BLUEWATER SPIRIT
WATER PURIFIER
OWNER’S MANUAL
EN
Applies only to products with serial number 1804-61001 and later

02
Owner’s manual
CONTENTS
OWNER’S MANUAL - EN 03
About this manual
This manual gives you the necessary instructions to operate and do minor troubleshooting on the
device. For more information
Bluewater global website
www.bluewatergroup.com Bluewater China website
Original language
The original language of this instruction is English, all other languages are translations of the original
instruction.
Regulatory information
Symbol Desicription
The CE marking and the related EC Declaration of Conformity is valid for the device when it is used in the same
condition as it was delivered from the manufacturer.
Limited warranty
Please visit www.bluewatergroup.com/warranty for more information on Limited warranty.
Symbols
The following symbols can be found on the water purifier:
Symbol Desicription
The ETL Listed Mark is proof that the device has been independently tested and meets the applicable published
standard.

03
© Bluewater Group 2018
EN
CONTENTS
Customer service
Environment information
80% of the the water purifier components and its packaging have a label to help you
recycle and discard it correctly. The water purifier is more ecient when it cleans
water for longer periods. Example: do not fill a glass with water. Fill a jug instead.
Appliances bearing this symbol must be deposited at the designated local reception
point for the disposal of electrical and electronic equipment. This product may not be
disposed by using the normal household refuse collection processes.
See “Troubleshooting” to solve minor problems before calling
service. If you need external service support, it can cost money.
Make sure to have the following data (found on the data plate
located behind the filter) available when calling Bluewater:
– Model
– Product number
– Serial number
OWNER’S MANUAL - EN
SAFETY 04
Safety instructions 04
Safety information 04
PRODUCT OVERVIEW 06
Models 06
Spirit outside 06
Spirit inside and replacement components 06
Control panel 07
SYSTEM OVERVIEW 08
System description 08
Intended use 08
Installation 09
Leak protection system 09
Low pressure protection 09
Water production 10
MAINTENANCE 11
Daily maintenance 11
Regular maintenance 11
TECHNICAL INFORMATION 12
TROUBLESHOOTING 13

04
Owner’s manual
SAFETY
Safety instructions
Before you install or operate the device, you must read the safety information. Obey the
instructions in this manual to prevent injuries or damage to the equipment. This manual
contains CAUTIONS and NOTICES that are applicable for the safe operation of the device.
A CAUTION identifies conditions that can cause injury, or
damage to the equipment.
Obey the instructions and do not continue until all conditions
are accepted and engaged.
A Note identifies important information for a trouble free and optimal use of the water
purifier.
Safety information
Do not drink the water when the service light shows that it is
not clean. Store water in vessels that are resistant to corrosion.
This appliance can be used by children who are more than 8
years old. It can also be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge, if they have been given supervision or instruction
about the use of the appliance in a safe way and understand the
hazards involved.
Do not repair or modify parts of the water purifier. This can
make it operate incorrectly, and lead to injury and damage not
covered by warranty.
Spirit is a reverse osmosis system. It contains a replaceable
membrane that is very important for eective reduction of total
dissolved solids (TDS).
Replace this membrane regularly. Test the cleaned water
periodically, at least one time every year to make sure that Spirit
performs correctly. If the water is not clean, tastes, or smells
bad, do not drink it.

05
© Bluewater Group 2018
EN
Only approved Bluewater sta can do servicing and repairs on
the water purifier. Only use original replacement cartridges and
parts from Bluewater. For the spare parts catalogue and contact
information for purchases, see www.bluewatergroup.com.
The water to be cleaned must obey the requirements in
“Technical information”.
Installation must comply with applicable local plumbing codes
and regulations.
Connect the water purifier to an earthed electrical supply. Use a
socket that is easy to access after installation. Only an approved
electrician must do permanent wiring on the system. A safety
switch must be installed on the system. Incorrect installation
can lead to damage, or make the water purifier dangerous to
use.
Do not use the power cord if there are visible signs of damage
on it. If the power cord is damaged, a qualified electrician must
replace it in order to prevent danger.
If the water purifier is disconnected from water and electricity for >5 days, store it as
described in Complete User manual “Put into storage”.

06
Owner’s manual
PRODUCT OVERVIEW
Models
Model Spirit 300 Electronically controlled Bluewater faucet
Spirit 300Cp Pressure controlled, compatible with
household appliances
Faucet adapted to reverse
osmosis
Spirit outside
6
5
910 8
34 2
1
7
Figure 1. Spirit outside
Pos Description Pos Description
1 Control panel 6 Power cord
2 On light 7 Electrical connection for faucet (Spirit 300)
3 Filter light 8 Feed water connection with grid filter
4 Service light 9 Drain water hose
5 Front cover 10 Clean water connection
Spirit inside and replacement components
Pos Description Art. no
1 Base plate
2 Prefilter, Carbon filter, granulated 919240004
3 Reverse osmosis membrane
Membrane service kit,
type HR (High Rejection)
155007301-SP
Membrane service kit,
type HF (High Flow)
150759380-SP
Figure 2. Spirit inside
1
2
3

