Bradley Halo S19214 Series User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
215-1685 Rev. P; ECN 18-05-015
© 2018 Bradley
Page 1 of 44 4/9/2018
S19214 Series
Halo™ Pedestal-Mount
Eyewash or Eye/Face Wash

2
S19214 Installation
4/9/2018 Bradley • 215-1685 Rev. P; ECN 18-05-015
Table of Contents
Table of Contents..........................................................................2
Pre-Installation Information ................................................................ 3-4
Halo Pre-Configured Models ................................................................5-6
Product Configuration ......................................................................7
Dimensions ..............................................................................8
Installation Instructions .....................................................................9
Service Parts — Bowl and Hub...........................................................10–11
Service Parts — Eyewash, Eye/Face Wash and Bowl Covers ...................................12–14
Service Parts — Base and Drain.............................................................15
Service Parts — Optional Accessories ........................................................16
Avant l’installation ..................................................................... 17-18
Modèles préconfigurés Halo ..............................................................19-20
Configuration du produit ...................................................................21
Dimensions .............................................................................22
Instructions d'installation ...................................................................23
Pièces de remplacement — Récepteur et moyeu.............................................24–25
Pièces de remplacement — Douche oculaire, Douche oculaire/faciale et couvercle anti-poussières .....26–28
Pièces de remplacement — Bride et drain .....................................................29
Pièces de remplacement — Accessoires en option ..............................................30
Información previa a la instalación. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31-32
Modelos preconfigurados Halo ............................................................33-34
Configuración del producto .................................................................35
Dimensiones ............................................................................36
Instrucciones de instalación. ................................................................37
Piezas de repuesto — Receptor y buje.....................................................38–39
Piezas de repuesto — Lavaojos, lavaojos/rostro y cubierta contrapolvo ...........................40–42
Piezas de repuesto — Base y drenaje ........................................................43
Piezas de repuesto — Accesorios opcionales ..................................................44

3
Installation S19214
Bradley • 215-1685 Rev. P; ECN 18-05-015 4/9/2018
WARNING
Flush the water supply lines before beginning installation and after installation is complete. Test
the unit for leaks and adequate water flow. Main water supply to the eyewash should be “ON” at all
times. Provisions shall be made to prevent unauthorized shutoff.
CAUTION
Emergency equipment must be supplied with tepid water (60°F to 100°F/15.6°C to 37.8°C). Any
prolonged exposure to near freezing water affects the body's ability to maintain body temperature,
increasing the risk of hypothermia.
NOTICE
Before installing this product, ensure that there are adequate clearances around the product and
activation of the product does not interfere with other products or obstructions.
Avoid cleaners containing organic solvents, alcohols and hydrocarbons. Rinse with water after
cleaning.
IMPORTANT
The installation and location of all safety drench showers, eye and eye/face washes must comply
with the requirements of ANSI/ISEA Z358.1.
Read this installation manual completely to ensure proper installation, then file it with the owner or
maintenance department. Compliance and conformity to drain requirements and other local codes
and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding any
packaging material. If any parts are missing, do not begin installation until you obtain the missing
parts.
The ANSI/ISEA Z358.1 standard requires an uninterrupted supply of flushing fluid. Bradley plumbed
emergency fixtures require a minimum of 30 PSI (0.21MPa) flowing pressure.
Self-closing spring-loaded valves are not UL classified to ANSI/ISEA Z358.1.
Weekly activation must be conducted on all plumbed emergency equipment to ensure a suitable
flushing fluid supply is present and any sediment build-up in the supply line is cleared. Emergency
equipment should be inspected monthly to address any maintenance issues ensuring the
equipment is in good operating condition and that there are no signs of wear.
Workers who may come in contact with potentially hazardous materials should be trained regarding
the placement and proper operation of emergency equipment per ANSI/ISEA Z358.1.
For questions regarding the operation or installation of this product, visit www.bradleycorp.com or
call 800-BRADLEY (272.3539).
Product warranties and parts information may also be found under ”Products” on our web site at
bradleycorp.com.

4
S19214 Installation
4/9/2018 Bradley • 215-1685 Rev. P; ECN 18-05-015
Supplies Required:
• (3)
3⁄8" floor anchors and bolts
• Teflon tape and pipe sealant
• 30 PSI (2.0 bar) min/90 PSI (6.1 bar) max flow pressure
• 125 PSI (8.6 bar) max static pressure
• Piping to ½" NPT (BSPP) water supply inlet (30–90 psi [2.0-6.1 bar])
• Piping to 1¼” NPT drain outlet on unit (if included with unit)
• OPTIONAL: sign-mounting hardware
Local codes may require the installation of a backflow prevention valve to complete proper installation.
Compliance with local codes is the responsibility of the installer. Valve must be tested annually to verify that it
is functioning properly. Backflow prevention valves are not included with the fixture and may be supplied by the
contractor or purchased from Bradley Corporation.

