SICK GM700 Ex User manual

OPERATING INSTRUCTIONS
GM700 Ex
Laser Gas Analyzer,
Version with Measuring Probe

Described product
GM700 Ex
Probe version
Version GM700-05, GM700-09
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Production location
SICK AG
Nimburger Str. 11 · D-79276 Reute · Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is only
permissible within the limits of the legal determination of Copyright Law. Any modifica‐
tion, abridgment or translation of this document is prohibited without the express writ‐
ten permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 7
1.1 Function of this document....................................................................... 7
1.2 Scope of application................................................................................. 7
1.3 Target groups (and document structure)................................................. 7
1.4 Further information................................................................................... 7
1.5 Data integrity............................................................................................. 7
1.6 Symbols and document conventions...................................................... 8
1.6.1 Warning symbols...................................................................... 8
1.6.2 Warning levels / Signal words................................................. 8
1.6.3 Information symbols................................................................ 9
2 Safety information............................................................................ 10
2.1 Main operating information..................................................................... 10
2.2 Warning information on the device.......................................................... 13
2.3 Intended use............................................................................................. 14
2.3.1 Purpose of the device.............................................................. 14
2.4 Responsibility of user............................................................................... 14
3 Product description........................................................................... 16
3.1 Product identification............................................................................... 16
3.2 Product characteristics............................................................................ 16
3.3 Type plate.................................................................................................. 16
3.4 Device variants......................................................................................... 17
3.5 Pressure and temperature sensor........................................................... 17
3.6 Options...................................................................................................... 17
3.7 Layout and function.................................................................................. 17
3.7.1 Function of the pressurized enclosure................................... 18
3.8 Purge air unit............................................................................................. 18
3.9 Check cycle............................................................................................... 19
3.10 Explosion protection in accordance with ATEX....................................... 20
3.10.1 Operation in potentially explosive atmosphere...................... 20
3.10.2 Zone of use GM700 Ex 3G components................................ 21
3.10.3 Pressurized enclosure system................................................ 22
3.10.3.1 Safety functions...................................................... 22
3.11 Sender/receiver unit - evaluation unit connecting hose........................ 22
3.12 GMP measuring probe in detail............................................................... 23
4 Transport and storage....................................................................... 24
4.1 Transport protection................................................................................. 24
4.2 Storage...................................................................................................... 25
5 Mounting............................................................................................. 26
5.1 Information on installation in potentially explosive atmospheres......... 26
5.2 Tools required............................................................................................ 27
CONTENTS
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 3
Subject to change without notice

5.3 Material required...................................................................................... 27
5.4 Preparing the sampling point................................................................... 27
5.5 GM700 Ex scope of delivery.................................................................... 28
5.6 Installation sequence............................................................................... 28
5.6.1 Installation example................................................................ 28
5.6.2 Overview of installation steps (duct-side preparation).......... 29
5.6.3 Installing the flange with tube................................................. 29
5.6.4 Install the evaluation unit........................................................ 31
5.6.4.1 Install the FS840.................................................... 31
5.6.5 Installing the purge air unit..................................................... 33
6 Electrical installation........................................................................ 34
6.1 Electrical installation safety information................................................. 34
6.2 Connection overview................................................................................ 36
6.2.1 Lines......................................................................................... 37
6.3 Connecting interfaces ............................................................................. 38
6.3.1 Connect I/O interfaces............................................................ 38
6.3.1.1 GM700 Ex 3G terminal connection diagram........ 38
6.3.1.2 Electrical connection of the evaluation unit EvU.. 40
6.4 Connecting the connecting hose to the SR-unit on the EvU.................. 41
6.5 Connecting pressure, temperature and purge air monitor ................... 41
6.6 Preparing the power supply...................................................................... 41
6.7 Connecting the FS840 Ex overpressure control..................................... 42
6.8 Electrical connection of SR-unit............................................................... 44
6.9 Connecting the potential equalization..................................................... 44
6.9.1 Connecting the potential equalization on the SR-unit........... 45
6.9.2 Connecting the potential equalization on the measuring
probe........................................................................................ 45
6.9.3 Potential equalization - evaluation unit and Ex control unit.. 46
7 Commissioning.................................................................................. 47
7.1 Safety information on commissioning..................................................... 47
7.2 Prerequisites for successful commissioning.......................................... 47
7.3 Material required ..................................................................................... 48
7.4 Overview of commissioning steps........................................................... 48
7.5 Zero adjust................................................................................................ 49
7.6 Fitting the SR-unit on the measuring probe............................................ 49
7.7 Aligning the measuring probe in flow direction...................................... 51
7.8 Feeding protective gas............................................................................. 52
7.8.1 Connecting the protective gas on the SR-unit....................... 52
7.8.2 Switch the pressurized enclosure on...................................... 54
7.9 Optical fine alignment of the sender/receiver unit ............................... 54
7.10 Installing the weatherproof cover ........................................................... 55
7.11 Starting measuring operation.................................................................. 56
7.11.1 Operating states...................................................................... 57
7.11.2 Select the ambient temperature range.................................. 57
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

