Bosch Ciso User manual

Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
F 016 L70 560 (2008.11) O / 291 WEU
Ciso
de Originalbetriebs-
anleitung
en Original instructions
fr Notice originale
es Manual original
pt Manual original
it Istruzioni originali
nl Oorspronkelijke
gebruiksaanwijzing
da Original
brugsanvisning
sv Bruksanvisning i
original
no Original driftsinstruks
fi Alkuperäiset ohjeet
el 

tr 

Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
F 016 L70 560 (2008.11) O / 291 WEU
Ciso
de Originalbetriebs-
anleitung
en Original instructions
fr Notice originale
es Manual original
pt Manual original
it Istruzioni originali
nl Oorspronkelijke
gebruiksaanwijzing
da Original
brugsanvisning
sv Bruksanvisning i
original
no Original driftsinstruks
fi Alkuperäiset ohjeet
el 

tr 

Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
F 016 L70 560 (2008.11) O / 291 WEU
no Original driftsinstruks
fi Alkuperäiset ohjeet
el 

tr 

F 016 L70 560_Cover.indd 1 07/01/2009 16:01:34

Deutsch . . . . . . . . . . . . . . . . . Seite 8
English. . . . . . . . . . . . . . . . . . Page 32
Français. . . . . . . . . . . . . . . . . Page 53
Español . . . . . . . . . . . . . . . . . Página 76
Português . . . . . . . . . . . . . . . Página 100
Italiano . . . . . . . . . . . . . . . . . Pagina 122
Nederlands . . . . . . . . . . . . . . Pagina 146
Dansk. . . . . . . . . . . . . . . . . . . Side 168
Svenska . . . . . . . . . . . . . . . . . Sida 189
Norsk . . . . . . . . . . . . . . . . . . . Side 208
Suomi . . . . . . . . . . . . . . . . . . Sivu 227
Qnnjplm` [hncgd 247
'P>8M2&.E3. 270
6
18
29
41
53
64
76
87
98
108
118
128
140
1
2
3
5
6
7
8910
4
Ciso
Deutsch | 11| 3
3
Bosch Power Tools F 016 L70 560 | (25.11.08)

A3
4
5
A2
3
A1
2
1
2 9
2 9
7
2 9
7
B10B9
B8B7 21
3
B6B5
B4B3 8mm
B2B1
24 | Deutsch2|
4
F 016 L70 560 | (25.11.08) Bosch Power Tools

C2
3
4
C1
1
2
7
10
2
2
11
C4
8
7
C3
6
5
10
211
2
12
Deutsch | 11| 3
5
Bosch Power Tools F 016 L70 560 | (25.11.08)

en
Safety Notes
f
Improper use can cause serious injury. Please read all
safety precautions and the user manual before use.
General Power Tool Safety Warnings
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or seri-
ous injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Explanation of symbols
Read all safety warnings and all instructions. Fail-
ure to follow the warnings and instructions may re-
sult in electric shock, fire and/or serious injury.
Danger – rotating blade. Keep hands and feet
out of openings while the machine is running.
Do not use the machine in the rain or leave it
outdoors when it is raining.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable liq-
uids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
WARNING
c) Keep children and bystanders away while operat-
ing a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapt-
er plugs with earthed (grounded) power tools. Un-
modified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded sur-
faces, such as pipes, radiators, ranges and refrig-
erators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for car-
rying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges and moving
parts. Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors, use an ex-
tension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is un-
avoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
24 | Deutsch2|
18
English
F 016 L70 560 | (25.11.08) Bosch Power Tools

3) Personal safety
a) Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A mo-
ment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will re-
duce personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on
the switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before turn-
ing the power tool on. A wrench or a key left at-
tached to a rotating part of the power tool may re-
sult in personal injury.
e) Do not overreach. Keep proper footing and bal-
ance at all times. This enables better control of the
power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jew-
ellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust col-
lection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct pow-
er tool for your application. The correct power tool
will do the job better and safer at the rate for which
it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool be-
fore making any adjustments, changing accesso-
ries, or storing power tools. Such preventive safe-
ty measures reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the pow-
er tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of un-
trained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
Deutsch | 11| 3
19
English
Bosch Power Tools F 016 L70 560 | (25.11.08)

f) Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a haz-
ardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
b) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together
may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acci-
dentally occurs, flush with water. If liquid con-
tacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or
burns.
6) Service
a) Have your power tool serviced by a qualified re-
pair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
Safety Warnings for Cordless Garden Pruners
fThis appliance is not intended for use by persons (in-
cluding children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowl-
edge, unless they have been given supervision or in-
struction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
fMinors should never be allowed to operate the tool; it
should never be left unattended and when not in use
should be stored in a locked place out of the reach of
children.
fDon’t use the machine or perform battery charging op-
erations in the rain.
fDon’t leave the machine in rain or wet locations.
fKeep bystanders well away from your work area.
fBe careful not to catch foreign matter between the
blades. If the blades are jammed with foreign matter,
immediately switch off the machine. Then remove the
foreign matter from the blades.
fTake care, avoid cutting electrical wires that may be
hidden.
24 | Deutsch2|
20
English
F 016 L70 560 | (25.11.08) Bosch Power Tools

fKeep your free hand away from the cutting area. Nev-
er touch the blades. They are very sharp and you may
cut yourself.
fBe vigilant when operating to ensure that the fingers
on the hand used to hold or move twigs to be pruned
are not exposed to the cutting blade.
fIf the On/Off switch 9is released quickly then the
blade 2will not return to the fully open position, but
will stay in its current position. Pulling the On/Off
switch 9to position “2.” will return the blade 2to the
fully open position.
fDon’t force the machine to make it cut. You could slip
and injure yourself or cut something else unintention-
ally.
fAlways check the blades carefully before operation.
fHandle the blades with extreme care to prevent cuts
or injury from the blades.
fOperate the “safety lock” after each use and before at-
tempting to perform inspection or maintenance.
fAlways wear protective gloves when using, adjusting
or cleaning the machine.
fOnly use the machine for it’s intended use (see “In-
tended Use”).
Safety Warnings for battery chargers
fKeep the battery charger away from rain or moisture.
Penetration of water in the battery charger increases
the risk of an electric shock.
fDo not charge other batteries. The battery charger is
suitable only for charging Bosch lithium ion batteries
within the listed voltage range. Otherwise there is dan-
ger of fire and explosion.
fKeep the battery charger clean. Contamination can
lead to danger of an electric shock.
fBefore each use, check the battery charger, cable
and plug. If damage is detected, do not use the bat-
tery charger. Never open the battery charger your-
self. Have repairs performed only by a qualified tech-
nician and only using original spare parts. Damaged
battery chargers, cables and plugs increase the risk of
an electric shock.
fDo not operate the battery charger on easily inflam-
mable surfaces (e. g., paper, textiles, etc.) or sur-
roundings. The heating of the battery charger during
the charging process can pose a fire hazard.
Functional Description
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
This machine is intended for domestic use in pruning
branches and plants with a thickness up to 9 mm (hard-
wood) and 14 mm (softwood).
Deutsch | 11| 3
21
English
Bosch Power Tools F 016 L70 560 | (25.11.08)

Delivery Scope
Carefully remove the machine from its packaging and
check if the following parts are complete:
–Ciso
–Battery Charger**
–Operating instructions
When parts are missing or damaged, please contact your
dealer.
** country specific
Product Features
The numbering of the product features refers to the illus-
tration of the machine on the graphics page.
1Blade – fixed
2Blade – moving
3Battery charge-control indicator
4Serial number
5Socket for charge plug
6Plug connector for charger
7Safety lock
8Battery charger
9On/Off switch
10 Blade screw
11 Spacer
Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Measured values determined according to EN 60745 (no-
load).
Typically the A-weighted sound pressure level of the
product is 67.2 dB(A).
The hand-arm acceleration is typically below 2.5 m/s2.
Cordless Garden Pruner Ciso
Article number 3 600 H55 ...
Rated voltage V 3.6
Number of battery cells 1
Cutting capacity mm
mm
9 (Hardwood)
14 (Softwood)
Charging time h 5
Weight according to
EPTA-Procedure 01/2003 kg 0.6
Battery Charger
Article number 2 607 225 ...
Charging current mA 250
Allowable charging temper-
ature range °C 0–45
The values given are valid for nominal voltages [U] of 230/240 V.
For lower voltage and models for specific countries, these values
can vary.
24 | Deutsch2|
22
English
F 016 L70 560 | (25.11.08) Bosch Power Tools

