Service Manual
Reference Number 738511-SM REV 00
©2015 Bose Corporation
Lifestyle®SoundTouch®525 SoundTouch®home entertainment system
System Level Packaging

2
Product Overview
The Lifestyle®SoundTouch®525 home entertainment system includes a control console,Acoustimass®module, 5
Direct/Reflecting®seriesIIspeakers,SoundTouch™wirelessadapterandauniversalremotecontrol.
TheSoundTouchseries II wireless adaptor adds Wireless N 5 GHz and Bluetoothconnectivity.
Contents
Product Overview ............................................................................................................................2
Safety Information.............................................................................................................................3
Electrostatic Discharge Sensitive (ESDS) Device Handling.......................................................3
Part List Notes ..................................................................................................................................4
Main Packaging List .........................................................................................................................5
Figure1. Main Packaging View ...........................................................................................................5
Essentials Kit Packaging List ..........................................................................................................6
Figure 2. Essentials Packaging View ..................................................................................................6
Satellite Packaging List....................................................................................................................7
Console Packaging List ...................................................................................................................7
Figure 3. Console Packaging ..............................................................................................................7
Revision History ...............................................................................................................................8

3
1. Parts that have special safety characteristics are identified by the symbol on schematics or by special
notes on the parts list. Use only replacement parts that have critical characteristics recommended by the manu-
facturer.
2.RefertoHI-POT testing procedures located in the product’s service manual.
ELECTROSTATICDISCHARGESENSITIVE(ESDS) DEVICEHANDLING
ThisunitcontainsESDSdevices. We recommend the following precautions when repairing,
replacingor transporting ESDS devices:
• Perform work at an electrically grounded work station.
•Wear wrist straps that connect to the station or heel straps that connect to conductive floor mats.
•Avoidtouching the leads or contactsof ESDS devices or PC boards evenif properly grounded. Handle boards by
the edges only.
•Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert unprotected devices into
materials such as plastic, polystyrene foam, clear plastic bags, bubble wrap or plastic trays.
SAFETY INFORMATION
CAUTION: THE BOSE®LIFESTYLE®SOUNDTOUCH®525 HOME THEATER SYSTEM, CON-
TAINS NO USER SERVICEABLE PARTS. TO PREVENT WARRANTY INFRACTIONS, REFER
SERVICING TO WARRANTY SERVICE STATIONS OR FACTORY SERVICE.
PROPRIETARYINFORMATION
THISDOCUMENTCONTAINS PROPRIETARYINFORMATION OF
BOSE CORPORATION WHICH IS BEING FURNISHED ONLY FOR
THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT
BYANAUTHORIZED SERVICE CENTER,AND SHALLNOT BE RE-
PRODUCED OR USED FOR ANY OTHER PURPOSE.

4
Part List Notes
1. The individual parts located on the PCBs are listed in the Electrical Part List.
2. This part is referenced for informational purposes only. It is not stocked as a repair part. Refer to the next higher
assemblyfora replacement part.
3. This part is critical for safety purposes. Failure to use a substitute replacement with the same safety
characteristicsas the recommended replacement part mightcreate shock, fire and/or otherhazards.

5
Main Packaging List
Item
Number Description Material Number Qty
V
ariant Note
1 COMMITMENT LETTER 251001 1
2 LINE CORD KIT
- LINE CORD, 120V, NON-POL, DET ,BLK, 1500
- LINE CORD,220V,EUR,DET,BLK,1500
- LINE CORD,230V,UKS,DET,BLK,1500
- LINE CORD,240V,AUS,DET,BLK,1500
- LINE CORD, 230V,KOREA,BLK,1500mm
- LINE CORD,110V,TAIWAN,BSMI,DET,1525mm
- LINE CORD,100V,JPN,DET,BLK,1500
- CARTON,D-C,CORR,16.13X5.13X3,275,B
-
279101-1310
280135-1310
280138-1310
284243-1310
311668-1310
329792-1310
280136-1310
321181-0010
1
2
2
2
2
2
2
1
US
EU
UK
AUS
KOREA
TAIWAN
JP
3
3 PACKING, INSERT, DC, 40.13X22.00, LS 535 714710-0010 1
4 CARTON, HSC-FOL, D-C, CORR 325008-0010 1
5 ESSENTIAL KIT, LS 525/535 - 1
6 SATPACK, LS525-III, BLK - 1
7 CARTON, RSC, 275DW, LS535 ST BK 638311-0030 1
8 BAG, POLY, HDPE 196638 1
9 PACKING, FOAM, EPS, BBOX 293513-001 1
10 BASS BOX, BLACK, DUAL, WWIP
BASS BOX, WHITE, DUAL, WWIP
BASS BOX, BLACK, 230V, WWIP
BASS BOX, WHITE, 230V, WWIP
297330-619S
297330-629S
297330-613S
297330-623S
1
EU/UK
EU/UK
11 PACKING, FOAM, EPS, BB-BTM 295444-001 1
12 CONSOLE ASSY,V35 H,L,US,SVCE
CONSOLE ASSY,V35 H,L,EU,UK,SVCE
CONSOLE ASSY,V35 H,L,JP,SVCE
CONSOLE ASSY,V35 H,L,APAC,SVCE
722696-111S
722696-211S
722696-311S
722696-511S
1 US
EU/UK
JP
AP

