Applies only to products with serial number 220401001 and later

02
CONTENTS
OWNER’S MANUAL  EN 03
MANUEL DU PROPRIÉTAIRE  FR 16
MANUAL DE USO  ES 30
MANUAL DO PROPRIETÁRIO  PT 43
MANUALE DEL PROPRIETARIO  IT 56
BEDIENUNGSANLEITUNG  DE 69
INSTRUKCJA OBSŁUGI  PL 82
   RU 95
HANDBOK  SE 108
OMISTAJAN KÄSIKIRJA  FI 121
BRUKERHÅNDBOK  NO 134
BETJENINGSVEJLEDNING  DK 147
用户手册  ZH160
 ARABIC  AR 172
About this manual
This manual gives you the necessary instructions to operate and do minor troubleshooting on the Pro.
For more information:
Bluewater global website
www.bluewatergroup.com
Bluewater China website
cn.bluewatergroup.com
Original language
The original language of this instruction is English, all other languages are translations of the original
instruction.
Regulatory information
Symbol Desicription
The CE marking and the related EC Declaration of Conformity is valid for the device when it is used in the same
condition as it was delivered from the manufacturer.
Limited warranty
Please visit www.bluewatergroup.com/warranty for more information on Limited warranty.
Symbols
The following symbols can be found on the water purifier:
Symbol Description
The ETL Listed Mark is proof that the device
has been independently tested and meets the
applicable published standard.
Pro Owner's manual

03 © Bluewater Group 2022
EN
CONTENTS
SAFETY 04
Safety instructions 04
Safety information 04
PRODUCT OVERVIEW 06
Models 06
Pro outside 06
Pro inside and replacement components 07
Control panel 07
SYSTEM OVERVIEW 08
System description 08
Installation 09
Leak protection system 09
Low pressure protection 09
Water production 10
MAINTENANCE 11
Daily maintenance 11
Regular maintenance 11
TECHNICAL INFORMATION 12
TROUBLESHOOTING 13
How to solve simple problems 13
Product performance 15
Customer service
See "Troubleshooting" to solve minor problems before
calling service support.
If you need service support, be sure to have the following data
(found on the data plate) available when calling your Bluewater dealer:
– Model
– Product number
– Serial number
Environment information
The water purifier is more ecient when purifying water for longer periods. Example:
Filling several liters is more ecient per liter than filling just one liter at a time.
80% of the water purifier components and its packaging are labeled to help you
recycle and discard correctly.
Appliances bearing this symbol must be deposited at the designated local reception
point for the disposal of electrical and electronic equipment. This product may not be
disposed of using the normal household refuse collection processes.

04
Pro Owner's manual
SAFETY
Safety instructions
Before you install or operate the device, you must read the safety information. Obey the
instructions in this manual to prevent injuries or damage to the equipment. This manual
contains CAUTIONS and NOTES that are applicable for the safe operation of the device.
A CAUTION symbol identifies conditions that can cause injury,
or damage to the equipment.
DO NOT USE Pro unless all cautionary conditions listed below
have been understood and met.
A Note symbol identifies important information for trouble free and optimal use of
the water purifier.
Safety information
Be aware! Do not use or drink the water before “PURIFICATION
LEVEL II or LEVEL III” light turns green.
When the system has been on standby, turn on the faucet and
let the water run until the "PURIFICATION LEVEL II or LEVEL III"
light turns green before using or drinking the purified water. Do
not drink the water during “PURIFICATION LEVEL I”.
This appliance can be used by children who are more than 8
years old. It can also be used by persons with reduced physical,
sensory, or mental capabilities or lack of experience and
knowledge, if they have been given supervision or instruction
about the use of the appliance in a safe way and understand the
hazards involved.
Do not repair or modify parts of the water purifier. This can
make it operate incorrectly and lead to injury and damage not
covered by warranty.
Pro is a reverse osmosis system. It contains a replaceable
membrane that is very important for eective reduction of total
dissolved solids (TDS). Replace this membrane regularly. Test
the purified water periodically using a TDS/Conductivity tester
at least one time every year, to make sure that Pro performs
correctly. For options, contact your Bluewater dealer. If there is
any indication that the purified water tastes, smells bad, is cloudy,
or there is a presence of particles, do not drink.