5
Installation S19214
Bradley • 215-1685 Rev. P; ECN 18-05-015 4/9/2018
Halo Pre-Configured Models
Halo Model
Number Description UL certified to ANSI/ISEA
Intertek certified
to EN standards
Eyewashes
 S19214EW Halo Eyewash, plastic bowl X X
S19214B Halo Eyewash, stainless steel bowl X X
Eyewashes with Dust Cover
S19214PDC Halo Eyewash, plastic bowl w/ dust cover X X
S19214DC Halo Eyewash, stainless steel bowl & hinged dust cover X X
Eye-Face Washes
S19214FW Halo Eye/face wash, plastic bowl X X
S19214Y Halo Eye/face wash, stainless steel bowl X X
S19214P Halo Eye/face wash, stainless steel bowl w/ hose spray X X
S19214YF Halo Eye/face wash, stainless steel bowl, hand/foot operated X X
Eye-Face Washes with Dust Cover
S19214PDCFW Halo Eye/face wash, plastic bowl w/ dust cover X X
S19214DCFW Halo Eye/face wash, stainless steel bowl & hinged dust cover X X
All Stainless Steel Eye/Face Wash
S19214BSS Halo stainless steel eye/face wash and bowl X X
S19214SC Halo stainless steel eye/face wash, bowl and cover X X
S19214SS Halo stainless steel eye/face wash and bowl with foot activation X X

6
S19214 Installation
4/9/2018 Bradley • 215-1685 Rev. P; ECN 18-05-015
Halo Pre-Configured Models
Halo Model Number Description
IAPMO Oceana
certified to
AS4775 & AS4020
Listed by
Intertek to
EN 15154-2
Eyewashes
 S19214EWZ Halo Eyewash, plastic bowl X
 S19214EWZS Halo Eyewash, plastic bowl, stainless steel piping X X
 S19214BZ Halo Eyewash, stainless steel bowl X
S19214BZS Halo Eyewash, stainless steel bowl, stainless steel piping X X
Eyewashes with Dust Cover
S19214PDCZ Halo Eyewash, plastic bowl w/ dust cover X
S19214PDCZS Halo Eyewash, plastic bowl w/ dust cover, stainless steel piping X X
S19214DCZ Halo Eyewash, stainless steel bowl & hinged dust cover X
S19214DCZS Halo Eyewash, stainless steel bowl & hinged dust cover, stainless steel piping X X
Eye-Face Washes
S19214FWZ Halo Eye/face wash, plastic bowl X
S19214FWZS Halo Eye/face wash, plastic bowl, stainless steel piping X X
S19214YZ Halo Eye/face wash, stainless steel bowl X
S19214YZS Halo Eye/face wash, stainless steel bowl, stainless steel piping X X
S19214YFZ Halo Eye/face wash, stainless steel bowl, hand/foot operated X
S19214YFZS Halo Eye/face wash, stainless steel bowl, hand/foot operated, stainless steel piping X X
S19214PZ Halo Eye/face wash, stainless steel bowl with drench hose X
Eye-Face Washes with Dust Cover
S19214PDCFWZ Halo Eye/face wash, plastic bowl w/ hinged dust cover X
S19214PDCFWZS Halo Eye/face wash, plastic bowl w/ hinged dust cover, stainless steel piping X X
S19214DCFWZ Halo Eye/face wash, stainless steel bowl & hinged dust cover X
S19214DCFWZS Halo Eye/face wash, stainless steel bowl & hinged dust cover, stainless steel piping X X
All Stainless Steel Eye/Face Wash
S19214BSSZ Halo stainless steel eye/face wash and bowl X X
S19214SCZ Halo stainless steel eye/face wash, bowl and cover X X
S19214SSZ
Halo stainless steel eye/face wash and bowl with foot activation X X
All models with EN 15154-2 or AS4775, AS/NZS 4020 Certification include BSPP threading.

