Boulder 812 User manual

i
255 South Taylor Avenue Louisville, Co 80027 U.S.A Tel: [phone]x116 E-mail: [e-mail] Web: www.boulderamp.com
Boulder Ampliers, Inc.
255 S. Taylor Avenue
Louisville, CO 80027
[phone], x110
www.boulderamp.com
BoulderAmpliersInc
@boulderampliers
@BoulderAmps
812 DAC Preamplier

1-1

About Boulder Ampliers, Inc.
Boulder was founded in 1984 and is the last high-performance audio manufacturer operating
in North America to still perform all of its own design, engineering and manufacturing in-
house. While this form of production may be more costly than outsourcing, the resulting quality
control and reliability of the nished products are never compromised.
In 2016, Boulder moved into a new, purpose-built production facility to increase manufacturing
eciency and oer space for expansion to meet the needs of future growth.

2-2
Congratulations and thank you for selecting the Boulder 812 DAC Pre-Amplier for your high-
performance sound system. We are certain it will provide you with many years of listening
pleasure.
e 812 represents the concerted eorts of numerous Boulder designers, engineers, and
technicians working to bring you the best audio playback components in the world. Please take a
few minutes to read through this instruction manual prior to using your 812. is will help you
understand the many functions and capabilities of the device. It will also allow you to maximize
the convenience and performance for which it was engineered.
Your Boulder 812 has undergone extensive laboratory tests for safety, functionality and technical
excellence. In addition, it has been individually subjected to rigorous listening trials in our
sound room utilizing a wide range of musical material. No product ever leaves our factory until
we are totally satised that it achieves its full potential.
 

3-3
About - - - - - - - - - - - - - - - - - - - - - - - - 1-1
ank You - - - - - - - - - - - - - - - - - - - - - -2-2
Introduction - - - - - - - - - - - - - - - - - - - - - -4-5
Analog features: . . . . . . . . . . . . . . . . . . . 4-5
Digital features: . . . . . . . . . . . . . . . . . . . . 4-5
Operational features: . . . . . . . . . . . . . . . . . . 4-5
Unpacking and Care . . . . . . . . . . . . . . . . . . 4-6
Before You Start . . . . . . . . . . . . . . . . . . . 4-6
How to Clean the Casework . . . . . . . . . . . . . . . 4-7
Placement and Installation . . . . . . . . . . . . . . . . 4-8
Connections - - - - - - - - - - - - - - - - - - - - - -5-9
Connecting the Analog Inputs . . . . . . . . . . . . . . . 5-9
Connecting to an Unbalenced Analog Source. . . . . . . . . . 5-10
Connecting the Digital Inputs:. . . . . . . . . . . . . . . 5-11
Connecting the 812 to a Home Network . . . . . . . . . . . 5-13
Connectiong the 812 to a Home Network . . . . . . . . . . . 5-14
Connecting a Mobile Device Directly to the 812’s Internal Network . . 5-15
Table of Contents

3-4
Table of Contents
About - - - - - - - - - - - - - - - - - - - - - - - - 1-1
ank You - - - - - - - - - - - - - - - - - - - - - - 2-2
Introduction - - - - - - - - - - - - - - - - - - - - - - 4-6
Analog Features: . . . . . . . . . . . . . . . . . . . 4-6
Digital Features: . . . . . . . . . . . . . . . . . . . 4-6
Unpacking and Care . . . . . . . . . . . . . . . . . . 4-7
Before You Start . . . . . . . . . . . . . . . . . . . 4-7
How to Clean the Casework . . . . . . . . . . . . . . . 4-8
Placement and Installation . . . . . . . . . . . . . . . . 4-8
Connecting the Digital Inputs:. . . . . . . . . . . . . . . 4-9
Connections - - - - - - - - - - - - - - - - - - - - - 5-10
Connecting the Analog Inputs (Back Panel) . . . . . . . . . . 5-10
Connecting Headphone Outputs (Front Panel) . . . . . . . . . 5-11
Output Connections on the back . . . . . . . . . . . . . . 5-12
Connecting to an Unbalanced Analog Source. . . . . . . . . . 5-13
Connection to AC Mains . . . . . . . . . . . . . . . . 5-14
Connecting the 812 to Home Network Via Ethernet . . . . . . . 5-16
Connecting the 812 Internal WiFi to a Home Network . . . . . . 5-17
Connecting an Apple or Android Mobile Device to the 812 . . . . . 5-18

