Body Solid DPEC.1 User manual

BODY-SOLID,Inc.
1900 S. Des Plaines Ave.
Forest Park, IL 60130 USA
Phone:[phone]
Fax:[phone]
www.bodysolid.com
OWNER'S MANUAL
DPEC.1

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 1.1
(A1)HEX BOLT 1/2"x1 1/2"L PARTIAL THREAD QTY.4
(A2)HEX BOLT 1/2"x2 1/4"L PARTIAL THREAD QTY.1
(A3)HEX BOLT 1/2"x3 1/4"L PARTIAL THREAD QTY.1
(A4)ROUND ALLEN HEAD 5/16"x1 1/2"L PARTIAL THREAD QTY.2
(A5)HEX BOLT 5/16"x2 1/2"L PARTIAL THREAD QTY.2
HARDWARE ILLUSTRATION
2
13456

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 1.2
(A6)HEX BOLT 5/16"x3 1/4"L PARTIAL THREAD QTY.4
HARDWARE ILLUSTRATION
2
13456

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-062007 1.3
(A8)HEX BOLT 1/2"x2 1/4"L PARTIAL THREAD QTY.3
(A9)HEX BOLT M4X65L PARTIAL THREAD QTY.2
(A10)ROUND ALLEN HEAD 3/8"X2"L PARTIAL THREAD QTY.1
(A11)ROUND ALLEN HEAD M6X20L PARTIAL THREAD QTY.20
2
13456
FRAME HARDWARE ILLUSTRATION
(C8)M4(I.D.)FLAT WASHER n12 QTY.2
Optional Purchase
TOP CAP(9211-111)
TOP CAP(9211-119)
"M4X65 ROUND BOLT" and "M4 WASHER" is used to assemble with 9211-111 and 9211-119 TOP CAP

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 1.4
(A12)ELASTIC BOLT QTY.1
(A13)10LB PIN (8250-071) QTY.1
(A15)ROUND ALLEN HEAD 5/32"x1/4"L PARTIAL THREAD QTY.4
2
13456
FRAME HARDWARE ILLUSTRATION

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-072007 1.5
(B1)NYLON LOCK NUT 1/2" QTY.6 (C1)1/2"(I.D.)FLAT WASHER n34 QTY.4
(C2)5/16"(I.D.)FLAT WASHER n24 QTY.6
(C3)5/16" SPRING WASHER QTY.6
2
13456
HARDWARE ILLUSTRATION
(C10)1/2"(I.D.)FLAT WASHER n25 QTY.8

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-062007 1.6
(B4)NYLON LOCK NUT 1/2" QTY.3 (C5)1/2"(I.D.)FLAT WASHER n34 QTY.4
(C6)3/8" SPRING WASHER QTY.1
(C7)M6(I.D.)FLAT WASHER n13 QTY.20
2
13456
FRAME HARDWARE ILLUSTRATION
(C9)1/2"(I.D.)FLAT WASHER n25 QTY.2

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 1.7
(A16)ROUND ALLEN HEAD M10X30L PARTIAL THREAD QTY.1
(B5)NYLON LOCK NUT M10 QTY.1
2
13456
Selector Rod HARDWARE ILLUSTRATION
(A17)FIRM SHEATH(8890-046) QTY.1

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 2
D1.n3/4"X16L STEEL BUSHING (8110-066)--------------------[2PCS]
D2.n36Xn26.5X15L STEEL BUSHING (8130-160)------------[2PCS]
D3.n1" CU WASHER (8520-008)------------------------------------[6PCS]
D4.2"X2" END CAP (9211-087)---------------------------------------[1PCS]
D5.58X116X2.5T FOOT CAP(9211-108)---------------------------[4PCS]
D6.58X116 END CAP(9211-112)-------------------------------------[3PCS]
D8.2"X2" RUBBER CANE CAP(9214-002)------------------------[1PCS]
D9.n3/4" SHAFT COLLAR(9211-046)------------------------------[2PCS]
D10.n4" RUBBER DOUNT(9310-017)-----------------------------[2PCS]
D11.95X250 RUBBER PAD(9310-060)----------------------------[3PCS]
D12.n117 PULLEY(9213-010B)-------------------------------------[7PCS]
D19.WEIGHT SELECTOR BAR(8210-042B)----------------------[1PCS]
D14.TOP PLATE(8400-006)------------------------------------------[1PCS]
D15.3015mm STEEL CABLE(FDPECA)---------------------------[1PCS]
D16.3220mm STEEL CABLE(FDPECB)---------------------------[1PCS]
D1 D2 D3 D4
D6 D8 D9 D11
D12 D14
D16
D5
D10
D15
30153015 3220
D17
D17.1/2" BOLT CAP(9212-024)--------------------------------------[2PCS]
D18.DPEC For DGYM Steel Cable(FDPECC)--------------------[1PCS]
HARDWARE ILLUSTRATION
D19

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 3
A[1PCS] B[1PCS]
C[2PCS] D[2PCS] F[1PCS]
G[1PCS] H[2PCS]
PARTS ILLUSTRATION SHEET

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 4
I[1PCS]
J[1PCS]
K[2PCS]
8220-135 L[1PCS]
9111-057 M[1PCS]
9111-058
N[1PCS]
9121-055
PARTS ILLUSTRATION SHEET
AA[2PCS]
8331-015
80
25
n13.5

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-062007 5
FRAME PARTS ILLUSTRATION SHEET
O[1PCS]
8380-046 P[1PCS]
8380-047
Q[1PCS]
8380-048 R[2PCS]
n3/4"X1425L
Z[1PCS]
9211-111A
T[1PCS]
6610-002
U[2PCS]
8313-144
95
250
V[9PCS]
8321-040
both side
W[1PCS]
8321-040
one side
X[2PCS]
8321-040
one side
63 50.5
63 50.5
50.563
Y[1PCS]
9440-164
40
40
40

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 6
Above shows STEP 1
assembled and completed
D5
D5
A
B
D5
D11 D5
M10X16L HEX BOLT X6
M10 WASHER X6

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 7
Above shows STEP 2
assembled and completed
M10X16L HEX BOLT X12
M10 WASHER X12
J
I

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 8
Above shows STEP 3
assembled and completed
D6
D4
D8
D6
D6
M10X16 HEX BOLT X11
M10 WASHER X11
G

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 9
Above shows STEP 4
assembled and completed
M10X25L CONE BOLT X4
n50 CAP X4
1/2"X2 1/4" HEX BOLT X2
1/2" WASHER n25 X2
D12x2
K
K
1/2" WASHER n25 X2
1/2" NYLON LOCK NUT X2
AAx2
# Repeat assembly for left side pulley

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 10
Above shows STEP 5
assembled and completed
A4 D2
D3
C
D
D3
n50XCAP
M10X25L CONE BOLT
x2
x2
x2 x2
H
D3x2
x2
x2
x2

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 11
Above shows STEP 6
assembled and completed
D12
F
C1
B1 A2
C1
D17x2
Press cap over
cable end holder

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 11.1
Cable to match illustration
D15
D15

ASSEMBLY INSTRUCTIONS
Page
DPEC
DPEC.1-042007 12
Above shows STEP 7
assembled and completed
L
M
N
C2
C3
A5 C2
C3
C2
C3 A6x4
x4
x4
A5
