Bosch GRG18V-3600C Assembly instructions

Operating / Safety Instructions
Consignes d’utilisation / de sécurité
Instrucciones de funcionamiento y seguridad
Call Toll Free for Consumer Information & Service Locations
Pour obtenir des informations et les adresses de nos centres de service après-vente, appelez ce numéro gratuit
Llame gratis para obtener información para el consumidor y ubicaciones de servicio
For English Version
See page 2 ●Version française Voir page 19 ●Versión en español Ver la página 37
IMPORTANT
Read Before Using ●IMPORTANT Lire avant usage ●IMPORTANTE Leer antes de usar
1-877-BOSCH99 (1-877-267-2499) www.boschtools.com
GRG18V-3600C
160992A8AK GRG18V-3600C 20230616.indd 1160992A8AK GRG18V-3600C 20230616.indd 1 6/16/2023 7:50:07 PM6/16/2023 7:50:07 PM

-2-
The definitions below describe the level of severity for each signal word.
Please read the manual and pay attention to these symbols.
This is the safety alert symbol. It is used to alert you to po-
tential personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Table of Contents
Safety Symbols
Safety Symbols ....................2
General Power Tool Safety Warnings ....3
Safety Rules for Cordless Rivet Tool.....5
Additional Safety Warnings ...........6
FCC Caution ......................6
Industry Canada ...................6
Specications .....................7
Intended Use ......................7
Symbols..........................8
Getting to Know Your Product ........10
Assembly ........................11
Inserting and Releasing Battery
Pack ......................11
Changing the Nosepiece ..........11
Empty the Mandrel Container ......11
Operation .......................12
Suitable Blind Rivet/Nosepiece
Combinations ...............12
Setting a Blind Rivet.............13
User Interface ..................14
Working Advice .................15
LED Worklight .................15
Suspension Device ..............15
Belt clip ......................15
Connectivity......................16
Connectivity functions ...........16
Functions in Conjunction with
the Power Tool ..............16
Maintenance .....................17
Cleaning or Replacing the Jaws ....17
Accessories ......................18
Service .......................18
Batteries......................18
Replacing the Built-in Coin Cell ....18
Tool Lubrication ................18
Motors . . . . . . . . . . . . . . . . . . . . . . . 18
Cleaning......................18
Accessory Storage & Maintenance...18
160992A8AK GRG18V-3600C 20230616.indd 2160992A8AK GRG18V-3600C 20230616.indd 2 6/16/2023 7:50:08 PM6/16/2023 7:50:08 PM

-3-
General Power Tool Safety Warnings
Read all safety warnings, instructions, illustrations and specifications
provided with this power tool. Failure to follow all instructions listed
below may result in electric shock, re and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Clut-
tered or dark areas invite accidents.
b. Do not operate power tools in explo-
sive atmospheres, such as in the pres-
ence of ammable liquids, gases or
dust. Power tools create sparks which
may ignite the dust or fumes.
c. Keep children and bystanders away
while operating a power tool. Distrac-
tions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs with
earthed (grounded) power tools. Un-
modied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or
grounded surfaces, such as pipes, ra-
diators, ranges and refrigerators. There
is an increased risk of electric shock if
your body is earthed or grounded.
c. Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric
shock.
d. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric
shock.
f. If operating a power tool in a damp
location is unavoidable, use a Ground
Fault Circuit Interrupter (GFCI) pro-
tected supply. Use of an GFCI reduces
the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the inu-
ence of drugs, alcohol or medication.
A moment of inattention while operat-
ing power tools may result in serious
personal injury.
b. Use personal protective equipment.
Always wear eye protection. Protective
equipment such as a dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate condi-
tions will reduce personal injuries.
c. Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and / or
battery pack, picking up or carrying
the tool. Carrying power tools with your
nger on the switch or energizing power
tools that have the switch on invites
accidents.
d. Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotat-
ing part of the power tool may result in
personal injury.
e. Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unex-
pected situations.
f. Dress properly. Do not wear loose
clothing or jewelry. Keep your hair
and clothing away from moving parts.
Loose clothes, jewelry or long hair can
be caught in moving parts.
g. If devices are provided for the connec-
tion of dust extraction and collection
facilities, ensure these are connected
160992A8AK GRG18V-3600C 20230616.indd 3160992A8AK GRG18V-3600C 20230616.indd 3 6/16/2023 7:50:08 PM6/16/2023 7:50:08 PM

