Thank you for purchasing this quality-built Briggs & Stratton generator. We’re pleased that you’ve placed your confidence in
the Briggs & Stratton brand. When operated and maintained according to the instructions in this manual, your generator will
provide many years of dependable service.
This manual contains safety information to make you aware of the hazards and risks associated with standby generators and
how to avoid them. Because we do not necessarily know all the applications this equipment could be used for, it is important
that you read and understand these instructions thoroughly before attempting to start or operate this equipment. This product
is only for use as an optional generator system which provides an alternate source of electric power and to serve loads such
as heating, refrigeration systems, and communication systems that, when stopped during any power outage, could cause
discomfort or inconvenience.
Save these original instructions for future reference.
This generator requires professional installation before use. Refer to the separate installation manual for full information.
Your installer should follow the instructions completely.
Where to Find Us
You never have to look far to find Briggs & Stratton support and service for your generator. Consult your Yellow Pages. There
are thousands of Briggs & Stratton authorized service dealers worldwide who provide quality service. You can also contact
Technical Service by phone at 800732-2989, or click on Find a Dealer at BRIGGSandSTRATTON.COM, which provides a list of
authorized dealers.
Generator and engine model and serial numbers should be recorded in the installation manual.
Briggs & Stratton Power Products Group, LLC
P.O. Box 702
Milwaukee, WI 53201-0702
Copyright © 2013. All rights reserved. No part of this material
may be reproduced or transmitted in any form without the express
written permission of Briggs & Stratton Power Products Group, LLC.
NOT
for
REPRODUCTION

3
Table of Contents
Important Safety Instructions........................4
Installation ....................................7
For the Installing Dealer/Contractor: ..............................7
Owner Orientation ............................................7
Fuel Factors .................................................8
Generator Location............................................8
Delivery Inspection............................................9
Controls ..................................... 10
System Control Panel.........................................12
Access Ports ...............................................13
Operation .................................... 14
Automatic Operation .........................................14
Setting Exercise Timer ........................................15
Maintenance .................................. 15
Fault Detection System .......................................15
Generator Maintenance .......................................17
Engine Maintenance..........................................18
Battery ....................................................21
Storage....................................................22
Maintenance Chart.............................. 23
Troubleshooting................................ 24
Warranty..................................... 25
Product Specifications ........................... 28
NOT
for
REPRODUCTION

4 BRIGGSandSTRATTON.COM
Important Safety Instructions
SAVE THESE INSTRUCTIONS - This manual contains
important instructions that should be followed during
installation and maintenance of the generator and batteries.
Safety Symbols and Meanings
The safety alert symbol indicates a potential personal
injury hazard. A signal word (DANGER, WARNING, or
CAUTION) is used with the alert symbol to designate a degree
or level of hazard seriousness. A safety symbol may be used
to represent the type of hazard. The signal word NOTICE is
used to address practices not related to personal injury.
DANGER indicates a hazard which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazard which, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazard which, if not avoided, could
result in minor or moderate injury.
NOTICE addresses practices not related to personal injury.
The manufacturer cannot possibly anticipate every possible
circumstance that might involve a hazard. The warnings in
this manual, and the tags and decals affixed to the unit are,
therefore, not all-inclusive. If you use a procedure, work
method or operating technique that the manufacturer does
not specifically recommend, you must satisfy yourself that
it is safe for you and others. You must also make sure that
the procedure, work method or operating technique that you
choose does not render the generator system unsafe.
Fire
Toxic Fumes
Explosive Pressure
Rotating Fan Blade
Lift Hazard Read Manual
Exploding BatteryRotating Belt/Pulley
Chemical BurnAuto Start
Hot SurfaceRotating Parts
Electrical ShockExplosion
WARNING The engine exhaust from this product
contains chemicals known to the State of California to
cause cancer, birth defects, or other reproductive harm.
WARNING Certain components in this product and
related accessories contain chemicals known to the State
of California to cause cancer, birth defects, or other
reproductive harm. Wash hands after handling.
WARNING Running engine gives off carbon monoxide,
an odorless, colorless, poison gas.
Breathing carbon monoxide could result in death,
serious injury, headache, fatigue, dizziness,
vomiting, confusion, seizures, nausea or fainting.
• Operate this product ONLY outdoors in an area that will
not accumulate deadly exhaust gas.
• Keep exhaust gas away from any windows, doors,
ventailation intakes, soffit vents, crawl spaces, open
garage doors or other openings that can allow exhaust
gas to enter inside or be drawn into a potentially occupied
building or structure.
• Carbon monoxide detector(s) MUST be installed and
maintained indoors according to the manufacturer’s
instructions/recommendations. Smoke alarms cannot
detect carbon monoxide gas.
WARNING Storage batteries give off explosive
hydrogen gas during recharging.
Slightest spark will ignite hydrogen
and cause explosion, resulting in
death or serious injury.
Battery electrolyte fluid contains
acid and is extremely caustic.
Contact with battery contents could cause severe
chemical burns.
A battery presents a risk of electrical shock and high short
circuit current.
• DO NOT dispose of battery in a fire. Recycle battery.
• DO NOT allow any open flame, spark, heat, or lit cigarette
during and for several minutes after charging a battery.
• DO NOT open or mutilate the battery.
• Wear protective goggles, rubber apron, rubber boots and
rubber gloves.
• Remove watches, rings, or other metal objects.
• Use tools having insulated handles.
NOT
for
REPRODUCTION

