Blueview NDF1005 User manual

NDF1005
Version: A1.7

NDF1005
LED NEON FLEX
2(8)
Features
Color options: Single color.
Design: Superior design with exquisite craftsmanship
ensure stable and reliable performance.
Top bending and easy to shape
Can be matched with the dimmer.
Warranty: 5 years indoor, 3 years outdoor.
Customization: multiple spec options, can be
customized upon requirements.
IP67 DC 24V
5Years 3Years
115°
NDF1005
Optical & Electrical Parameters
2200K
>90
/
24V DC
24V DC
2700K
3000K
3300K
3900K
5000K
6000K
Red 45 6
Green 510 71
Blue 98 13
Yellow 48 6
Orange 40 5
51 7.2
7.2
388
61454
62
65
63
70
66
467
496
470
520
490
NDF1005-Single color
NDF1005-Single color
ColorModel No. CRIVoltage Lm/m Lm/W Rated Power (W/m)
Other Parameters
NDF1005-Single color 336 5000mm 20.83mm -20~+60℃-20~+70℃
Model No. LED QTY (pcs/m) Min. Cuttable Length Working Temperature Storage Temperature
Profile Drawings
5000 [196.85]
5014.5 [197.42]
Glue Process (IP67) Glue Process (IP67)
Unit:mm [inch]
Standard Run
5000 [196.85]
5010 [197.24]

NDF1005
LED NEON FLEX
3(8)
Bending DiameterBend direction
IP67: Suitable for wet environment, can be soaked for a short time, the depth ≤ 1m, the time ≤ 1h. (factory assembly only)
Within 5m, the strip can be customized according to the integer multiple of the Min. cuttable length.
Sectional view
Notes:
Front cap Closing End-cap
Glue Process (IP67) Glue Process (IP67)
10.0 [0.39]
4.8[0.19]
Glue process the end cap after cutting, warranty will be provided upon IP65 rated.
No warranty will be provided if the injection moulded(IP68) end cap destroyed or reprocessed.
Corresponding molding equipment and mold needed for self-processing injection moulded end cap, contact the sales for more information.
Single color
Straight
Color
Outlet Direction
Molding Pressed (IP67)
Single color
Straight
Color
Outlet Direction
Glue Process (IP67)
IP Process Technology
15.0 [0.59]
12.0 [0.47]
12.0 [0.47]
10.0 [0.39]
30.0 [1.18]
Recommended power supply upon working length
1m 0.3 A 24V DC
24V DC
7.2 W 12 W Single Feed
5m 1.34 A 32.16 W 48 W Single Feed
Working Length
NDF1005
Recommended Power Power Supply ModeRated VoltageMeasured Current Measured Power

NDF1005
LED NEON FLEX
4(8)
AVERAGE BEAM ANGLE (50%): 113.9°
C 0 /180,114.1°
Unit：cd
C 90/270,113.6°
Luminous Intensity Distribution Diagram Average Illumination
Note: Above data are tested at 4000K, for other date, please consult sales rep.
Flux Out: 345.1lm 4000K
Height Eavg, Emax Beam Angle: 113.64° Diameter
0.5m
1.0m
1.5m
2.0m
2.5m
3.0m
3.5m
4.0m
4.5m
5.0m
185.3,662.0lx
46.3,165.5lx
20.6,73.6lx
11.6,414lx
7.41,26.5lx
5.15,18.4lx
3.78,13.5lx
2.90,10.3lx
2.29,8.17lx
1.85,6.62lx
152.94cm
305.89cm
458.83cm
611.78cm
764.72cm
917.66cm
1070.61cm
1223.55cm
1376.50cm
1529.44cm
Products and Tools
Cutter Electric drill Electric ironLED power supply
Product accessories
Item: Front cap
Model No.: ASY-NDF1005-N00NNH-EC
Dimensions L*W*H: 25.0*12.7*7.6mm
Quantity (5m): 4pcs
Free/Optional: Free
Item: Aluminum clip
Model No.: ASY-NDF1005-A3NN0020-MT
Dimensions L*W*H: 20*12.4*7mm
Quantity (5m): 15pcs
Free/Optional: Free
Item: Front connector set (no welding)
Model No.: ASY-NDF1005-F00NNH-EC
Dimensions L*W*H: 32.8*15.6*10.4mm
Quantity (5m): 1pcs
Free/Optional: Optional
Item: Screws
Model No.: PA3
Dimensions L*W*H: PA3*10mm
Quantity (5m): 30pcs
Free/Optional: Optional
Item: Closing End-cap
Model No.: ASY-NDF1005-N00NNX-EC
Dimensions L*W*H: 11.0*12.7*6.6mm
Quantity (5m): 4pcs
Free/Optional: Free
Item: PC clip
Model No.: ASY-NDF1005-P1NN0020-MT
Dimensions L*W*H: 25*12*9mm
Quantity (5m): 15pcs
Free/Optional: Free
Item: PC channel
Model No.: ASY-NDF1005-P3NN1000-MT
Dimensions L*W*H: 1000.0*12.0*9.0mm
Quantity (5m): 5pcs
Free/Optional: Optional
Item: Silicone Glue
Model No.: WR-7516
Dimensions: 45g/pc
Quantity (5m): 1pcs
Free/Optional: Optional

