Bosch WTE84102SN User manual

1 2 3 4 5 6
Emptying condensation
Empty container after each dryin g operation!
1. Pull out condensation container keeping it h orizontal.
2. Pour out condensation.
3. Always push container in fully unti l it clicks into place.
If n(Container) flashes in the displ ay panel aWhat to do if..., Page 10.
Cleaning the fluff filter
Clean the fluff filter after each dry ing operation.
1. Open the door, remove fluff from door/door area.
2. Pull out and fold open the fluff filter.
3. Remove the fluff (by wiping the filter with your hand).
If the fluff filter is very dirty or blocked, rinse with wa rm water and dry
thoroughly.
4. Close and reinsert the fluff filter.
Switching off the dryer
Turn the programme selector to 0(Off).
Do not leave laundry in the dryer.
Removing the laundry
The automatic anti-crease function c auses the drum to move at specific i ntervals, the washing remains
loose and fluffy for an hour (two hou rs if the additional Reduced Ironing function is also
selected-depending on model) .
... and adapt to individual requirements
Never start the dryer if it is damaged!
Inform your after-sales service . Inspecting the
dryer
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette light ers.
The drum must be em pty prior to loading.
See programme overview on page 7.
See also separate inst ructions for “Woollens basket”
(depending on model)
Your new dryer
Congratulations - You have chos en a modern, high-quality Bosch
domestic appliance.
The condensation dryer is distinguished by its eco nomical energy
consumption.
Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition .
Should you have any questions, our after-sales service will be ple ased
to help.
Disposal in an environmentally-respons ible manner
Dispose of packaging in an environmentally-responsible m anner.
This appliance is labelled in accordance with the European
guideline 2002/96/EG on waste electrical and electronic
equipment - WEEE.
The guideline provides a n EU-wide framework fo r the return and
recycling of old appliances.
For further information about our p roducts, accessories, spare parts
and services, please visit: www.bosch-home.com
Intended use Preparing for installation, see P age 8
Selecting and adjusting the programme
Drying
Condensation container
Control panel
ʋfor domestic use only,
ʋonly to be used for drying fabrics that have been
washed with water.
Do not leave children
unsupervised near the dryer.
Keep pets away from the dryer.
The dryer can be op erated by children 8 year s old
and older, by persons with reduced physical,
sensory or mental abilities and by persons with
insufficient experience or k nowledge if they are
supervised or have been instructed in its use by
a responsible adult.
Select the drying programme ...
Press the (start) button
1
2
3
Make sure your hands are dry.
Hold the plug only. Connecting the
mains plug
Drying
Drum
All buttons are sensitive and only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted! Air inlet
Fluff filter
Drum interior light
(depending on model)
Maintenance
flap Programme end once lights u p in the display.
Interrupt programme removing or addi ng laundry.
The drying cycle can be inte rrupted for a brief period so tha t laundry may be added or r emoved.
The programme selected must then be resumed and completed.
Never switch the dryer off before the drying process has ended.
Drum and door may b e hot!
1. Open door, the drying process is interrupted.
2. Load or remove laundry and close door.
3. If required, select a ne w programme and additional f unctions.
4. Press the (start) button.
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . .2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋInformation on laundry . . . . . . . . . . . . . . 5
ʋFine adjustme nt of th e drying result . . 5/6
ʋCare and cleaning . . . . . . . . . . . . . . . . . 6
ʋProgramme overview . . . . . . . . . . . . . . . .7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport . . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... / After-sales serv ice . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11
Information on laundry ...
Labelling of fabrics
Follow the manufacturer's care infor mation.
(Drying at normal temp erature.
'cDrying at low temperatu re aalso select V(Low Heat).
)cDo not machine dry.
Observe safety instructions with out fail aPage 11!
Do not tumble-dry the follow ing fabrics for example:
– Impermeable fab rics (e.g. rubber-coated fabrics) .
– Delicate materials (silk or curtains made from synthetic material) ath ey may crease
– Laundry contami nated with oil.
Drying tips
– To ensure a consiste nt result, sort the laundry by fabric type a nd drying programme.
– Always dry v ery small items (e.g. baby socks) together with la rge items of laundry (e.g. hand
towel).
– Close zips, hooks and eye lets, and button up covers.
Tie fabric belts, apron strings, etc. toge ther
– Do not over-dry ea sy-care laundry arisk of creasing!
Allow laundry to finish drying in th e air.
– Do not dry w oolens in the dryer, only use to fr eshen them up aPage 7, Woollens Finis h
Programme (depending on m odel).
– Do not iron laundry immediately after drying, fold items up and leave for a while athe
remaining moisture will t hen be distributed evenly.
– The drying result depends on th e type of water used during washing. aFi ne adjustment
of the drying result aPage 5/6.
– Machine-knitte d fabrics (e.g. T-shirts or jerseys) often shrink the first time the y are dried a
do not use the +:Very Dry programme.
