iRest ICOMFORT PLUS User manual

SAVE THESE INSTRUCTIONS
OPERATION INSTRUCTIONS
ICOMFORT PLUS MASSAGE CHAIR
Irelax Limited www.irelax.co.nz [email protected]

01
Thank you for purchasing this product. Before you use it, please read the Operation
Instructions in detail for the correct usage of this product, especially the important
safety warnings. Keep the Operation Instructions properly for future reference.
Note: Our conpany reserves the right to change and explain any product design
without prior notice. Product colors are subject to the actual products.
02-03
04-05
06
07
09-10
10-36
10
10-27
28
29
30
30
30
31
32
32
33
Safety and Maintenance
Safety Warning
Name of Components
Function
Introduction to the Remote Controller
Method of Usage
I.Turn on the power supply of this product
II.Massage Function Control Operation
III.Introduction to Armrest Shortcut Keys
IV.Voice Control Instruction
V.Turn off the power and stop massage
VI.Operation Instructions for Bluetooth Speaker Play
VII.Installation Instructions for Legrest
VIII.Instructions for Removal and Use of Head Cushion and Backrest
IX.Floor Protection
X. Instruction for Movement
Product Specification
TABLE OF CONTENTS

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this product.
·Pull out the plug after use or before cleaning to avoid any physical injury or damage to
the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or damaged.
·Do not use this product if the radiator hole is covered or blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
·Do not carry any fragile, explosive, or combustible material in your pocket, such as a
mobile phone and lighter when using the massage chair.
2. Operating Environment
·Do not use this product in a very moist environment such as the bathroom.
·Stop using this product immediately when the ambient temperature changes sharply.
·Do not use this product in any heavily-dusty or caustic environment.
·Do not use this product in a small space or a place without good ventilation.
·The normal room temperature ranges from 0 °C to 35 °C.
·Do not use this product in an excessively humid room such as a bathroom. Use it at a
relative humidity between 20% and 80%.
·Do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from any heat source such as a stove and air outlet of an air
conditioner.
·Do not use this product during thunder or lightning weather.
·Do not use this product in dusty places.
3. The following populations should not use this product
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical devices such as a
pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and those unconscious are
not allowed to use this product.
·People who are told by their physicians to have rest or who feel unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat must pay attention when
using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or cause damage to this
product.
·Do not pull the power cord when plugging or unplugging it. Rough handling is
forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a power switch and plug.
·Be away from this product in case of power failure to avoid any injury if power is
restored suddenly.
·Stop using this product at once while it works abnormal, and consult your local supplier.
·Stop using this product if you feel unwell, and consult your health care practitioner.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of this product by
the personnel responsible for their safety. Children should be supervised to ensure that
they do not play with this product.
·If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified staff in order to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center designated by the
manufacturer only. No user should disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is necessary to roll up the
power cord of this product and store this product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open flame. Avoid prolonged
exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and manufactured,
so no special maintenance is needed.
·Do not use a sharp object to stab at this product.
·Do not roll or pull this product on any uneven ground. Instead, it should be lifted before
moving.
·Please use this product intermittently. Do not keep it working continuously for a long
period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the normal operation sound.
·If the controller cannot work normally, check whether the plug and the power socket are
connected reliably, and whether the power switch is turned on.
·If the rated working time is over, this product will automatically activate the power-off
button; If this product keeps operating for a long period of time, the temperature
protector will stop this product automatically. The product can be used again after half
an hour.
7. Storage Conditions
·Storage room temperature: -5 °C to 35 °C.
·Relative humidity (RH) between 20% and 80%; free of corrosive gases, and a well-
ventilated room.

0504
Safety Warning Safety Warning
Warning Warning
When the legrest of the massage chair is lifted, nobody should apply pressure on
the legrest to prevent the massage chair from falling forward which will damage this
product or result in personal injuries.
Do not remove or pull out the remote controller cable or the power cord in the
standby or power-on state to avoid any damage to this product or accidental electric
shock of a body part. You are advised to unplug the remote controller cable and the
power cord and put them away after you use the massage chair.
Warning
Before sitting on the massage chair, make sure that the massage chair manipulator
does not stay in the seat cushion position to avoid discomfort to the buttocks during
the body pressing down and any damage to the massage chair manipulator.
Warning
When the zero-gravity lying function is enabled, be sure to check whether there is
any child or pet staying or playing under the bottom of the legrest and backrest, in
order to avoid any damage to this product or physical injury.
禁⽌下压

06 07
Name of Components
1. Head pillow
2. 3D digital speaker
(left side with voice
control device)
3. Shoulder airbag parts
4. Arm airbag parts
5. Pocket for remote control
or mobile phone
6. USB charger
7. Seat
8. Calf part
9. Foot part
10. Back part
11. Armrest
12. Handrail shortcut key
13. Side cover
14. Back plastic cover
15. Remote controller
16. Driver box cover
17. Moving roller
18. Power cable & plug
19. Fuse
20. Power switch
21. Power plug connector
Function
· This product has designed a set of massage manipulator that can walk up and
down, four-wheel drive and mute design.·
· There are five simulated massage techniques: finger pressing, kneading,
tapping, tapping and kneading at same time.
· Equipped with shoulder automatic positioning detection.
· Automatic massage functions: automatic massage includes 8 kinds of automatic
massage functions, including comfortable massage, relaxing massage, stretch
massage, shoulder and neck massage, back and waist massage, whole body
massage, fast massage ,spinal massage.
· With two memory function : iMenory 1, iMenory 2.
· Equipped with upper body manual massage function (the whole body, fixed point
and local, upper back ,lower back ,totally five massage parts are selected, and
the speed of each massage manipulation can be adjusted with five speed. In
fixed point and local state, the manipulator can adjust the position up and down;
When tapping, pressing and percussion massage, the width of the massage ball
can be wide, medium or narrow.
· Air pressure function : shoulder airbag massage (totally 4 airbags) ,armrest
airbag massage (totally 8 airbags), foot airbag massage (totally 12 airbags), there
level intensity adjustable.
· Zero wall design for save the room space.
· Backrest frame guide adopts curve guide technology, which completely conforms
to the curve of human back, and can enjoy massage from head to thigh.
· Music playback system, 3D digital audio built into left and right shoulder. Use
the Bluetooth function of the smart device to play music wireless.
· Equipped with intelligent voice control recognition function.,left armrest with voice
control wake up button , voice control can be optional stop or start.
· In the left and right palm air bags, there is a salient massage with a magnetic
massage function.
· Calf rest lifting or recline adjustment, lifting or recline adjustment of leg and back,
zero gravity I or zero gravity II and time setting adjustment function.
· At the bottom of foot have roller massage function, three pairs of rollors massage
on toe root; scraping massage function on the arch and heel.
· At the calf have kneading massage function which can relieve the stiffness and
stress of calf.
· Back heat , adopt with Carbon fiber far infrared heating.
· Left armrest with button : on/off button, footrest lifting&lying button, Auto mode
button, voice control wake up button.
· The right handrail is equipped with USB charging function.
· TFT Color screen controller.
· Shutdown automatic sitting function, manipulator automatic reset function.·
14
16
18
15
17
19 20 21
FUSE:
T5AL 250V POWER INPUT
ON/ OFF
1
2
3
4
8
10
11
712
13
6
5
9
