BrainLight FLOAT PLUS User manual

brainLight®-3D-Shiatsu Massage Chair FLOAT PLUS

brainLight®-3D-Shiatsu Massage Chair FLOAT PLUS
Thank you very much for purchasing the brainLight®-3D-Shiatsu Massage Chair FLOAT PLUS! The 3D-FLOAT PLUS
presents an upgrade of our 3D-FLOAT with a shoulder air pressure massage, foot sole massage and improved 3D
technology. Through an optimised bodyscan, the chair adjusts the massage directly to your body and pampers you in
the areas of your back, hips, shoulders, neck, feet and legs, using various Shiatsu massage and stretching techniques. You
have chosen the perfect revitalisation for your body.
In order to get the best experience out of the various functions of your massage chair, please read this manual
carefully before using it, especially the safety instructions.
Contents
Safety Instructions ..................................................... 3
Massage Chair Components ...................................... 6
Setup Instructions ..................................................... 8
Acupressure Points .....................................................11
Massage and Remote Control Functions .................... 12
– Automatic Programs ............................................... 13
– Automatic Recline Positions ....................................15
– Basic Settings ......................................................... 16
– Air Pressure Massage ...............................................17
– Massage for the Soles of the Feet ........................... 18
– Manual Back Massage ............................................ 18
– Half-automatic Back Massage ................................ 21
LCD Features ............................................................ 22
General Instructions for Use ...................................... 23
Troubleshooting: No Power ....................................... 25
Replacing the Main Fuse ............................................ 26
Product Specications .............................................. 27
2

brainLight®-3D-Shiatsu Massage Chair FLOAT PLUS Safety Instructions
To prevent any damage, accident or injury, please consider the following safety instructions:
1. People with any of the following conditions are advised to consult their physician or therapist before using the chair:
•People with heart diseases
•People with malignant tumors
•Women during pregnancy or menstruation
•People with abnormalities or curvature of the spine
•People under medical treatment
•People with osteoporosis
People suffering from thrombosis or similar vein conditions are advised not to use the foot and calf massage functions.
Children, those who are ill and disabled people should only use the chair under the supervision of an adult/carer.
2. Installation of the chair:
• Position the chair only on a at, level surface.
•Do not place the chair in a dirty, oily, foggy or damp environment.
•Do not expose the chair to direct sunlight and do not place it too close to other electrical appliances.
3. Before the application:
•Please read the safety instructions thoroughly before using your chair.
•People who weigh over 130kg / 20.5 stone / 286 lbs are not permitted to use the chair.
3

Safety Instructions
4. During the application:
•Do not allow children to play on the chair.
•Keep hands and feet away from the mechanics of the chair.
•Do not use the chair when it is wet and do not operate the chair with damp hands.
•Sit in the chair in an upright position.
•Do not insert any objects into the mechanics, seat cushion or footrest of the chair.
•The massage chair should not be used by more than one person at any time.
•Do not eat or drink while using the massage chair.
•Folding back the neck cushion results in a stronger massage in the neck area.
5. After the application:
•We recommend that after every use of the chair – as is recommended after any type of massage – you drink plenty
of water, in order to help the removal of toxins and waste from the limbic system.
•Please unplug the power cord from the wall socket when the chair is not in use.
6. Do not take the chair apart!
•Do not attempt to dismantle, repair, or modify the chair without the technical guidance of brainLight®GmbH.
•Do not clean the chair with alcohol or evaporative solvents.
•Unplug the power cord when cleaning or maintaining the chair.
Footrest and Armrests
Caution: In order to avoid injury and damage to the chair, please do not sit or stand on the footrest and please do not
lean or sit on the armrests.
4