-4-
General Power Tool Safety Warnings
and properly used. Use of dust collec-
tion can reduce dust-related hazards.
h. Do not let familiarity gained from
frequent use of tools allow you to
become complacent and ignore tool
safety principles. A careless action can
cause severe injury within a fraction of
a second.
4. Power tool use and care
a. Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
was designed.
b. Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with
the switch is dangerous and must be
repaired.
c. Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool
before making any adjustments, chang-
ing accessories, or storing power tools.
Such preventive safety measures reduce
the risk of starting the power tool ac-
cidentally.
d. Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools and accessories.
Check for misalignment or binding of
moving parts, breakage of parts and
any other condition that may affect the
power tool’s operation. If damaged,
have the power tool repaired before
use. Many accidents are caused by
poorly maintained power tools.
f. Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
h. Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces
do not allow for safe handling and con-
trol of the tool in unexpected situations.
5. Battery tool use and care
a. Recharge only with the charger speci-
fied by the manufacturer. A charger that
is suitable for one type of battery pack
may create a risk of re when used with
another battery pack.
b. Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and re.
c. When battery pack is not in use, keep
it away from other metal objects like
paper clips, coins, keys, nails, screws,
or other small metal objects that can
make a connection from one terminal
to another. Shorting the battery termi-
nals together may cause burns or a re.
d. Under abusive conditions, liquid may
be ejected from the battery, avoid
contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes,
additionally seek medical help. Liquid
ejected from the battery may cause ir-
ritation or burns.
e. Do not use a battery pack or tool that
is damaged or modified. Damaged or
modied batteries may exhibit unpre-
dictable behavior resulting in re, explo-
sion or risk of injury.
f. Do not expose a battery pack or tool to
fire or excessive temperature. Exposure
to re or temperature above 265 °F may
cause explosion.
g. Follow all charging instructions and do
not charge the battery pack or tool out-
side the temperature range specified
in the instructions. Charging improperly
or at temperatures outside the specied
range may damage the battery and
increase the risk of re.
6. Service
a. Have your power tool serviced by a
qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool
is maintained.
160992A8AK GRG18V-3600C 20230616.indd 4160992A8AK GRG18V-3600C 20230616.indd 4 6/16/2023 7:50:08 PM6/16/2023 7:50:08 PM

-5-
General Power Tool Safety Warnings
b. Never service damaged battery packs.
Service of battery packs should only
be performed by the manufacturer or
authorized service providers.
Safety Rules for Cordless Rivet Tool
a. Do not direct the rivet tool at yourself
or other persons during use and do not
work without the material to be riv-
eted. The blind rivet can be ejected from
the rivet tool and cause injury.
b. Do not work without a mandrel con-
tainer. Rivet mandrels are ejected from
the back of the rivet tool and can cause
injury.
c. In case of damage and improper use
of the battery, vapors may be emitted.
The battery can set alight or explode.
Ensure the area is well ventilated and
seek medical attention should you expe-
rience any adverse effects. The vapors
may irritate the respiratory system.
d. Do not open the battery. There is a risk
of short-circuiting.
e. The battery can be damaged by pointed
objects such as nails or screwdriv-
ers or by force applied externally. An
internal short circuit may occur, causing
the battery to burn, smoke, explode or
overheat.
f. Only use the battery with products
from the manufacturer. This is the only
way in which you can protect the battery
against dangerous overload.
g. Protect the battery against heat,
e.g. against continuous intense
sunlight, fire, dirt, water and
moisture. There is a risk of
explosion and short-circuiting.
h. Caution! When using the power tool
with Bluetooth®, a fault may occur in
other devices and systems, aeroplanes
and medical devices (e.g. pacemakers,
hearing aids). Also, damage to people
and animals in the immediate vicinity
cannot be completely excluded. Do not
use the power tool with Bluetooth®
in the vicinity of medical devices, gas
stations, chemical plants, areas with a
potentially explosive atmosphere or in
blasting areas. Do not use the power
tool with Bluetooth® in aircraft. Avoid
using the product near your body for
extended periods.
i. The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Robert Bosch Power Tools
GmbH is under license.
j. Ensure that the coin
cell is kept out of
the reach of chil-
dren. Coin cells are
dangerous.
k. Coin cells must nev-
er be swallowed or inserted into any
other part of the body. If you suspect
that someone has swallowed a coin cell
or that a coin cell has entered the body
in another way, seek medical attention
immediately. Swallowing coin cells can
result in severe internal burns and death
within 2 hours.
l. Ensure that coin cell replacement is
carried out properly. There is a risk of
explosion.
m. Only use the coin cells listed in this
operating manual. Do not use any other
coin cells or other forms of electrical
power supply.
n. Do not attempt to recharge the coin
cell and do not short circuit the coin
cell. The coin cell may leak, explode,
catch re and cause personal injury.
o. Remove and dispose of drained coin
cell correctly. Drained coin cell may
leak and damage the product or cause
personal injury.
p. Do not overheat the coin cell or throw
it into fire. The coin cell may leak,
160992A8AK GRG18V-3600C 20230616.indd 5160992A8AK GRG18V-3600C 20230616.indd 5 6/16/2023 7:50:09 PM6/16/2023 7:50:09 PM

