Bowflex TC10 User manual

004-4703.120117.E
Service Manual
Nautilus, Inc., [phone], www.NautilusInc.com - Customer Service: North America [phone], outside U.S. www.nautilusinternational.com | © 2011 Nautilus, Inc. | ® indicates trademarks registered in the United
States. These marks may be registered in other nations or otherwise protected by common law. Bowflex, and the B logo are trademarks owned by or licensed to Nautilus, Inc.
Table of Contents
Section Code Section Page Number
1 Important Safety Instructions 2
1 Safety Warning Labels and Serial Number 3
 1  Specications      3
1 Moving Your Machine 4
1 Leveling Your Machine 4
1 Maintenance 5
1 Walking Belt and Deck Lubrication 5
1 Walking Belt Alignment 7
1 Maintenance Parts 8
1 Troubleshooting 10
1 Console Error Codes 11
1 Console Error Code Troubleshooting 17
1 Replacement Procedure Skill Level 20
Part Replacement
2 Replacing the Console 21
3 Replacing the Console / Handlebar Assembly 23
4 Replacing the A/C Inlet 25
5 Replacing the Drive Belt 28
6 Replacing the Motor 31
7 Removing the Treadle Assembly 35
8 Replacing the Motor Control Board 40
9 Replacing the Walking Deck 44
10 Replacing the Front Roller 49
11 Replacing the Walking Belt 52
12 Replacing the Virtual Pivot 58
13 Replacing the Hydraulic Cylinder (shocks) 64
14 Replacing the Lower and Upper I/O Cables 66
Bowflex®TreadClimber® TC10
Service Manual
8017486.120117.A

2
Before servicing or using this equipment, obey the following warnings:
Read and understand the Service Manual before working on the machine. Failure to obey the instructions and safety warnings
could cause injury to the service technician or bystanders.
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the
wall outlet and/or the machine and wait 5 minutes before cleaning, maintaining or repairing the machine. Place the power cord in a
secure location.
• Keep bystanders and children away from the product being serviced at all times.
• Make sure that the repair is done in an appropriate work space away from foot traffic and exposure to bystanders.
• Some components of the equipment can be heavy or awkward. Enlist the service of a second person when you do maintenance
steps involving these components. Do not try to do heavy or awkward steps on your own.
• Use only replacement parts and hardware that are supplied or approved by Nautilus. Failure to use Nautilus-approved replacement
parts can adversely affect the safety and functionality of the equipment creating a risk to users and will void the warranty.
• Be sure that all warning stickers and instructional placards applied to the product stay present and in good condition when doing
maintenance or replacing components. If necessary, request replacement warning stickers or placards from Nautilus customer
service.
• Do not try to change the design or functionality of the machine being serviced as this can adversely affect user safety and will void
the warranty.
• Do not put the machine back in service until all shrouds, instructions, warning labels and correct functionality have been verified
and tested for correct performance.
8006735.120117.B
Service Procedures
Important Safety Instructions
This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Read and
understand all Warnings on this machine.
NOTICE: This document provides important safety instructions, adjustments, and general troubleshooting information for the maintenance of the Bowflex®
TreadClimber®TC10.
If you need assistance, please call Bowflex Customer Service at 1-800-605-3369.
This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Read and understand
all Warnings on this machine.
Nautilus, Inc., [phone], www.NautilusInc.com - Customer Service: North America [phone], [email protected] | outside U.S. www.nautilusinternational.com | Printed in China | © 2014 Nautilus, Inc. | ® indicates
trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Bowflex, the B logo, and TreadClimber are trademarks owned by or licensed to Nautilus, Inc.
WD-40®, and Lube-N-Walk®are trademarks of their respective owners.
Important Safety Instructions and General Troubleshooting
Information for the Bowflex®TreadClimber® TC10