3-5
Using the App on the 812 without WiFi or Ethernet . . . . . . . 5-19
Operation- - - - - - - - - - - - - - - - - - - - - - 6-20
Front Panel Controls . . . . . . . . . . . . . . . . . . 6-20
Volume . . . . . . . . . . . . . . . . . . . . . . 6-21
Preamplier and Headphone Exchange . . . . . . . . . . . . 6-21
Mute . . . . . . . . . . . . . . . . . . . . . . . 6-22
Standby . . . . . . . . . . . . . . . . . . . . . . 6-23
Bluetooth . . . . . . . . . . . . . . . . . . . . . . 6-24
Air-Play Functionality . . . . . . . . . . . . . . . . . 6-24
What is Roon? . . . . . . . . . . . . . . . . . . . . 6-25
Connecting to Roon on 812. . . . . . . . . . . . . . . . 6-25
Using Boulder Control App with Roon . . . . . . . . . . . . 6-25
Setup . . . . . . . . . . . . . . . . . . . . . . . 6-26
Volume Options . . . . . . . . . . . . . . . . . . . 6-26
Volume Type. . . . . . . . . . . . . . . . . . . . . 6-26
Max Volume . . . . . . . . . . . . . . . . . . . . . 6-27
Default Volume . . . . . . . . . . . . . . . . . . . . 6-27
Mute Level . . . . . . . . . . . . . . . . . . . . . 6-28
Balance . . . . . . . . . . . . . . . . . . . . . . 6-29
Input Settings . . . . . . . . . . . . . . . . . . . . 6-30
Input Trim . . . . . . . . . . . . . . . . . . . . . 6-30
Input Balance . . . . . . . . . . . . . . . . . . . . 6-30

3-6
eater Mode/DAC Mode . . . . . . . . . . . . . . . . 6-31
Output Settings . . . . . . . . . . . . . . . . . . . . 6-32
Headphone Gain . . . . . . . . . . . . . . . . . . . 6-32
DAC Mode . . . . . . . . . . . . . . . . . . . . . 6-32
Preamp Output Always On . . . . . . . . . . . . . . . . 6-32
System Settings . . . . . . . . . . . . . . . . . . . . 6-33
Factory Defaults . . . . . . . . . . . . . . . . . . . 6-35
Input Defaults . . . . . . . . . . . . . . . . . . . . 6-36
Programming - - - - - - - - - - - - - - - - - - - - 7-37
HTML Programming . . . . . . . . . . . . . . . . . 7-37
Appendix - - - - - - - - - - - - - - - - - - - - - - 8-38
Technical Specications . . . . . . . . . . . . . . . . . 8-38
Weights and Dimensions . . . . . . . . . . . . . . . . 8-40
812 DAC Preamplier Dimensions . . . . . . . . . . . . . 8-41
Troubleshooting . . . . . . . . . . . . . . . . . . . 8-42
Notes: . . . . . . . . . . . . . . . . . . . . . . . 8-43

4-7

e 812 embodies years of development and is one of the most advanced audio components
available. Here are some of the features that set the 812 apart from the competition:
Analog Features:
• Boulder rotary volume control. (100 dB range)
• 1/8 inch, 1/4 inch, Pentaconn and 4 pin XLR headphone outputs.
• Low power-consumption Standby mode.
• Two pair Analog Inputs.
• One pair of balanced outputs XLR connectors for preamp out.
Digital Features:
• Boulder digital conversion system.
• Ethernet, USB Memory device, USB-B, Coaxial, 2 Toslink digital input connections.
• Bluetooth.
• Roon™ endpoint compatibility.
• Network streaming.
• UPnP renderer.
• AirPlay functionality.
Operational Features:
• Boulder Controller app control.
• Headphone sensitivity adjustments.
• Automatic soware updates when connected to the Internet.
• Comprehensive setup congurations.
• Control app for Android and Apple devices.
• IP control with two-way communication for external control systems.
• HTML Control and Setup page for access to additional customizable features.

