PANARAY®MA12 & MA12EX
Modular Line Array Loudspeaker Family
Panaray®MA12 Modular Line Array Loudspeaker
The Panaray MA12 modular line array loudspeaker is designed for acoustically demanding indoor spaces where speech intelligibility is critical and
speech reproduction is the main requirement. To deliver full-range music performance, bass augmentation is required. Twelve 2.25" (57mm)
mid/high-frequency drivers mounted in a vertical line array deliver 145º of horizontal dispersion and narrow vertical pattern control. The MA12
loudspeaker delivers 300 watts of power handling and can be mounted in single or multiple loudspeaker configurations. This loudspeaker is
well-suited for indoor applications such as houses of worship, auditoriums, transportation hubs, atriums, malls, gymnasiums and multipurpose spaces.
MA12 MA12EX
PRODUCT FEATURES
Indoor Applications • •
Outdoor Applications •
Articulated Array®Loudspeaker Design 1•
Speech-Only Applications • •
Speech and Full-Range Music Applications (with added bass augmentation) •
SYSTEM PERFORMANCE (Single Module)
Frequency Response (-3 dB) 2155 Hz – 12 kHz 75 Hz – 13 kHz
Frequency Range (-10 dB) 2100 Hz – 16 kHz 58 Hz – 16 kHz
Calculated Maximum SPL @ 1m 3113 dB 109 dB
Input Power Rating (continuous/peak) 4300W/1200W 150W/600W 7
Axial Sensitivity (SPL/1W @ 1m) 588 dB 87 dB
Nominal Horizontal Coverage (-6 dB) 145° 160°
Nominal Vertical Coverage (-6 dB) 620° 20°
Nominal Impedance (transformer bypass) 8g8g
Minimum Impedance 6.2g7.1g
Crossover Frequency N/A N/A
Recommended High-Pass Filter 125 Hz 65 Hz
TRANSDUCERS
Driver Complement Twelve 2.25" (57mm) mid/high-frequency drivers Twelve 2.25" (57mm) high-excursion, weather-resistant drivers
PHYSICAL
Enclosure Material Powder-coated aluminum Powder-coated aluminum
Grille Powder-coated steel Powder-coated aluminum
Connectors Two parallel wired Neutrik Speakon®NL4 connectors
One two-conductor barrier strip
Two parallel wired Neutrik Speakon®NL4 connectors
Two two-conductor barrier strips
Suspension Attachment 4 x M6 threaded inserts 6 x M6 threaded inserts
Dimensions (H x W x D) 38.8" x 4.2" x 5.1"
(986mm x 107mm x 130mm)
38.8" x 4.1" x 5.5"
(986mm x 104mm x 140mm)
Net Weight 18.7lbs 20.8lbs
Shipping Weight 20.8lbs 22.9lbs
Color Available in black or white, paintable Available in black or white, paintable
Family Comparison Guide
NEW Panaray®MA12EX Modular Line Array Loudspeaker
The newest addition to the Panaray MA12 loudspeaker family, the Panaray MA12EX modular line array loudspeaker is designed to deliver high
speech intelligibility and full-range music from 75 Hz to 13 kHz (-3 dB), without additional bass augmentation, in both indoor and outdoor
acoustically demanding spaces. Twelve 2.25" (57mm) high-excursion, weather-resistant drivers mounted in an Articulated Array®loudspeaker
design1deliver 160º of horizontal dispersion and narrow vertical pattern control. The Panaray MA12EX loudspeaker delivers full-range performance
at 150 watts, and speech-only performance at 300 watts. The loudspeaker can be mounted in single or multiple loudspeaker configurations. It is
well-suited for indoor and outdoor applications such as houses of worship, multipurpose spaces, recreation, retail, restaurants, auditoriums,
transportation hubs, gymnasiums, atriums and malls.

MA12 MA12EX
MA12 AND MA12EX LOUDSPEAKER ACCESSORIES
CB-MA12 Coupling Bracket
Coupling bracket for stacking multiple MA12 loudspeakers.
•
CB-MA12EX Coupling Bracket
Coupling bracket for stacking multiple MA12EX loudspeakers. •
CVT-MA12 Transformer 70V/100V
Transformer for use with MA12 loudspeakers. Bracket included for coupling transformer to loudspeaker.
•
CVT-MA12EX Transformer 70V/100V
Transformer for use with MA12EX loudspeakers. Bracket included for coupling transformer to loudspeaker.
•
WB-MA12/MA12EX Pitch-Only Bracket
Bracket offers pitch adjustment for MA12 and MA12EX loudspeakers. • •
WMB-MA12/MA12EX Bi-Pivot Bracket
Bracket offers pitch and yaw adjustment for MA12 and MA12EX loudspeakers. • •
WMB2-MA12/MA12EX Pitch Lock Upper Bracket
Bracket offers 0-10° of pitch adjustment for the single or stacked MA12 and MA12EX loudspeakers.
This bracket is used along with the WB-MA12/MA12EX pitch-only or WMB-MA12/MA12EX bi-pivot brackets.
••
Bose Professional Systems Division
Design IPerformance ISupport
For more information about the Panaray®MA12 and MA12EX
Modular Line Array loudspeaker family, please visit:
pro.Bose.com
1) Articulated Array®loudspeaker technology produces wide, uniform sound coverage by angling every other driver within the
enclosure to create 160 degrees of horizontal coverage and consistent tonal balance.
2) Frequency Response and Range: Data is the average response in the typical coverage area with the recommended equalization applied.
3) Calculated Max SPL: Calculated based on input sensitivity with recommended equalization applied and maximum input power rating
exclusive of power compression.
4) Input Power Rating: Pink noise with a 6 dB crest factor is bandpass limited to the operating range of the loudspeaker and applied
for 100 hours.
5) Axial Sensitivity: Full-bandwidth pink noise with recommended equalization amplified to a level of 1 watt and applied to the
loudspeaker in an anechoic environment.
6) Vertical coverage varies by number of modules vertically arrayed and distance from line-source boundary. Use Modeler®software
for the best prediction.
7) 150W for full-range music and speech applications. Speech-only applications (155 Hz to 12 kHz), power handling (continuous)
at 300W/1200W.