8 Operation............................................................................................ 58
8.1 Safety......................................................................................................... 58
8.1.1 Check before commissioning.................................................. 58
8.2 Operating and display elements (evaluation unit).................................. 58
8.2.1 Function buttons...................................................................... 59
8.3 Menu tree of the evaluation unit............................................................. 60
8.3.1 Menu tree Measuring.............................................................. 60
8.3.2 Menu tree Diagnosis............................................................... 60
8.3.3 Menu tree Parameter.............................................................. 61
8.3.4 Menu tree Calibration.............................................................. 63
8.3.5 Menu tree Maintenance.......................................................... 63
8.4 Operating using the serial interface........................................................ 64
8.4.1 Significance of command line elements................................ 64
8.4.2 Setting for serial interfaces..................................................... 64
8.4.3 Serial interface command - MEAS ......................................... 64
8.4.4 Serial interface commands - Diag.......................................... 65
8.4.4.1 Table with warning messages................................ 65
8.4.4.2 Call up the Table with error messages.................. 65
8.4.4.3 View the device configuration................................ 65
8.4.4.4 Check the system state and configuration........... 65
8.4.4.5 Call up diagnostic data........................................... 65
8.5 Setting the display contrast..................................................................... 65
9 Maintenance...................................................................................... 67
9.1 Safety......................................................................................................... 67
9.2 Maintenance plan..................................................................................... 69
9.2.1 Expendable, wearing and spare parts.................................... 70
9.3 Preparatory work....................................................................................... 70
9.4 Function test of the pressurized enclosure system................................ 70
9.4.1 Maintenance work on the FS840........................................... 71
9.4.2 Repair work on the FS840...................................................... 71
9.5 Removing the sender/receiver unit......................................................... 71
9.6 Visual check of the sender/receiver unit and evaluation unit............... 72
9.7 Cleaning the optical interfaces................................................................ 73
9.8 Etalon tool................................................................................................. 74
9.9 Filter box measurement to check the measuring channels (for dry
gases)........................................................................................................ 75
9.10 Checking the evaluation unit................................................................... 77
9.11 Cleaning the purge air unit....................................................................... 78
10 Troubleshooting................................................................................. 79
10.1 Safety......................................................................................................... 79
10.2 Monitoring and diagnostic system........................................................... 80
10.3 Device not functioning.............................................................................. 81
10.4 Evaluation unit not functioning................................................................ 81
10.4.1 Communication fault between evaluation unit and receiver 82
CONTENTS
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 5
Subject to change without notice

10.5 Ex operation malfunction......................................................................... 82
10.6 Error messages......................................................................................... 82
10.6.1 Error messages........................................................................ 82
10.6.2 Warning messages.................................................................. 84
10.7 Repairing inadequate purge air supply................................................... 85
10.8 Corrosion on flange.................................................................................. 85
11 Decommissioning............................................................................. 86
11.1 Safety information for decommissioning................................................ 86
11.2 Decommissioning Ex-relevant subassemblies....................................... 87
11.3 Removing the device................................................................................ 87
11.4 Preparing the device ready for shipping.................................................. 88
11.5 Environmentally compatible disposal ..................................................... 89
12 Technical data.................................................................................... 90
12.1 System: GM700 Ex version 3G / zone 2................................................. 90
12.2 Sender/receiver unit................................................................................ 90
12.3 Measuring probe....................................................................................... 91
12.4 Evaluation unit Ex version I/O module.................................................... 91
12.5 Technical data for pressurized enclosure system................................... 92
12.5.1 Technical data energy supply.................................................. 92
12.5.2 Limit values for terminal assignment FS840......................... 92
12.5.3 Technical data for Protective gas............................................ 92
12.5.4 Technical data for enclosure................................................... 92
12.5.5 Pressurized enclosure system settings.................................. 92
12.6 Dimension drawings: Sender/receiver unit............................................ 94
12.7 Dimension drawings: Open measuring probe (GMP)............................. 95
12.8 Dimension drawing, purge air unit........................................................... 96
12.9 Dimension drawings, evaluation unit with pressurized enclosure sys‐
tem FS840................................................................................................ 97
12.10 Dimension drawings: Mounting flange DN125....................................... 97
12.11 Dimension drawing, weatherproof cover, sender/receiver unit............. 98
13 Annex.................................................................................................. 99
13.1 Conformities.............................................................................................. 99
13.2 Electrical protection.................................................................................. 99
13.3 Ex certifications........................................................................................ 99
13.4 Possible ambient temperatures............................................................... 99
13.4.1 Ambient temperature ranges.................................................. 99
CONTENTS
6O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