4-8

Unpacking and Care
e 812 is somewhat heavy and features nely nished casework. Please use care when
unpacking, liing, and installing the 812 to avoid personal injury or damage to the casework and
furniture. e 812 weighs 18 lbs. (8.16 kg).
Be sure to save all packing materials! e 812 is shipped in a foam wrap to protect the units ne
nish. Try not to damage this wrap in the event that the unit must be transported elsewhere in
the future.
Before You Start
You should have received a large, heavy box. e pieces included inside the box are:
1. 812 DAC Preamplier
2. Quick Start Guide
3. Power Cord
4. Headphone Jack Cover
5. USB Wi Dongle
If any of these pieces are missing or damaged, please contact your authorized Boulder dealer
immediately before continuing with the installation.

4-9

How to Clean the Casework
If the 812 must be cleaned, use only a so, lint-free cloth moistened with plain water.
Never use any type of chemical cleaner unless recommended by your dealer or the Boulder
factory.
Do not use bleach! Bleach will remove the anodized surface of the casework.
Never use any type of abrasive to clean the casework.
If you have any questions, please contact your authorized Boulder dealer.
Placement and Installation
Your Boulder 812 is designed to reduce the eects that external magnetic elds and radio
frequencies (RF) have on its circuitry. While placement is not critical, known magnetic elds
should be avoided whenever possible.
Because it is somewhat heavy, the 812 must be placed on a sturdy, stable surface.
Be sure to leave access to the AC mains and interconnect cables when installing the 812.
Depending on how easy it is to access the back panel of the 812, it may be wise to pre-install the
power and interconnect cables before placement.

4-10
Connecting the Digital Inputs:
e 812 can be connected to many dierent types of digital sources and will provide excellent
sound quality for each. e 812 includes digital input connections for Toslink (optical), USB
Memory Devices, USB type B, Coaxial and Ethernet/ Network audio. e 812 is also a Roon
endpoint, which enables it to stream from multiple audio subscription services.
Connect each digital source to one of the digital inputs provided on the rear panel of the 812.
Later, you will be able to program each input with the source’s name and photo (please see Input
Settings on page 28), so you may want to make a list of each source as you connect them.
NOTE: A NAS hard drive connected to the USB inputs must be self-powered. e USB input
connections on the 812 cannot provide enough power for a NAS hard drive.


5-11
Connecting the Analog Inputs (Back Panel)
To get started listening, you only need to connect sources to the 812 as you would any other
preamplier. Please take note of the following:
e 812 can be connected to many dierent types of analog sources and will provide excellent
sound quality for each. To fully realize the sonic potential of your 812, use balanced cable
connections whenever possible. Balanced cables minimize interference from magnetic and RF
sources.
Connect each analog source to one of the two inputs provided on the rear panel of the 812.

Input 1
Input 2

5-12

Connecting Headphone Outputs (Front Panel)
On the front of the 812 there is 4 outputs for dierent types of headphones. Le is the 4 pin
XLR headphone output. Top middle Sony Pentaconn headphone output. Bottom middle is the
1/8 inch jack. On the right is the 1/4 inch headphone jack. You can use up to all 4 headphone
outputs simultaneously with no fear of harming the amplier or headphones.
4 Pin XLR Pentaconn 1/8 inch 1/4 inch

5-13

Output Connections on the back
ere is one set of XLR analog output connections on the back of the 812 to go to an amplier.
When used as a preamplier, these outputs can also serve as a xed level output in "DAC Mode."
Outputs

5-14
Connecting to an Unbalanced Analog Source
Although the inputs and outputs are all of the 3-pin XLR type, an unbalanced source can easily
be accommodated by using a special cable. is cable has an RCA phono-type connector on the
source end and a 3-pin XLR connector for the input/output on the 812 end.
e negative input (pin 3) should be wired to ground only at the RCA phono connector. is
brings the inverted input reference of the 812 to the unbalanced source ground, thus reducing
ground loops.
Another option for connecting unbalanced sources is the Boulder ABL2 input adapter. It
converts a balanced input into an RCA phono input at the rear of the 812. Like the above cable,
the negative input of the 812 is connected to the ground of the RCA phono. However, this
negative side will then share the shield wire with the chassis ground and will not have the best
hum rejection.


