OWNER'S MANUAL
DLAT.1

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-042007 1.1
HARDWARE ILLUSTRATION
(A1)HEX BOLT 1/2"x1 1/4"L PARTIAL THREAD QTY.2
(A2)HEX BOLT 1/2"x2"L PARTIAL THREAD QTY.2
(A3)HEX BOLT 1/2"x3 1/4"L PARTIAL THREAD QTY.1
(A4)HEX BOLT 1/2"x4 1/4"L PARTIAL THREAD QTY.2
(A5)HEX BOLT 1/2"x5 1/2"L PARTIAL THREAD QTY.3
2
13456

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-042007 1.2
HARDWARE ILLUSTRATION
(A6)HEX BOLT 1/2"x5 3/4"L PARTIAL THREAD QTY.1
(A7)HEX BOLT 3/8"x2 1/4"L PARTIAL THREAD QTY.1
(A9)HEX BOLT 5/16"x3 1/4"L PARTIAL THREAD QTY.2
2
13456

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-042007 1.3
HARDWARE ILLUSTRATION
(A10)HEX BOLT 1/2"x1 1/4"L PARTIAL THREAD QTY.4
(A11)HEX BOLT 1/2"x3 1/4"L PARTIAL THREAD QTY.1
CONNECT DGYM
(B1)NYLON LOCK NUT 1/2" QTY.5
(C1)1/2"(I.D.)FLAT WASHER n34 QTY.10
(A21)ROUND ALLEN HEAD M10X75L PARTIAL THREAD QTY.2
(C12)M10(I.D.)FLAT WASHER n27 QTY.2
2
13456

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-062007 1.4
(A13)HEX BOLT 1/2"x2 1/4"L PARTIAL THREAD QTY.1
(A14)HEX BOLT M4X65L"L PARTIAL THREAD QTY.2
(A15)ROUND ALLEN HEAD 3/8"X2"L PARTIAL THREAD QTY.1
2
13456
FRAME HARDWARE ILLUSTRATION
(C10)M4(I.D.)FLAT WASHER n12 QTY.2
Optional Purchase
TOP CAP(9211-111)
TOP CAP(9211-119)
"M4X65 ROUND BOLT" and "M4 WASHER" is used to assemble with 9211-111 and 9211-119 TOP CAP

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-042007 1.5
(A16)ELASTIC BOLT QTY.1
(A17)10LB PIN (8250-071) QTY.1
(A19)ROUND ALLEN HEAD M6X20L PARTIAL THREAD QTY.24
(A20)ROUND ALLEN HEAD 5/32"X1/4"L PARTIAL THREAD QTY.4
2
13456
FRAME HARDWARE ILLUSTRATION

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-042007 1.6
(B2)NYLON LOCK NUT 1/2" QTY.10
(C3)1/2"(I.D.)FLAT WASHER n34 QTY.17
(C6)5/16" SPRING WASHER QTY.2
(C5)5/16"(I.D.)FLAT WASHER n24 QTY.2
(C4)3/8"(I.D.)FLAT WASHER n19 QTY.2
(B3)NYLON LOCK NUT 3/8" QTY.1
HARDWARE ILLUSTRATION
2
13456
(C13)1/2"(I.D.)FLAT WASHER n25 QTY.4

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-062007 1.7
(B5)NYLON LOCK NUT 1/2" QTY.1
(C8)1/2"(I.D.)FLAT WASHER n25 QTY.2
(C9)3/8" SPRING WASHER QTY.1
(C11)M6(I.D.)FLAT WASHER n13 QTY.24
2
13456
FRAME HARDWARE ILLUSTRATION

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-042007 1.8
(A22)ROUND ALLEN HEAD M10X30L PARTIAL THREAD QTY.1
(B6)NYLON LOCK NUT M10 QTY.1
2
13456
Selector Rod HARDWARE ILLUSTRATION
(A23)FIRM SHEATH(8890-046) QTY.1