Declaration of Conformity
We declare under our sole responsibility that the product
described under “Technical data” is in conformity with
the following standards or standardization documents:
EN 60745 (battery powered product) and EN 60335 (bat-
tery charger) according to the provisions of the directives
2006/95/EC, 2004/108/EC, 98/37/EC (until
28 Dec 2009), 2006/42/EC (from 29 Dec 2009).
Technical file at:
Bosch Lawn and Garden Ltd., PT-LG/EAE,
Stowmarket, Suffolk IP14 1EY, England
2009
Leinfelden, 05.01.2009
Made in UK 2009,
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Assembly
For Your Safety
f
Warning! Switch off and engage the safety lock 7 be-
fore adjusting or cleaning.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
Battery Charging (see main figure)
fDo not use other battery chargers. The supplied bat-
tery charger is designed for the Lithium-Ion battery in
your machine.
Observe correct mains voltage: The voltage of the power
source must agree with the voltage specified on the
nameplate of the unit. Equipment marked with 230 V can
also be connected to 220 V or 240 V.
The Electronic Cell Protection (ECP) protects the lithium
ion battery against deep discharging. When the battery is
run down or discharged, the machine is shut off by means
of a protective circuit: The blade no longer moves.
Do not continue to press the On/Off
switch after the machine has been auto-
matically switched off. The battery can be damaged.
Plug the mains plug of the battery charger into a socket
outlet and the charger plug 6into the socket 5on the rear
side of the handle.
The battery charge indicator 3lights up green to indicate
the charging procedure. The battery is fully charged as
soon as the battery charge indicator 3is no longer lit.
–During the charging procedure, the handle of the ma-
chine warms up. This is normal.
–Disconnect the battery charger from the mains supply
when not using it for longer periods.
–The power tool cannot be used during the charge pro-
cedure; it is not defective when inoperative during the
charging procedure.
f
Protect the battery charger against moisture!
WARNING
Deutsch | 11| 3
23
English
Bosch Power Tools F 016 L70 560 | (25.11.08)

Operation
Initial Operation
Switching On (see figures A1 – A2)
nDis-engage the safety lock 7by moving the button as
shown.
oFully insert finger and pull the
On/Off switch 9back from pos-
tion „1.“ to postion „2.“ (work-
ing position) and hold.
pTo close the blade 2pull the
On/Off switch 9back to postion
“3.”. To open the blade 2return
On/Off switch 9to position “2.”.
Switching Off (see figure A3)
qRelease the On/Off switch 9and allow it to return to
position “1.”. The blade 2will then return to the fully
open position.
rEngage the safety lock 7by moving the button as
shown.
Note: If the On/Off switch 9is released quickly then the
blade 2will not return to the fully open position, but will
stay in its current position. Pulling the On/Off switch 9to
position “2.” will return the blade 2to the fully open po-
sition.
2.
1. 3.
Working Advice
Pruning Tips (see figures B1 – B10)
fNever operate the machine in an awkward posture.
This may cause serious injury.
fKeep your free hand away from the cutting area. Nev-
er touch the blades. They are very sharp and you may
cut yourself.
B1 Always wear protective gloves while pruning.
B2 Never cut too close to the stem so the wound can
heal properly.
B3 Always make the cut about 8 mm from the bud.
B4 The cut should slope away from the bud so the rain
can run off.
B5 If you remove an entire stem, cut back to the point
where it branched.
B6 Never push the blade of the pruner into the ground
to cut suckers.
B7 Cut branches one by one as shown.
B8 Remove overcrowds or crossing stems.
B9 Remove thin or weak growth.
B10 Always remove dead, damaged and diseased
branches.
24 | Deutsch2|
24
English
F 016 L70 560 | (25.11.08) Bosch Power Tools

Pruning Seasons
Softwood
(cutting up to 14 mm)
Medium wood
(cutting up to 12 mm)
Hardwood
(cutting up to 9 mm)
Character of wood Period
Laurel January, February, March, April
Magnolia January, February, March, April
Character of wood Period
Apple January
Deutzia June, July
Forsythia April, May, December
Philadelphus June, July
Roses September, October, November
Weigela June, July
Character of wood Period
Holm oak January, February, December
Hornbeam January, February, December
Maintenance and Service
Maintenance and Cleaning
Warning! Switch off and engage the safety
lock 7.
For safe and proper working, always keep the
machine clean.
Always wear protective gloves when using, ad-
justing or cleaning the machine.
Regularly check for obvious defects such as loose fixings,
and worn or damaged components.
If the machine should happen to fail despite the care tak-
en in manufacture and testing, repair should be carried
out by an authorised customer service agent for Bosch
garden products.
In all correspondence and spare parts orders, please al-
ways include the 10-digit article number given on the type
plate of the machine.
Changing the Blade (see figures C1 –C4)
Warning! Switch off and engage the safety
lock 7.
Always wear protective gloves when using, ad-
justing or cleaning the machine.
Never attempt to operate the machine without
the blade, spacer or screw correctly secured
to prevent damage to the machine.
Ensure blade is in the fully open position and
safety lock 7 is engaged.
Deutsch | 11| 3
25
English
Bosch Power Tools F 016 L70 560 | (25.11.08)

