Service Manual
Companion®5 Multimedia
Speaker System
Electronic Copy Only

2
CONTENTS
Electrostatic Discharge Sensitive (ESDS) Device Handling .......................................................3
Warranty .............................................................................................................................................3
Product Description ......................................................................................................................... 3
Specifications....................................................................................................................................4
Part List Notes ..................................................................................................................................5
Packaging Part List, Companion®5 Multimedia Speaker System (see Figure 1) ......................6
Figure 1. Companion 5 Multimedia Speaker System Packaging View ................................................6
Bass Module, Exploded View (see Figure 2) ................................................................................7
Figure 2. Bass Module, Exploded View ...............................................................................................7
Electrical Part Lists .................................................................................................................... 8-16
Electrical Part List, Bass Module DSP PCB ............................................................................ 8-15
Electrical Part List, Bass Module I/O PCB ...................................................................................16
Disassembly Procedures ......................................................................................................... 17-18
Audio Test Procedures ............................................................................................................ 19-20
USB Test Procedures .................................................................................................................... 21
Service Manual Revision History .................................................................................................22
CAUTION: The Companion 5 Multimedia Speaker System contains no user-serviceable parts. To
prevent warranty infractions, refer servicing to warranty service stations or factory service.
PROPRIETARY INFORMATION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF
BOSE CORPORATION WHICH IS BEING FURNISHED ONLY FOR
THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT
BY AN AUTHORIZED BOSE SERVICE CENTER OR OWNER OF THE
BOSE PRODUCT, AND SHALL NOT BE REPRODUCED OR USED
FOR ANY OTHER PURPOSE.

3
ELECTROSTATIC DISCHARGE SENSITIVE (ESDS)
DEVICE HANDLING
This unit contains ESDS devices. We recommend the following precautions when repairing,
replacing or transporting ESDS devices:
•Perform work at an electrically grounded work station.
•Wear wrist straps that connect to the station or heel straps that connect to conductive
floor mats.
•Avoid touching the leads or contacts of ESDS devices or PC boards even if properly
grounded. Handle boards by the edges only.
•Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert
unprotected devices into materials such as plastic, polystyrene foam, clear plastic bags,
bubble wrap or plastic trays.
Product Description Companion®5
The Companion 5 is a multi-channel multimedia speaker system connecting to personal
computers via a USB 2.0 interface. No additional sound card is required to enjoy 5.1-channel
audio
content from the host PC. The two speaker arrays combined with advanced audio processing
algorithms provide a spacious presentation of stereo content and a compelling experience with
multi-channel content. A control module brings the master volume control, simple touch mute
control and jacks for an auxiliary analog stereo input and headphones.
The Companion 5 system consisting of the following major components:
1. Bass speaker enclosure with Woofer
2. Control Module with an 8-foot (2.4M) cable.
3. Two two-element speaker arrays with integrated cables, uniquely keyed and identified for
left and right locations.
The speaker arrays are mounted on removable speaker stands that are engineered to position
the speakers at the correct height and angle on either side of a computer monitor. The
transducers contained in the speaker enclosures may not be replaced. The speaker grills are
glued in to prevent movement during shipping.
The integrated speaker cable is hard wired into the speaker enclosure and is not removable.

4
Specifications
Mechanical
Dimensions: Bass Module: 8 5/8 “H x 7 1/8” W x 16 3/4” D
(21.8 x 18 x 42.5 cm)
Satellite Speaker: 9” H x 5 3/4” W x 4” D (22.86 x
14.60 x 10.16 cm)
Control Pod: 2 1/2 “D x 1 1/8” H
(6.35 x 2.79 cm)
Weight: Bass Module: 18.1 lbs (8.2 kg) unpacked
Satellite Speaker (stand
included):
1.8 lbs (.816 kg) each
Packaged System 27 lb (12.3 kg) packed
Finish: Bass Module: Scratch-resistant, satin-finish
vinyl
Satellites: Painted polymer finish
Bass Box: Ported
Bass Box Port Tuning: 50 Hz
Electrical
Power Rating: USA/Canada: 115 VAC 60 Hz
Japan: 100 VAC 50/60 Hz
Euro: 230 VAC 50/60 Hz
Nominal System
Bandwidth:
48 Hz to 18 kHz
Maximum SPL: 102 dBSPL (at normal
listening distance)
Output: Bass: 48Hz – 250Hz
Satellites: 250Hz – 18Khz
USB: USB 2.0 full-speed device with
B-receptacle
Supports 6-channel USB
Audio Device and volume
control and mute USB HID
(Human Interface Device)
controls
Audio device and HID controls
are all supported by standard
USB host firmware