– Starched laun dry is not always s uitable for dryers astarch leaves behind a coating tha t
adversely affects the drying operation.
– Use the correct dosage of fabric softener as per the m anufacturer's instructions when
washing the laundry to b e dried.
– Use the timer program me for small loads athis improves the drying result.
Environmental protection / Energy-saving tips
– Before drying, spin the la undry thoroughly in the washing machine athe hig her the spin
speed the shorter the drying time wi ll be (consumes less energy), also sp in easy-care
laundry.
– Put in, but do not exceed, the maximu m recommended quantity of laundry a
programme overview aPage 7.
– Make sure the room is well ventilated during drying.
– Do not obstruct or seal up the air inlet.
– Keep the air cooler cl ean aPage 6 “Care and c leaning”.
Fine adjustment of the drying result
Adjustment of the levels of dryness
1 x to
the right
Press and hold V(Low H eat)
and turn 5 x to the right
Press V(Low Heat) until
the required level is reached
Turn to
0(Off)
Turn to
0(Off)
Fine adjustment of the drying result
H(drying), (iron dry), +(cupboard dry),
R/(fluff/finished) a re displayed in seq uence.
Short signal w hen changing from leve l 3 to 0, oth erwise
long signal.
Care and cleaning
Dryer housing, control panel, air cooler, moisture sensors
– Wipe with a soft, damp cloth.
– Do not use harsh cleaning ag ents and solvents.
– Remove detergent and cle aning agent residue immediately.
Clean the protective f ilter 5 - 6 time s a year
or if o(Filter) flashes after clea ning the fluff filter.
Air cooler / Protective filte r
When cleaning, only remove the protective filter. Clean the air cooler
behind the protective filter once a year.
– Allow the dryer to cool.
– Residual water may leak out, so place an absorbent towe l
underneath the mainte nance door.
1. Unlock the mainten ance door.
2. Open the maintena nce door fully.
3. Turn both locking levers towards each another.
4. Pull out the protect ive filter/air cooler.
Do not damage the protective filte r or air cooler.
Clean with warm water only. Do not use any ha rd or sharp-edged
objects.
5. Clean the protective filter/a ir cooler thoroughly,
Allow to drip dry.
6. Clean the seals.
7. Re-insert the prote ctive filter/air cooler,
with the handle facing down.
8. Turn back both loc king levers.
9. Close the mainten ance door until the lock c licks into place.
Moisture sensors
The dryer is fitted w ith stainless steel moi sture sensors. The sensor s
measure the level of moisture in the laundry. After a long p eriod of
operation, a fine layer of limescale m ay form on the s ensors.
1. Open the door and clean the m oisture sensors with a damp spong e
which has a rough surface.
Do not use steel wool or abrasive mat erials.
Only when switched off!
Additional
functions
Service displays
H+R/"drying, iron dry, cupboard dry, fluff/finished
n(Container) Empty the condensati on container.
o(Filter) Clean the fluff filter and/o r air cooler under running water aPage 4/6.
Programme selector
ʋV(Low Heat)
Reduced temperature for del icate fabrics 'that require
a longer drying time; e.g. for po lyacrylics, polyamide, elastane or aceta te.
Fine adjustment
of the drying
result
The drying result (e.g. Cupboa rd Dry) can be adjusted over t hree levels (1 - max. 3) for the
Cottons,Synthetics,LIFMix and Super 40’ programmes apresetting = 0. A fter
one of these programmes has be en finely adjusted, the setting is retained for the others.
Further information aPage 5/6.
0, 1, 2, 3
Display panel
Read these instructions and the separate
Energy-saving mode instr uctions before
operating the dryer.
Observe the safety instr uctions on page 11.

7
Programme overview also see Page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tum ble drying. After drying...
c
iron laundry

lightly iron laundry
@c
do not iron laundry
c
mangle laundry
PROGRAMMES TEXTILE TYPE AND I NFORMATION ** Cottons max. 7 kg Hard-wearing fabrics, boil-resista nt fabrics made of cotton or l inen.
** Synthetics max. 3.5 kg Non-iron laun dry made of synthetic fibres and blended fabric, easy-care c otton. ** LIFMix max. 3 kg Mixed items of laundry madeof cotton and synt hetics (Mix).
Iron Dry c÷@c Fabric s suitable for ironing (iron fabrics in order t o avoid creasing). +. Cupboard Dry @Single-layer fabrics. *+: Very Dry @Fabrics made of th ick, multilayered items of clothi ng.
Timed progr. 20 min max. 3 kg Pre-dried, multi-layered, sensit ivefab rics made of acrylic fibres, or separate small items of laundry.
Also for subsequent drying .
Super 40’ max. 2 kg
Laundry made of synthetic fibr es, cotton or blended fabrics (for example) that needs t obe d ried quickly. The values may differ from the those specified dep ending on the type of fabric, mixture of laundry to be dried, resi dual moisture in the fabric and loading capacity.
