Bosch NIN-73023 User manual

FLEXIDOME IP starlight 7000 VR
NIN‑73013 | NIN‑73023
Installation manual
en english

FLEXIDOME IP starlight 7000 VR Table of contents | en 3
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
Table of contents
1Safety 4
1.1 Safety precautions 4
2Short information 5
3System overview 6
3.1 Performance 6
3.2 Using the camera 6
3.3 Application variants 7
4Planning information 8
4.1 Unpacking 8
4.2 Contents 8
5Installation 9
5.1 Preparation 9
5.2 Local storage 9
5.3 Wiring 10
5.3.1 Cable tree 10
5.3.2 Earthing 10
5.3.3 Network (and PoE power) 10
5.3.4 Auxiliary power 11
5.3.5 Alarm 11
5.3.6 Audio 11
5.3.7 Video 11
5.4 Mounting the camera module 12
5.4.1 Mounting flush to ceiling 12
5.4.2 Mounting to ceiling with SMB-IP 13
5.5 Camera positioning and field-of-view 14
5.5.1 Pan 14
5.5.2 Tilt 14
5.5.3 Twist 15
5.6 Local set-up 15
5.6.1 Using the install wizard 15
5.6.2 Reset 16
5.7 Mount inner and outer dome 16
6Connection via web browser 18
7Configuration 19
8Troubleshooting 20
8.1 Resolving problems 20
8.2 Testing the network connection 21
8.3 Customer service 21
9Maintenance 22
9.1 Cleaning 22
9.1.1 Lens cleaning 22
9.2 Repair 22
10 Decommissioning 23
10.1 Transfer 23
10.2 Disposal 23
11 Technical data 24

4en | Safety FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
1 Safety
!
Caution!
Indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury.
Notice!
Indicates a situation which, if not avoided, could result in damage to the equipment or
environment, or data loss.
1.1 Safety precautions
!
Caution!
The Low Voltage power supply unit must comply with EN/UL 60950. The power supply must
be a SELV-LPS unit or a SELV - Class 2 unit (Safety Extra Low Voltage - Limited Power
Source).
!
Caution!
Installation should only be performed by qualified service personnel in accordance with the
National Electrical Code (NEC800 CECSection60) or applicable local codes.
Read, follow, and retain for future reference all of the following safety instructions. Follow all
warnings before operating the device.
1. Clean only with a dry cloth. Do not use liquid cleaners or aerosol cleaners.
2. Do not install device near any heat sources such as radiators, heaters, stoves, or other
equipment (including amplifiers) that produce heat.
3. Never spill liquid of any kind on the device.
4. Take precautions to protect the device from power and lightning surges.
5. Adjust only those controls specified in the operating instructions.
6. Operate the device only from the type of power source indicated on the label.
7. Unless qualified, do not attempt to service a damaged device yourself. Refer all servicing
to qualified service personnel.
8. Install in accordance with the manufacturer's instructions in accordance with applicable
local codes.
9. Use only attachments/accessories specified by the manufacturer.
10. Protect all connection cables from possible damage, particularly at connection points.
11. Connect the yellow/green earth wire of the camera to the system earth of the installation
to ensure correct safety and EMC/RFI protection.

FLEXIDOME IP starlight 7000 VR Short information | en 5
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
2 Short information
http://www.boschsecurity.com/catalog_overview.htm
This manual has been compiled with great care and the information it contains has been
thoroughly verified. The text was correct at the time of printing, however, the content can
change without notice. Bosch Security Systems accepts no liability for damage resulting
directly or indirectly from faults, incompleteness or discrepancies between this manual and
the product described.
For more information please contact the nearest Bosch Security Systems location or visit
www.boschsecurity.com
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.