05 © Bluewater Group 2022
EN
We recommend only approved technicians, distributors or
Bluewater service personnel perform installations, servicing and
repairs on the water purifier. If not performed adequately, this
can make it operate incorrectly, and lead to injury and damage
not covered by warranty.
Only use original replacement cartridges and parts
from Bluewater. For the spare parts catalogue,
see www.bluewatergroup.com. For purchase information,
contact your Bluewater dealer.
The inlet water must meet the requirements stated in
"REQUIREMENTS FOR INLET WATER to water purifier”.
Installation must comply with applicable local plumbing codes
and regulations.
Connect the water purifier to an earthed/grounded electrical
supply. Use a plug that is easy to access after installation. Only
an approved electrician must do permanent wiring on the
system. Incorrect installation can lead to damage or make the
water purifier dangerous to use.
Do not use the power cord if there are visible signs of damage
on it. If the power cord is damaged, a qualified electrician must
replace it to prevent danger.
Do not use Pro without filters. This can cause damage to the
system. The filters can be removed when Pro is cleaned or put
into storage.
If the water purifier is disconnected from water and electricity for >5 days, store it as
described in Complete User manual “Put into storage”.
Contact your Bluewater dealer for advice before moving the water purifier from one
place to another.

06
Pro Owner's manual
PRODUCT OVERVIEW
Models
Model Capable of handling
higher TDS, including
brackish inlet water
Suitable for commercial
use Purified water rinse valve suitable for environments
where extra high water
quality is required
Pro 400C-HF 
Pro 400C-HR 
Pro 400BC-HR  
Pro 400CV-HR  
Pro 400BCV-HR   
Pro 600C-HF 
Pro 600CV-HR  
Pro outside
12 3 4 5 87 9 10 11 12
6
Figure 1. Pro outside
Pos Description Pos Description
1 Control panel 7 Electrical connection for faucet (optional)
2 Front cover 8 Drain water hose
3Purified water connection 9Power cord
4Purified water tube 10 Inlet water tube
5 Rinse water tube (only for CV models) 11 Inlet grid filter
6 Air gap bracket (only for CV models) 12 Inlet water connection

07 © Bluewater Group 2022
EN
Pro inside and replacement components
Figure 2. Pro inside
Control panel
For information about combinations of lights that flash or are on, see
"Troubleshooting".
ON/OFF
FILTER IIFILTER I
STOP
PURIFICATION LEVEL
1
2
3
4
5
6 7 8
Figure 3. Control panel
Pos Light/Button Description
1 ON/OFF On:
O:
Flashes:
The water purifier is connected to power.
The water purifier is not connected to power.
The water purifier is flushing.
2 FILTER I On: Pro 400: Replace FILTER I.
Pro 600: Replace both FILTER I and II.
3 FILTER II On: Pro 400: Replace FILTER II.
Pro 600: Replace both FILTER I and II.
4 STOP Flashes/On: Something is wrong, see "Troubleshooting".
5 Button Various functions.
6 PURIFICATION
LEVEL I On: Incomplete purification: DO NOT DRINK.
7 PURIFICATION
LEVEL II On: Medium purification: Ready to drink.
8 PURIFICATION
LEVEL III On: Highest purification: Ready to drink.
12 3 4
Pos Description Part Number
1 Base plate 150706401-SP
2 FILTER I, Pro 600: Carbon Block 919240005
FILTER I, Pro 400: Sediment filter 919240002
3 FILTER II, Pro 600: Carbon Block 919240005
FILTER II, Pro 400: Carbon GAC 919240003
4 Reverse osmosis membrane
Membrane service kit, type HR
(High Rejection) 150718900-SP
Membrane service kit, type HF
(High Flow) 150718901-SP
Membrane service kit PRO-series,
Brackish (B) 150718902-SP

