BOSER Technology BPF-3012 User manual

BPF-3012
Ultra Slim, 12.1” Fanless Panel PC,
Touch Screen, 12V DC Adapter

Copyright Disclaimers
The accuracy of contents in this manual has passed through checking and review before
publishing. BOSER Technology Co., Ltd., the manufacturer and publisher, is not liable for
any infringements of patents or other rights resulting from its use. The manufacturer will
not be responsible for any direct, indirect, special, incidental or consequential
damages arising from the use of this product or documentation, even if advised of
the possibility of such damage(s).
This manual is copyrighted and BOSER Technology Co., Ltd. reserves all
documentation rights. Unauthorized reproduction, transmission, translation, and
storage of any form and means (i.e., electronic, mechanical, photocopying, recording)
of this document, in whole or partly, is prohibited, unless granted permission by BOSER
Technology Co., Ltd.
BOSER Technology Co., Ltd. reserves the right to change or improve the contents of
this document without due notice. BOSER Technology Co., Ltd. assumes no
responsibility for any errors or omissions that may appear in this manual, nor does
it make any commitment to update the information contained herein.
T
T
Tr
r
ra
a
ad
d
de
e
em
m
ma
a
ar
r
rk
k
ks
s
s
BOSER is a registered trademark of BOSER Technology Co., Ltd.
ISB is a registered trademark of BOSER Technology Co., Ltd.
Intel is a registered trademark of Intel Corporation.
Award is a registered trademark of Award Software, Inc.
AMI is a registered trademark of AMI Software, Inc.
All other trademarks, products and or product names mentioned herein are
mentioned for identification purposes only, and may be trademarks and/or
registered trademarks of their respective companies or owners.
© Copyright 2008 BOSER Technology Co., Ltd.
All Rights Reserved.
Edition 1.1, November 10, 2010

Table of Contents
Chapter 1 General Description ..................................1
1.1 Major Features....................................................................... 2
1.2 Specifications ........................................................................ 2
1.3 Dimensions ............................................................................ 4
Chapter 2 Unpacking ..................................................5
2.1 Opening the Delivery Package............................................. 5
2.2 Inspection............................................................................... 5
Chapter 3 Hardware Installation ..............................7
3.1 Installation SBC..................................................................... 7
3.2 HDD Installation..................................................................... 8
3.3 WLAN Device Installation ..................................................... 9
3.4 Back Cover Installation......................................................... 9
3.5 Wall Mount Kit...................................................................... 10
Chapter 4 Touch Screen Driver Installation ..........13
4.1 Resistive Type Touch Screen Driver Installation............. 13

Declaration of Conformity -- CE Mark
BOSER Technology hereby acknowledges that compliance testing in
accordance with applicable standards of the EU’s EMC Directive,
89/336/EEC, was successfully completed on a sample of the equipment
identified below:
Equipment Class: Information Technology Equipment
Product Model Series: BPF-3012
This Product Complies With: EN55022: Class A for Radiated emissions
EN50082-2: Heavy Industrial EMC Immunity
We, the undersigned, hereby declare that the equipment specified above
conforms to the above directives and standards.
Manufacturer:
BOSER TECHNOLOGY CO., LTD.

Safety Instructions
The safety recommendations outlined in this section are to be read,
understood and followed before operating the product. Keep this
information in a safe place for future reference. Failure to comply with any
of the following safety procedures could result in serious damage.
Do not operate product for any purposes other than its intended use
This product is intended for indoor use only
Do not operate product if power cord is damaged in anyway
Do not insert objects into openings
Do not immerse product in water or permit liquids to spill inside
Turn off power when unattended or not in use. Unplug product before
moving it or when it is not in use for an extended period of time. The
socket-outlet shall be installed near the equipment and shall be easily
accessible
Do not alter or extend electric plug. Plug is configured for appropriate
electrical supply
Do not overload electrical outlets beyond their capacity as this can result in a
fire
NOTE: DO NOT TOUCH THE PRODUCT OR ANY OTHER SENSITIVE
COMPONENTS WITHOUT ALL NECESSARY ANTI-STATIC
PROTECTIONS.

Life Expectancy of Constituent Parts
This section describes the life expectancy of constituent parts (backlight,
power supply, internal cooling fan and touch screen) which make up to
BPF-3012.
TFT Display Backlight
Display brightness decreases over time with use. The expected operating
lifetime of the backlight time to reach 50% initial brightness) is 30,000 hours
(assuming continuous lit state at 25 degrees C). Actual lifetime result may be
different.
Touch Screen
The operating lifetime of the touch screen is approximately 1 million
operations (as tested by mechanical manipulation under 100g of force at a
rate of two presses per second)

1
Chapter 1
General Description
The BPF-3012 is a latest Industrial Panel PC, Panel PC features
anti-vibration design and is a best cost-effective alternation for users.
This precise streamline platform can be applied to Kiosk, DSA,
transaction terminal, POS, home security system, ATM system and
voting machine parking field and more.
It has a built-in ultra low power consumption VIA V4 Eden 1GHz CPU is
responded to demands of cost-effective panel system. All of BPF
series Panel PC Support resistive touch screens, highly expandable, it
is an ideal for space-limited environments, and furthermore it supports
an optional rotational WLAN antenna for wireless network connection.