1 About this document
1.1 Function of this document
These Operating Instructions describe:
•Device components
•Installation
•Operation
•Maintenance work required for reliable operation
1.2 Scope of application
These Operating Instructions are only applicable for the measuring device described in
the product identification.
They are not applicable for other SICK measuring devices.
The standards referred to in these Operating Instructions are to be observed in the
respective valid version.
1.3 Target groups (and document structure)
This Manual is intended for persons installing, operating and maintaining the device.
Operation
The device may only be operated by qualified persons who, based on their device-spe‐
cific training and knowledge as well as knowledge of the relevant regulations, can
assess the tasks given and recognize the hazards involved.
Installation and maintenance
Skilled persons are required for installation and maintenance.
Please observe the information at the beginning of the respective Sections.
1.4 Further information
•Operating Instructions of the purge air supply
•Final inspection record
3G / Zone 2
•Manual, Pressurized enclosure FS840 and purge medium valve
NOTE
bObserve all supplied documents.
1.5 Data integrity
SICK AG uses standardized data interfaces such as, for example, standard IP technol‐
ogy, in its products. The focus here is on product availability and features.
SICK AG always assumes that the customer is responsible for the integrity and confi‐
dentiality of data and rights involved in connection with using the products.
In all cases, the customer is responsible for the implementation of safety measures
suitable for the respective situation, e.g., network separation, firewalls, virus protection
and patch management.
ABOUT THIS DOCUMENT 1
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 7
Subject to change without notice

1.6 Symbols and document conventions
1.6.1 Warning symbols
Table 1: Warning symbols
Symbol Meaning
Hazard (general)
Hazard by voltage
Hazard in potentially explosive atmospheres
Hazard by explosive substances
Hazard by inflammable substances
Hazard by oxidizing substances
Hazard by laser radiation
Hazard by toxic substances
Hazard by noxious substances
Hazard by high temperature
Hazard for the environment/nature/organic life
1.6.2 Warning levels / Signal words
DANGER
Risk or hazardous situation which will result in severe personal injury or death.
WARNING
Risk or hazardous situation which could result in severe personal injury or death.
CAUTION
Hazard or unsafe practice which could result in less severe or minor injuries.
Notice
Hazard which could result in property damage.
Note
Hints
1 ABOUT THIS DOCUMENT
8O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

1.6.3 Information symbols
Table 2: Information symbols
Symbol Significance
Information on consistency of the product relative to Guideline 2014/34/EU (ATEX)
Important technical information for this product
Important information on electric or electronic functions
ABOUT THIS DOCUMENT 1
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 9
Subject to change without notice

2 Safety information
2.1 Main operating information
Work on the device
WARNING
Risk of explosion
Work on the device assumes an Ex free zone at the installation location otherwise there
is an explosion risk.
bEnsure the work area is Ex free when working on the device.
WARNING
Injury risk through incorrect lifting and carrying of the device
Injuries can occur due to the weight and projecting enclosure parts when the equip‐
ment tips over or drops.
bConsider the device weight before lifting.
bObserve the regulations for protective clothing (e.g., safety shoes, non-slip gloves).
bGrip underneath the equipment when possible to carry it safely.
bDo not use projecting parts on the device to carry the device.
bCall in further personnel for assistance as required.
bUse a hoist or transport equipment as an option.
bPay attention to the transport safety device.
bClear obstacles that could cause falls and collisions out of the way.
DANGER
Risk for system safety through work on the device not described in these Operating
Instructions
Carrying out work on the device not described in these Operating Instructions or associ‐
ated documents can lead to unsafe operation of the measuring system and therefore
endanger plant safety.
bOnly carry out the work on the device described in these Operating Instructions
and associated documents.
DANGER
Risk of explosion through incorrect performance of maintenance work
Incorrect performance of maintenance work in potentially explosive atmospheres can
cause serious injuries to people and damage during operation.
•Maintenance and commissioning tasks as well as checks should only be carried
out by experienced/trained personnel with knowledge of the rules and regulations
for potentially explosive atmospheres, especially:
– Ignition protection types
– Installation procedures
– Zone classification
•Standards to be applied:
– IEC 60079‑14, Annex F: Knowledge, expertise and competence of responsi‐
ble persons, craftsmen and designers
– IEC 60079-17: Electrical installations inspection and maintenance
– IEC 60079-19: Equipment repair, overhaul and reclamation
2 SAFETY INFORMATION
10 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

