BONAIRE BAHV12 User manual

Operator’s Manual
+LJK9ROXPH,QIODWRU'HIODWRU
5DIWV$LU0DWWUHVVHVDQGRWKHU,QIODWDEOHV
For Outdoor Use
CAUTION:
Read the Safety Guidelines and All Instructions Carefully Before Operating
Model: %$+9
xSafety Guidelines
xOperation

For assistance with parts and customer service, please call 1-800-874-5771, :00am to :00pm,
Monday through Friday, 0RXQWDLQ time or email: [email protected].
TABLE OF CONTENTS
General Safety Rules......................................................... 1
Safety Symbols, Words and Labels................................... 1
Specifications..................................................................... 2
Important Safety Information ............................................. 3
+LJK9ROXPHInflator 'HIODWRUParts Diagram ................. 4
+LJK9ROXPH Inflator 'HIODWRUOperating Instructions ...... 5
GENERAL SAFETY RULES
Read and understand all instructions. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
Work Area
Keep your work area clean and well lit. Cluttered benches and dark areas increase the possibility of
personal injury or property damage.
Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep bystanders, children and visitors away while operating a power tool. Distractions can cause
you to lose control.
SAFETY SYMBOLS, WORDS AND LABELS
The safety instructions provided in this manual are not intended to cover all possible conditions that may occur
during product operation. Always use common sense and pay attention to all WARNING and CAUTION
statements in this manual.
WARNING WARNING indicates a potentially hazardous situation. Failure to avoid may result in
serious injury or death.
CAUTION CAUTION indicates a potentially hazardous situation. Failure to avoid may result in
minor personal injury.
INTENDED USE: This product is intended for consumer use only.
1

SPECIFICATIONS
CAUTION
THIS INFLATOR OPERATES ONLY ON DC 12 VOLT. DO NOT ATTEMPT TO OPERATE THIS
INFLATOR WITH ANY OTHER SOURCE OR VOLTAGE. DO NOT REWIRE OR RECONFIGURE
INFLATOR FROM ITS ORIGINAL DESIGN OR PERSONAL INJURY OR BODILY HARM MAY OCCUR.
Voltage DC 12 Volt
Power Requirement DC 12 Volt – For use with 12 Volt DC Power Outlet Only
IMPORTANT INFORMATION ABOUT THIS PRODUCT
The Hi-Speed Raft Inflator is specifically designed to inflate items that require a large volume of air at low
pressure such as air mattresses, rubber rafts, beach toys, etc. Follow these instructions for easy and
specific use of your Bon-Aire HiJK9ROXPHInflator'HIODWRU.
2
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Unit will not start. 1. Inflator power cord
is not plugged in.
2. Vehicle engine is
not running.
3. Fuse in 12 Volt DC
power cord blown.
(Please see image A below).
1. Firmly insert the power cord's plug into a
working 12 Volt DC Power Outlet.
2. In a well ventilated area, start vehicle engine
so that it is safely running in a "parked" gear.
3. Replace fuse in 12 Volt DC power cord.
(Please see image B below).
Good Fuse Blown Fuse
The connecting
wire is not broken.
The connecting
wire is broken.
image A
image B

IMPORTANT SAFETY INFORMATION
WARNING
Read and understand all instructions. Failure to follow instructions can result in electric shock, fire and/or
serious personal injury. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
 Use 12 Volt DC only. Make sure that your 12 Volt power outlet is free of any ash residue or debris.A dirty
12 Volt power outlet can cause the inflator and power cord to overheat. Overheating can causedamage to
your inflator/vehicle and could cause bodily harm or injury. Disconnect power when not in use.
 Make sure the connection between the 12 Volt plug in and the 12 Volt power outlet is secure. A loose
connection can cause the 12 Volt power outlet to arc and or spark which can cause damage to your inflator
and the 12 Volt power outlet.
 This HiJK9ROXPH,QIODWRU'HIODWRU is designed to inflate air mattresses, rafts, beach toys and other high
volume inflatables. Do not use for any purpose other than inflating.
 After using inflator be sure to turn off powerDQGXQSOXJIURP9ROWSRZHUVXSSO\.
 The inflator is not a toy. Keep away from children at all times.
 Do not carry inflator by the power cord as damage may occur.
 Do not leave the inflator unattended while in operation.
 Do not over inflate item you are inflating. Please follow the manufacturer’s instructions for the item you are
inflating.
 Keep the inflator away from flammable areas/liquids at all times.
 Do not operate the inflator in wet or damp areas.
 Operate the inflator only with the accessories and or attachments that are included.
 If available it is recommended that safety glasses be used when operating the inflator.
 When operating your inflator ZLWKDYHKLFOHDVWKHSRZHUVRXUFHit is recommended that your engine be
turned on and running. Thisallows your vehicle battery to maintain a full charge and therefore your inflator
will operate at maximumpower and efficiency. It is 2. to operate your inflator when your vehicle engine is
turned off and notrunning, but if your vehicle battery is not fully charged your inflator will operate slower
and also couldpossibly drain your battery of 12 Volt current.
WARNING
IF YOUR VEHICLE ENGINE IS TURNED ON AND RUNNING WHEN YOU ARE USING YOUR INFLATOR,
YOU MUST BE ABSOLUTELY SURE THAT YOUR VEHICLE IS OUTSIDE OR IN AN OPEN, WELL
VENTILATED AREA AND NOT INSIDE A CONFINED CLOSED AREA SUCH AS A GARAGE. ALWAYS
ALLOW FOR PROPER VENTILATION IF YOU ARE RUNNING YOUR VEHICLE ENGINE. IF YOU DO NOT
FOLLOW THESE INSTRUCTIONS, BODILY HARM OR ASPHYXIATION RESULTING IN DEATH COULD
OCCUR.
3

