Branch Ergonomic Chair User manual

Ergonomic Chair
Assembly Guide

The new way of working
you’ve been waiting for.
Scan here for a digital copy
of your assembly guide.

Caution
!
Use this product only for seating one person at a time.
Some screws may be preassembled. If preassembled, ignore assembly instructions.
Do not use this chair as a step stool/ladder, or on uneven floor surfaces.
Do not sit on any part of the chair except the seat.
Do not use chair unless all bolts, screws, and knobs are tightened.
Every six months, please make sure all bolts, screws, and knobs are fully tightened to ensure
stability.
If any parts are missing, broken, damaged, or worn, stop use of the product until repairs are
made using factory-authorized parts.
Failure to follow these warnings could result in serious injury.

Backrest (x1) Armrest (x2) Seat (x1)
5 Star Base (x1) Cylinder (x1) Casters (x5)
Mechanism (x1)
Components
Spring
Washer (x3)
811-3$<-0
(x1)
*pre-installed
in armrests
Armrest Bolt
30mm (x2)
Back Bolt
20mm (x3)
Flat
Washer (x5)
Allen Key
5mm (x1)
Hex
Nut (x2)*

With the 5 Star Base upside-down, push the Casters (x5) into each hole with a fair amount
of force (they should ‘pop’ in). Once completed, turn over so the casters are on the floor and
insert the Cylinder into the 5 Star Base with the larger end on the bottom.
Set the assembled base aside for now - we’ll get back to it later!
12
1

First, thread each of the Back Bolts (x3) with a Spring Washer (x3) and then a Flat Washer
(x3). With the Backrest and Mechanism upside down, slide the seat back into the slot of the
Mechanism. Then, using the Allen Key, screw in the middle bolt loosely first to hold the two
pieces together, secure the left and right bolts, then return to and tighten the middle bolt.
Use your chair box as a table to help! Place the Mechanism on top of the box while letting
the Backrest hang over the side to make it easier to attach both pieces.
2
Back Bolt
Spring Washer
Flat Washer

Grab the chair frame that you assembled in Step 2, and insert it into the Cylinder.
Push down firmly to secure.
3
12

With the Cushion upside down, insert Armrests (x2) into the sides of the chair, making sure
the armrest Adjustment Buttons face the front of the seat (the same direction as the Lock
Levers shown above). Next, thread each of the Armrest Bolts (x2) and Flat Washers (x2)
into the Pre-inserted Hex Nuts in the Armrests, and tighten.
4
Adjustment Button
Lock Lever
Armrest Bolt
& Washer
Pre-inserted
Hex Nut
1
2

5
Grab the seat you assembled in Step 4. On the right side of the Cushion, hold the Seat Depth
Adjustment Pull open while sliding the seat onto the chair frame. Ensure the track on the
bottom of the seat engages on both sides of the Mechanism. Push the seat all the way back
to the base until you hear a click, and release the Pull to secure.
Caution: The seat is only secure once a click is heard when fastening it to the frame.
1
2
Seat Depth
Adjustment Pull

6(optional)
To install: Attach Headrest to the top rear of the chair back frame. Align the holes on the
headrest base to the chair frame, insert both Screws, and tighen with the Allen Key.

All done!
Go ahead, try it out. You may experience what we call an “ahhh” sensation. That’s completely
normal. You’re now well equipped for whatever the workday throws at you.
Now, don’t be shy. Show us how it looks!
@branchfurniture
#ocebybranch

User Guide
Seat Height:
Paddle-shaped lever on the right side
To raise:
While taking your weight
o the chair, lift lever up.
To lower:
While seated, lift lever up.
To recline:
Twist the lever and lean
back. Twist again to lock.
To return upright:
While seated, twist lever
to unlock. Lean back until
you hear a click, then lean
forward.
Armrest Width:
Lever by base of each armrest
To adjust width:
Pull out levers and slide
the base of each arm out
or in. Push levers in to
lock.
Seat Tilt & Lock:
Paddle-shaped lever on left side
Armrest Height:
Button under each armrest
To raise or lower:
While seated, push and
hold button to raise or
lower arm. Release
button to lock.

Lumbar:
Handles on back of chair
To adjust height:
Grasp handles with both
hands and lift up or down
at the same time.
Seat Tilt Tension:
Center round dial below seat
To adjust tilt tension:
Standing in front of the
chair, identify the small
turn dial. Twist clockwise
to tighten tilt tension and
counterclockwise to
loosen it.
User Guide Cont.
Armrest Depth:
Top of each armrest
To adjust depth:
While seated, grasp top of
armrest and slide it
forward or backward.
Seat Depth:
Square lever on right side below cushion
To adjust depth:
Pull out and hold lever
while sliding seat forward
or back. Release lever to
lock.

FAQ & Troubleshooting
Issue
The armrest bolts don’t
seem fully tightened.
I can’t get the seat onto
the chair frame.
My chair won’t tilt.
My chair is stuck in the
reclined position.
The armrests on my chair
are wobbling or not stable.
My lumbar support feels
uncomfortable.
Suggestion
The bolts attaching the armrests to the chair should permit
them to slide. Use the locking levers to tighten.
Pull out the square lever on the side of the seat before
attempting to slide onto the frame.
Make sure to unlock the tilt by twisting the left lever on
your chair up.
If you chair is stuck mid-tilt, recline all the way back until
you hear a click. That will reset the tilt lock and your chair
back should rise to upright.
After you set your preferred armrest width, make sure to
lock the armrests using the two levers above the height
and tilt adjustment levers. When locked, these levers
should be parallel to the seat.
Use the two handles on both sides of the lumbar support
to adjust it up or down. The lumbar rest is designed to
support an upright posture, but if it stays uncomfortable,
you can remove it by rotating the pad 90 degrees (without
rotating the support arm) and applying firm pressure until
it pops o. Contact us if you want a consultation.
Phase
Assembly
Assembly
Usage
Usage
Usage
Usage

Contact
Have a question, comment, or suggestion?
[e-mail]
branchfurniture.com
