Borglocks BL3100 ECP Series User manual

Borg Locks Help Line: [phone]
BL3100 & 3400 ECP Series
Fitting XL Latchbolt - Part No. BLGATELATCHNEW
To t the XL latchbolt, the existing latchbolt will need to be removed. The tools required to t are a 1.5mm (1/16”)
hex key and 4mm (3/16”) hex key.
Please Note: Before
following step 1, it is advised that the 2 x grub screws are heated with hot water to
.
release the thread lock. Take extreme care when pouring hotwater onto the grub screws.
1. Using a 1.5mm (1/16”) hex key, remove the 2 x hex head grub screws located either side of the latch sleeve
As per Fig.1 and Fig.2 below.
Fig.1 Fig.2
Fig.3
2. Using a 4mm (3/16”) hex key, remove the hex head bolt located in the end of the latchbolt as per Fig.3. Keep this
bolt, as this will be needed when the XL latchbolt is tted.
3. Holding the latchbolt sleeve, grip and rotate the latchbolt anti-clockwise until it comes away from the sleeve - as
per Fig.4
Fig.4
Latchbolt
Sleeve
Latchbolt
Fig.5
Latchbolt
Sleeve
XL Latchbolt
Ball
Bearing
4. Ensure that the 2 x ball bearings are in line with the holes either side of the XL latchbolt as per Fig.5. If there is
not already - place a small amount of grease around the ball bearings to ensure they do fall out of the holes. With
the bearings in position, screw the threaded part of the XL latchbolt (clockwise) into the latchbolt sleeve until both
halves join as per Fig.6.
Continued Page 2
Ball Bearing &
Latchbolt Hole
Fig.6

BL3100 & 3400 ECP Series
Fitting XL Latchbolt - Part No. BLGATELATCHNEW
5. Ensure that bevelled edge of the latchbolt is facing the correct way and that the ball bearings are in alignment
with the latchbolt hole. Using the 1.5mm (1/16”) hex key, replace the 2 x hex head grub screws located either side
of the latchbolt sleeve. As per Fig.7 and Fig.8 below.
Please note: Do not overtighten the grub screws as this will prevent the latchbolt from rotating and the
ability to adjust the length. The head of the grub screws should be ush with the threaded holes on the
latchbolt sleeve. Loosen the grub screws slightly if the latchbolt does not rotate.
Fig.7 Fig.8
6. Adjust the latchbolt to the desired length by rotating it anti-clockwise to increase the length between 115mm-
130mm. When at the desired length, using the 4mm (3/16”) hex key, replace the hex head bolt located in the end
of the latchbolt as per Fig.9.
When tightening the hex head bolt the 2 x ball bearing will expand out into the holes either side of the latchbolt
sleeve.
Fig.9
Any problems when tting the XL latchbolt or for any other technical advice please call:
Borg Locks Help Line: [phone]