-6-
explode, catch re and cause personal
injury.
q. Do not damage the coin cell and or
take the coin cell apart. The coin cell
may leak, explode, catch re and cause
personal injury.
r. Do not allow damaged coin cells to
come into contact with water. Leaking
lithium may mix with water to create
hydrogen, which could cause a re, an
explosion, or personal injury.
Safety Rules for Cordless Rivet Tool
GFCI and personal protection devices like
electrician’s rubber gloves and footwear
will further enhance your personal safety.
Develop a periodic maintenance schedule
for your tool. When cleaning a tool be care-
ful not to disassemble any portion of the
FCC Caution
Industry Canada
Additional Safety Warnings
The manufacturer is not responsible for
radio interference caused by unauthorized
modications to this equipment. Such modi-
cations could void the user’s authority to
operate the equipment. This device complies
with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful inter-
ference, and
2. This device must accept any interference
received, including interference that may
cause undesired operation.
NOTE! This equipment generates uses and
can radiate radio frequency energy and, if
not installed and used in accordance with
the instructions, may cause harmful inter-
ference to radio communications. However,
there is no guarantee that interference will
not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can
be determined by turning the equipment off
and on, the user is encouraged to try to cor-
rect the interference by one or more of the
following measures:
• Reorient or relocate the receiving an-
tenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This device contains licence-exempt
transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Devel-
opment Canada’s licence-exempt RSS(s).
Operation is subject to the following two
conditions:
(1) this device may not cause interference,
and
(2) this device must accept any interference,
including interference that may cause unde-
sired operation of the device.
tool since internal wires may be misplaced
or pinched or safety guard return springs
may be improperly mounted. Certain clean-
ing agents such as gasoline, carbon tetra-
chloride, ammonia, etc. may damage plastic
parts.
160992A8AK GRG18V-3600C 20230616.indd 6160992A8AK GRG18V-3600C 20230616.indd 6 6/16/2023 7:50:09 PM6/16/2023 7:50:09 PM

-7-
Specifications
Intended Use
Model Number GRG18V-3600C
Voltage rating 18 V
Stroke 1 in.
Pulling force 3,595 lbs.
Weight 4.4 to 6.6 lbs.
Permitted battery temperature during charging +32…+113°F (0…+45°C)
Permitted ambient temperature during operation and
storage -4…+122°F (-20…+50°C)
Recommended ambient temperature during charging +32…+95°F (0...+35°C)
Battery Packs / Chargers:
Please refer to the battery/charger list, included with your tool.
NOTE: For tool specications refer to the nameplate on your tool.
The power tool is intended for setting blind rivets.
160992A8AK GRG18V-3600C 20230616.indd 7160992A8AK GRG18V-3600C 20230616.indd 7 6/16/2023 7:50:09 PM6/16/2023 7:50:09 PM

-8-
Symbols
Important: Some of the following symbols may be used on your tool. Please study them and
learn their meaning. Proper interpretation of these symbols will allow you to operate the
tool better and safer.
Symbol Designation/Explanation
V Volts (voltage)
A Amperes (current)
Hz Hertz (frequency, cycles per second)
W Watt (power)
kg Kilograms (weight)
lbs Pounds (weight)
min Minutes (time)
s Seconds (time)
⌀Diameter
n0No load speed (rotational speed, at no load)
n Rated speed (maximum attainable speed)
.../min Revolutions or reciprocation per minute (revolutions, strokes, surface
speed, orbits etc. per minute)
0 Off position (zero speed, zero torque...)
1, 2, 3, ...
I, II, III,
Selector settings (Speed, torque or position settings. Higher number means
greater speed.)
Innitely variable selector with off (Speed is increasing from 0 setting.)
Arrow (action in the direction of arrow)
Alternating current (type or a characteristic of current)
Direct current (type or a characteristic of current)
Alternating or direct current (type or a characteristic of current)
Class II construction (Designates Double Insulated Construction tools.)
Earthing terminal (grounding terminal)
160992A8AK GRG18V-3600C 20230616.indd 8160992A8AK GRG18V-3600C 20230616.indd 8 6/16/2023 7:50:09 PM6/16/2023 7:50:09 PM

