Bluewater Pro Series User manual

BLUEWATER PRO
WATER PURIFIER
COMPLETE USER MANUAL
Applies only to products with serial number 1845-01001 and later

02
Complete User manual
CONTENTS
INTRODUCTION 03
About this manual 03
Limited warranty 03
Environment information 03
Disposal 03
Symbols 03
Safety instructions 04
Safety information 04
PRODUCT OVERVIEW 06
Models 06
Pro outside 06
Pro inside and replacement components 07
Move the water purifier 08
SYSTEM OVERVIEW 09
System description 09
Leak protection system 10
Low pressure protection 10
Water production 11
INSTALLATION 12
Unpack Pro 13
Position Pro 14
Install clean water faucet 14
Install feed water connection 15
Install drain water connection 15
Connect the water purifier 16
Do a check for leaks 17
MAINTENANCE 18
Each month 18
Each 4-6 months 19
Replace prefilter 21
Each year 22
Other 23
TECHNICAL INFORMATION 30
Technical data 30
Requirements on feed water to water purifier 31
TROUBLESHOOTING 32
How to solve simple problems 32
Product performance 34

03 © Bluewater Group 2019
INTRODUCTION
About this manual
This manual contains complete user instructions for the Pro. It gives you the necessary
instructions to safely install, operate, do maintenance and do troubleshooting on the device.
Original language
The original language of this instruction is English.
Printing options
This manual is made to be printed as a double sided A4 or A5 booklet.
Limited warranty
Refer to www.bluewatergroup.com/warranty for more information on Limited warranty.
Environment information
80% of the the water purifier components and its packaging have a label to help you
recycle and discard it correctly. The water purifier is more ecient when it cleans
water for longer periods. Example: do not fill a glass with water. Fill a jug instead.
Disposal
At the end of the water purifier’s life, disconnect the plug from the electrical supply and cut
the cable at the point where it enters the appliance. Make sure that children do not play with
the left-over cable. Contact your local authority for information about where the water purifier
can be left, or contact your dealer.
Appliances bearing this symbol must be deposited at the designated local reception
point for the disposal of electrical and electronic equipment. This product may not be
disposed by using the normal household refuse collection processes.
Symbols
The following symbols can be found on the water purifier:
Symbol Description Symbol Description
The WQA Gold Seal is proof that the
water purifier has been independantly
tested and is certified against NSF/ANSI
58 and CSA Standard B483.1. It has also
been tested and certified against NSF/
ANSI 372.
The ETL Listed Mark is proof that the
device has been independently tested
and meets the applicable published
standard.

04
Complete User manual
Safety instructions
Before you install or operate the device, you must read the safety information. Obey the
instructions in this manual to prevent injuries or damage to the equipment. This manual
contains CAUTIONS and NOTES that are applicable for the safe operation of the device.
A CAUTION identifies conditions that can cause injury, or
damage to the equipment.
Obey the instructions and do not continue until all conditions
are accepted and engaged.
A Note identifies important information for a trouble free and optimal use of the water
purifier.
Safety information
Install the water purifier in accordance with local regulations. If
you are not sure, contact a Bluewater dealer for aid. Bluewater
has no responsibility for installation of the water purifier.
Only use the cleaned water when the lights “Purification level II
and/or III” on the control panel are on.
This appliance can be used by children who are more than
8 years old. It can also be used by persons with reduced
physical, sensory or mental capabilities or lack of experience
and knowledge, if they have been given supervision or
instruction about the use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.
Do not repair or modify parts of the water purifier. This can
make it operate incorrectly, and lead to injury and damage not
covered by warranty.
Pro is a reverse osmosis system. It contains a replaceable
membrane that is very important for eective reduction of
total dissolved solids (TDS). Replace this membrane regularly.
Test the cleaned water periodically, at least one time every
year, to make sure that Pro performs correctly. If the water is
not clean, tastes or smells bad, do not drink it.

05 © Bluewater Group 2019
Only approved Bluewater sta can do servicing and repairs
on the water purifier. Only use original replacement cartridges
and parts from Bluewater. For the spare parts catalogue and
contact information for purchases, see
www.bluewatergroup.com.
The water to be cleaned must obey the requirements in
"Technical information" on page 30.
Installation must comply with applicable local plumbing codes
and regulations.
Connect the water purifier to an earthed electrical supply.
Use a socket that is easy to access after installation. Only an
approved electrician must do permanent wiring on the system.
A safety switch must be installed on the system. Incorrect
installation can lead to damage, or make the water purifier
dangerous to use.
Do not use the power cord if there are visible signs of damage
on it. If the power cord is damaged, a qualified electrician must
replace it in order to prevent danger.
Do not use Pro without a filter. To do so can cause damage. When Pro is cleaned or
put in storage, the filter can be removed.
If the water purifier is disconnected from water and electricity for >5 days, store it as
described in Complete User manual "Put into storage" on page 27.