5
PART LIST NOTES
1. This part is not normally available from Customer Service. Approval from the Field Service
Manager is required before ordering.
2. The individual parts located on the PCBs are listed in the Electrical Part List.
3. This part is critical for safety purposes. Failure to use a substitute replacement with the
same safety characteristics as the recommended replacement part might create shock, fire
and/or other hazards.
4. This part is available as finished goods. Order this part using the product code listed.
5. This part is referenced for informational purposes only. It is not stocked as a repair part.
6. RoHS compliant part - Restriction of Hazardous Substances (RoHS) is a directive of the
European Union which took effect July 1, 2006. The directive is aimed at protecting the health
and environment and mandates that electronics products sold in the European Union must be
essentially void of six hazardous substances: lead, mercury, cadmium, hexavalent chromium,
PBB and PBDE flame retardants.

6
COMPANION®5 PACKAGING VIEW
Figure 1. Companion 5 Multimedia Speaker System Packaging View
10
12
3
4
5
7
8
9
11
12
6
13
Item Description Part number Note
1 PACKING, FOAM, EPS, RS, BB 298097
2 PACKING, FOAM, EPS 295570
3 REMOTE CONTROL ASSY 295974-001
4 ARRAY/STAND ASSY, RIGHT 300634-001
5 ARRAY/STAND ASSY, LEFT 300635-001
6 PACKING, FOAM, EPS 295570
7 LINE CORD, 120V, PDL DET, BLK
LINE CORD, 100V, DET, NONPVC, BLK
LINE CORD, 230V, UKS, DET, BLK
LINE CORD, 240V, AUS, DET, BLK
LINE CORD, 220V, EUR, DET, BLK
262814-001
286080-001
280138-001
284243-001
280135-001
3
8 GUIDE, OWNERS, COMP5, 3L 295925
9 CABLE, USB 2.0, TYPE A TO B, 6FT
CABLE, USB 2.0, TYPE A TO B, 10FT
292477-001
292477-002
10 FOOT, RUBBER, PSA BACKED, 4 PACK 297482-001
11 PACKING, FOAM, EPS, BB 300269
12 ASSY, BBOX, COMP 5, 120V
ASSY, BBOX, COMP 5, 230V
290172-S139
290172-S239
13 CARTON, RSC 295572
- CARTON, KIT 300267-K

7
BASS MODULE EXPLODED VIEW
Figure 2. Bass Module Exploded veiw
17
6
7
8
2
1
34
9
5
4X
12
13
14
15 16
11
10 18
4X
4X
Note: The Transformer and Woofer are
note replaceable. The cabinet is glued
together preventing access to these parts.
19
Item Description Part number Qty. Note
1 SCREW, TT, 8-32X0.5, PAN, XREC/SQ 289393-008 4 5
2 CABLE, 8 CONDUCTOR 291574-150 1
3 KNOB, VOLUME CONTROL, BLACK 294599-001 1
4 CLIP, SPRING, KNOB 262542 1
5 LABEL, I/O,BASS MODULE 295923-001 1
6 COVER REAR BASS MODULE 296122-002 1 5
7 FOAM, GRILLE, ARRAY,.125" 272036-002 6
8 HARNESS, USB, TYPE B TO MINI B 296603-001 1
9 PAD, FOAM, .25" X .75" X .06 278144-001 2
10 PCB ASSY, INPUT/OUTPUT, US/JAPAN
PCB ASY, INPUT/OUTPUT, ROHS, EURO
299764-001
299765-002
1
11 BRACKET, INPUT/OUTPUT, PCB 292181-002 1 5
12 SCREW, TAPP, 8-11x.437, PAN, XRC/S 289388-007 9 5
13 HARNESS, IDC, FLAT CABLE 291575-088 1
14 SCREW, TAPP, 8-11x1.5, PAN, XRC/SQ 289388-024 4 5
15 ASSY, PCB, DSP, US/JAPAN
ASSY, PCB, DSP, ROHS, EURO
299766-201
303250-202
1
16 BRACKET HEATSINK 296120-001 1 5
17 SCREW, TAPP, 6-32, PAN, TORX 279948-08 4 5
18 PAD, THERMAL, DIODE 295975-001 1 5
19 HEATSINK, COMPANION 5 296119-001 1 5

