Brickcom OSD-040 36x Series User manual

36x Outdoor Speed Dome
Network Camera
OSD-040 36x Series
Quick Installation Guide
Quality Service Group

Read Before You Use
1. Power off the camera device
immediately if it starts smoking or
smells unusual.
2. Power off the camera device
immediately if the camera is exposed
to rain or liquid.
3. Do not set the camera device near
any heat sources. (Ex: television and
oven)
4. Keep the camera device away from
direct sunlight.
5. Do not set the camera device over the specific
operating temperature.

6. Do not set the camera device in any wet
and humid environments.
7. Do not set the camera device on
unsteady surfaces.
8. Do not attempt to dismantle the camera
device.
9. Do not drop or hit the camera device.
10. Do not use the camera device when
there is lightning.

1. Check Package Contents
a. Speed Dome Camera
b. Mount Kit
c. I/O Cable
d. Waterproof Rubber
e. Warranty Card f. M5 Screw
g. Dome Cover h. Lubricant
i. Product CD j. Screw for Dome Cover
k. Easy Installation Guide

2. Device Description
<Bottom View>
<I/O Cable>
<Dimension>
Mount
Holder
Ethernet RJ45
10/100 Socket
Safety Wire Hook
I/O Cable Connector
Reset Button
Power LED
Link LED
Audio Out(Pink)
AC Power Input
Extension I/O
Terminal Block
Video Out
Microphone/Line In(Green)

3. Camera Connection
1. Connect the camera to a switch using an Ethernet cable.
2. Connect supplied I/O cable to the camera.
3. To attach external devices, such as sensors and alarms, connect them
to the extension I/O terminal block.

4. Hardware Installation
Before Installation
The SD-040 36x is supplied with a dome cover to protect the camera unit.
Before installation, follow these instructions to attach the dome cover and
remove the mount holder.
1. Unpack the dome package and take out the Dome body.
2. Rotate the mount holder and take it off the Dome body.
3. Remove the protective cover and PE sheet.

4. Apply lubricant to the Dome cover’s water-proof rubber to make the
installation process smoother.
NOTE: The tiny protrusion on the dome cover must align with one of
the four holes on the dome body.
5. Attach the Dome cover to the Dome body by gently pressing down on
the sides of the Dome cover with both hands.
NOTE: DO NOT press the cover from the top as this may cause
damage to the Dome body.
6. Screw the Dome cover and body together.

Install Camera with Mount Kit
1. Make a cable entry hole on the wall/ ceiling to insert the cable(s).
2. Mount the Speed Dome camera according to the “Speed Dome
Mounting Accessories Installation Guide”.
3. Attach the waterproof rubber to the selected mount kit.
4. Route the Ethernet and I/O cables through the top holder and join the
selected mount kit with supplied screws and washers. Then adjust the
Waterproof Rubber over the joint.
5. Connect the Ethernet and I/O cables and hook the safety wired to the
camera.
6. Attach the camera to the top cover with the supplied screw and
washers.
Wall Mounting: Pendant Mount (mounting example)
NOTE: Refer to the mounting instruction in the “Speed Dome Mounting
Accessories Installation Guide” for more details.

5. Setup the Network Camera
1. Insert the Installation CD into the CD-ROM driver. Run Auto-Run Tool
directly from the CD-ROM to start the installation. When installing the
Brickcom software kit for the first time, select a desired language for the
interface. The available languages are listed in the scroll box. Click
<Install> and follow the steps to install the EasyConfig wizard on the
desired computer.
Please follow the instruction of the InstallShield Wizard to finish the
Brickcom Software Kit installation.

2. To launch EasyConfig or PC-NVR Standard, select the application and
click <Finish>. When launching the PC-NVR program, please refer to
the PC-NVR user manual.

EasyConfig
To launch EasyConfig, select EasyConfig from the start menu. If Complete
Setup type was used in the software installation, an EasyConfig icon was
installed on the desktop. Double click to open the icon.
If Custom Setup type was used in the software installation and an EasyConfig
icon was not installed on the desktop, the program will be installed under
C:\Program Files\Brickcom\EasyConfig unless the program was saved to a
preferred directory.
1. Click <Start> to continue. The program will automatically search
for the camera in the intranet.
NOTE - Check “Skip the hardware installation guide” to skip checking the
hardware connection. To check the hardware installation settings, do not
check the option box.

2. Select either “Simple Mode” or “Professional Mode” to obtain the
camera’s IP settings. If “Simple Mode” is selected, EasyConfig will
set up the connection automatically. If “Professional Mode” is
selected, the user will need to configure the IP settings manually.
3. There may be many cameras in the local network. Differentiate the
cameras using their UPnP name. Double click on the camera from
the survey list to connect.

4. Enter the username and password of the camera. For first time
use, the default username and password are “admin/admin.”
5. For configuring the IP address settings, select either <Settings
remain the same>, <Automatically obtain an IP Address (DHCP)>
or <Set IP Address configuration manually>. The DHCP setting is
recommended.

a. If <Set IP Address configuration manually> is selected, the
following pages will be displayed.

6. If the camera supports the EasyLink
TM
function, the following
page will be displayed. Otherwise, this page will not be shown.
*If desired, click <Skip> to skip this setting.
EasyLink
TM
is a unique Brickcom function which allows users to assign a unique
EasyLink name to their network camera’s IP address. There is no need to
configure the router to open up ports or remember hard-to-memorize IP
addresses. Users can log onto [uniqueEasyLinkname].mybrickcom.com to
view the camera’s web GUI and live view.
•Enter a unique EasyLink name whose length must be between 5-32
characters.
•When finished, click the arrow button to continue.

7. When the IP address settings have been configured, the screen will
either display a successful or failed connection message. If the
connection failed, either try again or quit the installation.
a. If “DHCP IP address settings” was selected, the failure page will
be displayed as below:
b. If “Static IP address settings” was selected, the failure page will
be displayed as below:

c. If the connection was successful, the user will see the message:
“Congratulations. The installation of the camera is complete.”
When this window is displayed, click <PC-NVR> to start the PC-NVR
program, <Live View> to view the live video from the connected IP
camera, or <X> in the top right corner of the screen to close the
installation window. To run the PC-NVR program, please refer to the
PC-NVR user manual for more information.