*for Cottons and Synthetics programmes only
**Dryness levels can be selec ted individually a+:Very Dry, +. Cupboard Dry and Iron Dry (depending on the model).
Degree of dryness can be finely adjusted; multi-layered textile s require a longer drying time than single-layered items of clothing. Recommendation: Dry separa tely.
9306 / 9000847734 *847734* Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Deutschland
WTE84102SN
8
Installation
– Delivery specification : dryer, instructions for insta llation and use, woollens ba sket
(depending on model).
– Check dryer for transpo rt damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by any of the protruding parts (e.g . the door) as they may break off.
– Do not set up in a roo m that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have t he appliance connected b y an expert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is i nstalled on a clean, l evel
and solid surface.
– Keep the coolin g grille at the front of the dryer
unobstructed.
– Keep the area ar ound the dryer clean.
– Make the dryer level using the thre aded feet
and a spirit level.
Do not remove the threaded feet under any
circumstances.
Mains conn ection see safety instruction s a Page 11.
– Connect to an AC earthed socket. If in doubt ha ve the socket checked by an expert.
– T he mains voltage and th e voltage shown on the rating plate (
a Page 9) must correspond.
– The connected load and necessary fuse p rotection are specified on th e rating plate.
Converting the installed load Note the fu se protection of the socket.
10/16 Amps
Frost protection / Transport
Preparation
1. Empty the condensation container
a page 4.
2. Select any programme using the programme selector.
3. Press the (start) b utton a condensation is pumped in to the container.
4. Wait 5 min ., and then empty the condens ation container again.
5. Turn the p rogramme selector to 0(Off).
1.
Take all accessory parts
out of the drum.
The drum must be em pty.
Make sure that the air
inlet remains unobstru cted
Clea n and level
2.
3.
turn to
0(Off)
Press and hold selection
then turn 3 x to t he right turn to
0(Off)
Set
amperage
1 x to the
right
Feedback (depending on model): off
flashes
10 A
16 A 33
Do not operate the d ryer if
there is a danger of frost .
Do not set up the d ryer behind a door or sliding
door as this may obstruct or pr event the dryer door
from opening. This will prevent a potentially fatal
danger to children from locki ng themselves in.
9
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm (height adjusta ble)
Weight approximately 45 kg
Max. capacity 7 kg
Condensation container 4.2 l
Connection voltage
Connected load
Fuse protection see appliance rating plate
Ambient temperature
Product number/
Production number
You can find the rating plate on the back of the dryer.
ʠDrum interior light (depen ding on model) (bulb E14, 25 W)
The drum lights up after the door is opened or closed, and a fter the programme starts,
and switches off automatically. Changing the bulb apage 10.
Consumption rates (The value on the label is achieved at the maximum heat setting.)
Fabrics/programmes Residual mois ture in the
fabrics after spinning
Drying time** Energy
consumption**
cCottons 7 kg 10 A 16 A 10 A 16 A
+. Cupboard Dry* 1400 rpm (50%) 112 min 98 min 3.54 kWh 3.54 kWh
1000 rpm (60%) 131 min 115 min 4.13 kWh 4.13 kWh
800 rpm (70%) 150 min 133 min 4.72 kWh 4.72 kWh
Iron Dry* 1400 rpm (50%) 93 min 69 min 2.55 kW h 2.55 kWh
1000 rpm (60%) 111 min 82 min 3.22 kWh 3.22 kWh
800 rpm (70%) 130 min 94 min 3.90 kWh 3.90 kWh
Synthetics 3.5 kg
+. Cupboard Dry* 800 rpm (40%) 48 min 42 min 1.35 kWh 1.35 kWh
600 rpm (50%) 60 min 51 m in 1.65 kWh 1.65 kWh
* Programme setting for testing in accordance with applicable s tandard EN61121.
** The values m ay differ from those specified, depending on the type of fa bric, composition of
laundry to be dried, residual moisture in the fabric and the amoun t of laundry being loaded.
Fabrics/programmes Drying time Annual energy consumption
cCottons 7 kg / 3.5 kg*
+. Cupboard Dry*** 89 min / per cycle 497 kWh / per year
***Programme setting for testing and energy labelling in ac cordance with Directive 2010/30/EU.
Optional accessories (from after-sales service usin g order number)
Platform
For easier loading and unloa ding. The basket contained in the drawer can be u sed to carry
the laundry.
Washer-dryer stack connec tion set
The dryer can be placed o n top of a suitable washin g machine with the same width a nd depth
to save space. The dryer must be fastened to the w ashing machine using this connection set.
With pull-out worktop: WTZ 11300
Connection fittings for condensation outlet
The condensation is conveyed direc tly via a hose.
Installation underneath the worktop
Instead of the appliance covering plate, you must have a metal cover fitted by
a specialist.
WMZ
20500
WTZ
11310
WTZ
1110
WTZ
10290
10
What to do if ...