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-062007 2
D1.n3/4"X16L STEEL BUSHING (8110-066)---------------------[2PCS]
D8.58X116X2.5T FOOT CAP(9211-108)----------------------------[2PCS]
D10.58X116 END CAP(9211-112)------------------------------------[2PCS]
D14.n3/4" SHAFT COLLAR(9211-046)------------------------------[2PCS]
D15.n2 1/2"X19.2X19.4T RUBBER DOUNT(9310-010)---------[2PCS]
D1 D2 D3 D4
D6 D7 D8 D9
D11 D12 D13 D14
D16
D5
D10
D15
D7.50X100(40X80)NYLON BUSHING(9211-107)-----------------[2PCS]
D11.40X80 END CAP(9211-113)--------------------------------------[2PCS]
D4.n8 SPRING SNAP LINK(8810-001)------------------------------[2PCS]
D17.95X250 RUBBER PAD(9310-060)-------------------------------[2PCS]
D17
D2.n3/4"X45L STEEL BUSHING (8110-067)---------------------[8PCS]
D3.n1" SHAFT COLLAR(8130-024)----------------------------------[2PCS]
D5.n1" END CAP(9211-016)-------------------------------------------[2PCS]
D6.n60 END CAP(9211-065)-------------------------------------------[2PCS]
D9.COVER(9211-110)----------------------------------------------------[2PCS]
D12. 3" Nylon Washer (9214-008)-------------------------------------[4PCS]
D13. n1"x2.5t Round End Cap(9260-021)--------------------------[2PCS]
D16.95X140L RUBBER PAD(9310-035)-----------------------------[2PCS]
HARDWARE ILLUSTRATION

ASSEMBLY INSTRUCTIONS
Page
DLAT
DLAT.1-042007 3
D25.WEIGHT SELECTOR BAR(8210-042B)-------------------------[1PCS]
D18 D19
D25
D21 D22
D18.n117 PULLEY(9213-010B)-----------------------------------------[8PCS]
D19.TOP PLATE(8400-006)----------------------------------------------[1PCS]
D21.1975mm STEEEL CABLE(FDLATA)------------------------------[1PCS]
D22.3250mm STEEL CABLE(FDLATB)--------------------------------[1PCS]
D23.DLAT For DGYM Steel Cable(FDLATC)-------------------------[1PCS]
19751975 3250
HARDWARE ILLUSTRATION
D24.150X250L RUBBER PAD(9310-036)-----------------------------[1PCS]
D24

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-042007 4
DLAT
PARTS ILLUSTRATION SHEET
A1[1PCS] B[1PCS]
C[1PCS] D[1PCS] E[1PCS]
F[1PCS] G[1PCS] H[2PCS] I[1PCS]
J[1PCS]
n1"X600L K[1PCS] L[1PCS]
8313-130
197
62
238
CONNECT DGM
20LB1200D

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-042007 5
DLAT
PARTS ILLUSTRATION SHEET
M[1PCS]
8343-146 N[1PCS] 8343-147 O[2PCS] 8343-140 P[1PCS] 8290-001
Q[1PCS]
9121-054 R[2PCS]
9161-021B
n150X250L

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-062007 6
DLAT
FRAME PARTS ILLUSTRATION SHEET
S[1PCS]
6610-001 T[1PCS] 8380-044
U[1PCS]
8380-052 V[1PCS] 8380-045
W[2PCS]
n3/4"X1932L
250
95
AC[1PCS]
9211-119A
Y[2PCS]
8313-144
AA[12PCS]
8321-040
both side
AB[2PCS]
8321-040
one side
50.563
50.563
Z[1PCS]
9440-165
40
40

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-042007 7
DLAT
Above shows STEP 1
assembled and completed
I
D11
D7
D
D6
D16
D16
D6
A1
D7
D8
D8
D10
3/8" WASHER X2
3/8"X1"L HEX BOLT X2

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-042007 8
DLAT
Above shows STEP 2
assembled and completed
A1
C3
1/2"X1-1/4" HEX BOLT X2
A1 C3
1/2" WASHER X2
1/2"X2-3/4" HEX BOLT X2
1/2" WASHER X2 E
A3
F
B2
C3
C3 B2 C3

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-042007 9
DLAT
Above shows STEP 3
assembled and completed
S
Y
M10X25L CONE BOLT X8 D17
C11
A19
x4
x4
DLAT single weight stack assembly instructions
x2
x2
AB
AA

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-042007 10
DLAT
Above shows STEP 4
assembled and completed
J
D11
D10
C3
B2
B2 C3
L
C3 A4x2
x2
M10X25L HEX BOLT X2
M10 WASHER X2
5/16"X5/16" SCREW
1/2"X3/4"L HEX BOLT X2
1/2" WASHER X2

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-042007 11
DLAT
Above shows STEP 5
assembled and completed
A13C8
D18 C8 B5
AA
AB
AA
AA
AA
AA HH
D15
D15
W
D14
W
AA
D14
AA
AA
D19
AA
C11
A19
x24
x24
AA
AA

ASSEMBLY INSTRUCTIONS
Page
DLAT.1-042007 12
DLAT
Above shows STEP 6
assembled and completed
A16
C9
A15
A17
D25