07
© Bluewater Group 2018
EN
Control panel
Figure 3. Control panel
Pos Light/button Description
1 ON The water purifier is connected and operates correctly.
2 FILTER light Flashes quickly:
Flashes:
On:
The feed water pressure is too low.
The water purifier operates. The filter must be replaced.
The water purifier has stopped. The filter must be
replaced.
3 SERVICE light Flashes quickly:
Flashes:
On:
The water quality meter does not function.
Decreased water quality.
The water purifier has stopped, the water quality has
decreased
2 & 3 FILTER and
SERVICE light
Flashes quickly: There is a water leakage or condensation on the base
plate.
4 Faucet lights Green:
Flashes yellow:
Yellow:
Shows good water quality (this can take up to 120
seconds).
The water quality has decreased. Wait for the green light.
The water purifier has stopped. Look at the control panel
5 FILTER button
6 SERVICE button
Spirit 300
4
1
2
36
5

08
Owner’s manual
SYSTEM OVERVIEW
System description
Spirit 300CpSpirit 300
8
7
6
4
5
2
3
1
Figure 4. System overview, an example of a Spirit installation
Pos Description Pos Description
1 Water purifier 5 Bracket for drain water hose
2Power cord 6 Bluewater faucet
3Feed water hose 7Clean water hose
4 Drain water hose, installed with an air-gap 8 Faucet electrical connection (Spirit 300)
Intended use
The water purifier is intended to produce purified water. Do not use it for any other purpose.
Any use beside indoor home environment and for purposes other than purifying water for
household use is considered as unintended use and will automatically void your warranty.
The electronically controlled Spirit 300 is intended to produce the quantity of water that is
normally required for cooking and drinking in a household.
The pressure controlled Spirit 300Cp can be connected to other devices such as
dishwashers.

09
© Bluewater Group 2018
EN
Installation
Installation must comply with applicable local plumbing codes
and regulations.
Only connect the water purifier to the cold water supply. The
water must be of sucient quality and fulfill the requirements
on feed water.
Clean the water purifier as described in Complete User manual
“Flush Spirit” before you drink purified water. The cleaning time
is 45 minutes. Cleaning can not be stopped.
We recommend that the water purifier is installed by a professional, who is
recommended by an authorised Bluewater dealer. Installation instructions can be
found in the Complete User manual and on www.bluewatergroup.com.
Leak protection system
A sensor at the bottom of the water purifier senses water leaks. If there is a leak, the feed
water supply is stopped. The water purifier cannot be started again until the leak has been
repaired.
Low pressure protection
If Spirit stops because of low pressure, the cause of the low
pressure must be removed. If not, Spirit can be permanently
damaged.
Low pressure restart function
Only included in models suitable for commercial use.
When Spirit has stopped because of a low pressure problem (feed water), water production
can be started manually by pushing the filter button 5 seconds.
The low pressure restart is a function to ensure maximum availability of water.
Spirit starts automatically when it has stopped because of low pressure. It tries to start
three times: after 3 minutes, after 20 minutes and after 4 hours. If the water pressure is not
suciently high after three tries, Spirit will stop.

10
Owner’s manual
Water production
12
Figure 5. Water production on/o
Automatic flush
An automatic flush will be performed if one of the conditions below are fulfilled:
+30 s
6 h
20 s +10 s = 60 s
15 min
Spirit 300Cp 2.5 min
Spirit 300 4.5 min
1
2
3
Figure 6. Automatic flushing
Pos Description
1 Flush after drawing water. Production cycles shorter than 60 seconds are added together,
and flush takes place when total drawing time exceeds 60 seconds.
2 Flush after maximum operation time 15 minutes. Next production cycle can be started
immediately after completed flush.
3 Water purifier in standby mode. Spirit is connected to water and power and It is more than 6
hours since the last flush.

11
© Bluewater Group 2018
EN
MAINTENANCE
Daily maintenance
Check indicator lights
Step Action
1 Make sure that the filter light or the service light are not on or flashes.
2 Make sure that the yellow faucet light is not on or flashes. (Spirit 300).
Clean the water purifier
Do not use chemicals to clean the surface. Alcohol, petrol,
organic and inorganic acids, strong basic chemicals (such as
concentrated dish washing detergent) will cause damage to the
surface.
Do not use hard or sharp tools to clean the water purifier.
Step Action
1 Clean the outer surface with a soft moist cloth and a weak soap solution to remove dust,
stains and dirt.
2 Dry with a soft dry cloth.
Regular maintenance
Regular maintenance is important for correct function and long
term operation. Only educated and approved personnel can do
the maintenance.
For instructions on how to do maintenance, see Complete User manual
on www.bluewatergroup.com
Frequency Description
1 month Check connections
Wipe o condensation from base plate.
4-6 months* Replace filters. Replace the filters after what comes first of 4–6 months or
18925 l (5000 gal) of purified water.
6 months* Descale
1 year Test the water at least one time every year . If the water is not clean, do not
drink it. Contact a Bluewater dealer.
3–5 years* Replace reverse osmosis membrane
*Frequency depending on water quality and usage