3
SAFETY WARNING LABELS AND SERIAL NUMBER
SPECIFICATIONS
-Moving parts can crush and
cut.
-Keep guards in place.
-Lock out power before
servicing.
9.
•
•
* on inside of Treadles
* under Rear Step
* under Rear Step
* beside power inlet
002-2268
Serial Number
Product Specication
Maximum User Weight: 300 lbs (136 kgs)
Power Requirements:
Operational Voltage: 120VAC 60 Hz
Operating Current: 10A max
This product, its packaging, and components contain chemicals known to the
State of California to cause cancer, birth defects, or reproductive harm. This
Notice is provided in accordance with California’s Proposition 65. If you would
like additional information, please refer to our web site at www.nautilus.com/
prop65.
53”
(134 cm)
51” (129 cm)
30” (77 cm)

4
Moving Your Machine
The TreadClimber®tnessmachineweighsapproximately158lbs(71.8kg)whenfullyassembledand
requires caution when being moved. Use the Transport Hand Bar found under the front of the machine
tomoveit.TogetaccesstotheTransportHandBar,turntheLevelersuntilyouhavesufcientclearance
betweenthemachineandoor.
Your machine can be rolled on the transport wheels to a new location. Lower your machine slowly into
itsnewlocationwithoutinjurytoyourheadorngers.
Do not use the uprights, handlebars, or the Console to lift or move the machine. Injury to
you or damage to the machine can occur.
The machine may be moved by one or more persons depending on their physical abilities
and capacities. Make sure that you and others are all physically t and able to move the
machine safely.
Place the machine on a clean, hard, level surface, free from unwanted material or other objects that may hamper your ability to move
freely. A rubber mat should be used below the machine to prevent the release of static electricity and protect your ooring.
For safe storage of the machine and to prevent unsupervised operation of the machine always remove the Safety Key and
disconnect the power cord from the wall outlet and the AC input. Place the power cord in a secure location.
Leveling Your Machine
Levelers are found on the front of the TreadClimber®machine. Make sure the TreadClimber®machine is level and stable before you exercise. To
adjust:
1. Loosen the upper locking nut.
2. Turn the leveler to adjust the height.
3. Tighten the upper locking nut to lock the leveler.
Do not adjust the levelers to such a height that they detach
or unscrew from the machine. Injury to you or damage to the
machine can occur.
13 mm

5
MAINTENANCE
Read all maintenance instructions fully before you start any repair work. In some conditions, an assistant is required to do the necessary tasks.
Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that regular maintenance is
done. Worn or damaged components must be repaired or replaced immediately. Only manufacturer supplied components can be
used to maintain and repair the equipment.
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from
the wall outlet and/or the machine and wait 5 minutes before cleaning, maintaining or repairing the machine. Place the power cord in a
secure location.
Daily: Before each use, inspect for loose, broken, damaged, or worn parts. Do not use the machine if any of these conditions exist. Use a
dry cloth to wipe off any perspiration after each use.
Weekly: Check for smooth roller operation. Clean the machine to remove dust, dirt, or grime. Clean the top of the belt with a slightly damp,
soapy cloth and wipe carefully and thoroughly with a dry cloth. Do not let any liquid get below the belts or into the Base Frame.
Monthly: Make sure all bolts and screws are tight. Tighten if necessary.
NOTICE: Do not clean with a petroleum based solvent or an automotive cleaner. Be sure to keep the Console free of moisture.
Walking Belt and Deck Lubrication
The TreadClimber®machine is equipped with a low maintenance deck and belt system. Belt friction can affect the function and life of the machine.
Your TreadClimber® tnessmachinecamewithastartersupplyoflubricationforthebelts.
Lubrication Schedule
User Level Total Workout Hours per Week When to Lubricate
Light less than 3 hours every 3 months
Moderate 3 to 5 hours every 2 months
Heavy 5 or more hours every month
We recommend that you use one of the following:
• Lube-N-Walk®Treadmill Lubrication Kit (available from www.bowflex.com or your local specialty fitness dealer)
• 100% pure silicone, available at most hardware and auto parts stores.
Asyouuseyourtnessmachine,theConsolewillshow“LUbE”atsettimes.Thisisonlyareminderandshould be added to your inspection
schedule. Only apply lubricant as necessary. Push the START button to accept the reminder.
For the best results lubricate the Treadles periodically with a silicone lubricant, using the following instructions:
1. Unplug the machine fully from the wall outlet, and remove the power cord from the machine. Place the power cord in a secure location.
2. Carefully lift each belt and apply silicone lubricant in the center of the Treadle deck along the entire reachable length of the deck. Apply 0.5 to 1.5
oz. of the lubricant on the deck underneath each belt.