-9-
Symbols
Important: Some of the following symbols may be used on your tool. Please study them and
learn their meaning. Proper interpretation of these symbols will allow you to operate the
tool better and safer.
Symbol Designation/Explanation
Alerts user to read manual.
Alerts user to wear eye protection.
Alerts user to wear respiratory protection.
Alerts user to wear hearing protection.
Alerts user to wear eye, respiratory, and hearing protection.
This symbol designates that this tool is listed by Underwriters Laboratories,
to United States and Canadian Standards.
This symbol designates that this tool is listed by the Canadian Standards
Association.
This symbol designates that this tool is listed by the Canadian Standards
Association, to United States and Canadian Standards.
This symbol designates that this tool is listed by the Intertek Testing Ser-
vices, to United States and Canadian Standards.
Designates Li-ion battery recycling program.
160992A8AK GRG18V-3600C 20230616.indd 9160992A8AK GRG18V-3600C 20230616.indd 9 6/16/2023 7:50:10 PM6/16/2023 7:50:10 PM

-10-
Getting to Know Your Product
Bosch GRG18V-3600C Cordless Rivet Tool
(1) (2)
(3) (4) (5)
(6)
(9)
(10)
(12)
(13)
(11)
(7) (8)
(b) (c) (d)
(f) (e)
(a)
Fig. 1
1 Nosepiece
2 Cover Sleeve
3 Hanging Ring
4 Nosepiece Magazine
5 Mandrel Container
6 Handle (insulated gripping surface)
7 Belt Clip
8 Wrench
9 Battery Pack*
10 Battery Release Button*
11 User Interface
a Indicator: Jaw Maintenance Re-
minder
b Indicator: Jaw Maintenance Re-
minder
c Power Tool Status Indicator
d Working Modes Indicator
e AUTO Button to select the working
mode
f RESET Button to reset the reminder
12 On/Off Switch
13 LED Worklight
*sold separately
160992A8AK GRG18V-3600C 20230616.indd 10160992A8AK GRG18V-3600C 20230616.indd 10 6/16/2023 7:50:11 PM6/16/2023 7:50:11 PM

-11-
3. Screw the Mandrel Container 5back
onto the power tool by turning it clock-
wise.
(5)
Fig. 3
Assembly
Disconnect battery pack from tool before making any assembly, adjust-
ments or changing accessories. Such preventive safety measures reduce
the risk of starting the tool accidentally.
Inserting and Releasing Battery
Pack
(Fig. 1)
To insert the battery pack:
1. Slide charged Battery Pack 9into the
housing until the battery pack locks into
position.
To check if the battery is locked in place,
lightly pull the battery in the opposite direc-
tion. If the battery moves, do not use the
tool and repeat the insertion procedure until
the battery is locked in place and does not
slide backwards.
Your tool is equipped with a secondary lock-
ing latch to prevent the battery pack from
completely falling out of the handle, should
it become loose due to vibration.
To remove the battery pack:
1. Press the Battery Pack Release Button
10 and slide the Battery Pack 9forward.
2. Press the Battery Pack Release Button
10 again and slide the Battery Pack 9
completely out of tool housing.
Changing the Nosepiece
(Fig. 2)
The Nosepiece Magazine 4contains nose-
pieces of three different sizes, enabling the
user to exchange nosepieces quickly.
1. Use the Wrench 8to unscrew the Nose-
piece 1 from the Cover Sleeve 2.
2. Screw the new Nosepiece 1on and
tighten it with the Wrench 9.
Empty the Mandrel Container
(Fig. 3)
Always empty the Mandrel Container 5for
broken-off rivet mandrels before it is com-
pletely full in order to prevent blockages.
1. Unscrew the Mandrel Container 5by
turning it anticlockwise.
2. Empty the Mandrel Container 5into a
suitable recycling or waste bin.
(1) (8)
(4)
(2)
Fig. 2
160992A8AK GRG18V-3600C 20230616.indd 11160992A8AK GRG18V-3600C 20230616.indd 11 6/16/2023 7:50:11 PM6/16/2023 7:50:11 PM

-12-
Operation
Suitable Blind Rivet/Nosepiece
Combinations
The use of a combination not listed in the
table below may lead to poor fastening or a
malfunction of the power tool.
Disconnect battery pack from tool before making any assembly, adjust-
ments or changing accessories. Such preventive safety measures reduce
the risk of starting the tool accidentally.
Blind rivet Nosepiece
Size Labelling Hole diameter
Dia.1/8" (3.0mm)
Dia.1/8" (3.2mm)
1/8" (3.0/3.2) Dia.0.09" (2.3−2.4mm)
Dia.5/32" (4.0mm) 5/32" (4.0) Dia.0.11" (2.7−2.8mm)
Dia.3/16" (4.8mm)
Dia.3/16" (5.0mm)
3/16" (4.8/5.0) Dia.0.13" (3.3−3.4mm)
Dia.1/4" (6.0mm)
Dia.1/4" (6.4mm)
1/4" (6.4) Dia.0.18" (4.6−4.7mm)
160992A8AK GRG18V-3600C 20230616.indd 12160992A8AK GRG18V-3600C 20230616.indd 12 6/16/2023 7:50:11 PM6/16/2023 7:50:11 PM