06
Complete User manual
PRODUCT OVERVIEW
Models
Model Capable of handling
higher TDS, including
brackish inlet water
Suitable for commercial
use without an automatic
shuto
Clean water rinse valve
suitable for environments
where extra high water
quality is required
Pro 400B-HR 
Pro 400C-HF 
Pro 400C-HR 
Pro 400BC-HR  
Pro 400CV-HR  
Pro 400BCV-HR   
Pro 600C-HF 
Pro 600CV-HR  
Pro outside
Figure 1.
1
2 3 4 5 87 9 10 11 12
6
Pro outside
Pos Description Pos Description
1 Control panel 7 Electrical connection for faucet (optional)
2 Front cover 8 Drain water hose
3Clean water connection 9 Power cord
4Clean water tube 10 Feed water tube
5 Rinse water tube (only for CV models) 11 Grid filter
6 Air-gap bracket (only for CV models) 12 Feed water connection

07 © Bluewater Group 2019
Pro inside and replacement components
Figure 2. Pro inside
Control panel
For information about combinations of lights that flashes/are on, see
"Troubleshooting" on page 32.
Figure 3. Control panel
Pos Light/button Description
1 on/o On:
O:
Flashes:
The water purifier is connected to power.
The water purifier is not connected to power.
The water purifier flushes. Flushing cannot be stopped.
2 filter I On: The filter must be replaced. Pro 600: Replace both Carbon
Block filters.
3 filter II On: The filter must be replaced. Pro 600: Replace both Carbon
Block filters.
4 stop Flashes/On: Something is wrong, see "Troubleshooting" on page 32.
5 button Various functions
6 purification level I On:
On:
On:
Purification level I-III indicates clean water purification
level. Low level I to high level III.
7 purification level II
8 purification level III
Pos Description Art.-Nr.
1 Base plate
2 Prefilter I, Pro 600: Carbon Block 919240005
Prefilter I, Pro 400: Sediment filter 919240002
3 Prefilter II, Pro 600: Carbon Block 919240005
Prefilter II, Pro 400: Carbon filter,
granulated
919240003
4 Reverse osmosis membrane
Membrane service kit, type HR
(High Rejection)
150718900-SP
Membrane service kit, type HF
(High Flow)
150718901-SP
1
2
34
1
2
3
4
5
6 7 8

08
Complete User manual
Data plate
The data plate is located on the rear side of the water purifier.
Figure 4. Data plate
Move the water purifier
Always transport the water purifier upright.
Install according to "Installation" on page 12.
Put the water purifier into storage if it will not be used for 4 months or more, or if it is
to be disconnected from the water and electricity for >5 days, see "Put into storage"
on page 27.
Contact your Bluewater dealer for advice before moving the water purifier from one
place to another.
Figure 5. Move the water purifier

09 © Bluewater Group 2019
SYSTEM OVERVIEW
System description
1
2
3
4
5
6
Figure 6. System overview, an example of Pro installation
Pos Description Pos Description
1 Water purifier 4 Drain water hose, installed with an air-gap
2Power cord 5 Bracket for drain water hose
3Feed water tube 6Clean water tube

10
Complete User manual
Leak protection system
A sensor at the bottom of the water purifier senses water leaks. If there is a leak, the feed water
supply is stopped. The water purifier cannot be started again until the leak has been repaired.
Low pressure protection
If Pro stops because of low pressure, the cause of the low
pressure must be removed. If not, Pro can be permanently
damaged.
Low pressure restart function
Figure 7.
2-10 bar
0,2-1 MPa
29-145 psi
Low pressure restart function
Only included in models suitable for commercial use.
When Pro has stopped because of a low pressure problem (feed water), water production can
be started manually by pushing the button.
The low pressure restart is a function to ensure maximum availability of water.
Pro starts automatically when it has stopped because of low pressure. It tries to start three
times: after 3 minutes, after 20 minutes and after 4 hours. If the water pressure is not
suciently high after three tries, Pro will stop.

11 © Bluewater Group 2019
Water production
Only use the cleaned water when the lights “Purification level
II and III” on the control panel are on. It can take up to 60
seconds before the water purifier indicates good water quality.
For models suitable for commercial use the faucet could be replaced by for example
a valve or a tank.
Figure 8. Water production on/o
Automatic flush
The length of the flush process varies between 5-120 seconds, depending on how
long the previous drawing of water lasted.
An automatic flush will be performed if one of the conditions below are fulfilled:
Figure 9. Automatic flush
Pos Description
1 Flush after drawing water. Every time after drawing water.
2 Flush when drawing water. After maximum operation time 15 minutes. (Pro 400B must be
manually restarted)
3 Water purifier in standby mode. Pro is connected to water and power. Flush is performed every
12 hours, regardless of when clean water was last produced.
12 h
15 min
2 min
1 2 3

