Bosch NBE-4502-AL User manual

6x30
x4
4.5x40 + O-ring
x4
M8 + O-ring
x4
T15x4
NPT¾" / M25
DINIONIP bullet 4000 / DINION IP bullet
5000
NTI-40012| NTI-50022
SafetyInstructions
de deutsch
en english
es español
fr français
zh-CHS 中国语文
CHS
6x25
M4
x4
x4
Menu
Reset
microSD card
(not included)
Video
out
(service)
49
(1.93)
122
(4.80)
mm (in)
49 (1.93)
122 (4.80)
x4
Ø6 mm
T4
x4
x4
IP67 T4
x4
VDA-POMT-PTZDOME VDA-CMT-PTZDOME
M8
x4
x4
IP67
NPT¾" / M25
12 VDC Power
Alarm
Audio In
CVBS
Ethernet (PoE)
Audio Out
24 VAC Power
RJ45
Ethernet
(PoE)
Default: DHCP on
(no DHCP: Auto-IP
169.254.x.x)
STP Cat5e
Ethernet (PoE)
Power
24 VAC or +12 VDC
SELV
Class 2
Power Supply
PoE
Earth
7 mm
(0.3 in)
24-28 AWG Color
Brown - Alarm NO
Yellow - Alarm COM
Blue - Alarm IN
Grey - Alarm GND
10 kOhm typ.
0.707 Vrms
16 Ohm typ.
0.707 Vrms
Alarm
Audio
In
Audio
Out
Red - Audio 0ut
Black - GND
White - Audio In
Black - GND
CVBS
75 Ohm
BNC female
Video Out
(not included)
BNC male
(F.01U.344.031
SPP BNC Cable.
IP Bullet 4K 5K 6K)
1 2 3 4 5
6 7 8 9 10

DINION IP 4000i/5000i/starlight 6000i IR
NBE-4502-AL | NBE-5503-AL | NBE-6502-AL
Bosch Security Systems B.V.
Torenallee 49
5617 BA Eindhoven
The Netherlands
www.boschsecurity.com
© Bosch Security Systems B.V., 2018
AM18-Q0723 | 2018.05 | v1.1
Quick Installation Guide
x4
T15
Tilt
90°
Twist
360°
Pan
360°
Menu
CVBS
On
Default
Focus
Zoom OK
Zoom (0-6)
Focus & Zoom OK
- autofocus
- autofocus
>2s
>2s
<2s
<2s
<2s
<2s
<2s
<2s
<2s
Analog format
<2s
Output OK
(not included)
IPHelper
Download >> Install
Lens Wizard
Configuration >> Camera >> Installer Menu
Zoom & Focus View & Configure
Bosch Video
Client
Video Security
Client
Configuration
Manager
11 12 13 14
1 2 3 4
