User Manual for H-Box Wireless Telehealth Hub
II
Instructions to User
Dear Users,
Thank you for purchasing our product. Please read the
manual carefully before using this device. Failure to
follow these instructions may cause measuring
abnormality or equipment damage.
The Manual is published in English and Boston Life
Labs LLC. has the ultimate right to explain the Manual.
No part of this manual may be photocopied, reproduced
or translated into another language without the prior
written consent. Boston Life Labs LLC. reserves the
right to improve and amend it at any time without prior
notice.
Version of this manual: Ver 1.0
All rights reserved.

User Manual for H-Box Wireless Telehealth Hub
III
Notes:
The contents contained in this manual are subject to
change without notice.
Information furnished by our company is believed to
be accurate and reliable. However, no responsibility
is assumed by us for its use, or any infringements of
patents or other rights of third parties that may result
from its use.
Instructions for Safe Operations
Read all information in the instruction manual
and any other literature included in the box
before using the unit.
Operate the unit only as intended. Don’t use for
any other purpose.
Necessary maintenance must be performed only
by qualified service technicians. Users are not
permitted to maintain it by themselves.
Cautions
Explosive hazard—DO NOT use the equipment
in environment with inflammable gas such as
some ignitable anesthetic agents.

User Manual for H-Box Wireless Telehealth Hub
IV
Warnings
The local law must be followed when disposing
of the device.
Attentions
֠Keep the device away from dust, vibration,
corrosive substances, explosive materials, high
temperature and moisture.
֠The device should be kept out of the reach of
children.
֠ If the equipment gets wet, please stop using it
and do not resume operation until it is dry.
When it is carried from a cold environment to a
warm and humid environment, please do not
use it immediately.

User Manual for H-Box Wireless Telehealth Hub
V
Table of Contents
1 OVERVIEW.........................................................1
1.1 A PPEARANCE ...................................................1
1.2 F EATURES ........................................................2
1.3 N AME AND M ODEL ..........................................2
1.4 A PPLICATIONS AND S COPE ..............................2
2 BASIC OPERATIONS........................................2
2.1 P OWER S UPPLY ................................................3
2.2 P OWER O N .......................................................3
2.3 P OWER O FF .....................................................4
3 TELEHEALTH FUNCTION..............................4
3.1 E NABLE /D ISABLE W IRELESS D EVICE .............4
3.2 D ATA T RANSFER ..............................................5
3.3 H OW I T W ORKS ...............................................5
4 SOCIALALARM FUNCTION (OPTION)........6
4.1 D ESCRIPTION ...................................................6
4.2 P ANIC BUTTON .................................................6
4.3 E MERGENCY C ALL ..........................................6

User Manual for H-Box Wireless Telehealth Hub
VI
4.4 S ETUP & T EST ..................................................7
5 RFID TAG READING.........................................8
6 EXCEPTIONALSITUATIONS..........................8
7 TECHNICAL SPECIFICATIONS......................9
8 MAINTENANCE.................................................9

User Manual for H-Box Wireless Telehealth Hub
-1-
1 Overview
1.1 Appearance
H-Box Front
GSM antenna
Microphone
LED
Speaker
Download
serial port
SIM card slot
Dongles
(not included)
Wireless button
Phone button
ON/OFF switch
RFID antenna
H-Box Bottom
Dongles
(not included)
Speaker
SIM card slot
ON/OFF switch
Phone button
Wireless button
Power prongs
(EU or US)
GSM antenna

User Manual for H-Box Wireless Telehealth Hub
-2-
The Wireless Telehealth Hub includes 12 dongle slots
located all around the upper part of the equipment.
Each dongle slot can receive one dongle.
1.2 Features
The Wireless Telehealth Hub is a GSM-based
equipment with telehealth and social alarm functions.
Automatically capture data from wireless sensors
and send them to a remote secure server;
Receive signal from panic button to trigger social
alarm phone call;
Read RFID tags to trigger specific actions;
1.3 Name and Model
Name: Wireless Telehealth Hub
Model: H-Box
1.4 Applications and Scope
The Wireless Telehealth Hub is intended for home and
medical center to transmit health data from wireless
device to secure remote server and make emergency
phone calls.
2 Basic Operations
The equipment is “plug & play” and doesn’t require

User Manual for H-Box Wireless Telehealth Hub
-3-
any complex user action to function.
2.1 Power Supply
The device is either powered by a standard AC socket
or by its internal batteries (capacity of up to 12 hours).
Each time the Wireless Telehealth Hub plugged in or
out of the AC socket, a deep “beep” sound is played.
2.2 Power On
1. Plug the back prongs into the AC socket.
2. Slide the ON/OFF switch to left, a sharp “beep”
sound is heard and the LED is red for 3 seconds.
3. Then a greeting music is played, the LED turns
blinking orange which means the Wireless Telehealth
Hub is searching the GSM network. When network is
found, the GSM equipment is registered and the LED
turns green.
4. Then the Wireless Telehealth Hub is making a
registration connection to the remote server, a clear
“Ok” tone is played when complete. The Wireless
Telehealth Hub is ready.