12
Complete User manual
INSTALLATION
Install the water purifier in accordance with local regulations. If
you are not sure, contact a Bluewater dealer for aid. Bluewater
has no responsibility for installation of the water purifier.
Install the water purifier in a vertical position on a horizontal
surface. Make sure that hose and cables can move freely when
the water purifier is installed.
Plumbing must be done by an approved plumber. Installation
must comply with applicable local plumbing codes and
regulations.
Only connect the water purifier to the cold water supply. The
water must be of sucient quality and fullfil the requirements
on feed water.
The first time Pro is connected to water and power, it does
an automatic cleaning procedure. The cleaning time is
60minutes. Cleaning cannot be stopped. Keep Pro connected
to power, and leave the faucet open.
Use the hose set that is supplied with the water purifier. Do not use used hose sets again.

13 © Bluewater Group 2019
Unpack Pro
Warning! Discard the packing material. It can cause injury to
children if they play with it.
Make sure that Pro shows no signs of damage, and that no accessories are missing.
Tell the Bluewater dealer about missing parts, damage and other problems. Tell the
transport company immediately if Pro is damaged during transport.
Figure 10. Unpack Pro
CV model

14
Complete User manual
Position Pro
Put Pro in a vertical position on a horizontal surface below the kitchen sink. Make sure
that the surface can support Pro
Position Pro near the cold water supply, the drain and an earthed electrical supply.
• Make sure that it is easy to see the control panel.
• Make sure that the front cover can be opened to get access to the prefilters.
• Hoses and cables can go in all directions from the connection point. Make sure that nothing can
crush them or cause damage to them.
Figure 11.
466 mm
460 mm
430
395
460
225
20 mm
20
20
466 mm
460 mm
430
395
460
225
20 mm
20
20
Position Pro
Install clean water faucet
For models suitable for commercial use the faucet could be replaced by for example
a valve or a tank.
Install the faucet according to the manufacturer’s instructions.
Figure 12. Install clean water faucet
3/8”

15 © Bluewater Group 2019
Install feed water connection
Only connect the water purifier to the cold water supply. The
water must be of sucient quality and fulfil the requirements
on feed water.
The water purifier is connected to cold water via the feed water hose. See "Requirements on
feed water to water purifier" on page 31.
Figure 13.
3/4”
321
Install feed water connection
Install drain water connection
Install the drain water hose with an air gap.
The flushed water goes through the drain water hose to the drain water outlet. This
hose can be a maximum of four meters long. The minimum internal diameter is
13mm.
Figure 14.
12
Install drain water connection

16
Complete User manual
Connect the water purifier
Do not connect the clean water hose to other drinking water
equipment before Pro has been flushed.
Applies to models that connects to a faucet.
Figure 15. Connect the water purifier
CV
3
2
19 mm
3/4”
1
ON
19
mm
3/4”
UK US ZH EU
5
476
>3 s
910 11
OFF
60 min
8

17 © Bluewater Group 2019
Do a check for leaks
The hose connections must be tight!
Figure 16. Do a check for leaks

18
Complete User manual
MAINTENANCE
Regular maintenance is important for correct function and
long term operation. Only educated and approved personnel
can do the maintenance.
If the water quality changes greatly, contact your Bluewater
dealer for advice.
Do not drink the water when the water purifier flushes, or
when you do maintenance with chemicals. It is not safe to use.
The water quality controls the maintenance frequency. If the feed water is of low
quality, do maintenance more frequently.
Each month
Do a check for leaks
See"Do a check for leaks" on page 17
Repair leaks
Figure 17. Repair leaks
Wipe o condensation from base plate
Figure 18. Wipe o condensation from base plate
1234567
1 2 3 4
5 6 7 8
min
10mm
(1/2”)

19 © Bluewater Group 2019
Each 4-6 months
Descale
The descaling product is harmful. Keep it where children
cannot get it. Clean your hands when you have used it.
Order the descaling product from a Bluewater dealer.
Frequency depends on water quality and usage!
To extend the water purifier lifetime: Descale Pro with 6 month intervals or when the
flow is decreased.
If Pro has been descaled and the filters have been replaced, but the water flow
cannot be restored, contact your Bluewater dealer.
The descale takes approximately 10 hours. Do not use the water purifier during this
time.
×1
3 s
II
II
I
5 6 7 8 9
200 g
7 oz ~25 °C (77 °F)
10 11 12 13 14
518
5 s
MAX
60 min
1 2 3 4

20
Complete User manual
45 s
15 16 17 18 19
>3 s
IIII
25 26 27 28
10 h
20 21 22 23 24
IIII
29 30 31 32
x3
1 min
5 s
36353433