6en | System overview FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
3 System overview
3.1 Performance
This camera provides clear images 24/7 – even at night or under low-light conditions.
The exceptional starlight sensitivity enables this camera to work with a minimum of ambient
light. The extended dynamic mode provides detailed images in scenes with challenging
lighting.
The camera is available in 1080p or 720p resolution versions and provides up to 60 images per
second.
The aesthetic vandal-resistant housing makes the camera suitable for indoor or outdoor
installation.
3.2 Using the camera
Use a web browser to access the camera features and to view the camera streams live. Use
the same browser interface to access and change the camera configuration parameters and
recording/storage functions (including local alarm recording, and recording to iSCSI-based
systems).
Refer to the software manual for more information on the browser interface.
The web browser is the most direct way of using the camera, however, the Bosch download
store provides several other free applications (listed below) for viewing and controlling the
camera.
Download store
Download the latest applications and firmware from:
http://downloadstore.boschsecurity.com/
VideoSecurityClient
The VideoSecurityClient is a free, easy-to-use video-surveillance application provided by
Bosch for local and remote monitoring of IP cameras and appliances. The software supports
up to 16 cameras.
BoschVideoClient
The BoschVideoClient is a free Windows application to view, operate, control, and administer
surveillance cameras and installations at remote locations. It offers a user-friendly interface for
easy live viewing of multiple cameras, playback, forensic search and export.
IP Helper
The IP Helper tool is a free PC application that makes it easy to detect Bosch cameras and
devices on your network.
Video security app
The Bosch video security mobile app has been developed to enable Anywhere access to HD
surveillance images allowing you to view live images from any location. The app is designed to
give you complete control of all your cameras, from panning and tilting to zoom and focus
functions. It’s like taking your control room with you.

FLEXIDOME IP starlight 7000 VR System overview | en 7
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
This app, together with the separately available Bosch transcoder, will allow you to fully utilize
our dynamic transcoding features so you can play back images even over low-bandwidth
connections.
3.3 Application variants
The camera has a choice of application variants that set up the camera for optimum
performance in a specific environment. Select the application variant best suited to your
installation.
The application variant must be selected before any other changes are made, as the camera
reboots automatically and resets the factory defaults when the application variant is changed.
This camera has the following application variants:
– Starlight mode (default) – to continue viewing in color at very low light levels
– Extended Dynamic mode - simultaneously see details in very bright and very dark objects
in the same scene

8en | Planning information FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
4 Planning information
4.1 Unpacking
This equipment should be unpacked and handled with care. If an item appears to have been
damaged in shipment, notify the shipper immediately.
Verify that all parts are included. If any items are missing, notify your Bosch Security Systems
Sales or Customer Service Representative.
The original packaging is the safest container in which to transport the unit and can be used if
returning the unit for service.
4.2 Contents
The packaging contains:
Quantity Component
1 FLEXIDOME IP camera
1 T-25H security torx bit
3 Screws (5 REF pozidrive DIN7505-B50mm)
3 Wall plugs (8 x 40mm)
1 Installation Guide
1 Identification label sheet
1 RJ45 shielded coupler
1 Desiccant sachet
The version of the camera with surface mount box contains:
Quantity Component
1 Surface mount box with RJ45 connection box
3 Screws (M5 x 16mm)
1 Rubber grommet for RJ45 connection box

FLEXIDOME IP starlight 7000 VR Installation | en 9
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
5 Installation
5.1 Preparation
To separate the different parts of the camera:
1. Remove the outer dome by unscrewing the 3 attachment bolts.
2. Remove the inner dome by gently pulling it from its mount seal.
3. Store the domes in a safe place where the outer dome cannot become scratched.
4. Remove the camera module from the surface mount box by unscrewing the 3 screws.
To remove the desiccant sachet:
1. Slide the sachet out of its storage slot in the camera.
2. Dispose of the sachet in an environmentally friendly way.
x3
DESICCANT
SILICA GEL
5.2 Local storage
Notice!
Local storage on memory cards should only be used for alarm recording. To minimize the risk
of losing information, use multiple, redundant recording systems and a procedure to back up
all digital information.
To insert a memory card:
1. Slide the memory card into the slot.
2. Press it firmly until it latches into place in the slot (when removing the card, press it
down firmly again until it unlatches).

10 en | Installation FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
5.3 Wiring
!
Caution!
The unit has connection terminals on flying leads. In wet or outdoor installations, use a field
wiring box with NEMA Type 4X or IP66 protection level or better. After connections are made,
ensure the watertight compartment is tightly closed and cables and conduits are properly
sealed to prevent water ingress.
Notice!
Use proper surge suppression on cables that are routed outdoors, or close to large inductive
loads or electrical mains supply cables.
5.3.1 Cable tree
Use the following table to identify the wires in the cable tree:
Wire color AWC Signal
Red 26 +12 VDC
Brown 26 -12 VDC
Yellow / Green 24 Earth
Black / Orange 28 Alarm Out A
White / Orange 28 Alarm Out B
White / Violet 28 Ground (Alarm In)
Orange / Violet 28 Alarm In 1
Violet 28 Alarm In 2
White 28 Audio In
(Shield) 28 Ground (Audio)
Black 28 Audio Out
BNC connector CVBS analog
5.3.2 Earthing
!
Caution!
This device must be connected to earth (ground).
Safety (power) ground is indicated by the symbol.
Connect the yellow/green wire of the camera to the system earth of the installation to ensure
correct safety and EMC/RFI protection.
5.3.3 Network (and PoE power)
Connect the camera to a 10/100 Base-T network:
– Use STP Category 5e cable with RJ45 connectors (the camera network socket is
AutoMDIX compliant).
– Power is supplied to the camera via the Ethernet cable compliant with the Power-over-
Ethernet standard.