If you cannot rec tify a fault yourse lf (e.g. switching o ff/on), please contact our after-sales
service. We will always find a n appropriate s olution and will avo id unnecessary vis its by
engineers. Trust the expertise of the manufacturer and rest assured that th e repair will be
carried out by trained se rvice technicians using orig inal spare parts. The cont act details of your
local after-sales se rvice can be found in the enc losed after-sales service d irectory, or by
calling one of these numbers:
–GB 0844 8928979 (Calls f rom a BT landlin e will be charge d at up to 3 pence p er minute.
A call set-u p fee of up to 6 pence may ap ply.)
–IE 01450 2655 (0.03 € per minut e at peak. Of f peak 0.008 8 € per minute .)
When contacting the af ter-sales service, please quote th e appliance's product numb er (E no.)
and production nu mber (FD) (see the inside of the door) .
Set the programme sele ctor to 0(Off) an d remove the app liance plug from the socket.
ʠThe (start) indicator lamp does
not light up.
Mains plug plugged in?
Programme selected?
Check the socket fuse.
ʠThe display pane l light and
indicator lights (depend ing on
model) go out and the (st art)
indicator light flashes.
Energy-saving mode is activa ted
a
see the separat e Energy-saving mode instr uctions.
ʠThe n(Container) and
(start) indicator lamp flash.
Empty the condensa tion container.
If featured, check hose for condensation o utlet.
ʠThe o(Filter) and
(start) indicator lamp flash.
Clean the fluff filter and/or ai r cooler under running wat er
a Page 4/6.
ʠDryer does not start. (start) button selected?
Door closed?
Programme set?
Ambient temperature g reater than 5 °C?
ʠWater is running out. Align dryer horizontally.
Clean air cooler seal.
ʠThe door opens b y itself. Push the door c losed until you hear it engage.
ʠCreasing. Laundry load exceeded?
Remove articles of clothing imm ediately after the end of the
programme, hang u p and pull into sha pe.
Unsuitable program me selected aPage 7.
ʠDrying result is not satisfacto ry
(laundry feels too damp).
Warm laundry feels damper tha n it actually is.
The selected program me does not suit the load. Use ano ther
drying programme or, in addit ion, select the time programme a
Page 7.
Use fine adjustment for the drying result aPage 1/2 and 5/6.
Fine layer of limescale on the humidity sensors
aClean the humi dity sensors aPage 6.
Programme termination, e.g. tank full , mains power supply failure,
door open or maximum drying time reached.
ʠDrying time too long. Rinse the fluff filters und er running water aPage 4.
Insufficient supply of air aensure that air can circulate.
Air inlet possibly blocked aClear inlet aPage 8.
Ambient tempe rature higher than 35 °C aventilate the room.
ʠThe humidity in th e room
increases significantly.
Make sure the room is sufficiently ventilated.
ʠMains failure. Remove laundry from the dry er immediately and spread out.
This allows the heat to dissipate.
ʠOne or more indic ator lights for
programme status are flashing.
Clean filter and air co oler a Page 4/6.
Check installation condi tions
a Page 8.
Switch off, leave to co ol down, switch on aga in, restart
programme.
ʠThe interior light is n ot working
(depending on model).
Pull out the appliance plug, remove the cover cap in the interior
above the door (use Torx 20 screw driver) and replace the bulb.
Close the cover cap.
Never operate the dryer w ithout a cover cap.
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immedia tely or disconnect the fuse.
ONLY use the
dryer...
– in rooms inside the hou se.
– to dry fabrics.
The dryer must
NEVER...
– be used for other purposes than those described above.
– be modified in terms of its techno logy or attributes.
Dangers – The dryer must not be used by children or persons w ho have not been
instructed in its use.
– Do not l eave children unsuper vised near the drye r.
– Keep pets away f rom the dryer.
– Remove all objects f rom pockets.
Make especially sure that cigarette lighters are removed as they constitute an
a explosion hazard.
– Do no t lean or sit on the door
a risk of tipping.
Installation – Secure loose cables a tripping hazard.
– Do not operate the dryer if there is a risk of frost.
Mains
connection
– Connect the dryer according to specifications to an AC e arthed socket, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-secti on must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug a nd socket must be compatible.
– Do not u se multiple plugs/cou plings and/or extension cables.
– Do no t hold the appliance plug with wet hands
a risk of electric shock.
– Never pull the appli ance plug out of the socket by its cable .
– Do no t damage the mains lead
a risk of electric shock.
Operation – Only load the drum with laundry.
Check the contents befo re you switch the dryer o n.
– Do no t use the dryer if the laundry ha s been in contact with solvents, o il, wax,
grease or paint (e.g. hair setting spr ay, nail polish remover, stain remover,
cleaning solvent, etc.)
a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger: do not use the dr yer
a explosion hazard.
– Do n ot put laundry containing foamed mate rial/rubber in the dryer
a elastic
material may be destroyed and th e dryer may be damaged due to pos sible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and m ay be contaminated wit h fluff.
Defect – Do not use the dryer if it is d efective or if you suspect it is.