8
ELECTRICAL PART LIST
Bass Module DSP PCB
Resistors
Reference
Designator
Description Part Number Note
R0010 5.9k, 0603, .1W, 1% 191465-5901
R0011 750 OHM, 0603, .1W, 1% 191465-7500
R0012 12.1K, 0603, .1W, 1% 191465-1212
R0013 19.6K, 0603, .1W, 1% 191465-1962
R0014 9.09 OHM, 0603, .1W, 1% 191465-9091
R0015 20K, 0603, .1W, 5% 199403-203
R0016 5.9K, 0603, .1W, 1% 191465-5901
R0018 392K, 0603, 1W, 1% 191465-3923
R0019 31.6K, 0603, .1W, 1% 191465-3162
R0020 1K, 0603, .1W, 1% 191465-1001
R0021 3.09K, 0603, .1W, 1% 191465-3091
R0022 1K, 0603, .1W, 1% 191465-1001
R0023 7.15K, 0603, .1W, 1% 191465-7151
R0025 47K, 0603, .1W, 5% 199403-473
R0026 4.7K, 0603, .1W, 5% 199403-472
R0050 150K, 0603, .1W, 1% 191465-1503
R0052 365K, 0603, 1W, 1% 191465-3653
R0054 100 OHM, 0603, .1W, 5% 199403-101
R0055 10 OHM, 0603, .1W, 5% 199403-100
R0056 365 OHM, 0603, .1W, 1% 191465-3650
R0057 11K, 0603, .1W, 1% 191465-1102
R0059 2K, 0603, .1W, 1% 191465-2001
R0060 7.87K, 0603, .1W, 1% 191465-7871
R0150 3.9K, ARRAY, SMT, 4 POS, 5% 186433-3924
R0151 8.25K, 0603, 1W, 1% 191465-8251
R0152 8.25K, 0603, 1W, 1% 191465-8251
R0162 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0163 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0164 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0165 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0250 3.9K, ARRAY, SMT, 4 POS, 5% 186433-3924
R0251 8.25K, 0603, 1W, 1% 191465-8251
R0252 8.25K, 0603, 1W, 1% 191465-8251
R0262 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0263 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0264 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0265 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0350 3.9K, ARRAY, SMT, 4 POS, 5% 186433-3924
R0351 8.25K, 0603, 1W, 1% 191465-8251
R0362 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0363 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0364 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0365 3.32 OHM, 0603, 1W, 1% 191465-3R32
R0451 47K, 0603, .1W, 5% 199403-473

9
ELECTRICAL PART LIST
Bass Module DSP PCB
Resistors (continued)
Reference
Designator
Description Part Number Note
R0452 4.7K, 0603, .1W, 5% 199403-472
R0453 150K, 0603, .1W, 1% 191465-1503
R0454 4.7K, 0603, .1W, 5% 199403-472
R1000 4.3K, 0603, .1W, 5% 199403-432
R1001 4.3K, 0603, .1W, 5% 199403-432
R1002 100 OHM, 0603, .1W, 5% 199403-101
R1003 100 OHM, 0603, .1W, 5% 199403-101
R1004 6.8K, 0603, .1W, 5% 199403-682
R1005 6.8K, 0603, .1W, 5% 199403-682
R1006 3.09K, 0603, .1W, 1% 191465-3091
R1007 10K, 0603, .1W, 1% 191465-1002
R1008 3.09K, 0603, .1W, 1% 191465-3091
R1009 10K, 0603, .1W, 1% 191465-1002
R1010 4.7K, 0603, .1W, 5% 199403-472
R1011 4.7K, 0603, .1W, 5% 199403-472
R4000 4.7 OHM, 0603, .1W, 5% 199403-4R7
R4001 100 OHM, 0603, .1W, 5% 199403-101
R4300 1.8K, ARRAY,SMT, 4 POS, 5% 186433-1824
R4301 1.8K, ARRAY,SMT, 4 POS, 5% 186433-1824
R4302 1.8K, ARRAY,SMT, 4 POS, 5% 186433-1824
R6000 3.09K, 0603, .1W, 1% 191465-3091
R6001 10 OHM, 0603, .1W, 5% 199403-100
R6002 2K, 0603, .1W, 1% 191465-2001
R6003 2K, 0603, .1W, 1% 191465-2001
R6005 4.7K, 0603, .1W, 5% 199403-472
R6006 100 OHM, ARRAY, SMT, 4 POS, 5% 186433-1014
R6008 100 OHM, ARRAY, SMT, 4 POS, 5% 186433-1014
R6009 15 OHM, 0603, .1W, 5% 199403-150
R6010 100 OHM, 0603, .1W, 5% 199403-101
R6011 5.11K, 0603, .1W, 1% 191465-5111
R6012 100 OHM, 0603, .1W, 5% 199403-101
R6013 5.11K, 0603, .1W, 1% 191465-5111
R6101 100 OHM, 0603, .1W, 5% 199403-101
R6102 2K, 0603, .1W, 1% 191465-2001
R6103 10K, 0603, .1W, 5% 199403-103
R6200 100 OHM, 0603, .1W, 5% 199403-101
R6201 7.87K, 0603, .1W, 1% 191465-7871
R6203 3.09K, 0603, .1W, 1% 191465-3091
R6204 3.09K, 0603, .1W, 1% 191465-3091
R6207 9.3K, 0603, .1W, 1% 191465-9311
R6208 4.7K, ARRAY, SMT, 4 POS, 5% 186433-4724
R6209 4.7K, 0603, .1W, 5% 199403-472
R6210 8.25K, 0603, 1W, 1% 191465-8251
R6211 4.7K, 0603, .1W, 5% 199403-472