5
WARNING Generator produces hazardous voltage.
Failure to properly ground generator could result
inelectrocution.
Failure to isolate generator from utility power could
result in death or serious injury to electric utility
workers due to backfeed of electrical energy.
• DO NOT touch bare wires or bare receptacles.
• DO NOT use generator with electrical cords which are
worn, frayed, bare or otherwise damaged.
• DO NOT handle generator or electrical cords while
standing in water, while barefoot, or while hands or feet
are wet.
• If you must work around a unit while it is operating,
stand on an insulated dry surface to reduce the risk of a
shock hazard.
• DO NOT allow unqualified persons or children to operate
or service generator.
• In case of an accident caused by electrical shock,
immediately shut down the source of electrical power and
contact the local authorities. Avoid direct contact with
the victim.
• Despite the safe design of the generator, operating this
equipment imprudently, neglecting its maintenance or
being careless could cause possible injury or death.
• Remain alert at all times while working on this equipment.
Never work on the equipment when you are physically or
mentally fatigued.
• Before performing any maintenance on the generator,
disconnect the battery cable indicated by a NEGATIVE,
NEG or (-) first. When finished, reconnect that cable last.
• After your system is installed, the generator may crank
and start without warning any time there is a power
failure. To prevent possible injury, always set the
generator’s system switch to OFF, remove the service
disconnect from the disconnect box AND remove the
15 Amp fuse BEFORE working on the equipment.
WARNING Hazardous Voltage - Contact with power
lines could cause electric shock or burns,
resulting in death or serious injury.
Lifting Hazard / Heavy Object - Could result
in serious injury.
• If lifting or hoisting equipment is used, DO NOT contact
any power lines.
• DO NOT lift or move generator without assistance.
• DO NOT lift unit by roof as damage to generator
will occur.
WARNING Propane and Natural Gas are extremely
flammable and explosive, which could cause
burns, fire or explosion resulting in death or
serious injury.
• Install the fuel supply system according to NFPA 37 and
other applicable fuel-gas codes.
• Before placing the generator into service, the fuel system
lines must be properly purged and leak tested.
• After the generator is installed, you should inspect the fuel
system periodically.
• NO leakage is permitted.
• DO NOT operate engine if smell of fuel is present or other
explosive conditions exist.
• DO NOT smoke around the generator. Wipe up any oil
spills immediately. Ensure that no combustible materials
are left in the generator compartment. Keep the area near
the generator clean and free of debris.
WARNING Exhaust heat/gases could ignite
combustibles or structures resulting in
death or serious injury.
Contact with muffler area could cause
burns resulting in serious injury.
• DO NOT touch hot parts and AVOID hot exhaust gases.
• Allow equipment to cool before touching.
• Exhaust outlet side of weatherproof enclosure must
have at least 5 ft. (1.5m) minimum clearance from any
structure, shrubs, trees or any kind of vegetation.
• Standby generator weatherproof enclosure must be at
least 5 ft. (1.5m) from windows, doors, any wall opening,
shrubs or vegetation over 12 inches (30.5 cm) in height.
• Standby generator weatherproof enclosure must have a
minimum of 5 ft. (1.5 m) overhead clearance from any
structure, overhang, or trees.
• DO NOT place weatherproof enclosure under a deck or
other type of structure that may confine airflow.
• Use only flexible fuel line provided. Connect provided fuel
line to generator. DO NOT use with or substitute any other
flexible fuel line.
• Smoke detector(s) MUST be installed and maintained
indoors according to the manufacturer’s instructions/
recommendations. Carbon monoxide alarms cannot
detect smoke.
• Keep at least minimum distances shown in General
Location Guidelines to insure for proper generator cooling
and maintenance clearances.
• Replacement parts must be the same and installed in the
same position as the original parts.
NOT
for
REPRODUCTION

6 BRIGGSandSTRATTON.COM
WARNING Moving parts could crush and cut.
Starter and other rotating parts could
entangle hands, hair, clothing, or
accessories resulting in serious injury.
• NEVER operate generator without protective housings,
covers, or guards in place.
• DO NOT wear loose clothing, jewelry or anything that
could be caught in the starter or other rotating parts.
• Tie up long hair and remove jewelry.
• Before servicing, remove 15 Amp fuse from control panel
and disconnect Negative (NEG or -) battery cable.
WARNING Hot pressurized coolant could cause serious
injury.
• DO NOT open radiator cap when hot.
• Before servicing, allow coolant to cool.
CAUTION Installing the 15A fuse could cause the
engine to start at any time without warning
resulting in minor or moderate injury.
• Observe that the 15 Amp fuse has been removed from the
control panel for shipping.
• DO NOT install this fuse until all plumbing and wiring has
been completed and inspected.
CAUTION Excessively high operating speeds could
result in minor injury and/or equipment damage.
Excessively low speeds impose a heavy load on generator.
• DO NOT tamper with governed speed. Generator supplies
correct rated frequency and voltage when running at
governed speed.
• DO NOT modify generator in any way.
NOTICE Improper treatment of generator could damage it
and shorten its life.
• Use generator only for intended uses.
• If you have questions about intended use, contact your
authorized dealer.
• Operate generator only on level surfaces.
• Adequate, unobstructed flow of cooling and ventilating air
is critical to correct generator operation.
• The access panels/door must be installed whenever the
unit is running.
• DO NOT expose generator to excessive moisture, dust,
dirt, or corrosive vapors.
• Remain alert at all times while working on this equipment.
Never work on the equipment when you are physically or
mentally fatigued.
• DO NOT start engine with air cleaner or air cleaner
cover removed.
• DO NOT insert any objects through cooling slots.
• DO NOT use the generator or any of its parts as a step.
Stepping on the unit could cause stress and break parts.
This may result in dangerous operating conditions from
leaking exhaust gases, fuel leakage, oil leakage, etc.
• If connected devices overheat, turn them off and
disconnect them from generator.
• Shut off generator if:
-electrical output is lost;
-equipment sparks, smokes, or emits flames;
-unit vibrates excessively.
-unit makes unusual noises.
NOT
for
REPRODUCTION

