Illustrated Parts List
Questions? Help is just a moment away!
Preguntas? La ayuda es justa un momento lejos!
Call: Pressure Washer Helpline
Llame: Línea Directa del Lavador a Presión
1-800-743-4115 M-F 8-5 CT
Web: www.briggsandstratton.com
Model No. 020228-2 Manual No. 197196B Rev. B (04/16/2008)

2
EXPLODED VIEW AND PARTS LIST — MAIN UNIT
Item Part # Description
1 196438GS BASE, w/Mounts
2 S195428GS HANDLE
3 196456GS KIT, Billboard w/Decals
195964GS Clips, Tree
30809GS Grommet
4 196006GS HOSE
5 200200GS ASSY, Pump
6 189971GS KIT, Chemical Hose
7 23139GS KEY
8 194298GS VALVE, Thermal Relief
9 200279GS KIT, Chemical Injection
10 200278GS KIT, Water Inlet
11 B2384GS FILTER
12 192525GS KIT, Pump Mounting Hardware
13 195854GS TURBO, Nozzle
14 195943GS KIT, Nozzles
198841GS Nozzle, Plastic, Soap
195842AEGS Nozzle, QC, Red
201580XGS Nozzle, QC, Orange
195842RGS Nozzle, QC, Yellow
15 B2203GS KIT, Handle Connector
Item Part # Description
16 196439GS KIT, Wheel
195454GS Axle
192050GS E-Ring
17 199117GS GUN
18 200595GS EXTENSION, QC
19 192310GS KIT, Vibration Mount
900 § ENGINE
Items Not Illustrated:
197196GS MANUAL, Operator’s
MS5573 MANUAL, Engine
194256GS KIT, Tag/Waring Srv
275034 DECAL, Warning
BB3061BGS OIL BOTTLE
87815GS GOGGLES
Optional Accessories:
100516GS KIT, O-Ring
6039 PUMP SAVER
§ - Contact Engine Manufacturer