2
Anti-vibration
With an unique anti-vibration design, All of BPF series Panel PC has
been approved for vibration tests at VIA V4 Eden 1GHz CPU in
operation mode with Hard Disk
Ultra slim design: 55~61 mm thickness
With streamlined mechanical layout, the BPF series panel PC has an
ultra slim thickness for space-limited environment. It is not only
decreases maintenance time but also saves the space considerably.
Cost-effective Fanless Embedded System
The BPF series Panel PC, the most slim, compact size, fanless
embedded computer, is powered by an ultra low power processor, VIA
V4 Eden 1GHz CPU onboard, The total power consumption of the
system is under 27W merely. It generates the best valve for both power
usage and cost saving. Without hard disk space and extra add-on
cards, All of BPF series panel PC presents an ultra slim design and
provides a cost-effective alternative for users. I/O feature contains
VGA, COM, dual LAN, USB 2.0, and PS/2 connectors.
1.1 Major Features
The BPF-3012 series comes with the following features:
¾Ultra slim, fanless, aluminum front panel design
¾12.1” TFT color panel display w/touch screen
¾Built-in HS-2615+VIA V4 Eden 1GHz CPU, 12V DC adapter
¾Onboard graphics, dual ethernet, audio controller
¾1 x 2.5” HDD space
¾BPF-3012-E provides CF, 4 x COM, 4 x USB2.0
¾BPF-3012-G provides Intel® Atom™ processor 1.6GHz
¾Option for dimmer controller, Wireless LAN module
1.2 Specifications
zSystem
SBC Model
HS-2615
CPU
VIA V4 Eden 1GHz CPU
BIOS
Award PnP Flash BIOS
System Chipset:
VIA CX700(M)
System Memory
1 x 200-pin SO-DIMM socket DDR2/533 up to 1GB

3
Display Chipset
VIA CX700(M)
Audio Chipset
VIA VT1708A
Ethernet Chipset
Dual RealTek RTL8139DL 10/100 Mbps LAN
Provides Wireless LAN Module (option)
Drive Bay
1 x 2.5” HDD space
Storage
1 x Type II CF socket
Watchdog Timer
Software programmable time-out intervals from 1~255 sec. or
1~255 min.
Dimensions (LxHxW)
34.5 x 26.5 x 7.43 cm
Cut Out size (LxH)
29.8 x 23.0 cm
Operation/Storage Temperature
0~+45 degrees C/-20~+70 degrees C
EMC
FCC/CE
Front Panel Protection
IP65 compliance
Power Adapter
12V DC in 84W adapter
zPanel & Touch Screen
LCD Size:
12.1”
Max Resolution:
800x3(RGB) x 600
Brightness:
400 cd/m2(typ.)
Contrast Ratio:
600:1 (typ.)
LCD Color:
16.2M/262K colors
Pixel Pitch (mm):
0.3075 x 0.3075
Touch Screen:
12.1” resistive
Dimmer Controller
Dimmer controller on front panel (option)

4
zI/O Interface
External I/O
4 x USB2.0, 4 x COM, 2 x LAN, CF, PS/2 KB/MS, VGA, MIC In,
Line Out
Rear I/O
01. USB2.0 * 2 06. Reset Button 11. VGA
02. COM 1 07. USB2.0 * 2 12. MIC In
03. COM 2 08. LAN * 2 13. Line Out
04. COM 3 09. CF 14. DC In
05. COM 4 10. KB/MS 15. ON/OFF
1.3 Dimensions
Dimension measure in cm

5
Chapter 2
Unpacking
2.1 Opening the Delivery Package
The BPF-3012 is packed with an anti-static bag. The board contains
sensitive electricity components that are easily damaged by static
(electricity). Do not remove the anti-static wrapping until proper
grounding have been taken. Safety instructions has been described
the anti-static precautions and procedures in the previous.
2.2 Inspection
After unpacking the Panel PC, place it on a raised surface and carefully
inspect it for any damage that might have occurred during shipment.
Ground the board and exercise extreme careful to prevent and damage
to the board from static.
The BPF-3012 delivery package contains the following items:
BPF-3012 x 1, w/Power Cable
Utility CD Disk x 1, including System Board User’s Manual x 1 and
BPF-3012 User’s Manual x 1
It is recommended that user keeps all the parts of the delivery package
intactness and store them in a safe/dry place for any reasons that
require for returning the product. In case you find any missing and/or
damaged items from the list, please contact your dealer or sale
representatives immediately.

6
This page intentionally left blank.

7
Chapter 3
Hardware Installation
This chapter illustrates how to install components into the Panel PC
system. External interface please refers to system board’s manual.
3.1 Installation SBC
1. Install the SBC with chassis.
2. Use Two screws install SBC with front panel.

8
3.2 HDD Installation
1. Remove the HDD drive bay holding bracket.
2. Install the holding bracket with HDD, then re-install HDD drive bay
back to chassis.

9
3.3 WLAN Device Installation
1. User can install the Network Card and Network antenna
module us below.
3.4 Back Cover Installation
1. Follow the photo instruction install the back cover into the
chassis.

10
3.5 Wall Mount Kit
1. Follow the photo instruction install the wall mount kit into the
chassis.

11

12
This page intentionally left blank.

13
Chapter 4
Touch Screen Driver Installation
This chapter illustrates the detail information of touch screen driver
installation procedures. The utility disk that came with the delivery
package contains an auto-run program that invokes the installation
programs for the touch screen driver. The following sections describe
the installation procedures of driver based on WIN2000 operating
systems. Other operation system may slightly different.
4.1 Resistive Type Touch Screen Driver
Installation
4.1.1 Installing Touch Screen Driver in WIN95/98
1. Insert Utility CD disk to your CD-ROM drive. The main menu
will pop up as shown below.
2. The screen displays copying “Installation Wizard” and
“PenMount Utilities Installation” screen plus “welcome”
message appear, click on Next>.

14
3. The next screen is “Software License Agreement”, select “I
accept” and click on Next>.
4. Click “Install” to begin the installation.