Repairs must only be carrie d out by the after-sales service.
– Do not use the drye r if the mains cable is defective. To avoid danger, only
have the defective mains cabl e replaced by the after-sales service.
– Always pull the mains plug out of the socket before chan ging the bulb for the
interior light
a risk of electric shock.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: pull out the appliance plug, then cut off the mains c able from the
appliance.
Dispose of at municipal was te disposal facility.
– Packaging: do not lea ve children alone with packing parts
a risk of suffocation.
– All materials are e nvironmentally sound and c an be reused.
Dispose of in an environmentally -responsible manner.
Dryer
en Instruction manu al

1 2 na
... and adapt to individual requirements
Never start the dryer if it is damaged!
Inform your after-sales service. Inspecting the
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.
See programme overview on page 7.
See also separate instructions for “Woollens basket
(depending on model)
Your new dryer
Congratulations - You have chosen a modern, high-quality Bosch
domestic appliance.
The condensation dryer is distinguished by its economical energy
consumption.
Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be pleased
to help.
Disposal in an environmentally-responsible manner
Dispose of packaging in an environmentally-responsible manner.
This appliance is labelled in accordance with the European
guideline 2002/96/EG on waste electrical and electronic
equipment - WEEE.
The guideline provides an EU-wide framework for the return and
recycling of old appliances.
For further information about our products, accessories, spare parts
and services, please visit: www.bosch-home.com
Intended use Preparing for installation, see Page 8
Selecting and adjusting the programme
ʋfor domestic use only,
ʋonly to be used for drying fabrics that have been
washed with water.
Do not leave children
unsupervised near the dryer.
Keep pets away from the dryer.
The dryer can be operated by children 8 years old
and older, by persons with reduced physical,
sensory or mental abilities and by persons with
insufficient experience or knowledge if they are
supervised or have been instructed in its use by
a responsible adult.
Select the drying programme ...
Press the Make sure your hands are dry.
Hold the plug only. Connecting the
mains plug
All buttons are sensitive and only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted! 
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋInformation on laundry . . . . . . . . . . . . . . 5
ʋFine adjustment of the drying result . . 5/6
ʋCare and cleaning . . . . . . . . . . . . . . . . . 6
ʋProgramme overview . . . . . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport. . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... / After-sales service . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11 ('caV)caaaaaaaa+aaaaaa
VV
H+Ro
Additional
functions
Service displays
H+R/"drying, iron dry, cupboard dry, fluff/finished
n(Container) Empty the condensation container.
o(Filter) Clean the fluff filter and/or air cooler under running water aPage 4/6.
Programme selector
ʋV(Low Heat)
Reduced temperature for delicate fabrics 'that require
a longer drying time; e.g. for polyacrylics, polyamide, elastane or acetate.
Fine adjustment
of the drying
result
The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3) for the
Cottons,Synthetics,LIFMix and Super 40’ programmes apresetting = 0. After
one of these programmes has been finely adjusted, the setting is retained for the others.
Further information aPage 5/6.
0, 1, 2, 3
Display panel
Read these instructions and the separate
Energy-saving mode instructions before
operating the dryer.
Observe the safety instructions on page 11.

3 4
Emptying condensation
Empty container after each drying operation!
1. Pull out condensation container keeping it horizontal.
2. Pour out condensation.
3. Always push container in fully until it clicks into place.
If n(Container) flashes in the display panel aWhat to do if..., Page 10.
Cleaning the fluff filter
Clean the fluff filter after each drying operation.
1. Open the door, remove fluff from door/door area.
2. Pull out and fold open the fluff filter.
3. Remove the fluff (by wiping the filter with your hand).
If the fluff filter is very dirty or blocked, rinse with warm water and dry
thoroughly.
4. Close and reinsert the fluff filter.
Switching off the dryer
Turn the programme selector to 0(Off).
Do not leave laundry in the dryer.
Removing the laundry
The automatic anti-crease function causes the drum to move at specific intervals, the washing remains
loose and fluffy for an hour (two hours if the additional Reduced Ironing function is also
selected-depending on model).
... and adapt to individual requirements
Inspecting the
dryer
Sorting and loading laundry
See also separate instructions for “Woollens basket”
Selecting and adjusting the programme
Drying
Condensation container
Control panel
ʋʋ
Select the drying programme ...
Press the (start) button
1
2
3
Connecting the
mains plug
Drying
Drum
All buttons are sensitive and only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted! Air inlet
Fluff filter
Drum interior light
(depending on model)
Maintenance
flap Programme end once lights up in the display.
Interrupt programme removing or adding laundry.
The drying cycle can be interrupted for a brief period so that laundry may be added or removed.
The programme selected must then be resumed and completed.
Never switch the dryer off before the drying process has ended.
Drum and door may be hot!