10
ELECTRICAL PART LIST
Bass Module DSP PCB
Resistors (continued)
Reference
Designator
Description Part Number Note
R0452 4.7K, 0603, .1W, 5% 199403-472
R6222 8.25K, 0603, 100MW, 1% 191465-8251
R7000 2K, 0603, .1W, 1% 191465-2001
R7001 2K, 0603, .1W, 1% 191465-2001
R7002 JUMPER,CHIP, 0805 133627
R7004 100 OHM, 0603, .1W, 5% 199403-101
R7005 100 OHM, 0603, .1W, 5% 199403-101
R7100 100 OHM, 0603, .1W, 5% 199403-101
R8000 27.4 OHM, 0603, .1W, 1% 191465-27R4
R8001 27.4 OHM, 0603, .1W, 1% 191465-27R4
R8002 1.5K, 0603, SMD, 100MW, 5% 199403-152
R9232 39K, 0603, SMD, 100MW, 5% 199403-393
R9233 4.7K, 0603, .1W, 5% 199403-472
R9235 23.7K, 0603, .1W, 1% 191465-2372
R9236 7.15K, 0603, .1W, 1% 191465-7151
R9237 16.5K, 0603, .1W, 1% 191465-1652
R9238 1.82K, 0603, 1/10W, 1% 191465-1821
R9240 10K, 0603, .1W, 5% 199403-103
RQ1 1M, 1206, 1/4W, 5% 124895-1055
RQ2 1M, 1206, 1/4W, 5% 124895-1055
RQ3 1M, 1206, 1/4W, 5% 124895-1055
RT6206 PTC, TEMP SENSE, 105C, 20% 258497-105 3
RT6307 PTC, TEMP SENSE, 105C, 20% 258497-105 3

11
ELECTRICAL PART LIST
Bass Module DSP PCB
Capacitors
Reference
Designator Description Part Number Note
C0010 15000uF, EL, SNP, 105C,25V,20% 261614-153EB3
C0015 .022uF, 0603,X7R, 50V, 10% 191470-223
C0019 .047uF, 0805,X7R, 50V, 10% 286499-473
C0024 .047uF, 0805,X7R, 50V, 10% 286499-473
C0025 .047uF, 0805,X7R, 50V, 10% 286499-473
C0028 2.2uF, EL, 85C,35V, 20% 177902-2R2H
C0029 .047uF, 0805,X7R, 50V, 10% 133623-473
C0048 4700uF, EL, SNAP, 105C, 50V, 10% 261614-472HB3
C0049 2.2uF, EL, 85C, 35V, 20% 177902-2R2H
C0050 22uF, EL,85C,50V, 20% 177902-220HA
C0051 .047uF, 0805,X7R, 50V, 10% 286499-473
C0054 0.1,X7R,0603, 10%, 50V 191470-104
C0055 2200PF, 0603, X7R,50V, 10% 191470-222
C0060 100uF, 7343, LO-R, TANT, 10V, 10% 275411-107
C0061 100uF, 7343, LO-R, TANT, 10V, 10% 275411-107
C0062 .01uF,0603, X7R, 50V, 1% 191470-103
C0063 470pF, 0603, COG,50V,5% 188454-471
C0064 .033uF, 0603,X7R, 50V, 10% 191470-333
C0099 100pF, 0805, COG,50V,5% 133622-101
C0151 33000pF, X7R SMD, 0603, 25V 257154-333K25
C0152 .01uF,0603, X7R, 50V, 1% 191470-103
C0153 .01uF,0603, X7R, 50V, 1% 191470-103
C0154 .01uF,0603, X7R, 50V, 1% 191470-103
C0155 .01uF,0603, X7R, 50V, 1% 191470-103
C0156 1uF,EL, 85C, 50V, 20% 177902-010H
C0157 1uF,EL, 85C, 50V, 20% 177902-010H
C0158 560pF, 0603, X7R,50V, 10% 191470-561
C0159 1uF,EL, 85C, 50V, 20% 177902-010H
C0160 1uF,EL, 85C, 50V, 20% 177902-010H
C0161 560pF, 0603, X7R,50V, 10% 191470-561
C0251 33000pF, X7R SMD, 0603, 25V 257154-333K25
C0252 .01uF,0603, X7R, 50V, 1% 191470-103
C0253 .01uF,0603, X7R, 50V, 1% 191470-103
C0254 .01uF,0603, X7R, 50V, 1% 191470-103
C0255 .01uF,0603, X7R, 50V, 1% 191470-103
C0256 1uF,EL, 85C, 50V, 20% 177902-010H
C0257 1uF,EL, 85C, 50V, 20% 177902-010H
C0258 560pF, 0603, X7R,50V, 10% 191470-561
C0259 1uF,EL, 85C, 50V, 20% 177902-010H
C0260 1uF,EL, 85C, 50V, 20% 177902-010H
C0261 560pF, 0603, X7R,50V, 10% 191470-561
C0351 33000pF, X7R SMD, 0603, 25V 257154-333K25
C0352 .01uF,0603, X7R, 50V, 1% 191470-103
C0353 .01uF,0603, X7R, 50V, 1% 191470-103
C0354 .01uF,0603, X7R, 50V, 1% 191470-103