08
Pro Owner's manual
SYSTEM OVERVIEW
System description
1
2
3
4
5
6
7
10
11
9
8
Figure 4. System overview, an example of Pro installation
Pos Description Pos Description
1 Water purifier. 4 Drain water hose, installed with air gap.
2 Power cord. 5 Bracket for drain water hose.
3Inlet water tube. 6Purified water tube.
Pos Accessories Pos Description
7 Standard RO faucet: Approved for use
with Reverse Osmosis purified water. 10 Storage tank: Use only tanks approved for use with Reverse Osmosis purified water.
8 Bluewater LED faucet: LED indicates
service and purified water quality
notifications.
11 Appliance: Dishwasher, coee machine,
ice maker, refrigerator etc. Appliances
must be approved for use with Reverse
Osmosis purified water.
9 Bluewater Triflow faucet: Provides
purified water in addition to hot and
cold non purified water.

09 © Bluewater Group 2022
EN
Installation
Pro must supply purified water directly to a faucet or storage
tank designed for reverse osmosis purified water. The purified
water must not travel through any non approved pipes or
faucets because this can cause corrosion damage.
Installation must comply with applicable local plumbing codes
and regulations.
Only connect the water purifier to the cold water supply.
The water must be of sucient quality and meet the
“REQUIREMENTS FOR INLET WATER to water purifier”.
If the Pro is not installed correctly, it will not be covered
under warranty.
The first time Pro is connected to water and power, the
INSTALLER MUST initiate a commissioning flush. This 60 minute
flush is a VERY IMPORTANT flush and must be allowed to
continue to completion. Keep Pro connected to power, with the
purified water faucet open for the entire time. Do not interrupt
this flush. Do not drink the water until this flush is complete. See
Complete User Manual for instructions on commissioning flush.
We recommend that the water purifier is installed by a Bluewater dealer. Installation
instructions can be found be in the Complete User manual and on
www.bluewatergroup.com.
Leak protection system
A sensor at the bottom of the water purifier senses water leaks. If there is a leak, the inlet water
supply is stopped. The water purifier cannot be started again until the leak has been repaired.
Low pressure protection
If Pro stops because of low inlet water pressure, the cause of
the low inlet pressure must be resolved.
Low pressure restart function
The low pressure restart is a function to ensure maximum availability of water.
If Pro has stopped due to low inlet water pressure, Pro attempts to restart automatically,
and continues restart attempts every 5 minutes, for up to 10 times. If the low inlet pressure
problem is not resolved by the 10th restart attempt, Pro will stop.
Once the low inlet pressure has been resolved, Pro can be restarted manually by pressing
the Button for 3 seconds.

10
Pro Owner's manual
Water production
Be aware! Do not use or drink the water before “PURIFICATION
LEVEL II or LEVEL III” light turns green. It can take up to 60
seconds before the water purifier indicates good water quality.
For models suitable for commercial use, the faucet could be replaced by, for example,
a valve or a tank.
Figure 5. Water production on/o
Automatic flush
The length of the flush process varies between 5 to 120 seconds, depending on how
much purified water has been produced.
An automatic flush will be performed if one of the conditions below is met:
12 h
15 min
2 min
1 2 3
Figure 6. Automatic flush
Pos Description
1 Automatic flush takes place after every use.
2 Automatic flush takes place after 15 minutes of total operation time. Purified water is not
available during the 2 minute flush.
3 Automatic maintenance flushes take place every 12 hours when Pro is connected to water
and power, and is in Standby mode.