7
Installation S19214
Bradley • 215-1685 Rev. P; ECN 18-05-015 4/9/2018
Product Configuration
Standard Selections (Must select one from each category)
Configuration
¨B
¨0
24" Drain Height
Standard, 6" Drain Height
Pipe Material
¨A
¨B
¨C
¨D
¨F
¨G
¨J
NPT, Yellow BradTect Galvanized Steel
NPT, All 304 Stainless Steel
NPT, All 316 Stainless Steel *
NPT, Chrome-Plated
BSPP, Yellow BradTect Galvanized Steel ‡
BSPP, All 304 Stainless Steel ‡
BSPP, Chrome-Plated ‡
Ball Valve
¨1
¨2
Stay-Open Eyewash, Chrome-Plated Brass
Stay-Open Eyewash, 316 SS
Eyewash – Eye/Face Wash
¨A
¨B
¨D
¨E
¨F
¨G
¨H
¨J
Halo Eyewash
Halo Eye/Face Wash
Halo Eyewash, 304 SS Yoke
Halo Eye/Face Wash, 304 SS Yoke
304 SS Halo Eye/Face Wash, 304 SS Yoke
Halo Eyewash, 316 SS Yoke
Halo Eye/Face Wash, 316 SS Yoke
316 SS Halo Eye/Face Wash, 316 SS Yoke
Bowl and Dust Cover
¨A
¨B
¨D
¨E
¨F
¨G
¨H
¨J
¨0
Plastic Bowl, No Dust Cover
Plastic Bowl, Plastic Dust Cover
304 SS, No Dust Cover
304 SS, 304 SS Dust Cover
304 SS, Plastic Dust Cover
316 SS, No Dust Cover
316 SS, 316 SS Dust Cover
316 SS, Plastic Dust Cover
No Bowl or Dust Cover
Activation
¨A
¨B
¨C
¨D
¨E
300 SS Handle
316 SS Handle
300 SS Handle, 300 SS Foot Pedal
300 SS Handle with 316 SS Foot Pedal *
316 SS Handle with 316 SS Foot Pedal *
Drench Hose and Backflow Prevention
¨A
¨B
¨C
¨D
¨0
Drench Hose Kit with Vacuum Breaker
Drench Hose Kit with N9 Backflow Preventer
Drench Hose Kit with 9D Backflow Preventer
Drench Hose Kit without Backflow Preventer
No Drench Hose and No Backflow Prevention
Freeze and Scald Protection
¨N
¨P
¨R
¨0
Anti-Freeze Valve
Anti-Scald Valve
Anti-Freeze and Anti-Scald Valves
No Anti-Freeze Valve and No Anti-Scald Valve
* Not available with barrier-free configurations.
‡ Not available in the U.S.
Model No. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S19214
How to Specify Model and Configurations
for Bradley Halo Products: 214
3421 7 8
9
6. Activation
7. Drench Hose and Backflow Prevention
8. Freeze and Scald Protection
1. Configuration
2. Pipe Material
3. Ball Valve
4. Eyewash – Eye/Face Wash
5. Bowl and Dust Cover
1
S
5 6
NPT = National Pipe Thread
BSPP = British Standard Pipe Parallel Threads
All selections made through the configurator are
only UL certified to ANSI/ISEA Z358.1

8
S19214 Installation
4/9/2018 Bradley • 215-1685 Rev. P; ECN 18-05-015
S19214 shown with Eyewash and Plastic Bowl
Dust Cover
Eyewash Bowl
6"
(152mm)
13"
(330mm)
34¾"
(883mm)
to Bottom
of Base
Dimensions
All dimensions assume standard thread engagement. Variations in manufacturing allow for +/- 1⁄8"
(3mm) per threaded joint. To find the tolerance of a dimension, add the number of thread joints
across the length of the dimension and multiply it by 1⁄8" (3mm).
35½"
(902mm)
to Bottom
of Base
13¼"
(337mm)
18½"
(470mm)
S19-430EH Drench Hose Foot Pedal Activation
19¾"
(502mm)
Water Flow Rate
Eyewash 4–5¼ gpm
Eye/Face Wash 4–5¼ gpm
Body Wash 2–8 gpm

9
Installation S19214
Bradley • 215-1685 Rev. P; ECN 18-05-015 4/9/2018
½" NPT below supply
inlet, or ½" BSPP
Adapter when option
is specified
1Assembly — Connect Base and Eyewash
Standard eyewash unit is shown. Other units are similar.
Connect components before securing the base to the floor. When connecting
components, use the rubber grip pad (provided) around pipes to prevent marring.
Apply pipe sealant (supplied by installer) to all male-threaded pipe joints, making
sure not to get any excess over the edge of the pipes.
BSPP = British Standard Pipe Parallel Thread (not available in the U.S.)
1¼" NPT drain
outlet or 1-1/4"
BSPP Adapter
when option is
specified
20½"
(521mm)
pipe length
Halo unit with 24"
drain option
Halo unit with standard
drain option
12¾"
(324mm)
pipe length
1¼" NPT
drain outlet
or 1-1/4"
BSPP
Adapter
when option
is specified
½” NPT below
supply inlet, or ½"
BSPP Adapter
when option is
specified
(3) Ø3⁄8" (10mm) holes on
Ø8" (203mm) bolt circle
For optional foot pedal
installation, the base
must be positioned
so that the hole in the
base is perpendicular
to the user.
³⁄₈" bolts and anchors
supplied by installer.

10
S19214 Installation
4/9/2018 Bradley • 215-1685 Rev. P; ECN 18-05-015
1
4
3
5
Cross (Item #3) is for use with freeze/scald
valves and drench hose accessories only.
2b
4
2a
2b
Service Parts —Hub with Bowl
15a
10a
10c
11a
12
17
14
13
16
17
15b
10b
11b
12
17
10c
Hub with Plastic Bowl
Hub with Stainless Steel Bowl
