Bose Wave WaveRadio/ User manual

Multimedia Pedestal for the Wave
®
Radio and Wave
®
Radio/CD
Owner’s Guide
®
®

2
Safety Information
WARNING: To reduce the risk of fire or electric shock, do not expose the pedestal to rain or
moisture. The apparatus shall not be exposed to dripping or splashing, and objects filled
with liquids, such as vases, shall not be placed on the apparatus.
WARNING: As with any electronic product, use care not to spill liquids into any part of the
radio. Liquids can cause a failure and/or a fire hazard.
These CAUTION marks are located on the bottom of your pedestal:
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
presence of uninsulated dangerous voltage within the system enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral triangle, as marked on the system, is intended to alert the user to
the presence of important operating and maintenance instructions in this owner’s guide.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, insert fully.
ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne correspondante
de la prise et pousser jusqu’au fond.
WARNING: No naked flame sources, such as lighted candles, should be placed on the apparatus.
Please read this owner’s guide
Please take the time to follow this owner’s guide carefully. It will help you set up and operate your pedestal properly, and
enjoy all of its advanced features. Save your owner’s guide for future reference.
Note: DO NOT place the pedestal on any heat-sensitive surface, such as the finished surface of fine furniture. Like all
electrical equipment, it generates some heat.
©1994-2003 Bose Corporation. No part of this work may be reproduced, modified, distributed or otherwise used without prior written
permission. All trademarks referenced herein are property of Bose Corporation. The Wave
®
radio design is a registered trademark.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
AVIS
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
ATTENTION : POUR RÉDUIRE LE RISQUE DE DÉCHARGE
ÉLECTRIQUE, NE RETIREZ PAS LE COUVERCLE (OU
L’ARRIÈRE). IL NE SE TROUVE ÀL’INTÉRIEURAUCUNE
PIÈCE POUVANT ÊTRE RÉPARÉE PARL’USAGER.
S’ADRESSER À UN RÉPARATEUR COMPÉTENT.

3
Important Safety Instructions
1. Read these instructions
– for all components before
using this product.
2. Keep these instructions
– for future reference.
3. Heed all warnings
–on the productand in theowner’s
guide.
4. Follow all instructions.
5. Do not use this apparatus near water or
moisture – Do not use this product near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet base-
ment, near a swimming pool, or anywhere else that wa-
ter or moisture are present.
6. Clean only with a dry cloth
– and as directed by
Bose Corporation. Unplug this product from the wall
outlet before cleaning.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions – To ensure reliable operation of the
product and to protect it from overheating, put the
product in a position and location that will not interfere
with its proper ventilation. For example, do not place
the product on a bed, sofa, or similar surface that may
block the ventilation openings. Do not put it in a built-in
system,suchasa bookcase oracabinetthatmay keep
air from flowing through its ventilation openings.
8. Do not install near any heat sources, such as radi-
ators, heat registers, stoves or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A ground-
ing-type plug has two blades and a third ground-
ing prong. The wider blade or third prong are
provided for your safety. If the provided plug does
not fit in your outlet, consult an electrician for re-
placement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched, particularly at plugs, convenience recep-
tacles, and the point where they exit from the ap-
paratus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tri-
pod, bracket or table specified
by the manufacturer or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time
– to prevent
damage to this product.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way: such as power-supply
cord or plug is damaged; liquid has been spilled or
objects have fallen into the apparatus; the appa-
ratus has been exposed to rain or moisture, does
not operate normally, or has been dropped
–Donot
attempt to service this product yourself. Opening or re-
moving covers may expose you to dangerous voltages
or other hazards. Please call Bose to be referred to an
authorized service center near you.
15. To prevent risk of fire or electric shock, avoid
overloading wall outlets, extension cords, or inte-
gral convenience receptacles.
16. Do not let objects or liquids enter the product
– as
they may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock.
17. See product enclosure bottom for safety related
markings.
18. Use proper power sources
– Plug the product into a
proper power source, as described in the operating in-
structions or as marked on the product.
Information about products
that generate electrical noise
If applicable, this equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates, us-
es, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may
cause harmful interference to radio communications. How-
ever, this is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harm-
ful interference to radio or television reception, which can
bedeterminedby turningtheequipmentoff and on,youare
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment to an outlet on a different circuit
than the one to which the receiver is connected.
•Consultthe dealeror an experiencedradio/TV technician
for help.
Thisproduct complieswith theCanadianICES-003 ClassB
specifications.