11 © Bluewater Group 2022
EN
MAINTENANCE
Daily maintenance
Check indicator lights
Step Action
1 Check that only the ON/OFF light is on, and no other lights are on or flashing, while Pro is
in Standby mode. If any other lights are on or flashing, see “Troubleshooting” section.
Clean the water purifier
Do not use chemicals to clean the surface. Alcohol, petrol,
organic and inorganic acids, strong basic chemicals (such as
concentrated dishwashing detergent) will cause damage to
the surface.
Do not use hard, sharp, or abrasive tools to clean the water purifier.
Step Action
1 Clean the outer surface with a soft moist cloth and a weak soap solution to remove dust,
stains, and dirt.
2 Dry with a soft dry cloth.
Regular maintenance
Regular maintenance is important for correct function and
long term operation. We recommend only Bluewater approved
service personnel perform maintenance and repairs.
For instructions on how to do maintenance, see Complete User manual
on www.bluewatergroup.com.
Frequency Action
1 month Check connections.
Wipe o condensation from the base plate.
4-6 months* Replace the filters every 4-6 months, or as indicated by the FILTER I and
FILTER II LED indicator lights.
6 months* Descale.
1 year Test the purified water every year. If the purified water is not clean, do not
drink it. Contact a Bluewater dealer.
4-6 years* Replace reverse osmosis membrane. Contact your Bluewater dealer.
*Frequency depending on inlet water quality and usage.

12
Pro Owner's manual
TECHNICAL INFORMATION
Model Size W×H×D Weight Power Power supply earthed/
grounded
Pro 400C-HF
Pro 400C-HR
Pro 400BC-HR
Pro 400CV-HR
Pro 400BCV-HR
220-240V 225×466×460 mm 29 kg 530 W 220-240V, 50-60 Hz
120V 8.9×18.3×18.1
inches 64 lbs 6 Amp 120V, 60 Hz
Pro 600C-HF
Pro 600CV-HR 220-240V 225×466×460 mm 29 kg 720 W 220-240V, 50-60 Hz
REQUIREMENTS FOR INLET WATER to water purifier
Do not use water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after
the system.
Only connect to the cold water supply. The temperature limits
are in the table below.
If the water quality changes greatly, contact your Bluewater
dealer for advice.
For more detailed information, see www.bluewatergroup.com.
Pro 400BC-HR
Pro 400BCV-HR Pro 400C-HF Pro 400C-HR
Pro 400CV-HR
Pro 600C-HF
Pro 600CV-HR
230V 120V 230V 120V 230V
Temperature 2-30 °C 36-86 °F 2-35 °C 36-95 °F 2-35 °C
Inlet water flowing
pressure 3-10 bar 0.3-1 MPa 43-145 psi 3-10 bar 0.3-1 MPa 43-145 psi 3-10 bar 0.3-1 MPa
TDS/PPM (Total
Dissolved Solids) < 7500 ppm < 1500 ppm < 1500 ppm
Inlet Water flow > 8 l/min > 2.1 gal/min > 8 l/min > 2.1 gal/min > 10 l/min
Conductivity µS/
cm @ 25 °C (77 °F) < 13 000 < 2000 < 2000
Hardness < 20 °dH <20.9 gpg < 20 °dH <20.9 gpg < 20 °dH
Turbidity (FNU) < 0.5 < 0.5 < 0.5
Iron Fe (II) / Fe (III) <1.5 / <0.3
mg/l <1.5 / <0.3 ppm <1.5 / <0.3 mg/l <1.5 / <0.3 ppm <1.0 / <0.3 mg/l
pH 4-10 4-10 4-10 4-10 4-10
Manganese (Mn2+) <0.3 mg/l <0.3 mg/l <0.3 mg/l <0.3 mg/l <0.3 mg/l
Chlorine (Cl2) <1.0 mg/l <1.0 mg/l <1.0 mg/l <1.0 mg/l <1.0 mg/l
Recommended inlet supply size: ½” in. OD Tubing ½” in. NPT or BSSP supply valve.