1. Open door, the drying process is interrupted.
2. Load or remove laundry and close door.
3. If required, select a new programme and additional functions.
4. Press the (start) button.
ʋʋʋʋʋʋʋʋʋʋʋʋʋ('caV)caaaaaaaa+aaaaaa
VV
H+Ro
H+R"noaʋV'LIFaa

56
na
ʋʋ
1
2
3

ʋʋʋʋʋʋʋʋʋʋʋʋʋInformation on laundry ...
Labelling of fabrics
Follow the manufacturer's care information.
(Drying at normal temperature.
'cDrying at low temperature aalso select V(Low Heat).
)cDo not machine dry.
Observe safety instructions without fail aPage 11!
Do not tumble-dry the following fabrics for example:
– Impermeable fabrics (e.g. rubber-coated fabrics).
– Delicate materials (silk or curtains made from synthetic material) athey may crease
– Laundry contaminated with oil.
Drying tips
– To ensure a consistent result, sort the laundry by fabric type and drying programme.
– Always dry very small items (e.g. baby socks) together with large items of laundry (e.g. hand
towel).
– Close zips, hooks and eyelets, and button up covers.
Tie fabric belts, apron strings, etc. together
– Do not over-dry easy-care laundry arisk of creasing!
Allow laundry to finish drying in the air.
– Do not dry woolens in the dryer, only use to freshen them up aPage 7, Woollens Finish
Programme (depending on model).
– Do not iron laundry immediately after drying, fold items up and leave for a while athe
remaining moisture will then be distributed evenly.
– The drying result depends on the type of water used during washing. aFine adjustment
of the drying result aPage 5/6.
– Machine-knitted fabrics (e.g. T-shirts or jerseys) often shrink the first time they are dried a
do not use the +:Very Dry programme.
– Starched laundry is not always suitable for dryers astarch leaves behind a coating that
adversely affects the drying operation.
– Use the correct dosage of fabric softener as per the manufacturer's instructions when
washing the laundry to be dried.
– Use the timer programme for small loads athis improves the drying result.
Environmental protection / Energy-saving tips
– Before drying, spin the laundry thoroughly in the washing machine athe higher the spin
speed the shorter the drying time will be (consumes less energy), also spin easy-care
laundry.
– Put in, but do not exceed, the maximum recommended quantity of laundry a
programme overview aPage 7.
– Make sure the room is well ventilated during drying.
– Do not obstruct or seal up the air inlet.
– Keep the air cooler clean aPage 6 “Care and cleaning”.
Fine adjustment of the drying result
Adjustment of the levels of dryness
1 x to
the right
Press and hold V(Low Heat)
and turn 5 x to the right
Press V(Low Heat) until
the required level is reached
Turn to
0(Off)
Turn to
0(Off)
Fine adjustment of the drying result
H(drying), (iron dry), +(cupboard dry),
R/(fluff/finished) are displayed in sequence.
Short signal when changing from level 3 to 0, otherwise
long signal.
Care and cleaning
Dryer housing, control panel, air cooler, moisture sensors
– Wipe with a soft, damp cloth.
– Do not use harsh cleaning agents and solvents.
– Remove detergent and cleaning agent residue immediately.
Clean the protective filter 5 - 6 times a year
or if o(Filter) flashes after cleaning the fluff filter.
Air cooler / Protective filter
When cleaning, only remove the protective filter. Clean the air cooler
behind the protective filter once a year.
– Allow the dryer to cool.
– Residual water may leak out, so place an absorbent towel
underneath the maintenance door.
1. Unlock the maintenance door.
2. Open the maintenance door fully.
3. Turn both locking levers towards each another.
4. Pull out the protective filter/air cooler.
Do not damage the protective filter or air cooler.
Clean with warm water only. Do not use any hard or sharp-edged
objects.
5. Clean the protective filter/air cooler thoroughly,
Allow to drip dry.
6. Clean the seals.
7. Re-insert the protective filter/air cooler,
with the handle facing down.
8. Turn back both locking levers.
9. Close the maintenance door until the lock clicks into place.
Moisture sensors
The dryer is fitted with stainless steel moisture sensors. The sensors
measure the level of moisture in the laundry. After a long period of
operation, a fine layer of limescale may form on the sensors.
1. Open the door and clean the moisture sensors with a damp sponge
which has a rough surface.
Do not use steel wool or abrasive materials.
Only when switched off!
H+R"noaʋV'LIFaa

7
Programme overview also see Page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying. After drying...
c
iron laundry

lightly iron laundry
@c
do not iron laundry
c
mangle laundry
PROGRAMMES TEXTILE TYPE AND INFORMATION ** Cottons max. 7 kg Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen.
** Synthetics max. 3.5 kg Non-iron laundry made of synthetic fibres and blended fabric, easy-care cotton. ** LIFMix max. 3 kg Mixed items of laundry madeof cotton and synthetics (Mix).
Iron Dry c÷@c Fabrics suitable for ironing (iron fabrics in order to avoid creasing). +. Cupboard Dry @Single-layer fabrics. *+: Very Dry @Fabrics made of thick, multilayered items of clothing.
