BNC SAMpack 120-D User manual

SAMpack 120-D
Spectroscopic Radiation Detection Backpack
User Manual
Berkeley Nucleonics Corporation, 2955 Kerner Blvd., San Rafael, CA 94901
Phone: [phone], Fax: [phone], [email protected], www.berkeleynucleonics.com

Manual revised June 2018
PeakAbout III for SAMpack120-D software version 1.0.6
Printed in U.S.A.
WARRANTY
Berkeley Nucleonics Corporation warrants all instruments, including component parts, to be free from
defects in material and workmanship, under normal use and service for a period of 12 months after delivery
to the original buyer only. If repairs are required during the warranty period, contact the factory for
component replacement or shipping instructions. Include the serial number of the instrument. This warranty
is void if the unit is repaired or altered by others than those authorized by Berkeley Nucleonics Corporation.
IMPORTANT! PLEASE READ CAREFULLY
NOTIFICATION OF COPYRIGHT
THE SOFTWARE IN THIS DEVICE IS PROTECTED BY COPYRIGHT LAWS AND INTERNATIONAL
TREATY. YOU MUST TREAT THE SOFTWARE LIKE ANY OTHER COPYRIGHTED MATERIAL.
COPYRIGHT LAWS PROHIBIT MAKING ADDITIONAL COPIES OF THE SOFTWARE FOR ANY
REASON OTHER THAN SPECIFICALLY DESCRIBED BELOW. YOU MAY NOT COPY THE WRITTEN
MATERIALS ACCOMPANYING THE PRODUCT.

SAMpack 120-D User Manual Page i SW Ver 1.0.6
User Manual
SAMpack 120-DTM
Spectroscopic Radiation Detection Backpack
CHAPTER 1. INTRODUCTION ....................................................................................................................1
1.1 Functional Description...................................................................................................................1
1.2Important Safety Information.........................................................................................................2
CHAPTER 2. SAFETY..................................................................................................................................3
2.1 Safety Warnings and Instructions .................................................................................................3
2.2 Classification.................................................................................................................................4
2.3 Labels............................................................................................................................................4
CHAPTER 3. SYSTEM DESCRIPTION........................................................................................................5
3.1 System Components.....................................................................................................................5
3.2 SAMpack 120-D Software.............................................................................................................5
3.3 Power and Battery Charger...........................................................................................................6
3.4 Before Operating the SAMpack 120-D .........................................................................................6
CHAPTER 4. PEAKABOUT III APPLICATION.................................................................................................7
4.1 Overview .......................................................................................................................................7
4.2 Navigating the PeakAbout III GUI.................................................................................................7
4.2.1 Gauge Screen ...........................................................................................................................7
4.2.2 Menu Structure for Radiation Monitoring ..................................................................................8
4.2.3 Menu Structure for Event Log and Device Setup......................................................................9
4.3 Basic Operating Instructions.......................................................................................................10
4.3.1 Prepare Equipment for Operation...........................................................................................10
4.3.2 Auto Calibration.......................................................................................................................11
4.3.3 Perform Background Measurement........................................................................................12
4.3.4 Perform Manual Calibration (Optional)....................................................................................13
4.3.5 Begin Monitoring Radiation.....................................................................................................14
4.3.6 When the SAMpack 120-D Has Alarmed................................................................................15
4.3.6.1 Radiation Directionality ...................................................................................................15
4.3.6.2 Range Finder...................................................................................................................17
4.3.7 Perform Manual ID..................................................................................................................17
4.3.8 Transmit Event Data to Reach-back.......................................................................................22
4.3.9 Transmit Event Data to RadResponder..................................................................................23
4.3.10 Attach Media Immediately After an Event...........................................................................24