13 © Bluewater Group 2022
EN
TROUBLESHOOTING
How to solve simple problems
If Pro stops because of an emergency, disconnect it from power and connect it again,
or press and hold the Button for 3 seconds to reset the emergency stop.
For more severe problems, see Complete User manual on www.bluewatergroup.com.
Symptom Cause Solution
The ON/OFF light flashes. The water purifier is flushing. Allow flush
to be completed before using the water
purifier.
Pro 400: Replace FILTER I.
Pro 600: Replace FILTER I
and II.
See Complete User manual.
The Inlet Grid Filter is blocked. See Complete User manual.
The inlet water pressure is
too low. Make sure that inlet water tubing is the proper size as specified in the
“REQUIREMENTS FOR INLET WATER
to purifier”.
Pro 400: Replace FILTER II.
Pro 600: Replace FILTER I
and II.
See Complete User manual.
The inlet water pressure is too
low. The water purifier has
stopped.
The water purifier will try to restart
automatically. Make sure that the inlet
water pressure is sucient. If necessary,
replace the filters. See Complete User
manual.
Press and hold the Button to restart the
water purifier. Release the Button when
the FILTER I light and STOP light go out.
FILTER I or FILTER II is blocked. Make sure that there is nothing in the
filters that may be blocking water flow.
If necessary, replace filters. See
Complete User manual.
The Inlet Grid Filter is blocked. See Complete User manual.
The inlet water pressure is too
low. Install a pressure boosting pump to increase the inlet water pressure.
Check the parts that may influence
the inlet water pressure. This includes
the inlet water line, the Inlet Grid Filter,
FILTER I, or any External Filters placed
in front of Pro. Make sure the inlet water
tubing is the proper size specified in the
“REQUIREMENTS FOR INLET WATER to
water purifier“.
The water purifier has
stopped. The purified water
quality is too low.
Disconnect the water purifier from
power. Connect it again to start the
automatic flush. Do this 2 times. If the
problem persists, do not use the water.
Contact your Bluewater dealer.

14
Pro Owner's manual
Symptom Cause Solution
The inlet water TDS/
Conductivity has increased
above the recommended inlet
water requirements. LEDs are
lit, but Pro does not stop.
Disconnect the water purifier from
power. Connect it again to start the
automatic flush. If the problem persists,
do not use the water. Contact your
Bluewater dealer.
The inlet water quality sensor
is not working correctly. LEDs
are lit, but Pro does not stop.
Disconnect the water purifier from
power. Connect it again to start the
automatic flush. If the problem persists,
do not use the water. Contact your
Bluewater dealer.
The leak protection system
has been activated. Disconnect the water purifier from power and clean any water from the
base plate of Pro. Connect unit to power
again and observe for any possible
leakage of water. If problem persists,
contact your Bluewater dealer.
The Commissioning Flush
procedure is ongoing. Please allow the Pro to complete the commissioning flush, do not disconnect
the power, do not press the Button, and
do not close the pure water faucet. The
flush can take up to 60 minutes.
The Commissioning
Flush procedure has been
interrupted due to low inlet
water pressure.
Make sure that the inlet water pressure is
sucient. Press the Button to restart the
water purifier.
The Commissioning
Flush procedure has been
interrupted.
Open the purified water faucet and verify
that the CV rinse function is open if your
model is equipped with this feature.
The flow rate from the
purified water faucet
is low.
The purified water tubing has
been sharply bent or blocked. Make sure that there are no sharp bends in the purified water tubing, and that it
can move freely.
The water purifier needs to be
descaled. See Complete User manual.
The water purifier
starts and stops
intermittently, or
repeatedly.
The water purifier may be
performing its 12 hour standby
flush. This flush lasts for
30 seconds. There may be
possible leaks between the
water purifier and the purified
water faucet, valve, tank, or
reverse osmosis purified water
approved appliance.
Examine all the tubing and fitting
connections for possible leakage.
Make sure that the ends of the water
tubes are circular, squarely cut, and have
no burrs or scratches.
Make sure that the purified water faucets
are watertight, and do not leak. If there
are any valves, make sure they are
watertight when they are closed.
There is a bad smell
from the water purifier. Possible Microbial (bacterial) growth in the water purifier
due to the water purifier not
being used for a long period
of time.
Pro may need to be disinfected.
See Complete User manual.