Timed progr. 20 min max. 3 kg Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.
Also for subsequent drying.
Super 40’ max. 2 kg
Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric and loading capacity.
*for Cottons and Synthetics programmes only **Dryness levels can be selected individually a+:Very Dry, +. Cupboard Dry and Iron Dry (depending on the model).
Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.
9306 / 9000847734 *847734* Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Deutschland
WTE84102SN
8
Installation
– Delivery specification: dryer, instructions for installation and use, woollens basket
(depending on model).
– Check dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by any of the protruding parts (e.g. the door) as they may break off.
– Do not set up in a room that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the appliance connected by an expert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean, level
and solid surface.
– Keep the cooling grille at the front of the dryer
unobstructed.
– Keep the area around the dryer clean.
– Make the dryer level using the threaded feet
and a spirit level.
Do not remove the threaded feet under any
circumstances.
Mains connection see safety instructions a Page 11.
– Connect to an AC earthed socket. If in doubt have the socket checked by an expert.
– The mains voltage and the voltage shown on the rating plate ( a Page 9) must correspond.
– The connected load and necessary fuse protection are specified on the rating plate.
Converting the installed load Note the fuse protection of the socket.
10/16 Amps
Frost protection / Transport
Preparation
1. Empty the condensation container
a page 4.
2. Select any programme using the programme selector.
3. Press the (start) button
a condensation is pumped into the container.
4. Wait 5 min., and then empty the condensation container again.
5. Turn the programme selector to 0(Off).
1.
Take all accessory parts
out of the drum.
The drum must be empty.
Make sure that the air
inlet remains unobstructed
Clean and level
2.
3.
turn to
0(Off)
Press and hold selection
then turn 3 x to the right turn to
0(Off)
Set
amperage
1 x to the
right
Feedback (depending on model): off
flashes
10 A
16 A 33
Do not operate the dryer if
there is a danger of frost.
Do not set up the dryer behind a door or sliding
door as this may obstruct or prevent the dryer door
from opening. This will prevent a potentially fatal
danger to children from locking themselves in.
ʠʠac++c+
ʠʠ
a
ʠnʠo
a
ʠʠʠʠaʠaaaaʠaaaaaʠʠʠ
aa
ʠ
aaaaaaaaaa

c@c c
LIFc÷@c +@+@a++
aaa
 a
1.
2.
3. 33Do not operate the dryer if
9
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)
Weight approximately 45 kg
Max. capacity 7 kg
Condensation container 4.2 l
Connection voltage
Connected load
Fuse protection see appliance rating plate
Ambient temperature
Product number/
Production number
You can find the rating plate on the back of the dryer.
ʠDrum interior light (depending on model) (bulb E14, 25 W)
The drum lights up after the door is opened or closed, and after the programme starts,
and switches off automatically. Changing the bulb apage 10.
Consumption rates (The value on the label is achieved at the maximum heat setting.)
Fabrics/programmes Residual moisture in the
fabrics after spinning
Drying time** Energy
consumption**
cCottons 7 kg 10 A 16 A 10 A 16 A
+. Cupboard Dry* 1400 rpm (50%) 112 min 98 min 3.54 kWh 3.54 kWh
1000 rpm (60%) 131 min 115 min 4.13 kWh 4.13 kWh
800 rpm (70%) 150 min 133 min 4.72 kWh 4.72 kWh
Iron Dry* 1400 rpm (50%) 93 min 69 min 2.55 kWh 2.55 kWh
1000 rpm (60%) 111 min 82 min 3.22 kWh 3.22 kWh
800 rpm (70%) 130 min 94 min 3.90 kWh 3.90 kWh
Synthetics 3.5 kg
+. Cupboard Dry* 800 rpm (40%) 48 min 42 min 1.35 kWh 1.35 kWh
600 rpm (50%) 60 min 51 min 1.65 kWh 1.65 kWh
* Programme setting for testing in accordance with applicable standard EN61121.
** The values may differ from those specified, depending on the type of fabric, composition of
laundry to be dried, residual moisture in the fabric and the amount of laundry being loaded.
Fabrics/programmes Drying time Annual energy consumption
cCottons 7 kg / 3.5 kg*
+. Cupboard Dry*** 89 min / per cycle 497 kWh / per year
***Programme setting for testing and energy labelling in accordance with Directive 2010/30/EU.
Optional accessories (from after-sales service using order number)
Platform
For easier loading and unloading. The basket contained in the drawer can be used to carry
the laundry.
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. The dryer must be fastened to the washing machine using this connection set.
With pull-out worktop: WTZ 11300
Connection fittings for condensation outlet
The condensation is conveyed directly via a hose.
Installation underneath the worktop
Instead of the appliance covering plate, you must have a metal cover fitted by
a specialist.
WMZ
20500
WTZ
11310
WTZ
1110
WTZ
10290
10
What to do if ...
