BOXLIGHT MimioFrame Manual

BOXLIGHT MimioFrame
Setup SOP
2022, 08, 17

Table of contents
Parts List
Accessories List
Parts Description
Assembly Teaching
Assembly Teaching
Calibration
Troubleshooting

Parts List
Parts Description Parts Description
①Frame edge ( AD segment ) ⑤Connection Element
②Frame edge ( CB segment ) ⑥Connection Element (Outlet)
③Frame edge ( BA segment ) ⑦Fixing Screw
④Frame edge ( DC segment ) ⑧USB control cable

Accessories List
Parts 1 2 3 4 5
Description Dummy Pen USB2.0 Cable
3M x 1
Double-sided
Tapes Spare Cable Download card
Photos

Parts Description - AD segment
Side Edge
The PCB board in the edge can be
pulled out and pushed in
The PCB board in the edge can be
pulled out and pushed in
Front Edge
①②
③④⑤
Parts Description
①USB control cable socket
②PCB connection cable
③PCB connection cable socket
④Insulation protective tape
⑤PCB connection cable socket

Parts Description - BA segment
Side Edge
The PCB board in the edge can be
pulled out and pushed in
The PCB board in the edge can be
pulled out and pushed in
Front Edge
①②③
Parts Description
①PCB connection cable socket
②Insulation protective tape
③PCB connection cable socket

Parts Description - CB segment
Side Edge
Front Edge ①
Parts Description
①PCB connection cable

Parts Description - DC segment
Side Edge
Front Edge
①
Parts Description
①PCB connection cable

Sequence 1 Sequence 2 Sequence 3
Assembly Teaching
Connect the D end of the side
strip to the PCB on both sides
with a cable
Connect the B end of the side
strip to the PCB on both sides
with a cable
1. Connect the B end of the
side strip to the PCB on both
sides with a cable
2. At the same time, connect
the USB control cable to the
connection socket

Assembly Teaching
Lock the connection element and fixing screws into the
connecting edge according to the picture.

Assembly Teaching
Schematic diagram of Mimio Frame assembly completed

Assembly Teaching
Connect the Mimio Frame to the NB (computer) and perform
Signal Testing to confirm that the assembly is error-free

Start up MimioFrame Calibration Tool
1. The current tool version is V5.23.
2. After MimioFrame is assembled, connect the touch frame
USB cable to the computer.
3. Execute the IndraRed Touch file without installation on the
computer

Signal Testing
Before installing to the board, perform Signal Testing first to confirm
whether the touch frame wiring is normal

Signal Testing
There is no error message in the Signal Testing (green tick icon),
indicating that the detection wiring is normal.

Assembly Teaching
Attach the Mimio Frame to the whiteboard with double-sided tape

Calibration
Connect Mimio Frame and NB with USB control cable and
execute 9-point calibration

Start up MimioFrame Calibration Tool
1. The current tool version is V5.23.
2. After MimioFrame is assembled, connect the touch frame
USB cable to the computer.
3. Execute the IndraRed Touch file without installation on the
computer

9-Point Calibrate
1. After installing MimioFrame on the board, connect the touch frame USB
to the computer,
2. Perform 9-point calibrate for touch positioning

9-Point Calibrate
1. Enter the 9-point calibrate function page, and click the 9 positioning
points in sequence.
2. After the 9-point calibrate is completed, it can be used normally.