-13-
Operation
Setting a Blind Rivet
(Fig. 2, 4, 5, 6)
1. Prepare the workpieces to be connect-
ed. If no holes are yet available, pre-drill
the workpieces.
2. Select a suitable Nosepiece 1. Screw
the nosepiece onto the Cover Sleeve 2
and tighten it with the Wrench 8(Fig.
2).
3. Use the AUTO Button 11e to select the
required working mode (see “Selecting
the Working Mode”, page 14).
4. Insert the rivet mandrel of the Blind
Rivet 14 into the nosepiece 1(Fig. 4).
5. Hold the power tool tightly and push
the blind rivet into the pilot hole (Fig.
5).
6. Depending on the working mode, press
the On/Off Switch 12 and wait until the
rivet mandrel has broken off.
7. Tilt the power tool backwards so that
the rivet mandrel can fall into the Man-
drel Container 5 (Fig. 6).
Note: After setting the blind rivet, ensure
that the broken-off rivet mandrel has fallen
into the mandrel container before setting
the next blind rivet.
(5)
Fig. 6
(1)
(14)
Fig. 4
Fig. 5
160992A8AK GRG18V-3600C 20230616.indd 13160992A8AK GRG18V-3600C 20230616.indd 13 6/16/2023 7:50:12 PM6/16/2023 7:50:12 PM

-14-
Operation
User Interface
(Fig. 7)
The User Interface 11 is used to select the
working mode and to indicate the status of
the power tool.
Indicator: Jaw Cleaning/Checking
Reminder
If the reminder 11a or 11b lights up, you
must check the Jaws 17. If required, clean
the jaws (see “Cleaning or Replacing the
Jaws”, page 17).
Only reset the reminder once you have
checked the jaws. To do so, press and hold
the RESET Button 11f for 2 seconds.
Status Indicator
Status indicator
11c Meaning
– Power tool switched
off
Green Power tool switched
on and ready to use
Yellow Warning message
Red Error message
Blue (ashing) Data transfer
Selecting the Working Mode
The AUTO Button 11e can be used to choose
between two working modes.
— AUTO ON working mode:
To set a blind rivet, press the On/Off
Switch 12 briey and then release it
again. The riveting process is automati-
cally completed.
Advantage: Convenient riveting
— AUTO OFF working mode:
To set a blind rivet, press and hold the
On/Off Switch 12 until the blind rivet
is fully set and the rivet mandrel has
broken off. Then release the On/Off
Switch 12 in order to complete the rivet-
ing process.
Advantage: Quick riveting (depending on
the blind rivet/nosepiece combination
that is used)
(b) (c)(d)
(f)
(11)
(e)
(a)
Fig. 7
Alerts
Problem Display
(see Fig. 7)
Display
Color
Cause Corrective Measure
Warning
Message
Yellow Jaws 17 dirty Clean the Jaws 17
Yellow Jaws 17 worn Check and, if required, replace the Jaws 17
Problem Toolbox
App
Display
Display
Color
Cause Corrective Measure
Warning
Message
Yellow Jaws 17 dirty Clean the Jaws 17
160992A8AK GRG18V-3600C 20230616.indd 14160992A8AK GRG18V-3600C 20230616.indd 14 6/16/2023 7:50:13 PM6/16/2023 7:50:13 PM