12
ELECTRICAL PART LIST
Bass Module DSP PCB
Capacitors (continued)
Reference
Designator Description Part Number Note
C0355 .01uF,0603, X7R, 50V, 1% 191470-103
C0356 1uF,EL, 85C, 50V, 20% 177902-010H
C0357 1uF,EL, 85C, 50V, 20% 177902-010H
C0358 560pF, 0603, X7R,50V, 10% 191470-561
C1000 2.2uF, EL, 85C, 35V, 20% 177902-2R2H
C1001 2.2uF, EL, 85C, 35V, 20% 177902-2R2H
C1002 100pF, 0805, COG,50V,5% 133622-101
C1003 100pF, 0805, COG,50V,5% 133622-101
C1004 100pF, 0805, COG,50V,5% 133622-101
C1005 100pF, 0805, COG,50V,5% 133622-101
C1006 33000pF, X7R SMD, 0603, 25V 257154-333K25
C1007 470uF, EL, 85C, 16V, 20% 296512-471C
C1008 470uF, EL, 85C, 16V, 20% 296512-471C
C1009 100pF, 0603, COG,50V,5% 188454-101
C1010 470pF, 0805, COG,50V,5% 133622-471
C1011 470pF, 0805, COG,50V,5% 133622-471
C4000 10uF, EL,85C,16V, 20% 177902-100C
C4001 33000pF, X7R SMD, 0603, 25V 257154-333K25
C4002 10uF, EL,85C,16V, 20% 177902-100C
C4003 33000pF, X7R SMD, 0603, 25V 257154-333K25
C4004 2.2uF, EL, 85C, 35V, 20% 177902-2R2H
C4005 33000pF, X7R SMD, 0603, 25V 257154-333K25
C4006 33000pF, X7R SMD, 0603, 25V 257154-333K25
C4300 1000pF, 0603, X7R, 50V,10% 191470-102
C4301 1000pF, 0603, X7R, 50V, 10% 191470-102
C4302 1000pF, 0603, X7R, 50V, 10% 191470-102
C4303 1000pF, 0603, X7R, 50V, 10% 191470-102
C4304 1000pF, 0603, X7R, 50V, 10% 191470-102
C4305 1000pF, 0603, X7R, 50V, 10% 191470-102
C4306 1000pF, 0603, X7R, 50V, 10% 191470-102
C4307 1000pF, 0603, X7R, 50V,10% 191470-102
C4308 1000pF, 0603, X7R, 50V,10% 191470-102
C4309 1000pF, 0603, X7R, 50V,10% 191470-102
C4310 1000pF, 0603, X7R, 50V,10% 191470-102
C4311 1000pF, 0603, X7R, 50V,10% 191470-102
C6000 .047uF, 0805,X7R, 50V, 10% 133623-473
C6001 33000pF, X7R SMD, 0603, 25V 257154-333K25
C6002 100pF, 0603, X7R,50V, 10% 191470-101
C6003 1000pF, 0603, X7R, 50V, 10% 191470-102
C6004 27pF, 0603,COG, 50V, 5% 188454-270
C6005 27pF, 0603,COG, 50V, 5% 188454-270
C6006 33000pF, X7R SMD, 0603, 25V, 10% 257154-333K25
C6007 .047uF, 0805,X7R, 50V, 10% 133623-473
C6008 .047uF, 0805,X7R, 50V, 10% 133623-473
C6100 100pF, 0805, COG,50V,5% 133622-101