6
NOTICE: Always use a 100% pure silicone lubricant. Do not use a degreaser like WD-40®or a petroleum based product as this could
seriously impact performance.
Note:TheWalkingBeltsmayneedtobeloosenedtoallowforaccessduringlubrication.Consultthe“AdjustingtheWalkingBelts”procedure
if necessary.
3. Connect the power cord back into the machine and then into the wall outlet.
4. Stay to one side of your machine.
5. Switch on your machine and start the belts at the slowest speed. Let the belts operate for approximately 15 seconds.
6. Switch off your machine.
7. Take care to clean up any excess lubricant from the Treadles. We also recommend a periodic inspection of the Treadle surfaces below the belts.
If the decks appear worn, contact a TreadClimber Representative (refer to the Contacts section of this manual).
To decrease the possibility of slipping, be sure the Treadle area is free from grease or oil. Clean off any excess oil from the machine
surfaces.

7
Walking Belt
Adjustment Bolts
Walking Belt Alignment
The walking belts need to be adjusted if they are out of center enough to cause a rubbing or scraping sound. Adjustments can be made at the Front
Roller of each Treadle.
Adjusting the Walking Belts – While operating the machine, notice where the belts run on each Treadle. The Walking Belt Adjustment Bolts are on
the front end of each Roller. If the belt is tracking too far to the right, use a properly sized Hex Key to turn the right adjustment bolt clockwise on that
belt in full turn increments. If the belt tracks too far to the left, do the same thing on the left adjustment bolt.
Note: Do not turn the bolts counterclockwise when you adjust the belt alignment.
Belt Tension Adjustment – Check the belt tension only when the machine is unplugged. From the belt’s midpoint, a correctly tensioned belt should
only have an inch of give. To check, pull the belt upward at its midpoint and measure the distance to the deck. If the distance is more than an inch,
the belt is loose. To tighten, turn both Walking Belt Adjustment Bolts clockwise one-half a turn and check tension again. Repeat this step if necessary.
Note: Bolts are turned counterclockwise equally to decrease belt tension.

8
Maintenance Parts
Cylinders
Power Cord
Safety Key
Rear Cover
Treadle Assembly
Right Upright
Left Upright
Rear Step
Console / Handlebar Assembly
Base Upright

9
Maintenance Parts (Treadle Assembly)
Walking Belt
Adjustment
Screw
Side Foot Support
Platform
Front Roller
Lower Walking
Belt Guide
Treadle Stop
Drive Belt
Drive Motor
Walking Belt
Guide
IGUS Bushing
A/C Inlet
Rear Roller
Motor Control
Board