Laser radiation
WARNING
Eye injuries through laser radiation
The invisible laser beam within the SR-unit is not accessible when fitted. Observe the
following when the SR-unit of the device is swiveled open during installation work for
test purposes and the laser beam is activated:
bNever look directly into the laser aperture when opening the SR-unit.
bLaser protection class 1: Wear laser protection glasses despite low radiation.
bObserve national valid limit values and standards that refer to these for industrial
safety.
Escaping hot gas
DANGER
Risk of fire through hot gas escaping in installations with overpressure conditions
On installations with overpressure, the purge air hose can be severely damaged by
escaping hot gas and can catch fire depending on the temperature. On installations
with overpressure as well as gas temperatures over 200°C:
bRegularly check the functionality of the reverse flow safeguard fitted in the mea‐
suring probe.
DANGER
Danger to life by leaking hot/toxic gases
Hot and/or noxious gases can escape during work on the gas duct, depending on the
plant conditions.
bWork on the gas duct may only be performed by skilled technicians who, based on
their technical training and knowledge as well as knowledge of the relevant regula‐
tions, can assess the tasks given and recognize the hazards involved.
Electrical safety
WARNING
Endangerment of electrical safety during installation and maintenance work when the
power supply is not switched off
An electrical accident can occur during installation and maintenance work when the
power supply to the device and/or lines is not switched off using a power isolating
switch/circuit breaker.
bBefore starting the work, ensure the power supply can be switched off using a
power isolating switch/circuit breaker in accordance with DIN EN 61010.
bMake sure the power isolating switch is easily accessible.
bAn additional separation device is mandatory when the power isolating switch can‐
not be accessed or only with difficulty after installation of the device connection.
bThe power supply may only be switched on again after work completion or for test
purposes by the persons carrying out the work under consideration of the valid
safety regulations.
SAFETY INFORMATION 2
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 11
Subject to change without notice

DANGER
Endangerment of electrical safety through missing power isolating switch
An electrical accident can occur during installation and maintenance work when the
power supply to the device and/or lines cannot be switched off using a power isolating
switch/circuit breaker.
bEnsure the power supply can be switched off using a power isolating switch/circuit
breaker in accordance with DIN EN 61010-1:2010.
bAn additional disconnecting device is mandatory when the disconnector switch is
difficult to access or cannot be accessed when connecting the equipment after
installation.
WARNING
Endangerment of electrical safety through power cables with incorrect rating
Electrical accidents can occur when the specifications for replacement of a removable
power cable have not been adequately observed.
bAlways observe the exact specifications in the Operating Instructions (Technical
Data Chapter) when replacing a removable power line.
Contamination of device through purge air failure
CAUTION
A faulty purge air supply can damage the measuring system
The measuring system can no longer be protected from contaminated sample gas and
is damaged.
bWhen the purge air supply appears faulty, immediately perform all actions
described in these Operating Instructions.
Responsibility for the safety of a system
ATTENTION
Responsibility for the safety of a system
The person setting the system up is responsible for the safety of the system in which
the device is integrated.
2 SAFETY INFORMATION
12 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

2.2 Warning information on the device
S/R unit
1
1
2 2
Figure 1: Warning information on the sender/receiver unit
SR-unit, front side
1 Danger sign: Laser radiation
2 Type plate GM700 Ex
SR-unit, right side
1 Danger sign: Laser radiation
2 Type plate GM700 Ex
Figure 2: Laser symbol on device
SAFETY INFORMATION 2
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 13
Subject to change without notice