13
ELECTRICAL PART LIST
Bass Module DSP PCB
Capacitors (continued)
Reference
Designator
Description Part Number Note
C0355 .01uF, 0603, X7R, 50V, 1% 191470-103
C6101 100pF, 0805, COG, 50V, 5% 133622-101
C6200 100pF, 0805, COG, 50V, 5% 133622-101
C6201 .047uF, 0603, X7R, 25V, 5% 196999-473
C6202 33000pF, X7R SMD, 0603, 25V, 10% 257154-333K25
C6220 .033uF, 0603, X7R, 50V, 10% 191470-333
C7000 33000pF, X7R SMD, 0603, 25V, 10% 257154-333K25
C7001 33000pF, X7R SMD, 0603, 25V 257154-333K25
C7002 33000pF, X7R SMD, 0603, 25V 257154-333K25
C7003 33000pF, X7R SMD, 0603, 25V 257154-333K25
C7004 33000pF, X7R SMD, 0603, 25V 257154-333K25
C7005 33000pF, X7R SMD, 0603, 25V 257154-333K25
C7006 33000pF, X7R SMD, 0603, 25V 257154-333K25
C7100 33000pF, X7R SMD, 0603, 25V 257154-333K25
C8000 47pF, 0805, COG, 50V, 5% 133622-470
C8001 47pF, 0805, COG, 50V, 5% 133622-470
C9209 33000pF, X7R SMD, 0603, 25V 257154-333K25
C9211 .01uF, 0603, X7R, 50V 10% 191470-103
C9212 .015uF, 0603, X7R, 50V, 10% 191470-153
C9213 100uF, EL, 85, 10V, 20% 177902-101A
C9219 .047uF, 0805, X7R, 50V, 10% 133623-473
C9220 10pF, 0603, COG, 50V, 5% 188454-100
Inductors
Reference
Designator
Description Part Number Note
L0050 22uH, 0.86A, SMT, 20% 290997-220T
L0902 560uH, 0.22A, SMT, 560uH, 20% 289382-561T
L4000 330 OHM, FERRITE BD, IND0603, 200MA 268373-331
L4001 330 OHM, FERRITE BD, IND0603, 200MA 268373-331
L6000 330 OHM, FERRITE BD, IND0603, 200MA 268373-331
L7000 330 OHM, FERRITE BD, IND0603, 200MA 268373-331
L7002 330 OHM, FERRITE BD, IND0603, 200MA 268373-331

14
ELECTRICAL PART LIST
Bass Module DSP PCB
Diodes
Reference
Designator
Description Part Number Note
D0010 DIODE, SMD, 10A, 200V, S10D 256405-200 3
D0011 DIODE, SMD, 10A, 200V, S10D 256405-200 3
D0012 DIODE, SMD, 10A, 200V, S10D 256405-200 3
D0013 DIODE, SMD, 10A, 200V, S10D 256405-200 3
D0016 DIODE, SMD, 10A, 200V, S10D 256405-200
D0450 DIODE, ZEN, SOT-23, 5.1V, 225MW, 5%, 135247-5231
D0901 DIODE, SWTCHING, SCHOTTKY, 1A/40V 195637-3
D1000 DIODE, SOT-23, BAV 99 147239
D1001 DIODE, SOT-23, BAV 99 147239
D1002 DIODE, SOT-23, BAV 99 147239
D1003 DIODE, SOT-23, BAV 99 147239
D6200 DIODE, SOT-23, BAV 99 147239
D6201 DIODE, SOT-23, BAV 99 147239
D9200 DIODE, SOT-23, BAV 99 147239
ZR10 DIODE, ZEN, SOD-123, 6V, .5W, 5% 174265-5233
ZR6220 DIODE, ZEN, SOT-23, 9.1V, 225MW, 5% 135247-5239
Transistors
Reference
Designator
Description Part Number Note
Q0010 MFET,60V,27A,NON-ISOLAT 271765-002
Q0011 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q0012 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q0024 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q0030 XSISTOR, BPLR, P, 40V, 200mA, SOT23 148596
Q0030 XSISTOR, BPLR, P, 40V, 200mA, SOT23
(RoHS)
287939-001 6
Q0031 XSISTOR, BPLR, N, 50V, 100mA, SOT23 146817
Q0031 XSISTOR, BPLR, N, 50V, 100mA, SOT23
(RoHS)
287935-001 6
Q0450 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q6001 XSISTOR, BPLR, P, 40V, 200mA, SOT23 148596
Q6001 XSISTOR, BPLR, P, 40V, 200mA, SOT23
(RoHS)
287939-001 6
Q6101 XSISTOR, BPLR, P, 40V, 200mA, SOT23 148596
Q6101 XSISTOR, BPLR, P, 40V, 200mA, SOT23
(RoHS)
287939-001 6
Q6102 XSISTOR, P, 50V, 2SA1341 146818
Q6200 XSISTOR, BPLR, N, 50V, 100mA, SOT23 146817
Q6200 XSISTOR, BPLR, N, 50V, 100mA, SOT23
(RoHS)
287935-001 6
Q6201 XSISTOR, BPLR, P, 40V, 200mA, SOT23 148596
Q6201 XSISTOR, BPLR, P, 40V, 200mA, SOT23
(RoHS)
287939-001 6