10
TROUBLESHOOTING
Condition/Problem Things to Check Solution
Unit will not power up/turn on/start Outlet Make sure outlet is functioning correctly. Verify this by plugging another
device (ex: lamp) into the outlet. If outlet is connected to a light switch,
checktomakesureitison.Ifoutletisnotfunctioningndaworking
outlet.
Power cord not plugged in MakesurethepowercordisrmlysecuredtoA/Cinletontheunitand
rmlyinsertedintoanon-GFIwallsocket.
Power switch turned off Makesurethepowerswitchattherearoftheunitisinthe“ON”posi-
tion. Switch will light up red to indicate power is present.
Safety key not plugged in Plug Safety Key into Console (See Safety Key (Emergency Stop Procedures)
within Features section).
Speed displayed is not accurate Display set to wrong unit of mea-
sure. (English/Metric)
Change display units.
Walking belt misalignment Rear belt guides Belts should ride on top of triangular black belt guides at rear of
treadles.
Tracking adjustment Belts are not required to be perfectly centered and are typically farther
out in the rear than they are in the front. This may vary depending on
user’s stride. If belt is tracking to one side far enough to cause rubbing
ofbelt,consultthe“AdjustingtheWalkingBelts”procedure.
Speed dependent grinding or
scraping noise
Belt alignment Check walking belt alignment. Belt contact with metal guides under
Treadle can make a loud grinding sound. If belts are misaligned, adjust
walking belt.
Rollers or motor Contact Customer Care for further assistance.
Hesitation or belt slipping when
walking on unit
Walking belt tension Adjustwalkingbelttensionbyfollowingthe“AdjustingtheWalkingBelt”
procedure.
Knocking noises when unit is
operating
Igus bushing If knocking sound seems to be coming directly from the rear roller,
checkIgus(yellow“hat”shaped)bushingsandreplaceifcracked.
Hydraulic cylinder bolts Check and tighten both upper and lower bolts that connect the hydraulic
cylinders to the unit.
Belts stop turning while in use Safety key Plug Safety Key into Console (See Safety Key (Emergency Stop Procedures)
in Features section).
Motor overload Unit may be overloaded and drawing too much current, causing unit
to shut power down to protect motor. Consult belt lubrication schedule
to determine if belts need lubrication, check walking belt tension, and
restart unit.
Outlet Outlet may not have enough power available for the machine due to
other devices on same circuit. Remove any devices from power circuit
and restart machine.
Consoledisplays“C”,“S”,or“H”
with a number
Console Cycle power off and on to clear the error. If issue recurs be sure to note
the display code and contact Customer Service for further assistance.
Consoledisplays“LUbE”code Belt lubrication Consult lubrication schedule and apply if necessary. Push START but-
ton.

11
• If the error code has never appeared before, the rst step should always be to power the machine off/on, and see if the code re-
appears. If the code re-appears, or has been seen before, then proceed with the steps below.
• After completion of each resolution step, restart the machine and see if the error returns. If not, proceed to the next resolution step. If
issue persists, after all steps followed, contact Customer Service for advanced troubleshooting assistance.
• If multiple codes are present attempt to resolve “Hxx” code before troubleshooting “Cxx” codes. After “Hxx” codes are resolved “Cxx”
codes may not re-appear.
Error Code Error Name Resolution
EStP Estop Error 1.CheckandmakesuretheE-Stopispluggedinandttedcorrectly.
2. Replace the upper electronics
C01 Console over voltage 1. Check all three I/O cable connections (MCB, top of upright, back of
console)
2. Replace I/O cables
3. Replace MCB (Motor Control Board)
C02 Console under voltage 1. Check all three (MCB, top of upright, back of console) I/O cable connec-
tions
2. Replace I/O cables
3. Replace MCB
C03/C04/C05/C06/C07 Console current/hdw errors 1.Troubleshootothercodesrstandrestartmacine.
2. Replace console
C08 Wrong MCB 1. Replace MCB with correct part for machine
H03 Critical motor current 1. Check that all MCB wiring is secure
2. Replace MCB
H05 Communication lost 1. Check all three I/O cable connections (MCB, top of upright, back of
console)
2. Replace I/O cables
3. Seek advanced troubleshooting assistance
H06 Communication issue 1. If issue returns after power off/on seek advanced troubleshooting as-
sistance
H07 Over speed condition 1. If error occurs when machine is powered up or when start button is
pressed, replace MCB
2. If error occurs due to pushing belts beyond motor speed, advise not to
push belts beyond motor speed
3. Seek advanced troubleshooting assistance
H08 No tach detected 1. Check that motor tach I/O cable is connected at both ends
2. Replace motor assembly
H11 Power supply voltage low 1. If error has occurred multiple times replace MCB
H12 Memory error 1. If error has occurred multiple times replace MCB
H13 Hardware failure 1. If error has occurred multiple times replace MCB
H15 Over current 1. Check belt lubrication/tension
2. If heavier user at low speeds set shocks to MIN travel and try shorter
workout at higher speed (over 2.0MPH)
3. If problem has slowly developed over a long period of time and has been
getting worse, replace motor.
ERROR CODES