7
Installation
We sincerely appreciate your patronage. For this reason, we
have made every effort to provide for a safe, streamlined
and cost-effective installation. Because each installation is
unique, it is impossible to know of and advise the trade of all
conceivable procedures and methods by which installation
might be achieved. Neither could we know of possible
hazards and/or the results of each method or procedure.
For these reasons, only current licensed electrical and
plumbing professionals should attempt generator system
installations. Installations must strictly comply with all
applicable codes, industry standards andregulations.
Your generator is supplied with this “Operator’s Manual”
and a separate “Installation Manual”. These are important
documents and should be retained by the owner after the
installation has been completed.
This product is only for use as an optional generator system
which provides an alternate source of electric power and
to serve loads such as heating, refrigeration systems, and
communication systems that, when stopped during any power
outage, could cause discomfort or inconvenience.
NOTICE This product does NOT qualify for either an
emergency standby or legally required standby system as
defined by NFPA 70 (NEC).
• Emergency generator systems are intended to
automatically supply illumination, power, or both, to
designated areas and equipment in the event of failure
of the normal supply. Emergency systems may also
provide power for such functions as ventilation where
essential to maintain life, where current interruption of
the normal supply would produce serious life safety or
health hazards.
• Legally Required standby generator systems are
intended to automatically supply power to selected
loads in the event of failure of the normal source
which could create hazards or hamper rescue or fire-
fighting operations.
Every effort has been made to ensure that information in this
manual is accurate and current. However, we reserve the right
to change, alter, or otherwise improve the product and this
document at any time without prior notice.
Only current licensed electrical and plumbing professionals
should attempt generator system installations. Installations
must strictly comply with all applicable codes, industry
standards, laws and regulations.
For the Installing Dealer/Contractor:
For most applications, the Installation manual contains all
the information required to properly install and start the
generator. This operator’s manual describes routine operation
and owner maintenanceprocedures.
If you need more information in this matter, please call
800732-2989, between 8:00 AM and 5:00 PM CT.
Owner Orientation
This section provides generator owners with the information
necessary to achieve the most satisfactory and cost effective
installation possible.
The illustrations are for typical circumstances and are meant
to familiarize you with the installation options available
with your generator. A thorough understanding of these
options will provide fundamental control over the cost of
your installation, as well as ensure your final satisfaction
andsecurity.
Federal and local codes, appearance, noise levels, fuel types,
and distances are the factors that must be considered when
negotiating with an installation professional. Remember
that as the distance from the existing electrical service and
gaseous fuel supply increases, and the number of 90 degree
bends in the fuel supply increases, compensations in piping
and wiring materials must be made. This is necessary to
comply with local codes and overcome electrical voltage
drops and gaseous fuel pressure drops.
The factors mentioned above will have a direct affect on
the overall price of your generator installation.
In some areas you may need to acquire electrical permits
for installing the generator, building permits for installing
gas lines, and permits for noise allowances. Your installer
should check your local codes AND obtain the permits before
installing the system.
For the Owner:
To help you make informed choices and communicate
effectively with your installation contractor(s), read and
understand Owner Orientation in this manual before
contracting or starting your generatorinstallation.
To arrange for proper installation, contact the store at which
you purchased your generator, your dealer, a licensed
electrician or your utility power provider.
The generator warranty is VOID unless the system is
installed by licensed electrical and plumbingprofessionals.
Every effort has been made to ensure that information in this
manual is accurate and current. However, we reserve the
right to change, alter, or otherwise improve the product and
this document at any time without prior notice.
The Emission Control System for this generator is warranted
for standards set by the U.S. Environmental Protection
Agency and by the California Air Resources Board (CARB).
NOT
for
REPRODUCTION

8 BRIGGSandSTRATTON.COM
Fuel Factors
An important consideration affecting the entire installation
is the type of fuel used by your generator. The system was
factory tested and adjusted using either natural gas or liquid
propane (LP vapor). For proper engine function, factors
that are inherent to each of these fuels, your location and
the duration of possible utility interruptions are important
considerations in the following fuel guidelines:
• Use clean, dry fuel, free of moisture or any
particulate material. Using fuels outside the following
recommended values may cause performanceproblems.
• In engines set up to run on propane (LP), commercial
grade HD5 propane with a minimum fuel energy of 2500
BTUs/ft3 with maximum propylene content of 5% and
butane and heavier gas content of 2.5% and minimum
propane content of 90%.
Natural gas rating will depend on specific fuel but typical
derates are between 10 to 20% off the LP gas rating.
Power Decrease at High Altitude or High Temperature
Air density is less at high altitudes, resulting in less available
engine power. Specifically, engine power will decrease 3%
for each 1,000 feet (300 meters) above sea level and 1% for
each 10° F (5.6°C) above 77°F (25°C). Make sure you and
your installer consider these factors when determining total
generator load.
Delivery Inspection
Carefully inspect the generator for any damage that may have
occurred during shipment.
If loss or damage is noted at time of delivery, have the
person(s) making delivery note all damage on the freight bill
and affix his signature under the consignor’s memo of loss
or damage. If loss or damage is noted after delivery, separate
the damaged materials and contact the carrier and your
installer for claim procedures. Missing or damaged parts are
not warranted.
The generator is supplied with:
• Fully-serviced coolant system
• Fully-serviced oil/lubricating system
• Flexible fuel hook-up hose
• Installation and start-up manual
• Operator’s manual
• Spare access door keys
• Spare 15A fuse
• Touch up paint
To be supplied by installer:
• Carbon monoxide detector(s)
• Smoke detector(s)
• Starting battery
• Reinforced concrete mounting pad
• Connecting wire and conduit
• Fuel supply valves/plumbing
• Various specialty tools/equipment
WARNING Propane and Natural Gas are extremely
flammable and explosive, which could cause
burns, fire or explosion resulting in death or
serious injury.
• The generator is equipped with an automatic safety gas
“fuel shut-off” valve.
• DO NOT operate the equipment if the “fuel shut-off” valve
is missing or inoperative.
NOT
for
REPRODUCTION