15
ELECTRICAL PART LIST
Bass Module DSP PCB
Transistors (continued)
Reference
Designator Description Part Number Note
Q6202 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q6203 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q7100 XSISTOR, BPLR, P, 40V, 200mA, SOT23 148596
Q7100 XSISTOR, BPLR, P, 40V, 200mA, SOT23
(RoHS) 287939-001 6
Q9031 XSISTOR, PNP, SOT-223, 60V, 800mA 269870-001
Q9032 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Integrated Circuits
Reference
Designator Description Part Number Note
U11 IC, VOLTREG, ADJ., 500MA, DPAK 258496-001
U20 IC, VOLT-REG, SOIC-8, LM317LM 173795-1
U50 IC, SWITCHING, 1MHz, BUCK CONV 288281-001
U51 XSISTOR, MOSFET, DUAL N, 50V, 3A 289259-001
U150 IC, POWER AMP, PSO-20, TDA8566TH 257975
U150 IC, POWER AMP, PSO-20, TDA8566 (RoHS) 289447-001
U250 IC, POWER AMP, PSO-20, TDA8566TH 257975
U250 IC, POWER AMP, PSO-20, TDA8566 (RoHS) 289447-001
U350 IC, POWER AMP, PSO-20, TDA8566TH 257975
U350 IC, POWER AMP, PSO-20, TDA8566 (RoHS) 289447-001
U902 BUCKCTLR, SO-8, PWM, 500kH, 40V, 5% 275415-004
U1000 IC, OP AMP, DUAL, RAIL TO RAIL 277563-001
U4000 IC, CODEC AUDIO,24-bit 289863-001
U6000 IC,MICRO CONTROLLER, 8-BIT 289864-001
U6001 IC, ET, SOT-23, MAX809, 2.63V 191158-06
U6002 IC, EEPROM, 64K, 2.7V, 2-WIRE 293549-064D
U6200 IC, VOLTAGE COMPARATOR, LM339 187618-001
U7000 IC DSP TMS320DA7051, 144RFP 289857-7051
U7001 IC, EEPROM, 512K, Serial, 2-WIRE 289858-0512B
Miscellaneous
Reference
Designator Description Part Number Note
J0010 CONN, HEADER, INLINE, PCB MNT, 2P 133220-02
J0150 CONN, LOCKNG,2.5MM, 8POS,LOC PIN 283142-010108
J0350 CONN, HEADER, INLINE, PCB MNT, 4P 133220-04
J1000 CONN, HEADER, 2.5MM, THRU, 16 POS 270584-016
J8000 CONN, HEADER, TYPE 2, USB MINI-B 296441-001
X6000 CRYSTAL, 6.0MHz, 291429-001

16
ELECTRICAL PART LIST
Bass Module I/O PCB
Resistors
Reference
Designator
Description Part Number Note
F1 FUSE, 2.0 AMPS, AXIAL, US/JAPAN
FUSE, SLO-BLO, 1.0A, EURO/UK/AUS
269855-02000
298780-1000
3
J1 AC CONNECTOR 273692-001
J2 CONN, HEADER, LOCKING, TOP, KEYED 271897-002 3
J3 CONN, HEADER, DUAL ROW, R/A 278156-04
J4 CONN, HDR, DUAL ROW, R/A,RED 278156-204
J5 CONN,HDR, DUAL ROW, R/A, BLK 278156-110
J21 CONN, LOCKNG, 2.5MM, 8POS, LOC PIN 283142-010108
J22 CONN, HEADER, 2.5MM, THRU, 16 POS 270584-016
Miscellaneous
Reference
Designator
Description Part Number Note
R20 10K, POTENTIOMETER, 1B, 20% 273741-001
R24 RES, CF, 1/4W, 5%, 10K 120968-1035

17
DISASSEMBLY PROCEDURES
Disassembly
The following procedure shows the disassem-
bly of the bass module to allow access to the
DSP and I/O boards.
Note: The cabinet is glued together prevent-
ing any type of internal repair beyond the
boards. The woofer and the transformer are
both inside the cabinet and cannot be re-
placed.
1. DSP board removal
1.1 Remove the four phillips-head screws
from the rear cover.
1.2 Pull the rear cover down and remove the
cables connected to J2, J21 and J22 on the
I/O board and J8000 from the DSP board.
1.3 Remove the four Phillips-head screws
located to the left and right of the heatsink.
1.4 Remove the cables connected to J350
and J10, this allows the heatsink and DSP
board to pull away from the bass module
cabinet.

