
loaded,itmightbenecessarytocopythecontactsfromtheSIM-cardtothemobilephone
memory!
Some mobilephonesdonotautomaticallyloadthephonebooktotheinfotainment,butthe
sendingmustbemanuallyinitiated(theprocedurevariesdependingonthemobilephone,
z.B. “send phone book to Bluetooth”).
The manual procedure must be repeated for refreshment if the mobile phone’s contacts
havebeenedited.
ThememoryofblueLOGiC®interface cansaveabout1000 callnumbers.
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page11
3.3. Setup,factorydefaults,update
Settings oftheblueLOGiC®interface canalsobechangedby
dialingsettingcodesinthevehicletelephonemode.Invehicles
withnavigationsystem itispossibletochangeitinthevehicle
infotainment’s menu under “Top 8”, too. Calleraudiovolume,
Ringingtonevolume and microphonesensitivitycanbeadjusted
separately.Theinterface canberesettofactorydefaultsand
updatesoftheParrotchipsetcanbeinitiated.Toexecuteafunction,justdialthe
corresponding code from the below table like a phone number and confirm with “pick-up”.
Function
Codeno.
Min
Max
Microphonesensitivity
+001xx
01
15
Calleraudiovolume
+0021xx
01
15
Ringingtonevolume
+0022xx
01
15
Factorydefaults
+009
ParrotUpdateMode
+000
To thecodesforvolume andsensitivityitisnecessarytoaddtwodigitsforthedesiredvalue
(01 min. to 15 max.). For example dial “+002112” to setthecalleraudiovolume tolevel12.
After dialing a code, the navigation will confirm with “call failed”.
System updatesoftheParrotchipsetarepossiblethroughBluetooth®viaPC.
3.4. A2DPaudiostreamingthroughCD-changeremulation
WhentheCD-changeremulationoftheblueLOGiC®interfaceisentered,itispossibleto
listentomusicfilesonthefactorysoundsystem whichareplayedbythemobilephone.The
availableoptionstocontroltheplayfunctionsofthemobilephonedependverymuchon
themobilephone.Somephonesdonotsupportall ofthebelowdescribedfunctions,for
exampleiPhones®donotsupportanytrackskipping.
Full functionsarestartingandstoppingtheplayback,nexttrackandprevioustrack.
IfthevehicleCD-changer mode of the vehicle’s navigation/radio system is activated, the
A2DPplaybackisautomaticallystarted(whileavirtualCD1isshown).WhentheCD-
changermodeisexited,theA2DPplaybackisstopped.Theplaybackispausedduringphone
callactivity.Track skipping is possible with the “next” and “back” keys of the head-unitor
thesteeringwheel.
Ifduringplayback,Track1ofthevirtualCDisconfirmed,amenuopens.Usetheoption
“random” of this menu to stop playback or „SCAN“ to start playback.
ThevolumeleveloftheA2DPcanbeadjustedinthemobilephonessettings.
www.dvsbg.com
car audio & multimedia system

Version12.07.2012,fromSW2.0.04BT-BMW01
page12
4. Specifications
IntegratedBluetooth®ChipParrotCK5050new
Operationvoltage10.5–14.8VDC
Stand-bypowerdrain<1mA
Operationpowerdrain120mA
Powerconsumption1.8W
Temperaturerange-30°Cto+80°C
Weight95g
Dimensions(boxonly)BxHxT106 x30 x71mm