9
Generator Location
The actual physical location of your generator has a direct
affect on:
1. The amount of plumbing required to fuel your generator.
2. The amount of wiring required to control and connect
your generator.
Specific location guidelines are discussed in the installation
manual. Acquaint yourself with that information and confer
with your installer. Be sure to ask how your site might
affect installation costs and compliance with local codes
andstandards.
• Install generator outdoors in an area that will not
accumulate deadly exhaust gas.
• DO NOT install generator where exhaust gas could
accumulate and enter inside or be drawn into a
potentially occupied building or structure.
• By law it is required in many states to have a Carbon
Monoxide (CO) detector in operating condition in your.
Carbon monoxide detector(s) (A) MUST be installed
and maintained indoors according to the manufacturer’s
instructions/recommendations. A CO monitor is an
electronic device that detects hazardous levels of CO.
When there is a buildup of CO, the monitor will alert the
occupants by flashing visual indicator light and alarm.
Smoke alarms cannot detect CO gas.
• Ensure exhaust gas is kept away from any windows,
doors, ventilation intakes, soffit vents, crawl spaces,
open garage doors or other openings that can
allow exhaust gas to enter inside or be drawn into a
potentially occupied building or structure. Neighboring
structures may be exposed to the engine exhaust from
your standby generator and must be considered when
installing your standby generator.
• Wind and air currents should be taken into
consideration when positioning generator.
See the installation manual for full details on safe generator
location.
WARNING Running engine gives off carbon monoxide,
an odorless, colorless, poison gas.
Breathing carbon monoxide could result in death,
serious injury, headache, fatigue, dizziness,
vomiting, confusion, seizures, nausea or fainting.
• Operate this product ONLY outdoors in an area that will
not accumulate deadly exhaust gas.
• Keep exhaust gas away from any windows, doors,
ventilation intakes, soffit vents, crawl spaces, open garage
doors or other openings that can allow exhaust gas
to enter inside or be drawn into a potentially occupied
building or structure.
• Carbon monoxide detector(s) MUST be installed and
maintained indoors according to the manufacturer’s
instructions/recommendations. Smoke alarms cannot
detect carbon monoxide gas.
WARNING Exhaust heat/gases could ignite
combustibles or structures resulting in death or serious
injury.
• Exhaust outlet side of weatherproof enclosure must
have at least 5 ft. (1.5 m) minimum clearance from any
structure, shrubs, trees, or any kind of vegetation.
• Standby generator weatherproof enclosure must be at
least 5 ft. (1.5 m) from windows, doors, any wall opening,
shrubs or vegetation over 12 in. (30.5 cm) in height.
• Standby generator weatherproof enclosure must have a
minimum of 5 ft. (1.5 m) overhead clearance from any
structure, overhang or trees.
• DO NOT place weatherproof enclosure under a deck or
other type of structure that may confine airflow.
• USE ONLY flexible steel fuel line provided. Connect
provided fuel line to generator. DO NOT use with or
substitute any other flexible fuel line.
• Smoke detector(s) MUST be installed and maintained
indoors according to the manufacturer’s instructions/
recommendations. Carbon monoxide alarms cannot
detect smoke.
• DO NOT place weatherproof enclosure in manner other
than shown in illustrations.
A
NOT
for
REPRODUCTION

10 BRIGGSandSTRATTON.COM
Controls
60 kW Generator
Read this operator’s manual and Important Safety Instructions before operating your generator.
Compare the illustrations of this model with your generator to familiarize yourself with the locations of various
controls and adjustments. Save this manual for future reference.
Generator is pictured with access doors removed for clarity
and screen guard open for clarity.
A - Exhaust Port — High-performance muffler lowers engine
sound level to comply with most residential codes.
B - Coolant Fill Door — Provides access for servicing engine
with coolant.
C - Air Cleaner — Protects engine by filtering dust and
debris out of intake air.
D - Battery Door opening — Provides access to starting
battery and air cleaner.
E - Engine Label — Identifies engine model and type.
F - Oil Dip Stick — Used to check the engine oil level.
G - Oil Fill Cap — Remove to service the engine with
recommended oil.
H - Screen Guard — Prevents fingers from touching radiator
fan and houses the coolant recovery bottle. Must stay
closed while generator is in use.
J - Coolant Recovery Bottle — Located on inside of screen
guard. Provides visual indicator of engine coolant level.
K - Oil Filter — Filters engine oil to prolong system life.
L - Fuel Inlet — Fuel supply is connected here.
M - Oil Drain Hose — Provided to facilitate oil changing.
N - ID Label (located on base) — Identifies unit by
serial number.
P - Circuit Breaker Enclosure — Equipped with removable
bottom to assist with conduit connection.
R - Control Panel Door opening — Provides access to
control panel, oil filter, etc.
S - Control Panel — Used for various test, operation and
maintenance functions. See System Control Panel.
ABC
D
A
EFG
H
J
K
L
M
N
P
R
S
NOT
for
REPRODUCTION

11
Access Ports
The generator is equipped with an enclosure that has
several access doors. The doors are named for a significant
component located behind them, as follows::
A- Fuel Inlet port (shown for reference)
B- Control Panel door
C- Exhaust opening (shown for reference)
D- Coolant Fill door
E- Battery door
F- Muffler door
The enclosure also includes muffler and radiator access
panels, used for cleaning those components. Those panels
should remain closed at all other times to assure proper
cooling, reduce noise, and for added safety.
Each generator is supplied with a set of identical keys. These
keys fit the locks that secure the access doors.
To open access door:
1. Insert key into lock of access door handle and turn key
one quarter turn counterclockwise.
2. Grasp door’s handle and turn one quarter turn
counterclockwise to open. Remove key.
3. Coolant Fill door is unlocked in the same manner. It can
be used for adding coolant or oil.
To close access door:
1. Close door and turn door’s handle one quarter
turnclockwise.
2. Insert key into lock of door handle and turn key one
quarter turn clockwise. Remove key.
WARNING Contact with muffler area could cause burns
resulting in serious injury.
• DO NOT touch hot parts and AVOID hot exhaust gases.
• Allow equipment to cool before touching.
CD
E
F
B
A
System Control Panel
The system control panel is a printed circuit board that is
integrated with the control panel of the generator. It contains
all the logic circuits, operator controls, and system displays
necessary to operate, program, and protect the generator. The
system control panel interprets and monitors electrical inputs
from related circuits throughout the unit.
Please refer to the supplied Control Panel Application Guide
for detailed information about the control panel.
NOT
for
REPRODUCTION