1
2
3
4
5
6
7
8
9
10
11
12
Figure 1. Main Packaging View

6
Essentials Kit Packaging List
1
2
3
4
5
6
7
8
9
10
11
Item
Number Description Material Number Qty
V
ariant Note
1 KIT, ADAPTIQ HEADSET 307702-001 1
2 CABLE ASSY, IR DONGLE, 3 EMITTER 324714-1010 1
3 LIT KIT, LS-525/535 III
- BAG, POLY, 14.38x9.87x2 mil
- BUMPER, RECESSED, FOOT
- GLOBAL WARRANTY CARD, 1 YR.
- DRIVE,FLASH, USB, 4GB
- GUIDE, OPER, ST, LS525/535, SIII, AST
- GUIDE, OPER,ST,LS525/535, SIII, EUR
GUIDE, OPER,ST,LS525/535, SIII, APAC
- GUIDE, OPER,ST,LS525/535, SIII, JPN
- CONTACT SHEET,GLOBAL,WHTH
-
103351
142839
324486-0010
353201-0020
744569-0010
744571-0010
744570-0010
744572-0010
744032-0010
1
US
EU/UK
AP
JP
4 ANTENNA, FM, DIPOLE, W/BALUN 373329-0010 1
5 CABLE, RCA, 6 FT 185931-101 1
6 ANTENNA ASSY, AM, CD20 199824-002 1
7 SDTCH II WIRELESS ADAPTER,CH 1-11
SNDTCH II WIRELESS ADAPTER,JP
SDTCH II WIRELESS ADAPTER,CH 1-11,TW
SNDTCH II WIRELESS ADAPTER,CH 1-13
SNDTCH II WIRELESS ADAPTER,EU
738854-0110
738854-0130
738854-0140
738854-0100
738854-0180
1 US
JP
TW
AP
EU
8 KIT, SUB-ASSY, BATTERY, AA, 4PK
- BATTERY, AA SIZE, SINGLE
- BAG, POLY,3X3.5
-
263269-001
194392
1
4
1
3
9 PACKING, TRAY, PULP 363690-0010 1
10 REMOTE, RF, USA/EU
REMOTE, RF, AP/JP (all languages) 354079-0050 354079-0060 1 US/EU
AP/JP
11 CARTON, D-C, 12.88X16.00X4.25 320599-0010 1
- CABLE, SIGNAL, USB-M/USB-A, M, 6FT,
W/FERRITE 629216-0010 1
- ANTENNA, DIPOLE, FM, PAL CONN 374402-0010 1 EU
- CABLE, FIBER OPTICAL, 3.5mm OD 629769-0010 1 EU


Figure 2. Essentials Packaging View

7
Satellite Packaging List
Console Packaging List
Description Material
Number Qty Note
CARTON, DC, 200B, 13.00X16.00X4.00, LS535 638306-0010 1
SAT ASSY, JCII, BLACK
SAT ASSY, JCII, WHITE 638474-0010 638474-0020 4
SAT ASSY, JCCII, BLACK
SAT ASSY, JCCII, WHITE 638475-0010 638475-0020 1
CABLES, SET, LCR, BLACK
CABLES, SET, LCR, WHITE 724669-2010 724669-3010 1
CABLES, SET, REAR, LR, BLACK
CABLES, SET, REAR, LR, WHITE 724670-2010 724670-3010 1

1
2
3
4
5
6
7
Item
Number Description Material Number Qty Note
1 GUIDE, SETUP, ST, LS, 525, 535, IV, AST
GUIDE, SETUP, ST, LS, 525, 535, IV, APAC
GUIDE, SETUP, ST, LS, 525, 535, IV, EUR
GUIDE, SETUP, ST, LS, 525, 535, IV, JPN
744574-0010
744576-0010
744575-0010
744577-0010
1
2 CABLE ASSY, SIGNAL, DIN-9, BLACK, 9144mm 302580-1001 1
3 CABLE, HDMI, 19POS, 2M, BLACK 326853-0110 1
4 PWR SUPPLY, EXT, UNVSL, 2.92A, 12V, 35W, BLK 353811-0010 1 3
5 PACKING, TRAY, PULP, LS-V CONSOLE 319197-0010 1
6 PACKING, TRAY, PULP, LS-V CONSOLE 319199-0010 1
2 CARTON, CORR, D-C, 20.25X16X5.88, 200, B 320600-0010 1

Figure 3. Console Packaging

8
Revision History
DATE REV ECN Description
09/2015 00 Initial Release

Specifications and Features Subject to Change Without Notice
Bose Corporation
The Mountain
Framingham Massachusetts USA 01701
P/N 738511-SM REV. 00 08/2015 (H)