If you cannot rectify a fault yourself (e.g. switching off/on), please contact our after-sales
service. We will always find an appropriate solution and will avoid unnecessary visits by
engineers. Trust the expertise of the manufacturer and rest assured that the repair will be
carried out by trained service technicians using original spare parts. The contact details of your
local after-sales service can be found in the enclosed after-sales service directory, or by
calling one of these numbers:
–GB 0844 8928979 (Calls from a BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may apply.)
–IE 01450 2655 (0.03 € per minute at peak. Off peak 0.0088 € per minute.)
When contacting the after-sales service, please quote the appliance's product number (E no.)
and production number (FD) (see the inside of the door).
Set the programme selector to 0(Off) and remove the appliance plug from the socket.
ʠThe (start) indicator lamp does
not light up.
Mains plug plugged in?
Programme selected?
Check the socket fuse.
ʠThe display panel light and
indicator lights (depending on
model) go out and the (start)
indicator light flashes.
Energy-saving mode is activated a
see the separate Energy-saving mode instructions.
ʠThe n(Container) and
(start) indicator lamp flash.
Empty the condensation container.
If featured, check hose for condensation outlet.
ʠThe o(Filter) and
(start) indicator lamp flash.
Clean the fluff filter and/or air cooler under running water
a Page 4/6.
ʠDryer does not start. (start) button selected?
Door closed?
Programme set?
Ambient temperature greater than 5 °C?
ʠWater is running out. Align dryer horizontally.
Clean air cooler seal.
ʠThe door opens by itself. Push the door closed until you hear it engage.
ʠCreasing. Laundry load exceeded?
Remove articles of clothing immediately after the end of the
programme, hang up and pull into shape.
Unsuitable programme selected aPage 7.
ʠDrying result is not satisfactory
(laundry feels too damp).
Warm laundry feels damper than it actually is.
The selected programme does not suit the load. Use another
drying programme or, in addition, select the time programme a
Page 7.
Use fine adjustment for the drying result aPage 1/2 and 5/6.
Fine layer of limescale on the humidity sensors
aClean the humidity sensors aPage 6.
Programme termination, e.g. tank full, mains power supply failure,
door open or maximum drying time reached.
ʠDrying time too long. Rinse the fluff filters under running water aPage 4.
Insufficient supply of air aensure that air can circulate.
Air inlet possibly blocked aClear inlet aPage 8.
Ambient temperature higher than 35 °C aventilate the room.
ʠThe humidity in the room
increases significantly.
Make sure the room is sufficiently ventilated.
ʠMains failure. Remove laundry from the dryer immediately and spread out.
This allows the heat to dissipate.
ʠOne or more indicator lights for
programme status are flashing.
Clean filter and air cooler a Page 4/6.
Check installation conditions
a Page 8.
Switch off, leave to cool down, switch on again, restart
programme.
ʠThe interior light is not working
(depending on model).
Pull out the appliance plug, remove the cover cap in the interior
above the door (use Torx 20 screw driver) and replace the bulb.
Close the cover cap.
Never operate the dryer without a cover cap.
aaaaaaaaaa

c@c c
LIFc÷@c +@+@a++
aaa
 a
1.
2.
3. 33Do not operate the dryer if
ʠʠac++c+ʠʠ
a
ʠnʠo
a
ʠʠʠʠaʠaaaaʠaaaaaʠʠʠ
aa
ʠ
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immediately or disconnect the fuse.
ONLY use the
dryer...
– in rooms inside the house.
– to dry fabrics.
The dryer must
NEVER...
– be used for other purposes than those described above.
– be modified in terms of its technology or attributes.
Dangers – The dryer must not be used by children or persons who have not been
instructed in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets.
Make especially sure that cigarette lighters are removed as they constitute an
a explosion hazard.
– Do not lean or sit on the door a risk of tipping.
Installation – Secure loose cables a tripping hazard.
– Do not operate the dryer if there is a risk of frost.
Mains
connection
– Connect the dryer according to specifications to an AC earthed socket, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/couplings and/or extension cables.
– Do not hold the appliance plug with wet hands
a risk of electric shock.
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead a risk of electric shock.
Operation – Only load the drum with laundry.
Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting spray, nail polish remover, stain remover,
cleaning solvent, etc.) a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger: do not use the dryer
a explosion hazard.
– Do not put laundry containing foamed material/rubber in the dryer a elastic
material may be destroyed and the dryer may be damaged due to possible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and may be contaminated with fluff.
Defect – Do not use the dryer if it is defective or if you suspect it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only
have the defective mains cable replaced by the after-sales service.
– Always pull the mains plug out of the socket before changing the bulb for the
interior light a risk of electric shock.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: pull out the appliance plug, then cut off the mains cable from the
appliance.
Dispose of at municipal waste disposal facility.
– Packaging: do not leave children alone with packing parts
a risk of suffocation.
– All materials are environmentally sound and can be reused.
Dispose of in an environmentally-responsible manner.
Dryer
en Instruction manual
