Bradley S19-210 User manual

Installation
215-604 Rev. W; ECN 12-05-033
© 2013 Bradley
Page 1 of 5 3/19/2013
S19-210SS
Pedestal-Mounted Stainless Steel
Eyewash with Foot Pedal
Table of Contents
Pre-Installation Information. . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Assembly of Components. . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
netzerotools.com
netzerotools.com
netzerotools.com
Bradley S19 210ss Pedestal Mounted Eye Face Wash
Bradley S19 210 Eye Face Wash Hand or Foot

2
S19-210SS Installation
3/19/2013
IMPORTANT
Read this installation manual completely to ensure proper installation, then file it with the
owner or maintenance department. Compliance and conformity to drain requirements and
other local codes and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding
any packaging material. If any parts are missing, do not begin installation until you obtain
the missing parts.
Flush the water supply lines before beginning installation and after installation is complete.
Test the unit for leaks and adequate water flow. Main water supply to the eyewash should be
“ON” at all times. Provisions shall be made to prevent unauthorized shutoff.
The ANSI Z358.1 standard requires an uninterrupted supply of flushing fluid. Bradley
plumbed emergency fixtures require a minimum of 30 PSI (0.21 MPa) flowing pressure.
Flushing fluid should be tepid per ANSI Z358.1.
The inspection and testing results of this equipment should be recorded weekly to verify
proper operation. This equipment should be inspected annually to ensure compliance with
ANSI Z358.1.
Workers who may come in contact with potentially hazardous materials should be trained
regarding the placement and proper operation of emergency equipment per ANSI Z358.1.
Installation
THIS
SIDE
UP
Packing List

P.O.Box309, Menomonee Falls,WI 53051
R
TESTTHISUNIT EACH WEEK
Test-operatevalve(s) each week and sign below.
Reportany malfunctions immediately.
Ventil(e)wöchentlich im Testbetrieb prüfen, bestätigt
durchUnterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESESGERÄT1ST WÖCHENTLICH ZUPRÜFEN.
ESSAIHEBDOMADAIRE
Testle fonctionnement des valveschaque semaine et
signeen bas. S'il y à quelque chosequi ne va pas fait
unrapport immédiatement.
P.O.BOX 309, MENOMONEE FALLS, WI 53052-0309 USA
TEL:1-800-BRADLEY FAX: [phone])
http://www.bradleycorp.com
114-051
netzerotools.com
netzerotools.com

3
Installation S19-210SS
3/19/2013
Installation Instructions
Flush the water supply line before beginning installation.
Supplies Required:
(3) ³⁄₈" floor anchors and bolts
Pipe sealant
Piping to ½" NPT water supply inlet on unit
Piping to 1¼" NPT drain outlet for eyewash
Sign-mounting hardware
Step 1: Secure base to floor
1. Install three suitable anchors (supplied by installer) for ³⁄₈"
bolts in the floor.
2. Bolt the base to the floor anchors using ³⁄₈" bolts (supplied
by installer).
Step 2: Assemble eyewash
1. Assemble eyewash components as shown on page 4.
Apply pipe sealant (supplied by installer) to all male-
threaded pipe joints.
Use the rubber grip pad provided or a strap wrench
around pipes when tightening to prevent marring.
Place the grip pad on the pipe, then put the wrench
over the grip pad and turn the pipe with the wrench.

When connecting the chain, first connect the chain
to the foot treadle “S” hook on the valve handle.
Make sure the chain is pulled tight and opens valve
completely. The length of chain will vary from unit to
unit.
Notice! Once the chain length is determined and confirmed
to operate the valve correctly, use a pliers to close all
s-hook openings to maintain this setting.
Step 3: Connect water supply
1. Connect the water supply piping (supplied by installer) to
the ½" NPT inlet on the eyewash.
2. Connect the drain piping (supplied by installer) to the 1¼"
NPT drain outlet on the eyewash.
3. Mount the safety sign to the wall using sign-mounting
hardware (supplied by installer).
4. Open the water supply lines. Test for leaks and adequate
water flow.
All dimensions assume standard thread
engagement. Variations in manufacturing allow
for +/- 1/8" (3mm) per threaded joint. To find
the tolerance of a dimension, add the number
of thread joints in between a dimension and
multiply it by 1/8" (3mm).
15³⁄₈"
(292mm)
40¾"
(1036mm)
35"
(887mm)
6"
(152mm)
5¹⁄₈"
(130mm)
netzerotools.com
netzerotools.com

4
S19-210SS Installation
3/19/2013
Assembly of Components
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
4.10
4.11 4.12
2
3
4
9.3
10
1
P.O. BOX 309,MENOMONEE FALLS, WI 53052-0309 USA
TEL:1-800-BRADLEY FAX:[phone])
http://www.bradleycorp.com
114-051
P.O. Box 309, Menomonee Falls,WI 53051
R
TESTTHIS UNIT EACH WEEK
Test-operatevalve(s) each week and sign below.
Reportany malfunctions immediately.
Ventil(e)wöchentlich im Testbetrieb prüfen,bestätigt
durchUnterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESESGERÄT 1ST WÖCHENTLICH ZU PRÜFEN.
ESSAIHEBDOMADAIRE
Testle fonctionnement des valves chaque semaine et
signeen bas. S'il y à quelque chose qui ne va pas fait
unrappor t immédiatement.
5
6
9.1 9.5
9.4
9.2
9.1
7
7.1
13
8
9
11
14
9.6
Items 4.1–4.12 come preassembled as Item 4.
1¼" NPT
Drain Outlet
½" NPT
Supply Inlet
Flow Control
This End
netzerotools.com
netzerotools.com

5
Installation S19-210SS
3/19/2013
Parts List
Item Part No. Qty Description
1131-062 1 Base
2 269-237 5 Pipe Tee 1¼" NPT
3 113-584 1 Pipe 1¼" NPT x 26½"
4 S90-317 1 Stainless Steel Spray Ring
Assy.
4.1 111-049 1 Inlet-Drain Fitting
4.2 124-028 1 Center Seal Gasket
4.3 187-053 1 Stainless Steel Bowl
4.4 173-009 1 Cup Strainer
4.5 S21-074 1 Supply Pipe
4.6 113-1159 1 Spacer, Drain
4.7 S05-131 1 Eyewash Yoke
4.8 107-371 2 Dust Cover
4.9 269-912 1 Swivel Stem
4.10 124-055 2 Quad Ring
4.11 S57-148 1 Spray Ring Assembly
4.12 110-209 1 Acorn Nut
5 113-965 1 Pipe, Stainless Steel ½" x 3½"
Item Part No. Qty Description
6269-241 1 Elbow
7 S27-328 1 ½" Ball Valve with Nut
7.1 110-248 1 Nut 316 Stainless Steel
8 S08-336 1 Handle Assembly
9 S45-1314SS 1 Stainless Steel Foot Treadle Kit
9.1 269-646 2 “S” Hook
9.2 134-009A 1 Stainless Steel Chain
9.3 181-014 1 Stainless Steel Foot Pedal
9.4 160-401 1 Screw
9.5 161-164 1 Nut, ³⁄₈"-16 Stainless Steel
Centerlock
9.6 128-136 1 Handle
10 114-051 1 Safety Sign
11 204-421 1 Emergency Tag
12 269-915 1 Grip Pad (not shown)
13 142-002DA 1 Lockwasher
14 153-372R 1 Adapter
Prepack S30-109 includes items 7, 8, 13, 14
For proper handle and ball valve kits, refer to instruction sheet 215-1774.