4
Setting Up
Before you begin...
Thank you for selecting this multimedia accessory pedestal from Bose
®
. Designed as a
simple and attractive solution, it allows you to connect and play a variety of auxiliary compo-
nents using your Wave
®
radio/CD or Wave
®
radio.
Benefits of the pedestal include:
•Wave
®
radio sound from a wide range of auxiliary audio sources
• Compact design that fits the lines and the functions of your Wave
®
radio/CD (Figure 1a) or
Wave
®
radio (Figure 1b)
• Quality construction and performance
Figure 1
Front and rear connection
panel of the (a) Wave radio/
CD pedestal and (b) Wave
radio pedestal
Simplifying connections to your Wave
®
radio
While the connectors are in slightly different locations on the back of the two different pedes-
tals, both provide the same connection options. They include three RCA input jacks and three
power outlet plugs on the rear panel. There is also a slot through which the Wave
®
radio
power cord passes to reach a wall outlet. The two additional power jacks on the pedestal are
for plugging in added components. Or you may choose to connect the Wave
®
radio power
plug to one of those pedestal jacks, as shown in Figure 2 on page 5.
When all the other connections are made, simply plug the pedestal power cord into an AC
(mains) wall outlet in your room. That supplies you with power enough for the radio and the
added components.
INPUT
(b)
(a)
INPUT

5
Setting Up
Connect your Wave
®
radio to its pedestal
Before you seat the radio in the pedestal:
1. Make the RCA jack connections, as shown in Figure 2a for the Wave
®
radio/CD, or 2b for
the Wave
®
radio.
•Insert the white cable connector from the pedestal into the white AUX IN jack labeled L
on the back of the radio.
•Insert the red cable connector from the pedestal into the red AUX IN jack marked R on
the back of the radio.
2. Push the radio power plug through the cut-out in the pedestal so it can reach a wall outlet
or one of the three AC outlets on the rear of the pedestal.
3. Plug the radio into an outlet.
Figure 2
How the (a) Wave
®
radio/
CD or (b) Wave
®
radio con-
nects to its pedestal
Seat your radio in the pedestal
Next, place the radio flat in the open platform of the pedestal (Figure 3). You can feel when it
is properly seated.
Figure 3
How the Wave
®
radio/CD
radio slips into the pedestal
(Wave
®
radio not shown)
WARNING: Do not plug in the pedestal power plug until all other connections are completed.
INPUT
Red RCA connector
White RCA connector
(a)
Wave®radio/CD
power plug
Red RCA connector
White RCA connector
Cut-out for
the radio plug
Wave®radio/CD
power plug Cut-out for
the radio plug
(b)
®
®

6
Setting Up
Adding components to your pedestal
Now you are ready to add multi-media sound sources (Figure 4).
Figure 4
Wave
®
radio/CD (a) and
Wave
®
radio (b) seated
in and connected to its
appropriate pedestal
The added components might include a Bose
®
Lifestyle
®
system, your TV, VCR, multi-disc
changer, or portable digital audio file player. In addition to the pedestal, you need an RCA
cable to connect from each component to one of the three pairs of RCA inputs on the
pedestal.
Note: If your component does not include an RCA output cable, you may need to purchase
an adaptor. Call Bose
®
Product and Technical Services,1-800-367-4008, for details.
R
AUXIN
L
INPUT
Volume
Sleep/Snooze
AUXAM/FMOn/Off
WaveRadio
AlarmMode
Alarm
Set Clock
Set
Presets
123
456
Tuning
INPUT jacks
for component connections
(a)
INPUT jacks
for component connections
(b) ®
®

7
Setting Up
One at a time
For each separate component you add, there is a simple two-step process:
1. Connect the ends of one RCA cable:
• to the audio output of the component you will use with the radio, and
• to one of the three pairs of INPUT jacks on the pedestal (Figure 5).
When inserting the connectors, be sure to connect red-to-red and white-to-white
at each end. This ensures consistent right and left channel connections for proper
performance.
Figure 5
RCA cable from one com-
ponent plugging into INPUT
jacks on the pedestal for
the (a) Wave
®
radio/CD and
(b) Wave
®
radio
R
AUXIN
L
INPUT
Component
RCA cable White RCA
connector
Red RCA
connector
(b)
(a)
Component
RCA cable
White RCA
connector
Red RCA
connector
®
®

8
Setting Up
2. Insert the power plug of the component into one of the power outlets on the rear of the
pedestal (Figure 6).
Figure 6
Plugging the component
power cord into the (a)
Wave
®
radio/CD pedestal
and (b) Wave
®
radio pedes-
tal power outlet
Repeat steps 1 and 2 for any other components you want to connect.
You can now plug the pedestal power cord into an AC (mains) wall outlet.
Component
power cord
Component
RCA cable
R
AUXIN
L
INPUT
Component
power cord
Component
RCA cable
(b)
(a)
®
®

