Borglocks BL4409 ECP Configuration guide

. 1 .
Fixing
Fixing
x 2.
(15)
(15)
Washers x 4.
x
x
BL4409 ECP
(12) (12) Code Change Key
(13)
(13) Hex Key x 2
(14)
Code C####
(14) Code Card
BORGLOCKS.COM
*
Deacvang on door code change plug (x1)

.2.
(holdback models Only)
When fitting to a left-hand door, remove the
rubber grommet from the base of the handle
and remove the exposed grub screw.
Lift the handle off, turn it 180°and slide back.
(Refit the grub screw and grommet).
Tape the template to the door, make sure
that you fold it along the line
Mark and drill 2 10mm holes
Special note
1. Determine your door type
2. Apply the template
3. Position and fix the slam latch,
support plate and keypad
Hold the keypad with its gasket and slam latch
support plate in position and with the fixing
screws supplied secure to the door
4. Position the spindle
5. Fix the slam latch
Locate the spindle in the back of the keypad,
ensuring that it engages with the latch
correctly dependant on the hand of the door
Using the fixing bolts supplied fix the
slam latch to the slam latch support plate
6. Fit the strike plate. Mortice
Position the strike plate on the door edge
so that it lines up with the latch bolt.
Drill and cut a recess for the latch bolt.
Fit the strike plate using only one wood screw
at first to ensure that it is positioned correctly.
When satisfied with its position secure
the strike with the 2nd screw.
R.H L.H
and 1 13mm holes.

.3.
BORG HELPLINE
0800 44 88 377
The latch bolt is reversible.
It is held in position with a internal hex screw.
Loosen the hex screw with a hex key and this will
allow you to rotate the latch bolt 180° converting it
from one hand to the other.
8. How to change the hand of
the Slam Latch
7. Fit the strike plate. Rim
Position the strike plate on the door frame or
post so that it lines up with the latch bolt
Mark the door for the correct screw fixing position
If necessary cut a recess for the latch bolt
Once positioned and ready secure the strike to the
door frame or post with the fixing screws provided
How to change your code
[phone]
9. How to change code
The code should be changed with the door/gate in the
open position. To change the code you will need to
know what the keypad is currently set to. The code can
be changed with the unit tted on/o󰀨 the door.
1. Enter existing code
2. Using code change key - insert into the hole in the *
button - fully press and hold until step 5.
3. Press `C` button to clear the existing code.
4. Enter the new code.
5. Release the code change key from the hole in the *
button.
6. Press `C` to set the new code.
7. The new code is now set and ready for use
8. Check that the code is working 5 times and that it is
withdrawing the latchbolt before closing the door/gate.
Please note: If a mistake is made whilst entering a
new code (with the * button pressed) the `C` button
can be pressed which will cancel any buttons that
have been pressed and you can start again.
BORGLOCKS.COM
BORGLOCKS.COM
BORGLOCKS.COM

Problems Cause Solution
Problems Cause Solutions
Installation Problems
Problem Solving Guide
The Borg guarantee: If a Borg lock should develop a fault within 1 year from date of
purchase we will repair it of charge.
DISCLAIMER: Under no circumstances should the lock be dismantled,
this will invalidate our warranty.
.4.
Please call our helpline for spares, repairs and technical advice on 0800 44 88 377.