-15-
Working Advice
The power tool with built-in Bluetooth® Low
Energy Module is equipped with a radio in-
terface. Local operating restrictions, e.g. in
aircraft or hospitals, must be observed.
In areas in which the Bluetooth® wireless
technology must not be used, the Bluetooth®
Low Energy Module must be switched off via
the app.
LED Worklight
The LED Worklight 13 improves visibility in
the immediate work area. It is automatically
switched on when the On/Off Switch 12 is
pressed.
Operation
Problem Toolbox
App
Display
Display
Color
Cause Corrective Measure
Warning
Message
Yellow Jaws 17 worn Check and, if required, replace the Jaws 17
Yellow Rechargeable battery9
state of charge weak
Replace or charge the rechargeable battery9
Yellow Rechargeable battery9
almost overheated
Replace or charge the battery9
or
Switch off the power tool and allow it to
cool down for 3–5 minutes until the status
indicator11c lights up green
Yellow Electronics almost over
almost overheated
Switch off the power tool and allow it to cool
down until the status indicator16 lights up
green
Yellow Jaws17 not in working/
neutral position
Press the on/off switch12 so that the Jaws17
return to the working/neutral position
Error
message
Red Rechargeable battery 9
state of charge critical
Replace or charge the rechargeable battery9
immediately
Red Rechargeable battery9
overheated
Replace the rechargeable battery 9
immediately
or
Switch off the power tool immediately and
allow it to cool down for 3–5 minutes until the
status indicator11c lights up green
Red Electronics overheated Switch off the power tool immediately
and allow it to cool down until the status
indicator11c lights up green
Red Jaws17 jammed Clean the Jaws17 and, if required, replace
them
Suspension Device
You can use the Hanging Ring 3to attach the
power tool to a suspension device (e.g. on a
production line).
To do so, fold the Hanging Ring 3upwards.
Regularly check the condition of the hanging
ring and the catch in the suspension device.
Belt clip
You can use the Belt Clip 7to conveniently
secure the power tool to your belt.
160992A8AK GRG18V-3600C 20230616.indd 15160992A8AK GRG18V-3600C 20230616.indd 15 6/16/2023 7:50:14 PM6/16/2023 7:50:14 PM

-16-
Connectivity
Connectivity functions
System Requirements for Using the
App
System Requirements
Mobile device
(tablet,
smartphone)
Android 6 (and newer)
iOS 11 (and newer)
Installing and Setting up the App
You will need to install the device-specic
app before you can use the connectivity
functions.
• Download the app from the correspond-
ing app store (Apple App Store, Google
Play Store).
Note: You will need to have a user ac-
count with the relevant app store to do
this.
App
name
iOS Android
Bosch
Toolbox
• Then select the MyTools or Connectivity
sub-item in the app.
• The display of your mobile device shows
you all of the subsequent steps required
to connect the power tool to the mobile
device.
Data transfer via Bluetooth®
The built-in Bluetooth® Low Energy Module
sends a signal at regular intervals. Depend-
ing on ambient conditions, multiple trans-
mission intervals may be required before the
power tool is detected. If the power tool is
not detected, check the following:
• Is the distance to the mobile device too
great? Reduce the distance between the
mobile device and the power tool.
• Is the coin cell for the built-in Blue-
tooth® Low Energy Module weak or
drained? Contact an authorised after-
sales service centre for Bosch power
tools to replace the coin cell.
• Switch Bluetooth® off and on again on
your mobile device. Check whether the
power tool has now been detected.
Functions in Conjunction with the
Power Tool
In conjunction with the Bluetooth® Low
Energy module, the following connectivity
functions are available for the power tool:
• Registration and personalisation
• Status check, output of warning and
error messages
• General information and settings (e.g.
reminder interval for checking the jaws)
• Management
160992A8AK GRG18V-3600C 20230616.indd 16160992A8AK GRG18V-3600C 20230616.indd 16 6/16/2023 7:50:14 PM6/16/2023 7:50:14 PM

-17-
Maintenance
Cleaning or Replacing the Jaws
(Fig. 8, 9, 10)
1. Remove the Cover Sleeve 2from the
power tool by turning it anticlockwise.
2. Use the Wrench 8to provide resistance
on the Joint 16 and loosen the Jaw
Sleeve 15.
3. Remove the Jaw Sleeve 15. This allows
access to the Jaws 17 and Pressure
Spring 18.
4. Clean the Jaws 17 and Pressure Spring
18 to remove dust and metal splinters.
5. If necessary, replace the jaws.
6. Reassemble all components in reverse
order.
(15)
(16)
Fig. 9
(2)
(15)
(17)
(18)
Fig. 10
(2)
Fig. 8
160992A8AK GRG18V-3600C 20230616.indd 17160992A8AK GRG18V-3600C 20230616.indd 17 6/16/2023 7:50:16 PM6/16/2023 7:50:16 PM