9
Getting The Sound
Using your pedestal with components connected
With auxiliary sound sources connected to your pedestal, you can easily command Wave
®
radio sound from them.
Before you begin to enjoy the sound, however, take note of which component is connected to
INPUT 1, 2, or 3 on the back of the pedestal. Those numbers coincide with the AUX buttons
on the pedestal front panel, which you will press to select the component you want to hear
(Figure 7).
Figure 7
AUX 1, AUX 2, and AUX 3
buttons on the pedestal for
the Wave radio
®
/CD
(shown)
To select and play a specific component
1. Turn on your component using its remote or console Power button.
2. Turn on the Wave
®
radio/CD (or Wave
®
radio) and select AUX (pressing the Wave®radio/
CD remote control AUX button will do both).
3. Press the AUX 1, 2, or 3 button on the front of the pedestal.
Note that the green LED (below the AUX button you press) lights up.
To adjust the sound
Use the Wave®radio/CD (or Wave®radio) remote to increase or decrease the volume of the
component that is playing.
Use the component remote control or console buttons to adjust any other feature of that
sound source and to turn the component off, as well as on.
Troubleshooting
AUX1 AUX2 AUX3
LEDs
®
Problem What to do
No sound or
sound is muffled • Make sure that both the pedestal and the radio are plugged into a functioning
power outlet.
•Check the connection of the component to the pedestal.Make sure it is connected to one
of the three pairs of INPUT jacks on the back of the pedestal.
• Make sure the pedestal RCA connectors are inserted into the AUX IN jacks, red-to-red
and white-to-white, on the Wave®/CD radio/CD (or Wave®radio). Refer to "Connect your
Wave®radio to its pedestal" on page 5.
A connected source is
playing, but no LED is lit • Make sure that both the pedestal and the radio are plugged into a functioning
power outlet.

10
Technical Information
Customer Service
For additional help in solving problems, contact Bose®customer service. Refer to the address
list on the inside back cover of this guide.
Warranty
What is covered:
All parts defective in material or workmanship.
For how long:
One year from the purchase date.
What we will do:
We will, at our sole option, repair or replace any defective parts free of charge.
What you must do:
A. Call Bose Customer Service and ask for shipping instructions.
B. Properly pack the unit, if possible, in the original carton for shipping.
Other conditions:
This warranty is fully transferable for the one-year period following purchase.
THE PROVISIONS OF THIS WARRANTY ARE IN LIEU OF ANY OTHER WARRANTY,
WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL, INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. BOSE CORPORATION’S
MAXIMUM LIABILITY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID BY YOU
FOR THE PRODUCT. IN NO EVENT SHALL BOSE BE LIABLE FOR SPECIAL, INCIDENTAL,
CONSEQUENTIAL, OR INDIRECT DAMAGES.
This warranty does not cover a defect that has resulted from improper or unreasonable use or
maintenance, accident, improper packing, or unauthorized tampering, alteration, or modifica-
tion as determined solely by us. This warranty is void if the label bearing the serial number
has been removed or defaced.
Other Law Rights:
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state or country to country. Some places do not allow limitations on implied war-
ranties or the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you.
Technical Information
Pedestal power rating
120V 50/60 Hz 500W
Dimensions
Wave®radio/CD Pedestal: Wave®radio Pedestal
37 /
8"H x 14"W x 101
/
2"D 33
/
8"H x 14"W x 101
/
2"D
(9.8 cm x 35.6 cm x 26.7 cm) (8.6 cm x 35.6 cm x 26.7 cm)
Weight
2.8 lb (1.2 kg)
Color
Graphite Gray, Platinum White

11
Bose Corporation
USA & Canada Sales
Bose Corporation, The Mountain
Framingham, MA 01701-9168
1-800-637-8781
USA & Canada Service
Bose Corporation, The Mountain
Framingham, MA 01701-9168
1-800-637-8781 or
508-879-7330, x63055
European Office
Bose Products B.V., Nijverheidstraat 8
1135 GE Edam, Nederland
TEL [phone] FAX [phone]
Australia
Bose Pty Limited
Unit 3/2 Holker Street
Newington NSW, 2127
TEL [phone]FAX [phone]
Deutschland
Postfach 1468
48504 Nordhorn
TEL [phone]FAX [phone]
France
6, Rue Saint Vincent
78100 Saint Germain in Laye
TEL [phone]FAX [phone]
Nederland
Bose B.V., Nijverheidstraat 8
1135 GE Edam, Nederland
TEL [phone] FAX [phone]
United Kingdom
Freepost EX 151
Exeter EX1 1ZY
TEL [phone]FAX [phone]
World Wide Web
www.bose.com

2003 Bose Corporation
The Mountain
Framingham, MA
01701-9168 USA
268765 AM Rev. 00 JN31057