18
DISASSEMBLY PROCEDURES
2. I/O Board Removal
2.1 Use a small flat-head screw driver to
pull the Bass control off of the rear cabinet.
2.2 Remove the three Phillips-head screws
that secure the I/O board in place.
2.3 Remove the plastic bracket that secures
the I/O board in place.
1.5 Remove the four 6-32 TORX screws that
holds the heatsink bracket in place.
1.6 Separate the heatsink, heatsink bracket
and DSP board.

19
Audio Test Procedures
Note: There are two different test procedures
for the Companion 5.
1. Audio test
2. USB light up and play test
Audio test
Equipment required:
1. Audio Signal Generator
2. Oscilloscope
3. Digital Multimeter
Test Set up
1. Connect the satellites to the output jacks on
the bass module.
2. Connect the control pod to the 10 pin input
connector on the bass module (the control pod
must be connected before power is applied).
3. Connect the power cord to an AC outlet.
4. Connect a signal generator to the audio
input cable and connect the cable to the input
jack on the control pod.
1. Bass Module Air Leak test
1.1 Apply a 100 mVrms, 55 Hz signal to the
input of the bass module.
1.2 Set the volume knob on the control pod to
maximum (fully clockwise), and set the bass
compensation control to it’s center detent (flat)
position.
1.3 Listen carefully for air leaks along all glued
joints, around the heat sink, connectors and at
the woofer mounting location.
PASS if no audible air leaks can be heard at a
distance > 1 ft from any exterior surface of the
Bass module.
FAIL if air leaks can be heard at a distance
> 1 ft from any exterior surface of the Bass
module.
1.4 Repair any air leaks around the heat sink
and connectors. Replace any bass module
that has air leaks around the bass box or
woofer mounting location.
2. Bass Module Sweep Test
2.1 Apply a 100 mVrms, 10 Hz signal to the
input of the bass module.
2.2 Set the volume knob on the control pod to
maximum (fully clockwise), and set the bass
compensation control to it’s center detent (flat)
position.
2.3 Listen carefully as you sweep the bass
module from 10 Hz to 500 Hz, then from 500
Hz to 10 Hz.
2.4 Listen carefully for buzzes, rattles, or other
extraneous noises from the woofer, cabinet,
plastic trim parts, or heat sink. A slight
whooshing sound from the port (at approxi-
mately 45 Hz) is acceptable.
2.5 Repair any noise heard from around the
heat sink and connectors. Replace the bass
module if it has noises from the woofer or
cabinet area.

20
Audio Test Procedures (continued)
3. Bass Module, Bass Compensation Test
3.1 Apply a 90 mVrms, 100 Hz signal to the
input of the bass module.
3.2 Set the volume knob on the control pod to
maximum (fully clockwise), and set the bass
compensation control to it’s center detent (flat)
position.
3.3 Rotate the bass compensation control fully
clockwise and counter clockwise.
3.4 Verify that the bass level cleanly increases
and decreases in level.
4. Satellite Sweep Test
4.1 Apply a 100 mVrms, 100 Hz signal to the
input of the bass module.
4.2 Set the volume knob on the control pod to
maximum (fully clockwise), and set the bass
compensation control to it’s center detent (flat)
position.
4.3 Use the list below to sweep the frequency
to the input. Listen carefully for buzzes, rattles,
or other extraneous noises from the Twiddler™
speakers, plastic satellite enclosure, grille, or
internal wires.
Sweep Range Input Signal
100Hz to 500Hz 100mVrms
500Hz to 2kHz 50mVrms
2kHz to 5kHz 25mVrms
4.4 Replace any satellite that is found to be
defective.
5. Satellite Air Leak Test
5.1 Apply a 60 mVrms, 300 Hz signal to the
input of the bass module.
5.2 Set the volume knob on the control pod to
maximum (fully clockwise), and set the bass
control to it’s center detent (flat) position.
5.3 Listen carefully for air leaks along edges
of the satellite and near the grille where the
Twiddler speaker is installed.
5.4 Replace any satellite that is defective.
6. Control Pod Functional Test
6.1 With the system completely set up, con-
nect power.
6.2 Set the volume knob on the control pod to
maximum (fully clockwise), and set the bass
control to it’s center detent (flat) position.
6.3 Touch the center of the control pod . Verify
that the LED turns from green to orange and
orange to green with each touch.
6.4 Verify that the sound is muted and un-
muted when the LED changes color and that
there is no audible pop when switching from
mute to un-mute.
6.5 Rotate the control pod ring, verify that the
volume increases and decreases and that the
ring moves smoothly.
6.6 Replace any control pod that is defective.