Caution:
•If you feel unwell or ill when using the chair, pause your session immediately by pushing the POWER-button.
•Unplug the power cord and do not use the chair if the leather or fabric cover is torn or worn-out. Contact the main-
tenance department at brainLight®GmbH.
•If you use greasy hair products, please place a towel under your head in order to protect the cover material of the chair.
• Please handle the remote control with care and operate using dry hands. A light touch with your ngertips is enough to
operate the chair. Please do not use any other, particularly sharp, objects to operate the remote control (pens, ngernails
etc.).
HEAT Function
In order to avoid the chair becoming uncomfortably hot, we advise you to wear appropriate clothing when using the
heat function.
•Children, disabled people and those with reduced sensory perception should not use the HEAT function.
•Do not use the HEAT function for longer than 30 minutes at one time. Allow the massage chair a few minutes to cool
down before using it again. Continuous use of the HEAT function can lead to overheating.
•For optimal well-being, we recommend the use of the HEAT function in combination with the massage functions.
•Turn off the HEAT function separately before switching off the whole chair using the POWER button.
Safety Instructions Safety Instructions
5

Shoulder
air pressure
massage
Backrest
Left side panel / Armrest
Casters
Massage Chair Components
Remote Control
Arm air pressure massage
Waist air pressure massage
Seat air pressure massage
Calf air pressure massage
Foot air pressure massage
Foot sole massage
6

Massage Chair Components Massage Chair Components
Main Switch Box
Power Cable Connection
Cartridge with Main Fuse
ON/OFF Switch
7

Setup Instructions
If your massage chair was delivered by brainLight®
GmbH, the following 12 steps have already been carried
out for you.
Step 1
Remove all packaging material. If you use sharp or poin-
ted tools, make sure not to damage the chair and the ac-
cessories.
Step 2
Pull back the backrest until it snaps in with a "click" sound.
Step 3
Put the side panels to the left and right of the chair. For
protection, please place a thick piece of material or a rug
on the oor under the side panels. On both sides, you will
nd 3 colour-coded air hoses. Connect the air hoses on
the armrests with the respective coloured air hoses at-
tached to the chair.
Step 4
Secure the 3 colour-coded air hoses with the metal clamp.
Step 2
The backrest locks into place with a „click“
sound when folded up.
Connect and secure the air hoses (3 air
hoses on each side of the chair).
Step 3 - 4
8

Setup Instructions Setup Instructions
Step 5
Subsequently, screw the side panels to the left and right
side of the chair frame. The 6 screws required for this are
packed separately (3 screws for each side panel). Please
make sure that the screws are sufciently tightened.
Step 6
Pull out the air hoses in the shoulder area on the backrest
about 8 cm on both sides.
Step 7
Connect each of these air hoses with the L-shaped con-
necting pieces of the shoulder massage units and push the
air hoses around 5 cm back into the backrest.
Step 8
Afx the shoulder massage units at the top and the bot-
tom with the screws that are already attached to the back
frame. Fasten the two zips on the left and right side of the
back frame cover.
Step 5
Afx the armrests with 3 screws on each
side.
Afx the shoulder massage units with the
pre-attached screws – 2 on each side.
Step 8
9

Step 9
Install the remote control holder: loosen the 3 pre-attached
screws on the outside of the right armrest with a cross-tip
screwdriver, position the holder and mount it with the
same 3 screws. Put the remote control in the bracket.
Step 10
Pick up the backrest overlay. The side on which you can
see two small cables is the top end. Connect these 2
cables with the same-coloured cables on the back frame
of the massage chair and please make sure that the trans-
parent plastic spouts fully cover the joints.
Step 11
Place the neck cushion over the backrest overlay.
Step 12
Connect the power cable with the main switch box on the
chair and plug it into a wall socket. Check again to ensure
all steps are complete – your chair is now ready for use.
Setup Instructions
Step 9
Mount the remote control holder with the
3 pre-attached screws.
10

Acupressure PointsSetup Instructions
11

1 2 3 4 5 6
7 9 11
8 10
391716151429 25
26
28
27
19
18
21
20
23
22
12 13
30
31
34
33
32
40
37
35
41
42
38
36
24