5-15
Connection to AC Mains
Your 812 is supplied with an AC mains power cord appropriate for the location where it was
purchased.
Connect the AC power cord to the Master AC Power Switch connection on the rear panel of the
812 as shown and plug the other end into AC mains.


5-16
When connecting various sources, make a list of what component is connected to each input
so you do not forget the order in which they are connected. You will then be able to name the
inputs on the within the Boulder control app. is list will be very helpful at that time.
Connections from sources such as a phono preamplier, tuner, or cable/satellite receiver can
be made to the analog input connections. Sources such as a DVD player, CD transport, music
server, or NAS drive can be made to the digital input connections.
e Ethernet connections are for network streaming via a UPnP/DLNA media server, Roon
interfacing and streaming, and Internet access to program input names or download soware
updates for the 812. e Ethernet jack should be connected to a network with an active Internet
feed.


5-17

Connecting the 812 to Home Network Via Ethernet
To connect the 812 to your home network via Ethernet. Plug an Ethernet cable into the
"NET" (Network) port located on the back of the unit. Make sure the other end of the cable is
connected to your home router.
If the unit is OFF, turn the unit ON and take it out of Standby. You should be connected to your
home network.
If the unit is ON, the 812 will place itself in standby. Aer the boot up sequence, your 812 should
automatically be connected to your home network.
NOTE: Anytime the 812 switches networks, loses, or gains a network connection, it will
automatically go into standby.
For the best reliability and performance we recommend bypassing any network switches and
running Ethernet directly into the router if possible.
If connecting the 812 via Ethernet, no provisioning is needed to connect to the app. Just connect
your mobile device to the same network your 812 is connected to, open the app and select the 812.

5-18
Connecting the 812's Internal WiFi to a Home Network
Note: You will need a mobile device or tablet and the Boulder Controller app in order to get the
IP address of the unit and to start provisioning process.
Make sure there is no Ethernet connected to the 812. If there is, disconnect and make sure
the 812 is turned OFF aer disconnecting. Connect the provided WiFi dongle, to the USB
host in the back of the unit. e 812 must be connected in a system connected to speakers or
headphones.
Turn on the 812 and allow it to boot up. It will go into Standby when boot-up is complete. Turn
the 812 ON from the front panel or from the Boulder Controller app.
Connect the mobile device or tablet to the 812's network by going into WiFi settings on the
mobile device. You will see "Boulder Amplier- (Your unit's serial number)".
Next open the Boulder Controller app. Select "Setup Wireless Network"
Six numbers will be audibly read from 0-9 through your speakers or headphones. Put those 6
numbers in the proof of possession line of the setup screen. ese numbers are unique to your
specic unit.
Select the network you wish to connect the 812 to and enter the password for that network.
Once the credentials are entered into the app press "Go." e number sequence should stop and
you should have full control of your 812 from your mobile device.
NOTE: For best performance and reliability we recommend using an Ethernet connection.
Once connected you should not have to go through the WiFi provisioning unless preforming a
factory reset or restoring WiFi defaults.
If you are having problems with your network setup, please contact your authorized Boulder
dealer.


5-19
Connecting an Apple or Android Mobile Device to the 812
e 812 can easily be controlled via a mobile device as long as the 812 and the mobile device are
on the same network and you have the Boulder Controller app. e app is available on the Apple
App Store or on the Boulder website (www.boulderamp.com) for android users. To connect your
mobile device and control the 812, follow these instructions:
1. Using a wired connection, connect the 812 to a network and then turn it ON via the AC
mains master switch on the rear panel.
2. Connect the Apple (iPhone, iPod, iPad, and/or OS X computer) or Android device to
the same network via a wired or WiFi connection.
3. Open the app on your mobile device select 812 [Your Units Serial number]
4. e “Go” button will then turn blue. Press the Go button on the app and you can
control the 812 from your mobile device.