12
H16 Over speed condition 1. If error occurs when machine is powered up or when start button is
pressed, replace MCB
2. If error occurs due to pushing belts beyond motor speed, advise not to
push belts beyond motor speed
3. Seek advanced troubleshooting assistance
H17 Motor wiring 1. Check motor wiring connections to MCB
2. Replace motor
3. Replace MCB
H18 Wiring short 1. Check all wiring connections at MCB
2. Replace MCB
H19 Voltage issue 1. Check all wiriing connections at MCB, AC plug assembly, and power cord
2. If error has occurred multiple times, replace MCB
H20 MCB backup monitor error 1. If error has occurred multiple times replace MCB
H22 Voltage issue 1. If error has occurred multiple times replace MCB
H23 No tach signal 1. Check motor power wire connection and tach I/O cable connection at both
ends
2. Check that tach wheel is mounted securely to motor shaft. If not, tighten
wheel.
3. Replace motor
H24 Current issue 1.Troubleshootanyothererrorrst.Ifothererrorsresolved,anderrorhas
occurred multiple times, replace MCB.
H26/28/H29 Circuitry issue 1. If error has occurred multiple times replace MCB
H30 Estop Error 1.CheckandmakesuretheE-Stopispluggedinandttedcorrectly.
2. Replace console
3. Replace MCB
H31 Speed higher than current 1. Check all motor connections at MCB
2. Seek advanced troubleshooting assistance

13
Console Service Mode
The Console has a Service Mode. Some options in the Service Mode can be adjusted to the users preferences, but most are helpful for
service of the machine. To access the Service Mode, hold down the Increase and Decrease buttons for 2 seconds.
Option Display Option Description
1 Unit Units Select your preferred unit of measurement; “Lb” = English Imperial, “Si” = metric
2 brt Brightness Control the contrast level of the Console; “8” = maximum intensity, “1” = minimum
3 LOG Error Log * Displays the last 10 error codes. When entering this menu, it automatically shows the latest er-
ror code. Pressing the DECREASE button will show you the second to the latest error and so on.
Pressing INCREASE will show you the oldest error. The time is reference to machine time/hours.
NOTE:ThenumberingheredoesnotrepresenttheMenu#inservicemode.SeeOwner’sManualforthe
actualMenunumber.
1. Units:N/A
2. Brightness:N/A
3. ErrorLog:Displaysthelast10errorcodes.Whenenteringthismenu,Itautomaticallyshowsthe
latesterrorcode.PressingtheDECREASEbuttonwillshowyouthesecondtothelatesterror
andsoon.PressingINCREASEwillshowyoutheoldesterror.Thetimeisreferencetomachine
time/hours
TC20


ErrorTime(Hour)in
TIMEsegment
Error
Time(Minutes‐in
SPEEDsegment
ErrorTypeinCALORIESsegment
ErrorNumberinGoCoach
segment
ErrorTime(Hour)‐InTIM
E
segment
ErrorTime(Minute)‐inDISTANCESegment
ErrorTypeinCALORIESsegment
ErrorNumberinSPEEDsegment
4 Con Console Ver-
sion *
Displays the software version
5 dr Drive Version * Displays the drive version
6 HrS Device Usage Displays the hours-minutes the system has been used. If a Console is replaced with a fresh
(not previously used with 0 statistics on hours/usage) the console will ask the MCB for machine
hours/usage. If MCB is replaced , Console will sync MCB with the correct machine hours.

