Argos Atlantic 759/0692 User manual

Issue 1 - 26/05/10
Assembly Instructions - Please keep for future reference 759/0692
Important – Please read these instructions fully before starting assembly
Atlantic Low Level Bistro Set- Coffee Table
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
For further assistance please visit http://www.argos-support.co.uk/
Dimensions
Diameter - 45cm
Height - 45cm

4.2
This product is
manufactured from
toughened safety glass.
In the unlikely event that
the glass fails it will break
in to a large number of
small fragments that may
be spread over a wide
area. This is a feature of
toughened glass,
designed to remove the
risk of injure from glass
breaking into large shards.
If the glass is chipped
or broken, stop using the
product and consult the
manufacture or supplier.
Check you have all the
components and tools
listed on page 2.
Remove all fittings from
the plastic bags and
separate them into their
groups.
Keep children and
animals away from the
work area, small parts
could choke if swallowed.
Make sure you have
enough space to layout
the parts before starting.
Do not stand or put
weight on the parts during
assembly, this could
cause damage.
Assemble on a soft
level surface to avoid
damaging the unit or your
floor.
Dispose of all packing
carefully and responsibly.
Do not sit or stand upon
horizontal glass surface.
Do not place very hot or
very cold items on the
glass unless adequately
thick tablemats are used to
prevent such items from
coming into contact with
the glass.
The unit
weights approximately
kgs.
Warning:
Please lift with care.
Wash glass with mild
soap and water, rinse
thoroughly, and dry glass
completely.
We recommend the us e
of furniture covers when
not in use.
Do not use the glass as
chopping surface. Do not
strike the glass with hard
or pointed items.
In order to prolong the
life and beauty of your
table, we recommend it be
stored in a dry and
protected area during off
season periods.
Do not use washing
powders or any abrasive
substances which may
scratch the surface.

Table top x 1 Leg frame x 1
Components - Parts
Please check you have all the parts listed below
2
2
1
3
Cross Bar x 1
Note:
The quantities below are the correct amount to complete the assembly. In some cases more
ABC
fittings may be supplied than are required.
Please check you have all the fittings listed below
Components - Fittings
D
15 mm Screw x 6 Metal washer x 6 Plastic cap x 6
Allen key x 1
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105

Assembly Instructions
Step 1
Step 2
3
Assembly frame
Suggest to complete this
product assembly by two
person.
2
1
2
1
A
B
C
2
1
Turn the table top
upside down, then place the
leg frame into position
and aligne with the cross bars
under the top .
Note, ensure the U shaped
section is pulled out.
Important:
Do not fully
tighten all screws
until assembly is
complete.
Fix leg frame and table
top with screws ,
washers , caps .
2
1
A
B
C

Assembly Instructions
Customer Helpline: 03456 400800
Step 3
Assembly is complete.
If you need help or have damaged or missing parts, call the
For further assistance please visit http://www.argos-support.co.uk/
Argos Limited
489-499 Avebury Boulevard Saxon Gate West Central Milton Keynes Bucks,MK9 2NW
4
tep 3
Fix cross bar and leg
frame with screws
washers ，caps .
For your safety, please lock
the leg before using
1
3
2
A
B
C
Step 4
3
2
A
B C