FLEXIDOME IP starlight 7000 VR Installation | en 11
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
Notice!
Use only PoE approved devices.
Power-over-Ethernet can be connected at the same time as a 12VDC power supply. If auxiliary
power (12VDC) and PoE is applied simultaneously, the camera selects PoE and shuts off the
auxiliary input.
5.3.4 Auxiliary power
Connect a SELV-LPS or a SELV Class2 power supply with a rated supply voltage of 12VDC as
follows:
– Cut back 7mm (0.28in) of insulation.
– Connect the power wires (red+ , brown-) to the external power supply.
!
Caution!
Use only a +12VDC power supply as an auxiliary power source.
The auxiliary power supply unit must be isolated from earth.
5.3.5 Alarm
Use the stranded and solid wires with maximum diameter AWG 22-28; only cut back 5mm
(0.2in) of insulation.
Alarm out:
Use the alarm output for switching external devices such as lamps or sirens.
The alarm output switching capability has max. voltage 30VAC or +40VDC; max. 0.5A
continuous, 10VA.
Alarm in:
Use the alarm input to connect external alarm devices such as door contacts or sensors:
– TTL logic, +5V nominal, +40VDC max, DC coupled with 50kOhm pull-up to +3.3V.
– Configurable as active low or active high.
Use a zero potential make-contact or switch as the actuator (with a bounce-free contact
system).
5.3.6 Audio
Connect audio devices to the audio input and audio output connectors.
The unit has full-duplex mono audio for two-way communication between a speaker or door
intercom system. The audio input signal is transmitted in sync. with the video signal.
Audio input:
Line input level (not suitable for direct microphone signal); impedance 18kOhm typical;
1Vrms maximum input voltage.
Audio output:
Line output level (not suitable for direct speaker connection); impedance 1.5kOhm minimum;
0.85Vrms maximum output voltage.
Use shielded audio connection cable with advised maximum cable lengths for audio line input
and output levels.
5.3.7 Video
Use the composite video connector (CVBS) on the camera to connect an analog monitor for
setting up the camera or as a permanent analog output for viewing or recording:

12 en | Installation FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
– To connect a monitor for set-up, use the optional 3m cable (NBN-MCSMB-30M) to
connect directly to the CVBS connector of a monitor.
– For a permanent analog output, use the optional 0.3m cable (NBN-MCSMB-03M) to
connect to a high quality coax cable.
5.4 Mounting the camera module
5.4.1 Mounting flush to ceiling
To mount the camera flush to the ceiling:
1. Mark out the recess hole and the three mounting holes. The mounting holes are equally
spaced around a diameter of 133mm (5.25in).
2. Cut out the inner recess hole: Ø105mm (4.13in).
3. Use a 8mm (0.31in) bit to drill the three mounting holes
4. Insert the supplied mounting plugs (8x40) into the mounting holes.
5. Use the supplied screws (DIN7505-B 50mm) to securely mount the camera to the ceiling
surface; if the ceiling is too thin, use appropriate ceiling bolts (not supplied).
57.6 (2.27) 57.6 (2.27)
33.3 (1.31)
66.5 (2.62)
Ø 133 ( Ø 5.25) mm (in)
4S box
(x2)
Ø 8 mm
x3
105 (4.13)
STP Cat5e
RJ45
Ethernet
(PoE)
Earth+12 VDC
Power
Alarm
Audio
BNC
female
75 Ohm
CVBS
Note:

FLEXIDOME IP starlight 7000 VR Installation | en 13
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
If using a recessed 4s mounting box, attach the camera to the box using two screws and
washers (M4x14).
5.4.2 Mounting to ceiling with SMB-IP
To mount the camera using a Surface Mount Box and cable conduit:
1. Use the SMB to mark out the cable hole in the ceiling and to mark the three mounting
holes. The mounting holes are equally spaced around a diameter of 133mm (5.25in).
2. Cut out the cable hole in the ceiling, and use a 8mm (0.31in) bit to drill the three
mounting holes.
3. Insert the supplied mounting plugs (8x40) into the mounting holes.
4. Use the supplied screws (pozidrive DIN7505-B 50mm) to securely attach the SMB to the
surface.
5. Feed the Ethernet RJ45 cable from source through the ceiling into the SMB
6. Remove the cover from the SMB cable conduit and slide out the rubber seals at either
end.
7. Thread the Ethernet cables from the camera and source through the seals (they can be
pulled open to fit the cables). If required, use the larger bore seal (supplied in parts
package) to fit thicker cables.
8. Slot the seals (with cables) into either end of the conduit.
9. Connect the Ethernet cables inside the conduit using the supplied RJ45 shielded
connector.
10. Close the cover on the conduit and position the conduit inside the SMB.
11. Feed the other camera cabling through the cable hole in the SMB.
12. If IP66 water ingress protection is required, connect the camera cabling to the source
cabling inside an IP66 approved box.
13. Mount the camera to the SMB using the 3 supplied screws (M5x16mm torx).
IP66
STP Cat5e
RJ45
Ethernet
(PoE)
Earth
+12 VDC
Power
Alarm
Audio
CVBS

14 en | Installation FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
5.5 Camera positioning and field-of-view
The camera module position can be adjusted along three axes and several zoom positions can
be selected.
To help position the camera and set the field-of-view:
1. Connect a monitor to the 2.5 mm jack using the optional monitor cable (S1460) which
provides a CVBS signal (for installation purposes only).
2. Apply power to the camera.
3. After power-up, wait a little (about 20 seconds).
4. Press the Menu button. This stops the IP video stream and enables the service video
analog output.
Menu
Reset
S1460
Notice!
Do not expose the image sensors to direct sunlight.
5.5.1 Pan
For horizontal adjustment (pan):
1. Rotate the camera module (1) in the base. Do not rotate more than 180° in either
direction.
2. Tighten the locking screw (2) with the supplied screwdriver bit.
1
5.5.2 Tilt
For vertical adjustment (tilt):
1. Loosen the two thumbwheels (1).
2. Swing the camera module between the wings. Do not rotate more than 90°.

FLEXIDOME IP starlight 7000 VR Installation | en 15
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
3. Tighten the two thumbwheels (1).
≤90°
1 1
5.5.3 Twist
To obtain a horizontal horizon (for tilted ceilings or sidewall mounting), twist the camera
module to align the picture shown on the monitor.
5.6 Local set-up
The Menu button on the control panel is used to access the camera install wizard. When there
is a choice in the wizard, the options are selected by either a short press (less than 2 s) or a
long press (more than 2 s) of the Menu button.
Use the install wizard for the following functions:
– Choose application variant
– Change image orientation
– Activate automatic back focus
– Choose analog output
Note:
The zoom and focus are adjusted again later (with the dome bubble in place) via the web
browser. This optimizes picture sharpness in both bright and low-level lighting.
5.6.1 Using the install wizard
To perform the set-up:
1. Power-up the camera and wait briefly until all LEDs show green.
2. Open the camera install wizard by pressing the Menu button.
3. To change the variant, briefly press Menu a number of times until the desired variant is
shown (remember that changing the variant will reboot the system and may eventually
need a reset to return to factory defaults).
4. To confirm the selected variant, press Menu for a longer time.
5. To rotate the image 180°, press and hold Menu until the image flips.
6. Briefly press the Menu button to set the start position for the automatic motorized focus
adjustment.
– You will hear the motorized automatic back focus process running.
– The progress is shown on the monitor.
7. Briefly press the Menu button again and again to scroll through the preset zoom
positions.
– The selection loops back to the beginning when you reach the last one.