Massage and Remote Control Functions
1 ENERGY
2 LUMBAR STRETCH
3 DEEP TISSUE
4 QUICK
Press this button for the 18-minute automatic program ENERGY. After a tiring day at
work or exhaustion from the day before, this program helps to overcome fatigue and gain
new strength in a short amount of time.
Press this button for the 18-minute automatic program LUMBAR STRETCH. Sitting at a
desk for long periods of time will particularly strain the lumbar spine. This stretch program
helps to relieve stress and alleviates spinal pain caused by long-term burdens.
Press this button for the 18-minute automatic program DEEP TISSUE. Stretching and
massaging the bones in the hands and feet initiates the relaxation of the whole body. We
recommend to let this program take effect by subsequently choosing one of the two
AUTO RECLINER positions (buttons 10 and 11).
Press this button for the 9-minute automatic program QUICK. If you are looking for a
quick all-round relaxation, we recommend this massage experience.
The automatic programs I, II, III, and IV have the following options:
Press once: 100 % air pressure intensity, press twice: 50 % air pressure intensity, press three times: 20 % air pressure
intensity
AUTOMATIC PROGRAMS (BUTTONS 1 – 9)
13

5 NECK RELAX With this button you can select the automatic program NECK RELAX. You have two
different program lengths to choose from: Press once for a 15- and twice for a 20-minute
program duration. The combination of a neck massage and different stretching techniques
releases tension in the head and limbs.
Massage and Remote Control Functions
The automatic program V has the following options:
Press once: 15-minute program with 100 % air pressure intensity, press twice: 20-minute program with 100 % air pressure
intensity, press three times: 20-minute program with 50 % air pressure intensity, press four times: 20-minute program with
20 % air pressure intensity.
The automatic programs I to V each begin with a back scan in order to adjust the massage optimally to your body.
The footrest will adjust itself automatically according to your leg length.
6 ARM STRETCH
7 LEG STRETCH
8 FULL BODY STRETCH
7-minute automatic program, primarily for stretching the arms and hands. The
footrest automatically adjusts itself to your leg length.
7-minute automatic program, primarily for stretching the legs and feet. The footrest
automatically adjusts itself to your leg length.
8-minute automatic program for stretching the whole body. The program begins
with a back scan in order to adjust the massage optimally to your body and the
footrest adjusts itself automatically according to your leg length.
14

Massage and Remote Control Functions Massage and Remote Control Functions
10 AUTO RECLINER: FLOAT
11 AUTO RECLINER: INVERSION
8-minute automatic program that primarily relaxes the waist using air
pressure. The program begins with a back scan in order to adjust the
massage optimally to your body and the footrest adjusts itself automati-
cally according to your leg length.
Sitting at a desk or standing for a long period of time creates great
pressure on the waist and pelvis. The reclined position FLOAT helps to
reduce this pressure and general exhaustion. This position is held for
around 30 minutes before the massage chair returns back to the starting
position.
Medical studies show that brain activity depends on the oxygen
content in the brain. Holding the body in the inversion position (feet
are positioned higher than the head) for 15 minutes allows the
enriched, oxygenated blood to ow to the head, stimulating brain
activity and therefore improving cognitive and memory performance
– essential for the health of the brain. The position is held for around
35 minutes before the massage chair returns back to the starting
position.
9 WAIST PRESSURE
AUTOMATIC RECLINE POSITIONS (BUTTONS 10 – 11)
15

Massage and Remote Control Functions
12 POWER
13 STOP
14 FOOTREST
15 RECLINE
16 FLOAT
17 FOOTREST EXTENSION
18 INFRARED HEATING FUNCTION
Press this button to switch the massage chair on/off. When switched off, the massage
chair and massage rolls return back to the starting position.
Press this button to end a massage program. The massage rolls will automatically go
back to their starting position, while the massage chair maintains its current position.
Press this button to adjust the angle of the footrest.
Press this button to adjust the recline angle of the massage chair.
Press this button to adjust the angle of the seat. Your body‘s center of gravity is shifted
so that you experience a feeling of weightlessness and oating.
Press this button to adjust the length of the footrest.
BASIC SETTINGS (BUTTONS 12 – 18)
Press this button to turn on/off the infrared heat function of the
massage chair. It revitalises your cells and improves the blood ow
in the back area.
16