12 BRIGGSandSTRATTON.COM
Operation
Important Owner’s Considerations
Engine Oil
This engine is shipped from the factory pre-run and filled
with non-synthetic oil (API SL 10W-30W). This allows
for system operation in a wide range of temperature and
climate conditions. Before starting the engine, check oil
level and ensure that engine is serviced as described in the
Maintenance section.
Coolant System
This engine is shipped from the factory filled with a
50-50 mix of automotive (ethylene glycol) anti-freeze and
water. This will provide optimum year round protection
against freezing, boiling and corrosion.
Battery
The installer must supply a valve-regulated, rechargeable
12 volt DC starting battery. See Battery in Final Installation
Considerations in the installation manual.
15 Amp Fuse
The generator’s 15 Amp fuse is critical to correct system
operation. The 15 Amp fuse was removed at the factory to
prevent the unit from starting during shipping. Your installer
will ensure the fuse is properly installed upon completion of
the installation.
NOTICE Any attempt to crank or start the engine before it
has been properly serviced with the recommended coolant
or oil will result in equipment failure.
• Refer to the Maintenance section for coolant and oil fill
information.
• Damage to equipment resulting from failure to follow this
instruction will void engine and generator warranty.
WARNING Battery posts, terminals and related
accessories contain lead and lead compounds - chemicals
known to the State of California to cause cancer and
reproductive harm. Wash hands after handling.
Automatic Operation
The generator’s control board constantly monitors utility
voltage. Should utility voltage drop below a preset level, the
control board will signal the engine to crank and start.
When utility voltage is restored above a preset voltage level,
the engine is signaled to shut down.
The actual system operation is not adjustable and is
sequenced by sensors and timers on the control board,
as follows:
Utility Voltage Dropout Sensor
• This sensor monitors utility source voltage.
• If utility source voltage drops below about 70 percent
of the nominal supply voltage, the sensor energizes
a 3 second timer. The timer is used to ‘sense’
brown-outs.
• Once the timer has expired, the engine will crank
and start.
Utility Voltage Pickup Sensor
This sensor monitors utility voltage. When utility voltage is
restored above 80 percent of the nominal source voltage, a
time delay starts timing and the engine will go to engine cool-
down.
Engine Cool-down Timer
When utility power is sensed and the load transfers back to
the utility source, the engine will go into a cool down period
as described below:
• If the generator has run for MORE than 5 minutes,
once the utility transfer occurs, the engine will
continue to run for about 1 minute before shutting
down.
• If the generator has run for LESS than 5 minutes, once
the utility transfer occurs, the engine will continue to
run until 5 minutes has elapsed before shutting down.
NOT
for
REPRODUCTION

13
Setting Exercise Timer
It is recommended to have the generator go through an
excercise cycle once every seven days. During this exercise
period, the unit runs for approximately 20 minutes and then
shuts down.
Refer to the Control Panel Application Guide supplied with this
generator for more detailed information on the exercise timer.
OR, refer to the Automatic Transfer Switch Application Guide
for more detailed information on the exercise timer.
Maintenance
The generator warranty does not cover items that have been
subjected to operator abuse or neglect. To receive full value
from the warranty, the operator must maintain the system as
instructed in the Maintenance section.
Servicing the System
Before performing any generator maintenance, always
perform the following steps:
1. Set generator’s circuit breaker to its OFF position.
2. Turn the generator off.
3. Remove 15 Amp fuse from control board.
4. Utility voltage is present at generator control board.
Disconnect power before servicing control board by
removing the fuses from the transfer switch.
5. After all servicing has been completed, replace fuses in
transfer switch, replace 15 Amp fuse in control board,
set circuit breaker ON and turn the generator on.
Shutdown Alarm Detection System
The generator may have to run for long periods of time with
no operator present. For that reason, the system is equipped
with sensors that automatically shut down the generator in
the event of potentially damaging conditions, such as low oil
pressure, high temperature, over speed, and other conditions.
The generator’s control board shows possible shutdown
alarms descriptions on the digital display.
The possible shutdown alarms are listed below:
• Overspeed
• Underspeed
• Low Oil Pressure
• High Coolant Temperature
• External Shutdown 1
• External Shutdown 2
• External Shutdown 3
• GCB (Generator Circuit Breaker) Fail
• Generator Overvoltage
• Generator Undervoltage
• Generator Overfrequency
• Generator Underfrequency
• Generator CCW Rotation
• Start Fail
• Stop Fail
• Battery Flat
• Voltage Autodetect
Reset Shutdown Alarm Detection System
The operator must reset the shutdown alarm detection system
each time it activates.
Refer to the Control Panel Application Guide supplied with
this generator for more detailed information on resetting the
Shutdown Alarm Detection System.
Overspeed
This shutdown alarm is indicated by Overspeed showing on
the digital display. This condition occurs if the engine speed in
greater than 115% of nominal engine RPM, which is derived
from generator frequency.
To remedy the problem, contact your installer or an
authorized dealer.
Underspeed
This shutdown alarm is indicated by Underspeed showing on
the digital display. This condition occurs if the engine speed
drops under the nominal engine RPM.
To remedy the problem, contact your installer or an
authorized dealer.
NOT
for
REPRODUCTION

14 BRIGGSandSTRATTON.COM
Low Oil Pressure
This shutdown alarm is indicated by Low Oil Pressure on
the digital display. The unit is equipped with an oil pressure
switch that uses normally closed contacts held open by
engine oil pressure during operation. Should oil pressure drop
below the 8 psi range, switch contacts close and the engine
will shut down.
To remedy the low oil pressure condition, add the
recommended oil to the FULL mark on the dipstick or contact
your installer or an authorized dealer.
High Coolant Temperature
This shutdown alarm is indicated by High Coolant
Temperature on the digital display. This condition occurs
when the temperature of the coolant exceeds the shutdown
threshold.
To remedy the problem, contact your installer or an
authorized dealer.
External Shutdown 1,2 or 3
This shutdown alarm is indicated by External Shutdown on
the digital display.
To remedy the problem, contact your installer or an
authorized dealer.
Generator Circuit Breaker (GCB) Fail
This shutdown alarm is indicated by GCB Fail on the digital
display. This condition occurs when the generator circuit
breaker trips or becomes non-functional.
To remedy the problem, contact your installer or an
authorized dealer.
Generator Overvoltage
This shutdown alarm is indicated by Generator Overvoltage
on the digital display. This condition occurs when the output
voltage exceeds the preset threshold.
To remedy the problem, contact your installer or an
authorized dealer.
Generator Undervoltage
This shutdown alarm is indicated by Generator Undervoltage
on the digital display. This condition occurs when the output
voltage drops below the preset threshold.
To remedy the problem, contact your installer or an
authorized dealer.
Generator Overfrequency
This shutdown alarm is indicated by Generator Overfrequency
on the digital display. This condition occurs when the
generator frequency is out of limits given by setpoints.
To remedy the problem, contact your installer or an
authorized dealer.
Generator Underfrequency
This shutdown alarm is indicated by Generator
Underfrequency on the digital display. This condition occurs
when the generator frequency is out of limits given by
setpoints.
To remedy the problem, contact your installer or an
authorized dealer.
Generator CCW Rotation
This shutdown alarm is indicated by Generator CCW on the
digital display. This condition occurs when the generator
phase is out of sequence.
To remedy the problem, contact your installer or an
authorized dealer.
Start Fail
This shutdown alarm is indicated by Start Fail on the digital
display. This condition occurs when the generator does not
start.
To remedy the problem, contact your installer or an
authorized dealer.
Stop Fail
This shutdown alarm is indicated by Stop Fail on the digital
display. This condition occurs when the generator fails to
stop.
To remedy the problem, contact your installer or an
authorized dealer.
Battery Flat
This shutdown alarm is indicated by Battery Flat on the digital
display. This condition occurs if the controller loses power
during starting sequence due to a bad battery condition. It will
not try to start again until the battery is functioning properly.
To remedy the problem, contact your installer or an
authorized dealer.
Voltage Autodetect
This shutdown alarm is indicated by Voltage Autodetect on
the digital display. This condition occurs if the controller
loses power during starting sequence due to a bad battery
condition. It will not try to start again until the battery is
functioning properly.
To remedy the problem, contact your installer or an
authorized dealer.
NOT
for
REPRODUCTION