15 © Bluewater Group 2022
EN
Product performance

16
Manuel du propriétaire
Service d’assistance technique
Voir « Dépannage »pour résoudre les problèmes simples avant d'appeler
le service d'assistance.
Si vous avez besoin d’une assistance technique, assurez-vous de
disposer des informations suivantes (figurant sur la plaque signalétique)
lorsque vous appelez votre distributeur Bluewater :
– Modèle
– la référence produit
– le numéro de série
Données environnementales
L’osmoseur est plus ecace lorsqu'il purifie l'eau pendant de longues périodes.
Exemple : Il est plus ecace de remplir plusieurs litres, au litre, que de remplir un seul
litre à la fois.
80 % des pièces de l’osmoseur et son emballage sont étiquetés pour vous aider à les
recycler et à les éliminer correctement.
Les appareils portant ce symbole doivent être déposés au point de collecte local
destiné à l'élimination des équipements électriques et électroniques usagés. Ce
produit ne doit pas être éliminé en utilisant le service de collecte des déchets
ménagers ordinaire.
TABLE DES MATIÈRES
SÉCURITÉ 17
Consignes de sécurité 17
Instructions de sécurité 17
PRÉSENTATION DU PRODUIT 20
Modèles 20
Extérieur de l’osmoseur Pro 20
Intérieur de l’osmoseur Pro intérieur et pièces de rechange 21
Panneau de commande 21
PRÉSENTATION DU SYSTÈME 22
Description 22
Installation 23
Système anti-fuites 23
Système anti-basse pression 23
Production d’eau 24
ENTRETIEN 25
Entretien quotidien 25
Entretien périodique 25
CARACTÉRISTIQUES TECHNIQUES 26
DÉPANNAGE 27
Résolution de problèmes simples 27
Performances du produit 29

17 © Bluewater Group 2022
FR
SÉCURITÉ
Consignes de sécurité
Avant d'installer ou d'utiliser le dispositif, veuillez prendre connaissance des informations de
sécurité. Ces consignes doivent être scrupuleusement suivies afin de prévenir les blessures
ou la détérioration de l'équipement. Ce manuel contient des MISES EN GARDE et des
REMARQUES destinées à garantir l’utilisation sécurisée du dispositif.
Le symbole de MISE EN GARDE signale des conditions
susceptibles d’entraîner des blessures ou la détérioration
possible du produit. ABSTENEZ-VOUS D’UTILISER Pro tant que
toutes les conditions de mise en garde énumérées ci-dessous
n’ont pas été comprises et satisfaites.
Un symbole Remarque signale des informations importantes pour une utilisation
optimale et sans problème due l’osmoseur.
Instructions de sécurité
Attention ! Ne pas utiliser ou boire l'eau avant que le voyant «
PURIFICATION DE NIVEAU II ou III » ne soit devenu vert.
Lorsque le système a été mis en veille, ouvrez le robinet et
laissez couler l'eau jusqu'à ce que le voyant « NIVEAU DE
PURIFICATION II ou NIVEAU III » devienne vert avant d'utiliser
ou de boire l'eau purifiée. Abstenez-vous de boire l'eau tant que
le système est sur le « NIVEAU DE PURIFICATION I ».
Ce dispositif peut être utilisé par des enfants à partir de 8
ans. Il peut également être utilisé par des personnes dont les
capacités physiques, sensorielles ou mentales sont réduites
ou qui manquent d'expérience et de connaissances, dans la
mesure où on leur a montré ou expliqué comment utiliser
l'appareil en toute sécurité et qu’elles comprennent les
risques encourus.
Ne pas réparer ou modifier les pièces de l’osmoseur. Il pourrait
en résulter un dysfonctionnement de l'appareil susceptible de
provoquer des blessures ou des détériorations non couvertes
par la garantie.