-18-
Accessories
To avoid accidents, always disconnect the battery pack from tool before
servicing or cleaning.
Do not use attachments/accessories other than those specified by
Bosch. Use of attachments/accessories not specied for use with the tool
described in this manual may result in damage to tool, property damage, and or personal
injury.
Standard equipment Optional accessories and attachments
― Nosepieces (multiple sizes)
― Mandrel Container
― 5/8” (16 mm) Wrench
― Belt Clip, Standard
― Belt Clip, Large
Maintenance
Service
NO USER SERVICEABLE
PARTS INSIDE. Preven-
tive maintenance performed by unau-
thorized personnel may result in misplac-
ing of internal wires and components
which could cause serious hazard. We
recommend that all tool service be per-
formed by a Bosch Factory Service Center or
Authorized Bosch Service Station.
Batteries
Be alert for battery packs that are nearing
their end of life. If you notice decreased tool
performance or signicantly shorter running
time between charges then it is time to re-
place the battery pack. Failure to do so can
cause the tool to operate improperly or dam-
age the charger.
Replacing the Built-in Coin Cell
The Bluetooth® Low Energy Module is t-
ted with a coin cell. You will be notied via
the Bosch Toolbox app if the coin cell is too
weak or if it is drained. The coin cell replace-
ment must be performed by Bosch or by an
after-sales service centre authorised to work
with Bosch power tools.
Caution: The coin cell must always be re-
placed with a coin cell of the same type.
There is a risk of explosion.
Remove and dispose of drained coin cell cor-
rectly. Drained coin cell may leak and dam-
age the product or cause personal injury.
Tool Lubrication
Your Bosch tool has been properly lubricat-
ed and is ready for use.
Motors
The motor in your tool has been engineered
for many hours of dependable service.
To maintain peak efciency of the motor,
we recommend it be examined every six
months. Only a genuine Bosch replace-
ment motor specially designed for your tool
should be used.
Cleaning
Certain cleaning agents
and solvents damage plas-
tic parts. Some of these are: gasoline, car-
bon tetrachloride, chlorinated cleaning sol-
vents, ammonia and household detergents
that contain ammonia.
Ventilation openings and switch levers must
be kept clean and free of foreign matter. Do
not attempt to clean by inserting pointed ob-
jects through opening.
Accessory Storage & Maintenance
Store accessories in a cool dry place and
avoid freezing. Before use check accessory
for cracks and fractures, do not use if dam-
age is suspected.
160992A8AK GRG18V-3600C 20230616.indd 18160992A8AK GRG18V-3600C 20230616.indd 18 6/16/2023 7:50:16 PM6/16/2023 7:50:16 PM

-19-
Symboles relatifs à la sécurité ................... 19
Consignes générales de sécurité du produit ........ 20
Règles de sécurité pour outil à riveter sans fil....... 22
Avertissements supplémentaires concernant la
sécurité ................................. 23
Mise en garde de la FCC ........................ 23
Industrie Canada.............................. 24
Spécifications ................................ 24
Utilisation prévue ............................. 24
Symboles.................................... 25
Familiarisez-vous avec votre produit .............. 27
Assemblage.................................. 28
Insertion et retrait du bloc-piles .............. 28
Changement de l’embout avant .............. 28
Videz le conteneur de mandrins .............. 28
Opération ................................... 29
Combinaisons de rivets aveugles/embouts
avant appropriées ..................... 29
Pose d’un rivet aveugle ..................... 30
Conseils pour l’utilisation ................... 32
Lampe de travail à DEL ..................... 32
Dispositif de suspension.................... 33
Agrafe de ceinture......................... 33
Connectivité ................................. 33
Fonctions de connectivité................... 33
Entretien .................................... 34
Nettoyage ou remplacement des mâchoires .... 34
Service .................................. 35
Piles .................................... 35
Remplacement de la pile en forme de pièce
de monnaie intégrée ................... 35
Graissage de l’outil ........................ 35
Moteurs ................................. 35
Nettoyage................................ 35
Rangement & maintenance des accessoires .... 35
Accessoires .................................. 36
Table des matières
Symboles relatifs à la sécurité
Les définitions ci-dessous décrivent le niveau de gravité pour chaque terme signalant un danger.
Veuillez lire le mode d’emploi et lire la signification de ces symboles.
C’est le symbole d’alerte relatif à la sécurité. Il est utilisé pour vous avertir
de l’existence possible d’un danger de lésion corporelle. Obéissez à tous les
messages relatifs à la sécurité qui suivent ce symbole pour éviter tout risque de
blessure ou même de mort.
DANGER indique une situation dangereuse qui, si elle n’est pas évitée, causera la
mort d’une personne ou une blessure grave.
AVERTISSEMENT indique une situation dangereuse qui, si elle n’est pas évitée,
causera la mort d’une personne ou une blessure grave.
MISE EN GARDE indique une situation dangereuse qui, si elle n’est pas évitée,
causera une blessure légère ou modérée.
160992A8AK GRG18V-3600C 20230616.indd 19160992A8AK GRG18V-3600C 20230616.indd 19 6/16/2023 7:50:16 PM6/16/2023 7:50:16 PM