SAMpack 120-D User Manual Page ii SW Ver 1.0.6
4.4 Operating Instructions: Event Log and Setup Menus .................................................................26
4.4.1 Use the Event Log to Access Event Data...............................................................................26
4.4.2 Use the Event Log to Transmit Event Data to Reach-back ....................................................29
4.4.2.1 Save Event Log File as N42.24 XML..............................................................................30
4.4.3 Use the Event Log to Transmit Event Data to the RadResponder Network...........................30
4.4.4 Use the Setup Menu for User Settings....................................................................................32
4.4.4.1 Enter User Name and Search Location ..........................................................................32
4.4.4.2 Select Alarm Ringtone ....................................................................................................33
4.4.4.3 Perform Background and Calibration..............................................................................33
4.4.4.4 Device Information ..........................................................................................................34
4.4.4.5 Password.........................................................................................................................35
4.4.5 Use the Setup Menu for Administrator Settings......................................................................36
4.4.5.1 Select Alarm Mode and Alarm Threshold .......................................................................36
4.4.5.2 Select Neutron Threshold ...............................................................................................37
4.4.5.3 Select Health Safety Threshold.......................................................................................38
4.4.5.4 Discrimination..................................................................................................................39
4.4.5.5Background Measurement Time.....................................................................................39
4.4.5.6 Calibration Measurement Count .....................................................................................39
4.4.5.7 Manual Identification Measurement Time.......................................................................40
4.4.5.8 Manual Identification Adjustment Time...........................................................................41
4.4.5.9 Isotope Library List..........................................................................................................41
4.4.5.10 Dose Rate Measurement Unit.........................................................................................42
4.4.5.11 Email Account .................................................................................................................43
4.4.5.12 Sequential Mode .............................................................................................................44
4.4.5.13 RadResponder Mode......................................................................................................46
4.4.5.14 SAMpack 120-D Connect Mode......................................................................................47
4.4.5.15 Select Password..............................................................................................................47
4.4.5.16 Restore Factory Hardware Configuration .......................................................................48
4.5 Upgrading PeakAbout III.............................................................................................................48
CHAPTER 5. PEAKID APPLICATION .........................................................................................................51
5.1 Connecting the SAMpack 120-D to a PC....................................................................................51
5.2 Installing PeakID .........................................................................................................................51
5.3 Navigating the GUI......................................................................................................................52
5.3.1 Spectrum Display Options.......................................................................................................53
5.4 Loading and Analyzing Event Data.............................................................................................54
5.4.1 Download Event Data from the SAMpack 120-D PDA to the PC ...........................................54
5.4.2 Load Event Data from the PC Database.................................................................................55
5.5 Managing the Isotope Library......................................................................................................56

SAMpack 120-D User Manual Page iii SW Ver 1.0.6
5.6 Saving Event Data in XML Format (ANSI 42.42)........................................................................57
5.7 Printing Event Data .....................................................................................................................58
5.8 Upgrading PeakID.......................................................................................................................59
CHAPTER 6. USEFUL TIPS AND REMINDERS .......................................................................................61
SPECIFICATIONS ......................................................................................................................................62

SAMpack 120-D User Manual Page 1 SW Ver 1.0.6
CHAPTER 1. INTRODUCTION
1.1 Functional Description
The SAMpack 120-D Spectroscopic Radiation Detection Backpack is engineered to meet ANSI42.34 performance
criteria for handheld instruments for the detection and identification of radionuclides. Its lightweight, portable design
makes it ideal for covert search, detection, and identificationwith high sensitivity as well as many types of radiological
surveys, including the most demanding applications, such as evaluation of radiation hazards by Homeland Security
and first responders.
The SAMpack 120-D replaces traditional instruments with a patented solution that seamlessly integrates smartphone
orPDA(personaldigitalassistant),ortabletPCtechnologywithnuclearradiationdetectors.ThestandardPDAincluded
with the SAMpack 120-D is the Samsung Galaxy J5.
The SAMpack 120-D is designed to accommodate two 2 x 2-inch scintillation detectors in orderto provide the highest
sensitivity,generalpurposeisotopeidentification,and 24 solid-stateneutrondetectors(2x2 cm2with 30% neutronQE)
High resolution detector options are available. Optionally, the system can also include a GM tube and/or a neutron
detector. In the standard configuration, the detector and electronics are encased in a water and shock-resistant
reinforced case fitted in a small, camouflage backpack (Figure 1.1). Shoulder pack, stationary, and custom
configurations are available as well.
The detector forwards data to the PDA via cabled USB (or Bluetooth). The PDA provides an easy-to-read display,
informing the user of the identity and levels of radionuclides present while helping to ensure personal safety. The
SAMpack 120-D can also use the PDA’s locator services to continuously transmit GPS locations for mapping of
radiation data. Upon completion of a survey, data maybe downloaded from the PDA to a PC.
Figure 1.1. SAMpack120-D Spectroscopic Radiation Detection Backpack
(including optional GM tube and neutron detector)

SAMpack 120-D User Manual Page 2 SW Ver 1.0.6
1.2 Important Safety Information
The SAMpack 120-D has been meticulously engineered toprovide safe, dependable, high performance for years. As
with any kind of electrical equipment, following instructions and taking basic precautions will prevent harm to the
operator and to the equipment.
Prior to using this equipmentyou should:
Read and understand this manual thoroughly, especially the chapter on safety (Chapter 2)
Read and understand thoroughly all warning labelson the equipment.
Store all documents providedwith the equipment in a safe place for future reference.