GM 700 Ex evaluation unit
2
134
Figure 3: Warning information on the EvU GMA700 front and right sides
1Protective gas warning
•Protective gas outlet
•Risk of suffocation when using inert gases
•20 minutes waiting time before opening the enclosure
2General warning: Warning of danger area
3Warning sign: Pull power plug before opening the device
4Type plate
2.3 Intended use
2.3.1 Purpose of the device
The device serves exclusively for emission and process monitoring of gases in industrial
plants.
The device measures continuously directly in the gas duct (in-situ).
2.4 Responsibility of user
NOTICE
Responsibility for the safety of a system
The plant operator may not make any technical changes to the GM700 system. Every
change voids the EU type approval.
Intended users
see "Target groups (and document structure)", page 7.
Correct project planning
•Basis of this Manual is the delivery of the device according to the preceding
project planning (e.g., based on the SICK application questionnaire) and the rele‐
vant delivery state of the device (see delivered System Documentation).
wIf you are not sure whether the device corresponds to the state defined dur‐
ing project planning or to the delivered system documentation: Please con‐
tact SICK Customer Service.
2 SAFETY INFORMATION
14 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

Special local conditions
In addition to the information in these Operating Instructions, follow all local laws, tech‐
nical rules and company-internal operating directives applicable wherever the device is
installed.
Read the Operating Instructions
bRead and observe these Operating Instructions.
bObserve all safety instructions.
bIf anything is not clear: Please contact SICK Customer Service.
Document retention
These Operating Instructions:
bMust be kept for reference.
bMust be passed on to new owners.
SAFETY INFORMATION 2
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 15
Subject to change without notice

3 Product description
3.1 Product identification
Product name GM700 Ex
Device version Measuring Probe Version
Manufacturer SICK AG
Erwin-Sick-Str. 1 · D-79183 Waldkirch · Germany
Type plates •Sender/receiver unit: On right side
•Control unit: On right side
•On measuring probe: On purge air fixture
3.2 Product characteristics
■The device serves for continuous measurement of gas concentrations in industrial
plants
■The device is an in-situ measuring system which means measuring is done directly
in the gas carrying duct
■Measuring components: NH3, NH3 + H2O
■Measuring principle: Diode laser spectroscopy (TDLS)
3.3 Type plate
Sender/receiver unit
01
02
03 04 05
06
07
No. Variable
01 Type code
02 Material number
03 Serial number
04 Min. gas temperature
05 Max. gas temperature
06 QR code
07 Month/year
Evaluation unit and connection unit
01
02
03 04 05
06
07
No. Variable
01 Type code
02 Material number
03 Serial number
04 Min. gas temperature
05 Max. gas temperature
06 QR code
07 Month/year
3 PRODUCT DESCRIPTION
16 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

3.4 Device variants
Sender/receiver unit
Table 3: Type code identification
Variants Measured components
•Ex zone 2: GMM700-0513EX3G NH3
•Ex zone 2: GMM700-0913EX3G NH3 / H2O
Connection unit
Table 4: Type code identification
Version
•Ex zone 2: GMA700-035X EX3G
3.5 Pressure and temperature sensor
A p/T sensor serves to measure pressure and temperature, see "Installation example",
page 28 and page 36.
3.6 Options
•Cover plate for purge air fixture of the sender/receiver unit
•Weatherproof cover
•Purge air unit
3.7 Layout and function
1
8
9
5
3
2
ß
4
67
Figure 4: GM700 Ex layout and function
1Sender/receiver unit GM700-0xxEX3G
2Evaluation unit GM700-035xEX3G
3Ex-p control FS840
4Metallic connecting hose between sender/receiver unit and evaluation unit
5Digital purge medium valve, 230 V, G3/8", 2 mm, Ex-p
PRODUCT DESCRIPTION 3
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 17
Subject to change without notice