12
Owner’s manual
TECHNICAL INFORMATION
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after
the system.
Only connect to the cold water supply. The temperature limits
are in the table "Requirements on feed water to water purifier".
For more detailed technical information see www.bluewatergroup.com
Parameter/Model Spirit 300 Spirit 300Cp
Size W×D×H [mm (“)] 150×365×462 (5.9×14.3×18.2) 150×365×462 (5.9×14.3×18.2)
Weight [kg (lbs)] 15 (33) 15 (33)
Power supply, earthed supply
Power supply, earthed supply US
220-240 V 50/60 Hz, 10A
120V 60Hz, 10A
220-240 V 50/60 Hz, 10A
120V 60Hz, 10A
Power (US) 350W (3Amps) 350W (3Amps)
Faucet with water quality indicator
light
N/A
Compatible with household
appliances
N/A 
Requirements on feed water to water purifier
Description Spirit 300 Spirit 300Cp
Pressure, flowing/dynamic [kPa (bar)
(psi)]
150 –1000 (1.5 –10)
(22 –145)
150 –1000 (1.5 –10)
(22–145)
Water flow [l/min (gal/min)] > 6 (1.6) > 6 (1.6)
TDS (Total disolved solids) [mg/l] < 1200 < 1200
Conductivity at 25°C (77°F) [μS/cm] < 1600 < 1600
Temperature [°C (°F)] 2–35 (36–95) 2–35 (36–95)
Hardness [°dH (grains/gallon)] < 10 (< 10.4) < 10 (< 10.4)
Iron Fe(II)/Fe(III) [mg/l] < 0.5/< 0.3 < 0.5/< 0.3
Turbidity [FNU] < 0.5 < 0.5

13
© Bluewater Group 2018
EN
TROUBLESHOOTING
For more severe problems, see Complete User manual on www.bluewatergroup.com
1 2 34 5 6 78
Symptom Cause Solution
1 The ON light is not on. The water purifier is not
connected to power.
Connect the water purifier to
power.
2 The FILTER light flashes,
and the yellow light on
the faucet flashes.
The filter must be replaced. See Complete User manual.
3 The FILTER light is on,
and the yellow light on
the faucet is on.
The water purifier has stopped.
The filter must be replaced.
See Complete User manual.
4 The SERVICE light
flashes, and the green
light on the faucet is
on. The water purifier
produces water.
The water quality has decreased,
but is safe to drink. The water
purifier will stop soon, see 5.
Contact Bluewater to replace the
membrane.
5 The SERVICE light is on,
and the yellow light on
the faucet is on.
The water purifier has stopped. A
filter replacement has caused air
to come into the system.
Disconnect the water purifier
from power.
Reconnect it. Let the water
purifier do the automatic flush.
The water purifier has stopped.
The clean water quality has
become too low.
Contact Bluewater to replace the
membrane.
6 The SERVICE light
flashes quickly and
the yellow light on the
faucet is on.
The water quality meter does not
function.
Contact your Bluewater dealer.
7The water purifier
makes noise because
the water pressure is not
sucient.
Or
The FILTER light flashes
quickly and the yellow
light on the faucet is on.
The inlet pressure is lower than
1.5 bar during operation.
Contact your Bluewater dealer.
The grid filter is blocked. See Complete User manual
The filter is blocked. See Complete User manual
The low pressure restart function
is active.
See "Low pressure protection" or
Complete User manual
8 The FILTER light and
the SERVICE light flash
quickly and the yellow
light on the faucet is on.
The overflow protection system
is activated.
Disconnect the water purifier
from power, and clean the base
plate. If the overflow protection is
activated again, contact your
Bluewater dealer.
The water purifier does
not start.
The water purifier flushes water. Wait for 5 minutes.
Spirit 300: The faucet
light is not on.
There is a problem with the
electronic faucet.
Contact your Bluewater dealer
The faucet cable is not
connected.
Make sure that the faucet cable
and connector are connected.

14
Owner’s manual
Symptom Cause Solution
The flow rate from the
clean water faucet is
low.
The water purifier needs to be
descaled.
See Complete User manual.
The clean water hose is
tensioned or jammed.
Make sure that the clean water
hose can move freely.
Water does not flow
from the clean water
faucet.
The feed water shut-o valve is
closed.
Open the feed water shut-o
valve.
The water smells bad. Microbial growth in the water
because the water purifier has
not been used for a week or
longer.
See Complete User manual.

BLUEWATER
Danderydsgatan 11
SE-114 26 Stockholm
Sweden
E: [e-mail]
www.bluewatergroup.com
Bluewater is a world leading water purification company.
Headquartered in Stockholm, Sweden, the company
helps people and businesses globally enjoy the health
and wellbeing benefits of cleaner, healthier tap water.
Bluewater innovates, makes and sells compact water
purifiers that harness the company’s patented reverse
osmosis technology to remove virtually all pollutants
from tap water, including lead, bacteria, pesticides,
medical residues, chlorine and lime-scale.
Please visit us at www.bluewatergroup.com
Document No 822901693 Revision 1909. © Bluewater Group 2019