15
Generator Maintenance
Generator maintenance consists of keeping the unit
clean. Operate the unit in an environment where it will
not be exposed to excessive dust, dirt, moisture or any
corrosive vapors. Cooling air louvers on the enclosure
must not become clogged with snow, leaves, or any other
foreign material. To prevent generator damage caused by
overheating, keep the enclosure cooling inlets and outlets
clean and unobstructed at all times.
Check the cleanliness of the unit frequently and clean when
dust, dirt, oil, moisture or other foreign substances are visible
on its exterior/interior surface. Inspect the air inlet and outlet
openings inside and outside the enclosure to ensure air flow
is not blocked.
DO NOT use direct spray from a garden hose to clean generator.
Water can enter the engine and generator and cause problems.
Cleaning the Generator
1. Turn the generator off.
2. Remove 15 Amp fuse from control board.
3. Clean generator as desired.
• Use a damp cloth to wipe exterior surfaces clean.
• Use a soft, bristle brush to loosen caked on dirt, etc.
• Use a vacuum cleaner to pick up loose dirt and debris.
• Use low pressure air (not to exceed 25 psi) to blow
away dirt. Inspect cooling air slots and openings on
the generator. These openings must be kept clean and
unobstructed.
4. Reinstall 15 Amp fuse in control board.
5. Turn the generator on and place in AUTO mode.
NOTICE Improper treatment of generator can damage it
and shorten its life.
• DO NOT expose generator to excessive moisture, dust,
dirt, or corrosive vapors.
• DO NOT insert any objects through cooling slots.
Engine Maintenance
The maintenance of an engine and related components are
critical to its operating performance and lifespan. Industrial
engines operate in an environment that often include hot
and cold temperatures and extreme dust. The recommended
maintenance schedule is listed in this section, however,
environmental operating conditions and additional installed
equipment may require more frequent inspection and
servicing. The owner and/or authorized service technician
should review the operating conditions of the equipment to
determine the inspection and maintenance intervals. Proper
engine cooling and lubrication are very important, so pay
particular attention to these matters.
Engine Oil
The engine is shipped from the factory pre-run and filled
with non-synthetic oil (API SL 10W-30). This allows for
system operation in a wide range of temperature and
climateconditions.
Oil Recommendation
Select and engine oil viscosity that will best match the
prevailing daytime temperature.
The oil must meet GM specification 9986231. Motor oils
meeting this spec receive the API (American Petroleum
Institure) starburst symbol:
HOT WEATHER
COLD WEATHER
SAE 10W-30
PREFERRED
SAE 15W-40
FOR THE BEST FUEL ECONOMY AND COLD STARTING, SELECT THE LOWEST
SAE VISCOSITY GRADE OIL FOR THE EXPECTED TEMPERATURE RANGE
IF NEITHER SAE 10W-30
NOR SAE 15W-40 GRADE
OILS ARE AVAILABLE, SAE
30 GRADE MAY BE USED AT
TEMPERATURES ABOVE 4
DEGREES C (40F), SAE 40
GRADE AY BE USED AT
TEMPERATURES ABOVE 27
DEGREES C (80F).
DO NOT USE SAE 10W-40
GRADE OIL OR ANY OTHER
GRADE NOT RECOMMENDED
RECOMMENDED SAE VISCOSITY GRADE ENGINE OILS
40°F (4°C)
It is noted that the GF-4 oils are also “backward compatible”
and are equal or better than previous grades of oil in all
aspects.
Synthetic Oils
Synthetic Oils have been available for use in industrial
engines for a relatively long period of time and may offer
advantages in cold and hot temperatures. However, it is not
known if synthetic oils provided operational or economic
benefits over conventional petroleum-based oils in industrial
engines. Use of synthetic oils does not permit the extension
of oil change intervals.
NOT
for
REPRODUCTION

16 BRIGGSandSTRATTON.COM16
Checking Engine Oil Level
NOTICE: It is important to be careful when checking engine
oil level. Oil must be maintained between the “ADD” and
the “FULL” mark on the dipstick. To ensure that you are not
getting a false reading, make sure the following steps are
taken before checking the oil level.
1. Stop engine.
2. Turn the generator off.
3. Remove 15 Amp fuse from control panel.
4. Allow approximately five minutes for the oil to drain
back into the oil pan.
5. Remove the dipstick. Wipe with a clean cloth or paper
towel and reinstall. Push the dipstick all the way into the
dipstick tube.
6. Remove the dipstick and note the amount of oil on the
dipstick. The oil level must be between the “ADD” and
“FULL” marks.
7. If the oil level is below the “ADD” mark, reinstall the
dipstick and proceed to step 6.
8. Remove the oil filler cap from the valve cover.
9. Add the required amount of oil to bring the level up to,
but not over, the “FULL” mark on the dipstick. Reinstall
the oil filler cap to the valve rocker arm cover and wipe
any excess oil clean.
Changing Engine Oil
KEEP OUT OF REACH OF CHILDREN. DON’T
POLLUTE. CONSERVE RESOURCES. RETURN
USED OIL TO COLLECTION CENTERS.
Change oil while the engine is still warm from running.
1. Turn the generator off.
2. Remove 15 Amp fuse from control panel.
3. Place oil drain hose (B) into an approved container.
4. Open valve (A) located on bottom of oil pan.
5. When oil has drained, replace brass fitting on hose.
6. Remove oil filter and dispose of properly.
7. Before installing a new oil filter, lightly lubricate the oil
filter gasket with fresh, clean oil.
8. Install the oil filter by hand until the gasket contacts the
oil filter adapter, then tighten the oil filter ½ to ¾ turn.
9. Add the required amount of oil to bring the level up to,
but not over the “FULL” mark on the dipstick. Reinstall
the oil filler cap to valve rocker arm cover and wipe any
excess oil clean.
10. If all engine servicing is complete, replace 15 Amp fuse
in control panel and and turn the generator on and place
in AUTO mode.
To make the task of adding oil more convenient, we
recommend use of a funnel attached to a length of tubing
long enough to reach from the Coolant Fill door to the oil fill
opening on the engine valve cover.
Engine V-Belts
The engine installed in this equipment uses drive belt(s) that
drive the water pump and alternator. The drive belt(s) are an
integral part of the cooling and charging system and should
be inspected according to the maintence schedule. When
inspecting the belts, check for:
• Cracks
• Chunking of the belt
• Splits
• Material hanging loose from the belt
• Glazing, hardening
If any of these conditions exist, the belt should be replaced.
NOT
for
REPRODUCTION