6Purge air fixture (without electronics)
7GMP measuring probe (without electronics)
8Temperature and pressure measurement
9Purge air supply
ßPressure switch for purge air monitoring
Function
•The device serves for continuous measurement of gas concentrations in industrial plants
•The device is an in-situ measuring system which means measuring is done directly in the gas carrying duct
•Measuring components: NH3, NH3 + H2O as well as reference values temperature and pressure
•Measuring principle: Diode laser spectroscopy (TDLS) (laser protection class 1)
•To maintain measuring reliability, a permanent air flow (optics purge air) protects and keeps the optics free
from soot and dust particles as well as condensate and moisture condensation
•Ignition protection type “pressurized enclosure” is effective when using the GM700 Ex in Zone 2 potentially
explosive atmospheres. All relevant enclosures of the sender/receiver unit and connection unit connected
together via a pressure-proof metal hose are purged with a protective gas. The protective gas can be air suc‐
tioned in from the non-potentially explosive atmosphere or an inert gas.
3.7.1 Function of the pressurized enclosure
Purpose of the pressurized enclosure
The pressurized enclosure ensures Ex atmosphere cannot enter the device from out‐
side. To this purpose, the gas analyzer enclosure is filled with a protective gas. Apart
from that, it is ensured that the gas pressure inside the gas analyzer enclosure is higher
than the surrounding air pressure.
Functionality during operation
The pressurized enclosure system functions in “leakage compensation” mode: An over‐
pressure is generated in the device in relation to the atmosphere after pre-purging has
completed. If the protective gas pressure sinks below the minimum pressure set, pro‐
tective gas feed is activated until the selected overpressure is reached again.
Safety functions
If the maximum permitted overpressure is exceeded or the maximum permitted under‐
pressure underrun, the Ex control unit switches an alarm contact which must be perma‐
nently evaluated (responsibility of plant operator, see FS840 Pressurized Enclosure
Manual).
3.8 Purge air unit
•The purge air unit must be in an Ex-free area and suction Ex-free purge air
•The purge air unit supplies filtered ambient air to the measuring probe
•This protects the front window of the SR-unit and the reflector in the measuring
probe against contamination and high gas temperatures
•The purge air is blown into the gas duct through the “flange with tube”.
NOTE
Further information on the purge air unit, see Operating Instructions of the purge air
unit.
3 PRODUCT DESCRIPTION
18 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice

3.9 Check cycle
Cyclic check cycle for zero and sensitivity checks
Start a check cycle via
•Timer trigger: Configurable 0 ... 1440 minutes (= 1 day), see menu “Settings /
Check Cycle”
•External digital input signal (Di 1)
Purpose of check cycle
■Checking the zero point and span point without feeding span gases.
Check cycle procedure
The measuring sequence to determine the zero and check point is performed. The digi‐
tal input uses a falling edge for triggering, i.e. performance of a check cycle is sup‐
pressed as long as the signal is high (e.g., for control purposes).
Signaling
“Function control” (relay 3) is signaled per digital output during output of the zero and
check point.
Output
The output runs for 90 seconds each for the zero point followed by the check point.
•Unit and scaling for the current zero point according to the settings.
•Check or span point is displayed as percentage scaled to 70% of the measuring
range.
The same calculation method is used for the deviation as for the gas concentration with
the exception of correction factors which result from a gas adjustment as well as cus‐
tomer correction factors from menu PAR/SETTINGS / REGRESS. FUNCT. During the
check cycle output, the zero and span point are displayed in the lower display line paral‐
lel to the analog output. These can be viewed in menu DIAG/CHECK VALUES/<GAS> for
subsequent checks. Prerequisite is that the output has already been made via an ana‐
log output.
Deviations
A warning message is output, e.g., “AO1 NH3 ZEROPoint” when the zero or check point
deviation is above 2% of the upper display limit of an analog output.
The warning message remains until the next check cycle output is within the tolerance.
PRODUCT DESCRIPTION 3
8019532/100Q/V1-1/2018-08 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 19
Subject to change without notice

3.10 Explosion protection in accordance with ATEX
3.10.1 Operation in potentially explosive atmosphere
3G / Zone 2: Connection unit and sender/receiver unit
The GM700 Ex complies with ATEX Directive 2014/34/EU with the
following characteristics:
•X II 3/-G Ex pzc op is [ia] IIC T4 Gc/-
•Special conditions (X identification):
°A measuring function for explosion protection is not part of the
EC type approval
•Explosion protection relating to optical radiation in the measuring
channel
The explosion protection relating to optical radiation in the measur‐
ing channel is satisfied in accordance with the temperature range
(-20°... +60 °C) specified by ATX/IECEx. The plant operator must
evaluate Ex atmospheres possibly present for exhaust gas temper‐
atures exceeding this range separately and take suitable protective
measures!
wLocation of Ex relevant subassemblies, see Chapter “Design
and Function”.
wDo not remove, add or modify any components to or on the
device unless described and specified in the official manufac‐
turer information. Otherwise the approval for the device for
use in potentially explosive atmospheres becomes void.
wAdhere to the maintenance intervals, see Chapter “Mainte‐
nance plan”.
wAfter switching off the main power supply: Wait 20 minutes
before opening the enclosure.
3 PRODUCT DESCRIPTION
20 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019532/100Q/V1-1/2018-08 | SICK
Subject to change without notice
