Blueview LED SILICONE NEON FLEX User manual

LED SILICONE NEON FLEX
NS2-10
01
Bending diameter：
landscape lighting and decorating lighting etc.
Note: constant current for NS2-10.
IP68
see table 3years
12/24V
By clips
2835
Features
Application
Installation
Flexible PCB with 2835 SMD LED technology
Bendable and cuttable every 50/62.5mm[1.99/2.46in]
Small size to satisfy different requirements
Dot-free linear neon-like illumination
Fabricated with Eco-friendly, weather-resistant silicone material
Colors in white, yellow, green, blue and red for options
IP67 perfect for outdoor use
Light
Surface
Light Surface
Base
Unit:mm

LED SILICONE NEON FLEX
NS2-10
02
Model No. Beam AngleLight Color
W
R
G
B
Y
O
Ra Luminous
Flux(lm/m)
Voltage
(DC V)
NS2-10
2900-25000
620-625nm
520-525nm
465-470nm
587-589.5nm
600-605nm
137°
80+
--
--
--
--
--
350
146
293
61
291
122
Color Temperature/
Wavelength(K/nm)
Power
(W/m)
Efcacy
(lm/w)
28.9
12.2
24.1
14.9
24.0
10.8
24
12
12
12
12
12
12
Optical & Electrical Parameters
Other Parameters
Model No.
NS2-10 112 15000*14*10 15 62.5
LED Quantity
(pcs/m)
Product Size
(mm)
Max Run
(Single Feed(m)
Min Cuttable
Length(mm)
Working
Temperature
Storage
Temperature
-20~+60℃-20~+70℃
NOTE:
Test environment temperature : 25±2°C.
The above data is typical values. The actual data of each single product may differ from the typical values.
The data is subject to change without notice.
Different color temperature will make luminous ux different.
Power tolerance:±10%.

LED SILICONE NEON FLEX
NS2-10
03
Unit:mm
Prole Drawings
Single Feed
Double Feed
NS2-10
Note:Please ask the sales for detail drawing
1
15
5
20
10
25
30
0.32
4.8
1.6
6.4
3.2
8.0
9.6
24
7.68
115.2
38.4
153.6
76.8
192
230.4
≥10
≥144
≥50
≥192
≥96
≥240
≥288
Single Feed
Single Feed
Single Feed
Double Feed
Single Feed
Double Feed
Double Feed
NS2-10
Model No. Working
Length(m)
Rated
Current(A)
Rated
Voltage(DC V)
Rated Power
(W) Recommended Power
Supply Conguration(W)
Power
Supply Mode
Working Length vs. Recommended Power Supply

LED SILICONE NEON FLEX
NS2-10
04
AVERAGE BEAM ANGLE(50%)：137.3°
C0 /180,137.6°
Unit：cd
C90/270,137.0°
Flux Out：183.9lm
Height Eavg，Emax Beam Angle：137.0° Diameter
Luminous Intensity Distribution Diagram
Average Illumination
NS2-10

LED SILICONE NEON FLEX
NS2-10
05
Product accessories
End cap with hole
(FREE)
Quantity(15m):3pcs
Quantity(30m):6pcs
End cap without hole
(FREE)
Quantity(15m):3pcs
Quantity(30m):6pcs
Plastic mounting clip
(FREE)
Quantity(15m):30pcs
Quantity(30m):60pcs
Metal mounting clip
(OPTIONAL)
Quantity(15m):30pcs
Quantity(30m):60pcs
Aluminum prole
(OPTIONAL)
Quantity(15m):30pcs
Quantity(30m):60pcs
Screw
(FREE)
Quantity(5 m):30pcs
Quantity(10m):60pcs
Silicone glue
(FREE)
Quantity(5 m):1pcs
Quantity(10m):2pcs
more accessories can be provided according to customer requirements
All accessories will be different depending on the product, please
correspond the accessory list to the product or reference purchase code.
Note:
Packaging Information
Roll the product on the reel
and tie it with PE lm.
Put the reel and accessory
bag together into carton box.
Seal and label the box. Use packing belt to pack. Add
edge protectors if necessary.
Label the reel. Fitting each reel with
corresponding accessory bag.
Model No.
390*390*20015000*14*10 15 2 4.8(1±10%) 6.8(1±10%)
Gross Weight(kg)
Packaging information
Every 1pc for a reel,one reel for a static shielding bag;
NS2-10
Product Size L*W*H
(mm)
Carton Size
(mm) Net Weight(kg)
Meter/Reel Reel/Carton
The above quantity and weight are only for the illustrated packaging method. There will be differences
in the quantity and weight with other packaging methods.
Note:

LED SILICONE NEON FLEX
NS2-10
06
Installation
1.Tools
Cutter Electric batchLED power supply Brush
2.Installation steps
Details of installation operation at input end
Details of installation operation at the end part
Solder the wire to the PCB
board
First put some glue inside of
the plug, then push into the
tape light
Wipe off the excess glue and
wait for the glue to solidify.
First put waterproof glue
inside of the end exit, then
push into the tape light
Wipe off the excess glue and
wait for the glue to solidify
3. Operation details of installation card
2
Screw the clip into the
installation position
Then slowly press the tape
light into the clip
The tape light is flatly and
rmly stuck in the clip

LED SILICONE NEON FLEX
NS2-10
07
Attentions
At welding part, note the positive and negative poles of lines and board and the
corresponding colors on the board; positive to positive and negative to negative
1.
Each connection point must use 10g silica gel, and treat waterproof and
insulation well;
2.
The screw of installation card must perpendicular to installation surface and be
fastened, as shown in the right.
3.
Note:
Cuttable mark Neat and smooth cut Slide a spindle into the roll
and then place the roll with
spindle on top of the box
provided.
Correct usage of products
Gently unroll the xture
without excessive force.
No cutting distort No embossing operation Do not twist
Do not repeatedly bending
This will damage the circuit
Do not wring Do not bend 90° No recessing operation
Cutting marks are on the PCB and can be seen through the tape light.
The above diagram only shows the correct or wrong way of operation. The product should be based on the actual product.
Note:

LED SILICONE NEON FLEX
NS2-10
08
Before installation, check that the product parameters are consistent with the requirements (Seeing product specications or product labels)
Load voltage, current, power and power supply should be matched with the product.
Follow the instructions of wiring diagram (rst connect the product and then the power supply) to avoid short circuit.
Make sure the correct connection of positive and negative poles between the product and power supply. Otherwise, the light will not be on.
Make sure the power cord rmly screwed into the terminal and it should not be pulled out by hands.
The terminal should have insulation,waterproof and anti-corrosive treatment.
Attentions
Common Faults and Troubleshoot
Quick Guide
Problems
All LEDs can not
light on.
LEDs can not light
on partly.
Brightness of LED
is inconsistent tor
insufcient.
LED icker.
Automatic power protection from the open or short
circuit in output of the power supply.
Fix the short circuit problem.
Correctly connection
Check the power supply system to x it.
Replace with more powerful power
Make sure the working voltage of the product within ±5% of
standard voltage, or keep balance by circuit power consumption.
Reduce the quantities of the product in series connection to meet
requirement.
Fix the short circuit problem.
Wrong connection of power supply.
Some switching mode power supplies are not
powered.
Power supply line error.
Mistaken wire connection of some of products
Power overloaded.
Connection point fault. Remove bad connection point.
Replace a new power supply.
Please follow the instructions
Power supply circuit excessive consumption.
Excessive quantities in series connection of the
product
Switching power supply failure.
Wrong Installation or use of products
Reasons
No electric supply.
Solutions

LED SILICONE NEON FLEX
NS2-10
09
Do not disassemble or retrot the light. Do not touch the surface of the light with a sharp object.
Do not do live-line working during installation,especially for high voltage product.
Do not use any organic chemical solvents.
Use neutral glass adhesive to x this product and it needs to be dried 4 hours in the open environment after operation.
Treat the ends and the circuit connection points that are not connected to the main line with insulation,waterproof, and anti-corrosion in the
installation.
Use 18AWG (0.75mm2 cross-sectional area) or thicker core wire to avoid adverse consequences caused by overheating, if the power cable need to
lengthen.
Make sure the input voltage meets the requirements and lines are connected correctly before lighting on.
The product is for signage, please do not use as general lighting.
Series connection within the max run.
The length of the power cable between the power supply and the led strip should not exceed 2 meters.Otherwise, large circuit loss will lead to
inconsistent brightness.
Installation, maintenance and repair should be operated by a qualied technician.
Repair should be operated by a qualied technician, if the external circuit or main line of this product is damaged.
The parameters given in this manual are typical values and for reference only.
All illustrations and drawings in this manual are for reference.
This product is subject to change without notice.
LED lighting products belongs to electronic products, please do recycling treatment according to the relevant WEEE directives.
Statements:
Recycling:
Statements and Recycling
Warning