4. ConsoleVersion:N/A
5. DriveVersion:N/A
6. DeviceUsage:Displaysthehours‐minutesthesystemhasbeenused.IfaConsoleisreplaced
withafresh(notpreviouslyusedwith0statisticsonhours/usage)theconsolewillasktheMCB
formachinehours/usage.IfMCBisreplaced,ConsolewillsyncMCBwiththecorrectmachine
hours.
TC10

TC10

7. DeviceMileage:DisplaystotalMachineMileage
HoursinTIME
segment
Minutes‐inSPEED
segment
HoursinTIME
segment
Minutes‐in
DISTANCEsegment
Menu#

14
7 diSt Device Mileage Displays total mileage



8. MotorCurrentHistory:Displaystheaveragemotorcurrentforthecurrentmaintenance
interval.Pushthedecreasebuttontoviewtheaverageofpreviousintervals.Every40machine
hours,theintervalincreases.

DistanceinTIME
segment
AverageInterval
Current–in
DISTANCEsegment
IntervalNumber–in
SPEEDsegment
Distancein
DISTANCE
segment
8 HiSt Motor Current
History *
Displays the average motor current for the current maintenance interval. Push the decrease
button to view the average of previous intervals. Every 40 machine hours, the interval increases.

9. HardwareType:Displaysthehardwaretype.CurrentlyallTreadclimbersaresetto32.
10. MotorCurrent:Displaystheinstantaneousmotorcurrent.Thismenucanbeusedto
troubleshootmachineforhighcurrent/highfriction.WARNING:pressingSTOPinthismenuwill
causethemachinetostoprightaway.Usershouldnobeonthemachinewhenstoppedis
pressed.WhenweenterthisMenu,a3secondscountdownstarts(justlikearegularworkout)
andthenmachinestartsmoving.UsercanchangespeedwithINCREASEandDECREASEbuttons.

AverageInterval
Current–inSPEED
segment
IntervalNumber–in
TIMEsegment
Instantaneous
Current–in
DISTANCEsegment
Speed–inSPEED
segment
WorkoutTime–in
Timesegment
9 Hd Hardware Type
*
Displays the hardware type

15
10 Curr Motor Current * Displays the instantaneous motor current. This menu can be used to troubleshoot machine for
high current/high friction.
Pressing STOP in this menu will cause the machine to stop right away. User should no be
on the machine when stopped is pressed.
When we enter this Menu, a 3 seconds count down starts (just like a regular workout) and then
machine starts moving. User can change speed with INCREASE and DECREASE buttons.

11. CoastTime:Atesttoseehowlongittakesthebeltstocometocompletestop.Thisisusedto
determinehow“smooth”themachineisasfarasmechanicalfrictiongoes.WARNING:pressing
STOPinthismenuwillcausethemachinetostoprightaway.Usershouldnobeonthemachine
whenstoppedispressed.WhenweenterthisMenu,a3secondscountdownstarts(justlikea
regularworkout)andthenmachinestartsmoving.UsercanchangespeedwithINCREASEand
DECREASEbuttons.Whenstopispressed,machinewillimmediatelytrytostop.Oncebeltsstop
movingcompletely,atotalcoasttimeisdisplayintheDistancesegment.

Instantaneous
Current–in
CALORIESsegment
Speed–inSPEED
segment
WorkoutTime–in
Timesegment
CoastdownTime–in
DISTANCEsegment
Speed–inSPEED
segment
WorkoutTime–in
Timesegment
11 CoAS Coast Time * A test to see how long it takes the belts to come to complete stop. This is used to determine how
“smooth” the machine is as far as mechanical friction goes.
Pressing STOP in this menu will cause the machine to stop right away. User should no be
on the machine when stopped is pressed.
When we enter this Menu, a 3 seconds count down starts (just like a regular workout) and then
machine starts moving. User can change speed with INCREASE and DECREASE buttons. When
stop is pressed, machine will immediately try to stop. Once belts stop moving completely, a total
coast time is displayed in the Distance segment.

12. LoopBack:CurrentlynotusedandwilldisplayFAILafterafewsecondsifentered.
13. ConsoleSerialNumber:Thismenuwilldisplaytheserialnumberoftheconsoleacrossallthe
displays.ItwillstartwithaCshowingthetypeofserialnumber(Console)withdigitsafterthat.