+,*+92/80( INFLATOR'()/$725 PARTS DIAGRAM
$ Carrying Bag
% Inflation Port
& 'HIODWLRQ 3RUW ZLWK 1R]]OH ± ,PDJH 
' 2Q2II 3RZHU /RFNLQJ 7ULJJHU
( 9ROW3OXJ,Q
) 2Q%RDUG 1R]]OH 6WRUDJH
* 1R]]OH$GDSWRUV
H. Spare Fuse (15 Amp)
I. 12 Volt Power Plug
4
;Ϳ ĞĨůĂƚŝŽŶWŽƌƚǁŝƚŚEŽnjnjůĞ
Image #1

+,*+92/80(,1)/$725'()/$725 OPERATING INSTRUCTIONS
CAUTION
DO NOT OVER-INFLATE ITEM BEING INFLATED. FOLLOW MANUFACTURERS
SUGGESTED PSI LEVELS ON ITEM YOU ARE INFLATING.
 Remove HLJK9ROXPH Inflator 'HIODWRUDQG3RZHU&RUGfrom &arrying %ag.
 Insert the VPDOOSOXJRIWKH12 Volt power cord intoWKH93/8*,1RQWKHEDFNVLGHRIWKHLQIODWRU
OLQLQJXSWKH7DEDQG6ORWDQGWKHQWXUQFORFNZLVHWR/RFNLQWRSRVLWLRQVHH,PDJH
 ,QVHUWWKHODUJH9ROWSRZHUFRUGSOXJLQWRDQ\ 12 Volt DC power outlet (see ,mage #)
 Select the proper Nozzle Adaptor and connect it to the +LJK9ROXPH,QIODWRU by pushing down andturning
LWslightly to the right to lock into placeRQWKH,QIODWLRQ3RUW%RQ3DUWV'LDJUDPSDJH.
 Insert Nozzle Adaptor into inflatable item’s $LU0DWWUHVV5DIWHWFair valve.
 Turn the power ON by squeezing the OQ/OII3RZHU/RFNLQJ7ULJJHU.
 Once you have reached the desired air pressure on the item you are inflating turn power OFF E\
VTXHH]LQJWKH2Q2II3RZHU/RFNLQJ7ULJJHUDJDLQ.
 Remove the 12 Volt power SOXJ from the DC 12 Volt power outlet
 5HPRYHWKH9ROWSRZHUFRUGIURPWKHEDFNRIWKH,QIODWRUE\WXUQLQJFRXQWHUFORFNZLVHXQWLOLWVWRSV
DQGWKHQEDFNFORFNZLVHVOLJKWO\ZKLOHSXOOLQJJHQWO\OLQHXSWDEDQGVORWWRUHPRYH.
 Remove all nozzles from the Inflation Port.
 Store WKH1R]]OHVLQWKH%DVHVHH,PDJHDQGWKHQVWRUHDOOLWHPV in the &arrying %ag.
To Deflate:
1. If you wish to 'eflate, follow the same procedure as above using the outlet that is marked “D()/$7,21” on
WRSRIWKHLQIODWRU±VHH&SDJHIRU'HIODWLRQ3RUWORFDWLRQDQG1R]]OHXVH
Image#ϭImage#Ϯ
5
Image#ϯ
WHEN USING HI*+92/80( INFLATO5'()/$72R TO INFLATE AIR MATTRESSES, RAFTS, BEACH
TOYS, ETC.
Note: Your HiJK9ROXPH Inflator'HIODWRU is a great device for inflating or deflating air mattresses, small boats
DQGUDIWV, inflatable toys and a host of other items that use a large volume of low pressure air. The HiJK9ROXPH
,QIODWRU'HIODWRU comes with three nozzles of varying sizes to fit most air valves on high volume inflatables.
To ,Qflate:

873 E. Citation Court
Boise, Idaho 83716 USA
800-874-5771
www.bon-aireindustries.com