17
Engine Coolant System
It is important that the cooling system of the engine be
maintained properly to ensure proper performance and
longevity.
The cooling system must be maintained according to the
recommended maintenance schedule and inspection should
include:
• The regular removal of dust, dirt, and debris from the
radiator core and fan shroud.
• Inspection of coolant hoses and components for leaks,
especially at the radiator hose connections. Tighten
hose clamps if necessary.
• Check radiator hoses for swelling, separation,
hardening, cracks, or any type of deterioration.
• Inspect the radiator cap to ensure proper sealing.
NOTICE: Alcohol or methanol based anti-freeze or plain
water are not recommended for use in the cooling system at
any time.
With the engine cold, check the coolant level in the coolant
recovery bottle (see Controls). Specifications for the coolant
system can be found in the Maintenance chart of this manual.
Coolant Specification - ethylene glycol 50-50 mixture w/
distilled water.
Coolant
WARNING Hot pressurized coolant could cause serious
injury.
• DO NOT open radiator cap when hot.
• Before servicing, allow coolant to cool.
Engine Air Cleaner
Once each year service the air cleaner, as follows. If
operating in a dusty environment, service more often.
1. Turn the generator off.
2. Remove 15 Amp fuse from control panel.
3. Remove filter cartridge - Remove the service cover by
disengaging three clips and detaching cover, starting
with the bottom two clips and the top clip last. Gently
move the end of the filter back and forth, then rotate
while pulling straight out.
4. Clean outlet tube and check Vacuator™
valve - Use a clean cloth to wipe the
filter sealing surface and the outlet tube
surfaces. Make sure that all contaminant
is removed before the new filter is
inserted. Be careful to not damage the sealing area on
the tube.
Visually check and physically squeeze Vacuator valve
attached to service cover to make sure it is flexible and
not inverted, damaged orplugged.
5. Clean filter - Use a soft bristle brush to loosen dirt
and a vacuum cleaner to remove dirt and debris. Low
pressure air (not to exceed 25 psi) may also be used to
blow away dirt. Replace filter cartridge if any holes are
detected in filter media.
6. Install clean filter properly - Insert the filter carefully.
Seat the filter by hand, making certain it is completely
into the air cleaner housing before securing the cover
in place. To complete a tight seal, apply pressure by
hand at the outer rim of the filter, not the flexible center.
(Avoid pushing on the center of the urethane end cap.)
No cover pressure is required to hold the seal.
NEVER use the service cover to push the filter into
place! Using the cover to push the filter in could cause
damage to the housing, cover, or fasteners and will void
the warranty. If the service cover hits the filter before
it is fully in place, remove the cover and push the filter
(by hand) further into the air cleaner and try again. The
cover should go on with no extra force.
7. Reinstall service cover - Once the filter is in place,
reinstall the service cover, positioning the cover with
the arrow and the word TOP to the top. Fasten the top
clip first, the bottom two clips last. Make sure that all
mounting bands, clamps, bolts, and connections in the
entire air cleaner system are tight and verify absence of
holes in piping - repair if needed.
8. Replace 15 Amp fuse in control panel.
9. Turn the generator on.
NOT
for
REPRODUCTION

Generator Electrical System Maintenance
The generator’s electrical system incorporates computers to
control various related components. The electrical system
connections and ground circuits require good connections.
Follow the recommended maintenance schedule located in
the Maintenance section of this manual.
When inspecting the electrical system, check the following:
• Check positive (+) and negative (-) battery cables for
corrosion, rubbing, chafing, burning, and ensure tight
connections at both ends.
• Check battery for cracks or damage to the case. Replace
as necessary.
• Inspect engine wire harness for rubbing, chafing,
pinching, burning, and cracks or breaks in the wiring.
• Verify that the engine harness connectors are correctly
locked in.
• Inspect ignition coil wire for hardening, cracking,
chafing, burning, separation, and split boot covers.
• Inspect spark plug wires for hardening, cracking,
chafing, burning, separation, and split boot covers.
• Replace spark plugs at the required intervals per the
recommended maintenance schedule.
• Verify that all electrical components are securely
mounted to the engine or chassis.
• Verify that any additional electrical services installed by
the owner are properly installed in the system.
18 BRIGGSandSTRATTON.COM
Battery
Servicing of batteries is to be performed or supervised
by personnel knowledgeable of batteries and the
required precautions. Keep unauthorized personnel away
frombatteries.
Charging the Battery
If it is necessary to charge the battery, proceed as follows:
1. Turn the generator on.
2. Remove 15 Amp fuse from control panel.
3. Disconnect negative battery cable from negative battery
terminal (indicated by NEGATIVE, NEG, or (-)).
4. Charge battery with battery charger at 2 Amps until
battery holds 12 Volts. DO NOT exceed 13.7 volts when
charging battery.
5. Connect negative battery cable to negative battery
terminal (indicated by NEGATIVE, NEG, or (-)).
6. Ensure hardware on both positive and negative battery
terminals is secure.
7. Reinstall 15 Amp fuse in control panel.
8. Turn the generator off.
9. Reset exercise timer. See Setting Exercise Timer.
WARNING Battery posts, terminals and related
accessories contain lead and lead compounds - chemicals
known to the State of California to cause cancer and
reproductive harm. Wash hands after handling.
NOTICE Failure to disconnect negative battery cable will
result in equipment failure.
• DO NOT attempt to jump start the generator.
• Damage to equipment resulting from failure to follow this
instruction will void engine and generator warranty.
Servicing the Battery
If it is necessary to service the battery, proceed as follows:
1. Turn the generator off.
2. Remove 15 Amp fuse from control panel.
3. Service or replace battery as required. See Battery
in Final Installation Considerations in the installation
manual for specific battery needed.
4. Connect red battery cable to battery positive terminal
(indicated by POSITIVE, POS, or (+)).
5. Connect black battery cable to negative battery terminal
(indicated by NEGATIVE, NEG, or (-)).
6. Ensure hardware on both positive and negative battery
terminals is secure.
7. Reinstall 15 Amp fuse in control panel.
8. Turn the generator on.
9. Reset exercise timer. See Setting Exercise Timer.
DON’T POLLUTE. CONSERVE RESOURCES,
RETURN USED BATTERY TO RECYCLING
COLLECTION CENTER.
NOT
for
REPRODUCTION