18
Manuel du propriétaire
Pro est un système d'osmose inverse. Il contient une
membrane remplaçable très importante pour une réduction
ecace des matières solides dissoutes totales (TDS).
Remplacez régulièrement cette membrane. Procédez à des
tests périodiques sur l'eau purifiée à l'aide d'un testeur TDS/
de conductivité, au moins une fois par an, pour vous assurer
que l’osmoseur Pro fonctionne correctement. Pour les options,
contactez votre revendeur Bluewater. Si vous constatez que
l'eau purifiée a mauvais goût, qu’elle sent mauvais, qu'elle est
trouble ou qu'elle contient des particules, ne la buvez pas.
Seuls les techniciens, distributeurs ou le personnel d’entretien
agréés de Bluewater sont habilités à procéder aux opérations
d’installation, d'entretien et de réparation de l’osmoseur
au risque de causer un dysfonctionnement de l'appareil
susceptible de provoquer des blessures ou des détériorations
non couvertes par la garantie.
N'utilisez que des cartouches et des pièces de rechange
authentiques Bluewater. Pour consulter le catalogue des pièces
détachées, rendez-vous sur www.bluewatergroup.com. Pour
les informations d’achat, veuillez prendre contact avec votre
revendeur Bluewater.
L'approvisionnement en eau doit répondre aux exigences
figurant dans la section « EXIGENCES CONCERNANT
L'APPROVISIONNEMENT EN EAU de l’osmoseur ».
L'installation doit être conforme aux codes et règlements locaux
en vigueur applicable aux activités de plomberie.
Branchez l’osmoseur à une prise électrique à la masse/à la
terre. Utilisez une prise aisément accessible après l'installation.
Seul un électricien agréé doit être autorisé à eectuer les
raccordements permanents du système. Une installation
incorrecte pourrait causer des détériorations ou mettre en
danger l’utilisateur de l’osmoseur.

19 © Bluewater Group 2022
FR
N'utilisez pas le câble d'alimentation s’il présente des signes
d'endommagement. Si le câble d'alimentation est endommagé,
un électricien qualifié devra le remplacer pour éliminer tout
risque potentiel.
N'utilisez pas l’osmoseur Pro sans filtre. Cela pourrait en eet
endommager le système. Les filtres peuvent être retirés lorsque
l’osmoseur Pro est nettoyé ou qu’il est rangé pendant une
période où il ne sera pas utilisé.
Si l’osmoseur est déconnecté de l'eau et de l'électricité pendant plus de 5 jours,
il doit être stocké comme décrit dans la section « Rangement » du manuel
d'utilisation complet.
Contactez votre revendeur Bluewater pour obtenir des conseils auprès de ce dernier.

20
Manuel du propriétaire
PRÉSENTATION DU PRODUIT
Modèles
Modèle Traitement des niveaux
de TDS plus élevés,
y compris de l'eau
d’approvisionnement
saumâtre
Adapté à un usage
commercial Robinet d'eau purifiée convenant aux
environnements où une
qualité d'eau particulièrement
élevée est exigée.
Pro 400C-HF 
Pro 400C-HR 
Pro 400BC-HR  
Pro 400CV-HR  
Pro 400BCV-HR   
Pro 600C-HF 
Pro 600CV-HR  
Extérieur de l’osmoseur Pro
12 3 4 5 87 9 10 11 12
6
Figure 7. Extérieur de l’osmoseur Pro
N° Description N° Description
1 Panneau de commande 7 Raccord électrique pour robinet (en option)
2 Capot avant 8 Flexible d’évacuation d’eau
3 Raccordement d’eau purifiée 9 Câble d'alimentation
4 Tuyau d'eau purifiée 10 Tuyau d'arrivée d’eau
5 Tuyau pour eau de rinçage (modèles en CV) 11 Filtre à grille d'arrivée
6Support du dispositif antiretour (uniquement
pour les modèles CV) 12 Raccord d'arrivée d’eau