14. DriveSerialNumber:ThismenuwilldisplaytheserialnumberoftheMCBacrossallthedisplays.
It’sstartswithadandfollowsthesamenumberruleasconsole.
CoastdownTime–in
DISTANCEsegment
Speed–inSPEED
segment
WorkoutTime–in
Timesegment
ConsoleSerial
Numberinthisimage
is3572
12 LooP Loop Back * A test to see if the Console is receiving data.

16
13 CSn Console Serial
Number
This menu will display the serial number of the console across all the displays. It will start with a
C showing the type of serial number (Console) with digits after that.
14 dSn Drive Serial
Number *
This menu will display the serial number of the MCB across all the displays. It’s starts with a “d”
and follows the same number rule as console.
15 dES Drive Error
Statistics *
Displays the latest hard error statistics for the MCB. Push the increase and Decrease buttons to
view all error statistics. The display toggles between BUS, MOT, Curr, tArS, ActS, 12S. Record all
values for these displays.
* for Service Technicians
Use the Increase and Decrease buttons to cycle through the Options. To change the value of an Option, push START and use the In-
crease and Decrease buttons to select the desired value. Push START to assign the new value to the Option.
Push STOP to exit an Option and the Service Mode.

17
Error Message Description Resolution Console Service
Mode Option Assist
H03. Critical Motor Current Motor Control Board (MCB) saw
Critical Current
1. What version of code?
2. Does this happen within a few seconds after the
belts starts moving? with user on it? without user on
it? If yes, replace Motor Control Board (MCB).
3. If no, check the Motor wiring connection and the
AC wiring connection.
Option 8, 10, 15
H05. Communication Lost Communication issue with MCB 1. Version 1.00? Does it happen during power UP?
If yes on both, power up the console, unplug the
communication cable from the MCB. Plug the cable
back in. Did H05 go away? Did another error appear?
2. Disconnect the communication cables at the top
of the right upright. Reconnect the cables. Did H05
go away? Did another error appear?
3. Contact Customer Service.
H06. Multiple communication
Packets Failed
Communication issue with MCB 1. Contact Customer Service and file an Advanced
Troubleshooting Form.
H07. System Over Speed Over speed condition was detected. 1. Does error happen as soon as machine starts the
workout or turns ON?
-Replace MCB
2. Is this error combined with any other error?
-troubleshoot other errors along with error.
3. Is the user backpushing the belt or intentionally
pushing back on the belts?
- Avoid pushing back on the belts
4. Contact Customer Service and file an Advanced
Troubleshooting Form.
8, 10, 15
H08. No Tach is Plugged in MCB detected that there was no Tach
plugged in.
1. Check to see the Tach cable is plugged in correctly
to the MCB.
2. Check the Tach Assembly.
3. Replace Tach Assembly.
4. Replace MCB.
15
H11. Power supply Supply Low MCB Saw that The one of it’s power
supply is under operation voltage
1. Replace MCB.
2. Replace Console.
15
H12. Memory Initialization failed Software update failed or MCB is not
programmed
1. Restart the device. Does issue still occur?
-If YES, replace the MCB.
-If NO, contact Customer Service.
H13. Hardware Failure MCB detected that one of the main
hardware components has failed or is
not working properly.
1. Does this occur all the time?
-If YES, Check all wirings. Replace MCB.
2. Contact Customer Service and file an Advanced
Troubleshooting Form.
8, 10, 15
H15. Over Current MCB Saw excessive current during
workout that could potentially damage
the motor or heat up
1. Does this issue happen without the user on the
machine?
If Yes:
-Check the motor wiring and Inlet wiring.
-Replace Motor.
-Replace MCB.
If NO:
-user weights between 200-300 at lower speeds of
0.5-2.0 MPH?
Then lube the Belt, increase shock settings (less
travel), and increase speed.
8, 10, 15
Console Error Code Troubleshooting