19
Fuel System Inspection and Maintenance
Natural Gas/Propane Fuel System
The fuel system installed on this industrial engine has been
designed to various standards to ensure performance and
reliability. To ensure compliance to these standards, follow
the recommended maintenance schedule contained in this
section.
Pressure Regulator Maintenance and Inspection
NOTICE: The pressure regulator components have been
specifically designed and calibrated to meet the fuel system
requirements of the engine.
If the regulator fails to operate or develops a leak, it should
be repaired or replaced with the OEM recommended
replacement parts. When inspecting the regulator, check for
the following items:
• Check for any fuel leaks at the inlet and outlet fittings.
• Check for any fuel leaks in the regulator body.
• Check to ensure the regulator is securely mounted and
the mounting bolts are tight.
• Check the regulator for external damage.
Venturi/Throttle Control Device Maintenance and Inspection
NOTICE: The venturi and throttle body components have been
specifically designed and calibrated to met the fuel system
requirements of the engine.
When inspecting the venturi and throttle body, check for the
following items:
NOTICE: A dirty air cleaner may significantly alter the venturi
performance.
• Leaks at all fittings.
• Ensure the venturi and throttle body are securely
mounted.
• Inspect air cleaner element according to the
recommended maintenance schedule found in this
section.
• Inspect air inlet hose connection and clamp. Inspect
hose for cracking, splitting, or chaffing. Replace if any
of these conditions exist.
• Check fuel lines for cracking, splitting, or chaffing.
Replace if any of this conditions exist.
• Check for leaks at the throttle body and intake manifold.
Exhaust System Maintenance and Inspection
When inspecting the exhaust system, check the following:
• Inspect exhaust manifold at the cylinder head for leaks
and that all retaining bolts and shields (if used) are in
place.
• Inspect manifold to exhaust pipe fasteners to ensure
they are tight and that there are not exhaust leaks.
Repair as necessary.
• Inspect the oxygen sensor electrical connector to ensure
connector is seated and locked, check wires to ensure
there is no cracking, splitting, chaffing, or burning.
Replace or replace if necessary.
• Inspect exhaust pipe connection for leaks. Repair if
necessary.
Engine Exterior
Periodically inspect the engine exterior for contamination
and potential damage from dirt, leaves, rodents, spider webs,
insects, etc. and remove.
When Calling for Assistance
You must have the following information at hand if it is
necessary to contact a local service center regarding service
or repair of this unit:
1. Obtain the unit Model Number and Serial Number from
the unit ID label. See Controls for location of the label
or refer to the information recorded on the inside front
cover of the installation manual.
2. Obtain the engine identification numbers from the
engine label. See the Installation manual for location of
this information.
Storage
The generator system is designed for long term service as
a backup generator. There is no need to take any storage
precautions. However, if it becomes necessary to take the
system out of service for an extended period, call Technical
Services at 800743-4115, between 8:00 AM and 5:00PMCT
for specific recommendations.
NOT
for
REPRODUCTION

20 BRIGGSandSTRATTON.COM
Maintenance Chart
This maintenance schedule represents the manufacturer’s recommended maintenance intervals to maintain proper engine/
equipment function. Federal, State, or Local regulations may require additional or more frequent inspection or maintenance
intervals than those specified above. Check with the authority having jurisdiction for details.
Perform the following maintenance on the engine at the hours indicated and at equivalent hour intervals thereafter.
Maintenance Interval Hours
After
each
use
1000 1500 2000 2500 3000 3500 4000 4500 5000
General Maintenance Section
Visual check for fluid leaks X
Check engine oil level X
Check coolant level X
Change engine oil and oil filter Every 100 hours or Annually
Check fuel system for leaks Before and after any service or maintenance activity
Inspect accessory drive belts X X X X X
Inspect electrical system wiring X X
Inspect all vacuum lines and fitting X X
Engine Coolant Section
Clean debris from radiator core Every 100 hours or 60 days of operation
Change coolant - ethylene glycol 50-50
mixture w/ distilled water XXXXX
Inspect coolant hoses X X X
Replace coolant hoses and accessory
drive belt
Every 2,000 Hours or two years, whichever occurs first
Engine Ignition System
Inspect battery case for leaks/damage X X X X X
Inspect battery cables X X X X X
Inspect all electrical connector retainer
locks XXXXX
Replace spark plugs X X X
Inspect crank sensor timing wheel Every 100 hours or annually
Replace distributor cap and rotor X X
Clean secondary ignition coil tower X X X X X
Check spark plug wires X
Replace spark plug wires X
Fuel System Maintenance
Inspect air cleaner Every 200 hours (or every 100 hours in severe environments) and Annually
Check fuel shut-off valve function X X
Replace inline LPG filter X X X X X
Check LPG shut-off solenoid valve
function X X
Check air induction system X X
Check intake manifold X X
Engine Exhaust System
Inspect exhaust manifold and piping X X
Check oxygen sensor connector X X
NOT
for
REPRODUCTION