16 en | Installation FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
8. When you reach the desired zoom position, use a long press of the Menu button to set
the zoom position and to re-focus.
9. If the camera is not in focus, press Menu for a longer time to re-run the auto focus.
10. If the camera is correctly focused, briefly press the Menu button to access the video
analog output format screen.
11. Briefly press Menu to change the video analog output format as required.
12. When the correct format is shown, press Menu for a longer period to exit the wizard.
5.6.2 Reset
Use the factory reset button to restore the unit to its original settings. Any changes to the
settings are overwritten by the factory defaults. A reset may be necessary, for example, if the
unit has invalid settings that prevent it from functioning as desired.
Reset
5.7 Mount inner and outer dome
When the camera position is set and all adjustments have been made, disconnect the service
cable from the video jack.
To attach the inner and outer dome:
1. Place the desiccant sachet inside the inner dome to prevent damp.
2. Align the inner dome fin with the slot in the camera frame, and gently click the inner
dome into place in its mount seal
3. Check that the lens can move freely in the dome opening.
4. Mount the outer dome by screwing in the 3 attachment bolts.

FLEXIDOME IP starlight 7000 VR Installation | en 17
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
>1 Nm
x3
Desiccant
Desiccant

18 en | Connection via web browser FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
6 Connection via web browser
The unit must have a valid IP address and a compatible subnet mask to operate on your
network. By default, DHCP is pre-set at the factory to On and so your DHCP server assigns an
IP address. With no DHCP server the default address is 192.168.0.1
To view the camera in your web browser:
1. Start the Web browser.
2. Enter the IP address of the unit as the URL.
3. During initial installation, confirm any security questions that appear.
Note:
To see live images in your browser it might be necessary to download and install the MPEG-
ActiveX from the Bosch download store.
Protected Network
If a RADIUS server is used for network access control (802.1x authentication), the unit must
be configured first. To configure the unit, connect it directly to a computer using a network
cable and configure the two parameters, Identity and Password. Only after these have been
configured can communication with the unit via the network occur.
IP Helper tool
Alternatively, use the IP Helper tool to detect Bosch devices on the network:
1. Access the Bosch download store (http://downloadstore.boschsecurity.com/).
2. Download and install IP Helper.
3. Choose your specific camera from the list of cameras shown in the table on the left of the
screen
4. Click Open in browser to view the camera interface.

FLEXIDOME IP starlight 7000 VR Configuration | en 19
Bosch Security Systems B.V. Installation manual 03.2019 | V2.0 | AM18-Q0710
7 Configuration
The camera normally provides an optimal picture without the need for further adjustments.
However, you can use a web browser via the network to access a menu to change camera
settings such as user modes, passwords, picture settings and network settings.
Configuration options using the menu system on the camera itself are limited to basic setup
via the Wizard.
1. Open the camera in the web browser.
2. Click Configuration in the title bar.
3. Select Camera >> Installer Menu from the side bar.
4. Select the application variant before any other changes are made, as the camera reboots
automatically and resets the factory defaults when the application variant is changed.
If required, configure the parameters in other menus to suit your working environment (for
example, ID, passwords, date and time). Refer to the operation manuals of the software for
more information.

20 en | Troubleshooting FLEXIDOME IP starlight 7000 VR
03.2019 | V2.0 | AM18-Q0710 Installation manual Bosch Security Systems B.V.
8 Troubleshooting
8.1 Resolving problems
The following table is intended to help identify the causes of malfunctions and correct them
where possible.
Malfunction Possible causes Solution
Unit does not operate. Power failure. Check power supply.
Faulty cable connections. Check all cables, plugs,
contacts and connections.
No connection
established, no image
transmission.
Incorrect unit configuration. Check all configuration
parameters (reset to factory
default if necessary).
Faulty installation. Check all cables, plugs,
contacts and connections.
Wrong IP address. Check the IP addresses (ping).
Faulty data transmission within
the LAN.
Check the data transmission
with ping.
The maximum number of
connections has been reached.
Wait until there is a free
connection and call the
transmitter again.
No audio transmission to
remote station.
Hardware fault. Check that all connected audio
units are operating correctly.
Faulty cable connections. Check all cables, plugs,
contacts and connections.
Incorrect configuration. Check audio parameters on the
Audio configuration and LIVE
page functions pages.
The audio voice connection is
already in use by another
receiver.
Wait until the connection is free
and then call the sender again.
The unit does not report
an alarm.
Alarm source is not selected. Select possible alarm sources
on the Alarm sources
configuration page.
No alarm response specified. Specify the desired alarm
response on the Alarm
connections configuration page;
if necessary change the IP
address.
The unit is not
operational after a
firmware upload.
Power failure during
programming by firmware file.
Have the unit checked by
Customer Service and replace if
necessary.