18
Error Message Description Resolution Console Service
Mode Option Assist
H16. Backup protecion saw over
Speed
Backup Monitor saw over speed 1. Did this issue happen as soon as workout was
about to start?
-If YES: Check wiring and if all is well, replace MCB.
-If NO: Was there an H07 error as well?
Yes- Troubleshoot H07.
8, 10, 15
H17. Motor is OPEN MCB detected an Motor Open condition 1. Was this error received as soon as the workout
countdown?
-If YES: Check motor leads. Check motor connection
to MCB.
-If all is good, replace MCB.
-Replace Motor.
15
H18. Possible Short deteted in
MCB
MCB detected a short 1. Does this error occur as soon as the machine
workout starts?
-If YES: Replace MCB
-If NO:
2. Any other errors that are shown with H18? H03?
-If YES: Trouble shoot H03.
-If NO: Contact Customer Service.
8, 10, 15
H19. Motor Supply too low MCB saw supply for motor is below
operation voltage
Does this happen all the time when machine is
about to start a workout?
-If YES: Check AC Line In. If AC Line In is good, check
all other wirings. If all is good, replace MCB.
-If NO: Contact Customer Service and file an Ad-
vanced Troubleshooting Form.
10, 15
H20. Backup Micro did not
respond
Backup Monitor did not respond to
turning on relay
Does this happen all the time?
-If YES: replace MCB.
-If NO: restart machine, contact Customer Service
and file an Advanced Troubleshooting Form.
15
H22. Supply too High MCB Saw that the power supply is over
safe operating voltage
1. Does this error occur all the time?
-If YES: replace MCB.
-If NO: restart machine.
10, 15
H23. No Tach Pulse is seen MCB Detected that tach was plugged
in but saw no tach pulses
Does this error happen at the beginning of the
workout ( within a few seconds of entering workout
screen)? Does the motor move? Do the belts move?
-If YES: Check motor wire leads. Check Tach Wheel.
Check tach wiring on both MCB and Tach assembly.
-If NO: restart machine if error presists, contact Cus-
tomer Service and file an Advanced Troubleshooting
Form.
10, 15
H24. Backup Micro saw exessive
Current
Backup Monitor saw excessive Current
Limit and shut off the system.
Does this error happen all the time? When machine
is turned ON? When Machine is about to start a
workout?
-If YES: replace MCB.
-If NO : any other error show up with this error?
Troubleshoot other error (H03,H15)
8, 10, 15
H25. Backup Safety Internal Fault Backup monitor could not configure cor-
rectly due to hardware malfunction
1. Restart machine.
2. Error keeps happening? Replace MCB.
H26. BackupSafety Idmag bad
circuitry
Backup Monitor detected a bad Over
Current Detection Circuitry
1. Restart machine.
2. Error keeps happening? Replace MCB.
8, 10, 15

19
H28. Backup Has relay On with-
out Permission
Backup Monitor had relay ON without
permission
1. Restart machine. Does the error happen still?
2. Replace MCB.
H29. Possible Stuck Relay MCB wanted relay OFF but did not see
bus volts dropping.
1. Turn off machine and wait a couple of minutes.
Turn on the machine. Does error presist? Can you
hear a “relay” click? If not, replace MCB.
2. Contact Customer Service and file an Advanced
Troubleshooting Form.
6, 7, 8, 15
H30. Possible ESTOP detection
out of sync
Console ESTOP detection might be out
of sync with MCB
1. Check and make sure the E-Stop is plugged in and
fitted correctly.
2. Check console E-Stop cable connection.
3. Replace console.
4. Replace MCB.
15
H31. Motor Short MCB detected a fast over speed could
not see any current (due to fet being
off)
Does this error happen when machine is about to
start a workout?
-check motor connections and make sure they are
not loose.
-Contact Customer Service and file an Advanced
Troubleshooting Form.
8, 10, 15

20
REPLACEMENT PROCEDURE SKILL LEVEL
Level I : Low - very little mechanical knowledge or exposure.
Level II : Intermediate - some experience with mechanical procedures
Level III : Advanced - knowledgeable about mechanical procedures