Massage and Remote Control Functions Massage and Remote Control Functions
AIR PRESSURE MASSAGE (BUTTONS 19 – 25)
19 Automatic air pressure massage
20 Shoulder air pressure massage
21 Arm and hand air pressure massage
22 Foot and calf air pressure massage
23 Air pressure massage in the waist
and seat area
24 Air pressure massage in the arm,
hand and shoulder area
25 Air pressure massage in the waist,
seat, foot and calf areas
10-minute program that massages the shoulders, arms, hands, feet,
calves, waist and seat area using air pressure.
7-minute program that massages the shoulders using air pressure.
7-minute program that massages the arms and hands using air pressure.
7-minute program that massages the feet and calves using air pressure.
Air pressure massage on the legs and feet helps against edemata,
stretches the leg muscles and beauties the leg contours.
7-minute program that massages the waist and seat area using air
pressure.
10-minute program that massages the arms, hands and shoulders using
air pressure.
10-minute program that massages the waist and seat area, as well as
the feet and calves using air pressure.
17

Massage and Remote Control Functions
Two 7-minute programs that massage your feet using alternating
speeds. You can adjust the duration of the massage using the TIME
button.
Use this button to turn the manual foot sole massage on and off (press
twice ➔off).
Use this button to adjust the speed of the manual foot sole massage
(3 levels, preset to level 1).
Press these buttons to push out or retract the massage rolls. This
allows the rolls to massage your desired points more accurately and
release targeted tense muscles.
MASSAGE FOR THE SOLES OF THE FEET (BUTTONS 26 – 28)
26 Automatic foot sole massage
27 Turning the manual
foot sole massage on/off
28 Speed of the manual
foot sole massage
MANUAL BACK MASSAGE (BUTTONS 29 – 39)
29 3D massage intensity
All air pressure massage programs have the option of 3 intensity levels:
Press once = soft, press twice = medium, press three times = hard. You can change the duration of a program by using
the TIME button (button 31). You can adjust the recline position according to your wish using buttons 14 - 17.
18

Massage and Remote Control Functions Massage and Remote Control Functions
Press these buttons to choose from 4 different regions for the manual mas-
sage functions: shoulder and neck area, middle back, lumbar region and
whole back.
Press this button to adjust the massage time for the manual functions. The
duration is displayed on a digital time bar.
Press this button to turn the kneading massage on/off (press twice ➔off).
With the respective button, you can adjust the SPEED of the kneading
massage to your needs (6 levels, preset on level 3).
Press this button to turn the Shiatsu massage on/off (press twice ➔off).
With the respective button, you can adjust the WIDTH of the massage rolls
to your needs (3 levels).
Press this button to turn the tapping massage on/off (press twice ➔off).
With the respective buttons, you can adjust the SPEED of the tapping mas-
sage (6 levels, preset on level 3) and the WIDTH of the massage rolls to
your needs (3 levels).
30 Choice of massage region
31 Adjusting the massage time
32 Kneading massage
33 Shiatsu massage
34 Tapping massage
19

Press this button to turn the kneading and tapping massage on/off (press twice
➔off). With the respective button, you can adjust the SPEED of the kneading
and tapping massage to your needs (6 levels, preset on level 3).
Press this button to turn the apping massage on/off (press twice ➔off). Using
the respective buttons, you can adjust the SPEED of the apping massage
(3 levels, preset on level 1) and the WIDTH of the massage rolls to your needs
(3 levels).
Press this button to adjust the width of the massage rolls: wide, medium or
narrow. This does not work for KNEAD or KNEAD & TAP.
Press this button to adjust the massage speed of the manual functions. You
have up to 6 different levels to choose from.
Push these buttons to set the precise position of the massage rolls for the ma-
nual functions (buttons 32 - 36). You are not able to choose a REGION in
addition to this (➔press the REGION button until the display no longer shows
a chosen region).
35 Kneading and tapping massage
36 Flapping massage
37 Width of the massage rolls
38 Massage speed
39 Position of the massage rolls
Massage and Remote Control Functions
20