-20-
Consignes générales de sécurité du produit
Lisez toutes les consignes de sécurité, instructions, illustrations et spécifications
fournies avec cet outil électrique. Le non-respect de toutes les instructions figurant
ci-après pourrait causer un choc électrique, un incendie et/ou des blessures graves.
CONSERVEZ TOUS LES AVERTISSEMENTS ET TOUTES LES INSTRUCTIONS POUR RÉFÉRENCE
FUTURE.
Dans les avertissements, le terme « outil électroportatif » se rapporte à votre outil branché sur le secteur (avec fil) ou à
votre outil alimenté par piles (sans fil).
1. Sécurité du lieu de travail
a. Maintenez le lieu de travail propre et bien éclairé.
Les risques d’accident sont plus élevés quand on
travaille dans un endroit encombré ou sombre.
b. N’utilisez pas d’outils électroportatifs dans des
atmosphères explosives, comme par exemple en
présence de gaz, de poussières ou de liquides
inflammables. Les outils électroportatifs produisent
des étincelles qui risquent d’enflammer les pous-
sières ou les vapeurs.
c. Éloignez les enfants et les visiteurs quand vous
vous servez d’un outil électroportatif. Vous
risquez une perte de contrôle si on vous distrait.
2. Sécurité électrique
a. Les fiches des outils électroportatifs doivent cor-
respondre à la prise. Il ne faut absolument jamais
modifier la fiche. N’utilisez pas d’adaptateur de
prise avec des outils électroportatifs munis d’une
fiche de terre. Le risque de choc électrique est
moindre si on utilise une fiche non modifiée sur une
prise qui lui correspond.
b. Évitez tout contact du corps avec des surfaces
reliées à la terre tels que tuyaux, radiateurs,
gazinières ou réfrigérateurs. Le risque de choc
électrique augmente si votre corps est relié à la terre.
c. N’exposez pas les outils électroportatifs à la
pluie ou à l’humidité. Si de l’eau pénètre dans un
outil électroportatif, le risque de choc électrique
augmente.
d. Ne maltraitez pas le cordon. Ne vous en servez ja-
mais pour transporter l’outil électroportatif, pour
le tirer ou pour le débrancher. Éloignez le cordon
de la chaleur, des huiles, des arêtes coupantes
ou des pièces mobiles. Les cordons abîmés ou em-
mêlés augmentent les risques de choc électrique.
e. Si vous utilisez un outil électroportatif à
l’extérieur, employez une rallonge conçue pour
l’extérieur. Ces rallonges sont faites pour l’extérieur
et réduisent le risque de choc électrique.
f. S’il est absolument nécessaire d’utiliser l’outil
électroportatif dans un endroit humide, utilisez
une alimentation protégée par un disjoncteur de
fuite de terre (GFCI). L’utilisation d’un disjoncteur
GFCI réduit les risques de choc électrique.
3. Sécurité personnelle
a. Restez concentré, faites attention à ce que vous
faites, et servez-vous de votre bon sens lorsque
vous utilisez un outil électroportatif. N’employez
pas d’outils électroportatifs quand vous êtes
fatigué ou sous l’emprise de drogues, d’alcool
ou de médicaments. Quand on utilise des outils
électroportatifs, il suffit d’un moment d’inattention
pour causer des blessures corporelles graves.
b. Utilisez des équipements de sécurité personnelle.
Portez toujours une protection oculaire. Le port
d’équipements de sécurité tels que des masques
antipoussières, des chaussures de sécurité antidéra-
pantes, des casques de chantier et des protecteurs
d’oreilles dans des conditions appropriées réduira le
risque de blessure corporelle.
c. Évitez les démarrages intempestifs. Assurez-
vous que l’interrupteur est dans la position arrêt
(Off) avant de brancher l’outil dans une prise de
courant et/ou un bloc-piles, de le ramasser ou de
le transporter. Le transport d’un outil électroportatif
avec le doigt sur la gâchette ou le branchement de
cet outil quand l’interrupteur est en position de
marche (ON) est une invite aux accidents.
d. Enlevez toutes les clés de réglage avant de mettre
l’outil électroportatif en marche. Si on laisse une
clé sur une pièce tournante de l’outil électroportatif,
il y a risque de blessure corporelle.
e. Ne vous penchez pas. Conservez toujours une
bonne assise et un bon équilibre. Ceci vous permet-
tra de mieux maîtriser l’outil électroportatif dans des
situations inattendues.
f. Habillez-vous de manière appropriée. Ne portez
pas de vêtements amples ou de bijoux. Attachez
les cheveux longs. N’approchez pas les cheveux,
les vêtements ou les gants des pièces en mouve-
ment. Les vêtements amples, les bijoux ou les
cheveux longs risquent d’être happés par les pièces
en mouvement.
160992A8AK GRG18V-3600C 20230616.indd 20160992A8AK GRG18V-3600C 20230616.indd 20 6/16/2023 7:50:16 PM6/16/2023 7:50:16 PM