User Manual for H-Box Wireless Telehealth Hub
-4-
2.3 Power Off
At anytime, slide the ON/OFF switch to the right, the
Wireless Telehealth Hub will shut down with a sharp
“beep”.
3 Telehealth Function
3.1 Enable/Disable Wireless Device
In order for the Wireless Telehealth Hub to be enabled
for receiving data from a new wireless device, simply
insert the wireless device dongle (provided with the
wireless device) inside one available slot of the
Wireless Telehealth Hub.
In order to disable a wireless device, simply pull off the
matching dongle from the Wireless Telehealth Hub.
Each time a dongle is inserted in or pulled off a dongle
slot, the Wireless Telehealth Hub is synchronized with
the server to allow receiving data. This synchronization
can take up to 30 seconds; when complete, the valid
dongles slowly blink one time.
Dongle

User Manual for H-Box Wireless Telehealth Hub
-5-
3.2 Data Transfer
If a wireless device is enabled with the Wireless
Telehealth Hub (see above) and the user makes a
measurement (also make sure the wireless device is
properly setup, see specific user manual for details), the
result value is automatically sent to the Wireless
Telehealth Hub and the remote secure server, the
matching dongle is fast blinking during data
transmission.
If the connection between the wireless device and the
Wireless Telehealth Hub after the data is transmitted,
the matching dongle slow blinks until the connection is
dropped or used again.
3.3 How It Works
When some dongles are plugged in, the Wireless
Telehealth Hub periodically enters into Bluetooth®
inquiring mode and will search for surrounding
wireless Bluetooth® devices. If a compatible
Bluetooth® device is found and its device ID matches
one of the dongle ID, the Bluetooth® device will
automatically pair and connect with the Wireless
Telehealth Hub.

User Manual for H-Box Wireless Telehealth Hub
-6-
4 Social Alarm Function (option)
4.1 Description
The social alarm function (also called P.E.R.S. for
Personal Emergency Response System) allows the
holder a panic button to automatically call the
emergency services by simply pressing the button.
4.2 Panic button
For Social Alarm functions, a panic button is necessary;
it can be used either as a wrist or a pendant.
When pressed, a small LED is blinking for 10
seconds inside the casing (behind the rubber part)
It doesn’t require to be recharged, the internal
battery life is up to 5 years;
The range of the panic button is above 100m
Never try to open a panic button.
4.3 Emergency Call
When the button of the panic button is pressed by its
holder, a signal is sent to the Wireless Telehealth Hub,
Panic button

User Manual for H-Box Wireless Telehealth Hub
-7-
that signal triggers a phone call to a preset number.
When the phone call is established, a 2 way
conversation is enabled; the remote emergency service
center operator already has all the information about the
caller and can take further action according to the
conversation outcome.
4.4 Setup & Test
Paring: Longtime press the Wireless button for 3
seconds, the Wireless Telehealth Hub plays a sharp
beep sound and enters into pairing mode for 1 minute.
If the button of a panic button is pressed, the Wireless
Telehealth Hub plays a sharp beep sound meaning that
the panic button is properly paired with the Wireless
Telehealth Hub.
Longtime press both the Wireless and Phone buttons for
about 3seconds to delete all the paired information and
enter into pairing mode.
Test Call: In order to perform a test emergency call,
press either the button of the panic button or longtime
press the Phone button of the Wireless Telehealth Hub.
Press or longtime press the Phone button again to end
the call.

User Manual for H-Box Wireless Telehealth Hub
-8-
5 RFID Tag Reading
An RFID reader antenna is located between the LED
and the speaker. When the RFID reader is powered on,
it can read any compatible RFID or NFC tag and the
Wireless Telehealth Hub can trigger an action based on
the software version.
In order to power on the RFID reader antenna for 1
minute, press the Wireless key.
When a tag is read by the RFID reader, a deep “beep” is
played.
Note: RFID tags should be ISO14443A/MIFARE
compatible.
6 Exceptional Situations
Error Indicators: TBD
Symbol Cause Correction
Error Indicators: TBD
Problem Causes and Solutions

User Manual for H-Box Wireless Telehealth Hub
-9-
7 Technical Specifications
A. Model No: H-Box
B. Color: White
C. Dimensions: ￠170mm*70mm
D. Weight: TBD
E. External Power: AC 110V-240, 50/60Hz
F. Internal Power: 3.7V Li-ion battery
G. Indicator: LED with Red, Green, Orange color
H. Speaker: 4 ohm, 5W
I. Microphone: -42dB±3dB
J. Operation Temperature: 0-45℃
K. GSM: Quad-band 850/900/1800/1900
L. RFID: ISO14443A/MIFARE compatible
8 Maintenance
In order to ensure the long service life of the device,
please pay attention to the use of maintenance.
A. TBD
B. TBD
C. The best storage environment of the device is -20ºC
to 60ºC ambient temperature and 10~95% relative
humidity.

User Manual for H-Box Wireless Telehealth Hub
-10-
Do not immerse the device in liquid.
It is recommended that the device should be kept
in a dry environment. Humidity may reduce the
life of the device, or even damage it.

User Manual for H-Box Wireless Telehealth Hub
-11-
Appendix
Key of Symbols
Symbol Description
Wireless button
Phone button
To power on or off the equipment
SN Serial number
Separate collection for this device.

User Manual for H-Box Wireless Telehealth Hub
-12-
Boston Life Labs LLC.
Address:
Cambridge Innovation Center
One Broadway 14th
Cambridge, MA 02142, U.S.A.
Tel: [phone]
Email: [e-mail]
Website: www.bostonlifelabs.com

User Manual for H-Box Wireless Telehealth Hub
FCC ID: YTKH-BOXU
This device complies with Part 15 of the FCC Rules:
Operation is subject to the following two conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference that is received,
including any interference that may cause undesired operation.
WARNING:
Changes or modifications to this unit not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the equipments.

User Manual for H-Box Wireless Telehealth Hub
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
