ASSEMBLY INSTURCTIONS for e-KLAVIER 1
ATTENTION!
Please assemble the piano on a level oor. All parts must be assembled in the correct
order. Use only the original parts (screws, brackets, etc.)
Using the wrong parts or screws can cause damage to the Blüthner e-Klavier 1. For
optimal setup, two people are required to assemble to Blüthner e-Klavier 1. It is
recommended that you ensure all the assembly parts are accounted for and prepared in
their proper quantity, as listed below, before beginning the assembly process.
WARNING!
Please read the attached installation and assembly instructions carefully, which
describes the precise assembly of the instrument. Failure to observe the instructions in
the installation chapter of this manual may cause damage or even injury.
LIST OF ASSEMBLY PARTS:
4 - wooden dowels 6 x 35 mm (Part No. SPN 01627)
2 - countersunk screws 5 x 70 mm (Part No. SPN 210175070)
4 - wooden dowels 8 x 30 mm (Part No. SPN 01631)
4 - socket head screws M6 x 50 mm (Part No. 00656 - black; 00657 - white)
6 - countersunk screws 4 x 30 mm (Part No. VIT 00587 - black; VIT 00588 - white)
6 - round head screws 3,9 x 13,5mm (Part No. 250990018 - black; 250990017 - white)
4 - countersunk screws M4 x 20 mm (Part No. VIT 00586 - black; VIT 00535 - white)
8 - socket head screws M6 x 50 mm (Part No. VIT 00656 - black; VIT 00657 - white)
2 - metal corner brackets (Part No. STF00200 - black; STF00201 - white)
1 - allen wrench (Part. No. 394000142)

lüthner e-Klavier Made in Germany
lüthner
e
-Klavi
er 1
Seite 3
Montage- /Aufbauanleitung
1
1. Insert two (2) wood dowels, each 6x35 mm (Part. No. SPN 01627) into the pre-
drilled holes in the bottom of the lower column.
2. Fasten the lower column to the base, inserting one (1) countersunk screw, 5 x
70 mm (Part. No. SPN 210175070) through the bottom of the cabinet foot. Use the
enclosed allen wrench (Part. No. 394000142).
3. Insert two (2) wood dowels, 8 x 30 mm (Part No. SPN 01631) in the pre-drilled
holes on the side cabinet.

lüthner e-Klavier
Montage- /Aufbausanleitung
Made in Germany
lüthner
e
-Klavier
1
Seite 4
1
4. Screw the two (2) pre-assembled side panels into the connecting base board with
two socket head screws on each side, M6 x 50 mm (Black Cabinet: Part. No. VIT
00656, White Cabinet: Part. No. VIT 00657).

lüthner e-Klavier Made in Germany
lüthner
e
-Klavi
er 1
Seite 5
Montage- /Aufbauanleitung
1
5. Screw the back panel between the side panels to the base board with six (6)
countersunk screws, 4 x 30 mm (Black Cabinet Part. No. VIT 00587, White Cabinet:
Part. No. VIT 00588).

lüthner e-Klavier
Montage- /Aufbausanleitung
Made in Germany
lüthner
e
-Klavier
1
Seite 6
1
6. Screw the metal corner brackets (Black Cabinet: Part. No. STF00200, White
Cabinet: Part. No. STF00201) along the inside of the side panels with three (3) round
head screws, 3,9 mm x 13, 5mm (Black Cabinet: Part. No. 250990018, White Cabinet
Part. No. 250990017).
7. From the rear of the back panel, insert two (2) countersunk screws, M4 x 20 mm
(Black Cabinet: Part. No. VIT 00586, White Cabinet: Part. No. VIT 00535), through to
the metal corner brackets placed in Step 6.

lüthner e-Klavier Made in Germany
lüthner
e
-Klavi
er 1
Seite 7
Montage- /Aufbauanleitung
1
8. Place the entire top piano case onto the wooden dowels atop the front columns,
inserting the dowels into the dowel holes found along the underside of the piano case.
9. Screw the four (4) socket head screws, M6 x 50 mm (Black Cabinet: Part No. VIT
00656, White Cabinet: Part No. VIT 00657), through each side panel and into the
piano case.

lüthner e-Klavier
Montage- /Aufbausanleitung
Made in Germany
lüthner
e
-Klavier
1
Seite 8
1
10. Plug the pedal cable into the socket beneath the keybed.
11. Plug the power cord in… and you are ready to play!