nEngage the safety lock 7by moving the button as
shown.
oUsing a 5 mm hex wrench socket key (not provided) to
remove the blade screw 10 which secures the blade.
Remove spacer 11.
pqRemove the blade 2as shown. Be careful not to al-
low any foreign matter to become attached to the blade
gear and do not damage it.
rsInsert blade 2as shown. Ensure that the blade 2has
located in the transmission link 12.
tRotate the blade 2to the fully open postion. Check the
blade 2location by gently pulling. If the blade 2is correct-
ly located then blade cannot be removed.
f
Incorrect location of the blade will damage the ma-
chine.
uRefit spacer 11. Ensure spacer 11 is located through
fixed blade and moving blade.
Refit the blade screw 10 and tighten it by using a 5 mm
hex wrench socket key (not provided). Do not overtight-
en.
fEnsure replacement parts fitted are Bosch approved.
After Pruning/Storage
f
Warning! Switch off and engage the safety lock 7.
f
Always wear protective gloves when using, adjusting
or cleaning the machine.
Clean the exterior of the machine thoroughly using a soft
brush and cloth. Do not use water, solvents or polishes.
Remove all debris.
Always lubricate the cutting blade with protective spray
before storage.
Store the machine in a secure, dry place out of the reach
of children with the safety lock 7engaged. Do not place
other objects on top of the machine.
After-sales Service and Customer Assistance
Our after-sales service responds to your questions con-
cerning maintenance and repair of your product as well as
spare parts. Exploded views and information on spare
parts can also be found under:
www.bosch-pt.com
Our customer consultants answer your questions con-
cerning best buy, application and adjustment of products
and accessories.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: [phone]
Fax: [phone]
E-Mail: [email protected]
24 | Deutsch2|
26
English
F 016 L70 560 | (25.11.08) Bosch Power Tools

Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: [phone]
Fax: [phone]
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: [phone]
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch.com.au
Transport
The battery is tested according to UN document
ST/SG/AC.10/11/Rev.3 Part III, subsection 38.3. It has ef-
fective protection against internal overpressure and short
circuiting as well as devices for the prevention of violent
rupture and dangerous reverse current flow.
The lithium-equivalent content in the battery is below ap-
plicable limit values. Therefore, the battery is not subject
to national or international regulations pertaining to dan-
gerous mediums, neither as an individual component nor
when inserted into a machine. However, the regulations
governing dangerous goods may be relevant when trans-
porting several batteries. In this case, it can be necessary
to comply with special conditions (e.g., concerning the
packaging). For more information, please refer to the in-
struction sheet (in English) under the following Internet
address: http://purchasing.bosch.com/en/start/
Allgemeines/Download/index.htm.
Disposal
The machine, accessories and packaging should be sort-
ed for environmental-friendly recycling.
Only for EC countries:
Do not dispose of power tools into house-
hold waste!
According the European Guideline
2002/96/EC for Waste Electrical and Elec-
tronic Equipment and its implementation
into national right, power tools that are no
longer usable must be collected separately and disposed
of in an environmentally correct manner.
Deutsch | 11| 3
27
English
Bosch Power Tools F 016 L70 560 | (25.11.08)

Battery packs/batteries:
Li-ion:
Please observe the instructions in sec-
tion “Transport”, page 50.
Do not dispose of battery packs/batteries into household
waste, fire or water. Battery packs/batteries should be
collected, recycled or disposed of in an environmental-
friendly manner.
Only for EC countries:
Defective or dead out battery packs/batteries must be re-
cycled according the guideline 91/157/EEC.
Batteries no longer suitable for use can be directly re-
turned at:
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: [phone]
Fax: [phone]
E-Mail: SPT-Technical.[email protected]
Subject to change without notice.
24 | Deutsch2|
28
English
F 016 L70 560 | (25.11.08) Bosch Power Tools