SAMpack 120-D User Manual Page 3 SW Ver 1.0.6
CHAPTER 2. SAFETY
2.1 Safety Warnings and Instructions
Following the warnings and instructions on this page is crucial to the safe and optimal operation of the SAMpack 120-
D.
Maintenance and Service:
If service is required while the unit is under warranty, contact the factory. Any repairs or alterations should
only be performed by technicians who areauthorizedby BerkeleyNucleonics Corporation.
Do not attempt toopen the unit. Opening the unit may void your warranty (see inside frontcover).
Safety Hazard:
High voltage inside the unit (up to 1000volts) presents a safety hazard. Do not attempt to open the unit.
Refer to the maintenance andservice instructions immediately above.
Disposal:
It is the responsibility ofthe operator tobe familiar with local,regional, and national regulations for handling,
shipping, and disposal of electronic equipment and lithium-ion batteries.
Do not household or municipalwaste collection services for disposal of electrical and electronic equipment.
Compatibility:
It is the responsibility of the operator to ensure that external equipment intended for connection to signal
input, signal output, or other connectors shall comply with the relevant European Standards (e.g.,
EN 61326-1:2006, EN 301 489-1 V1.9.2, and EN 301 489-17 V2.2.1).
If in doubt about the compatibility of a device, contact a technician authorized by Berkeley Nucleonics
Corporation.
SAMpack 120-D CONTAINS FCC ID: U8D-FB155BC-F
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operations.

SAMpack 120-D User Manual Page 4 SW Ver 1.0.6
2.2 Classification
EMC: Complies with EN 61326-1:2006, EN 301 489-1 V1.9.2, and EN 301 489-17 V2.2.1)
FCC Class: Class B Equipment (FCC CFR 47, part 15 subpart B, Section15.101)
Degree of protection against electric shock: Type BF Applied Part
Degree of protection againstthe ingress of water: IP65
Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or
nitrous oxide
2.3 Labels
The label showing the system power requirements and serial number (BSN, lower right corner) is located on the side
of the unit (Figure 2.1).
Figure 2.1. SAMpack 120-D label
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the user
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at own expense.
WARNING
Any changes or modifications not expressly approved by the manufacturer could void the user’s authority
to operate the equipment.

SAMpack 120-D User Manual Page 5 SW Ver 1.0.6
CHAPTER 3. SYSTEM DESCRIPTION
3.1 System Components
The SAMpack 120-D physically consists of a detector unit, aPDA (Samsung Galaxy J5 or equivalent), AC and vehicle
power adapter/chargers for the detector unit (one AC to 12V DC, and one 12V vehicle adapter/charger), a USB-to-
microUSB cable, an unmarked backpack, and a water- and shock-resistant carrying case (Figure 3.1). The two
software programsused with the SAMpack 120-D are described in Section 3.2.
Figure 3.1. SAMpack 120-D components
3.2 SAMpack 120-D Software
The SAMpack 120-D includes two dedicatedsoftware programs forconducting surveys andanalyzing results.
SAM III PeakAbout III for the PDA:
PeakAbout III is used for configuring and calibrating the system, and for real-time measurement and analysis
ofdataacquiredbythedetectorunit.ItisbasedontheAndroidoperatingsystemandworkswiththeSamsung
Galaxy J5 as well as many other PDAs that run Android.
PDAs shipped from Berkeley Nucleonics Corporation already have the current version of PeakAbout III
installed (in addition to the manufacturer’s software). Detailed instructions for operating PeakAbout III are in
Chapter 4.
SAM III PeakID for the PC:
PeakID supports management of Event Log files, data analysis including integration of data from multiple
units, and data backup. It is compatible with PCs that run Windows 7 or higher.
Detailed instructions forinstalling and operating PeakIDare in Chapter 5.

Please contact Berkeley Nucleonics for the full User Manual
Berkeley Nucleonics Corporation
[email protected] | www.berkeleynucleonics.com
2955 Kerner Blvd, San Rafael, CA 94901 | 800-234-7858