NDF1005
LED NEON FLEX
5(8)
1. All accessories can be added according to customer requirements;
2. If customers want to process molded caps by themselves, they should use the corresponding molds and molding equipment;
3. If customers reprocess the molded cap themselves, the resulting quality risks are not covered by the warranty;
Accessories diagram
Note:
PC clip 25 12 Optional
CustomizedPC channel 1000 12
Name TypeL(mm) W(mm)
W
L
Installation Methods and Steps
Front cap installation
Closing end-cap installation
Weld the wire to the PCB board.
Apply waterproof glue to the end cap,
then push the cap into the strip.
Apply waterproof glue to the front
cap, then push the cap into the strip.
Wipe off the excess glue and wait for
the glue to solidify.
Wipe off the excess glue and wait for the
glue to solidify.
Insert the connector into the bottom of the PCB board
(pay attention to the positive and negative poles)
Install the connector cover onto the connector
(pay attention to wires)
Connector installation

NDF1005
LED NEON FLEX
6(8)
Aluminum track installation
Screw the aluminum track to the
installation position.
Press the strip into the aluminum track Finished
Notes:
At the welding place, please pay attention to the positive and negative poles of the wire and the strip;
Each connection must use 10g silica gel for waterproof and insulating treatment;
The screws must be vertical to the mounting surface and be fastened, as shown in the figure on the right;
Please choose suitable operation steps according to the actual needs;
During mounting, please pay attention to the min bending diameter, and best to use original factory accessories;
More information, please feel free to consult us;
-
-
-
-
-
-
Label the reel;
Seal the carton box; Use packing belt to pack. Add
edge protectors if necessary.
Put reel, accessory bag and
desiccant together into static
shielding bag;
Roll the product to a reel Seal and label the static
shielding bag;
Label the box;Put the packed static shielding
bag into carton box;
Packaging Information
Carton Size (mm) Meter/Reel Reel/Carton Gross Weight (kg)Product Size (mm)Model No. Net Weight (kg)
5000*10*4.8 5 / (1±10%) 16.15 (1± 10%)40550*400*340NDF1005
One piece(5m) per reel, and the reel is packed in an outer box.
For other customized length packaging, please ask our sales rep.
The above-mentioned packaging quantity and weight are only for the illustrated packaging method. For other packaging
methods, the packaging quantity and weight will be different. The actual weight is subject to the actual product.

NDF1005
LED NEON FLEX
7(8)
Reliability test
Environmental test
Mechanical
strength testing
Blueview standard
Blueview standard
Project Category Test conditions
Fix the ends of the sample on the tension machine, then power on and
record the tension value when the sample is turned off.
Light on the sample, forward and reverse rotation 360° one time each, a
total of 10 times.
TA=25°C, continuous power on
Simulated TH=60 °C, continuous power on
TH=60°C/4h,TA=20°C/1h,TL=-40°C continuous cycle and power on
Outcome
Pass
Reference standards
Temperature cycling test
Tensile test
Twisting test
Room temperature aging test
High temperature resistance test
Warning Mark
Cuttable identifier Neat and smooth cut
Side bending
Light Surface
Do not bend many times,for it can
endanger electronic lines.
The cutting mark is on the PCB, and the cutting position can be identified in the product cutting line window or the laser mark on the product surface;
After unpacking, use warning signs during handling and installation, and rigorous operation can bring a pleasant experience;
Note:
Do not use on wringing(twist) Do not bend at right angles Do not throw or pull when taking
products
Do not make irregular cuts.
Insert a stick on the reel and place
it on the packing box,and rotate the
reel to get the product.
use in convex direction
Light Surface
Use in concave direction
Light Surface
Do not use in distortions

NDF1005
LED NEON FLEX
8(8)
Packaging information
Recycling
Warning
Attentions before installation
Statements and Recycling
Do not disassemble or retrofit the light. Do not touch the surface of the light with a sharp object.
Do not do live-line working during installation,especially for high voltage product.
Do not use any organic chemical solvents.
Use neutral glass adhesive to fix this product and it needs to be dried 4 hours in the open environment after operation.
Treat the ends and the circuit connection points that are not connected to the main line with insulation,waterproof, and anti-corrosion in the installation.
Use 18AWG (0.75mm2 cross-sectional area) or thicker core wire to avoid adverse consequences caused by overheating, if the power cable need to
lengthen.
Make sure the input voltage meets the requirements and lines are connected correctly before lighting on
This product is for signage, and do not use as general lighting.
Series connection within the max run.
The length of the power cable between the power supply and the led strip should not exceed 2 meters.Otherwise, large circuit loss will lead to
inconsistent brightness.
Installation, maintenance and repair should be operated by a qualified technician.
Before installation, check that the product parameters are consistent with the requirements (Seeing product specifications or product labels)
Load voltage, current, power and power supply should be matched with the product.
Follow the instructions of wiring diagram (first connect the load and then the power supply) to avoid short circuit
Make sure the correct connection of positive and negative poles between products and power supply. Otherwise, the light will not be on.
Make sure the power cord firmly screwed into the terminal and it should not be pulled out by hands.
The terminal should have waterproof and anti-corrosive treatment.
Repair should be operated by a qualified technician or supplier, if the external circuit or main line of this product is damaged.
The parameters given in this manual are typical values and for reference only
All illustrations and drawings in this manual are for reference.
This product is subject to change without notice.
LED lighting products belongs to electronic products, please do recycling treatment according to the relevant WEEE directives.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
