Briggs & Stratton CLEANSHOT 2050PSI User manual

TM
Questions_ HeHpis just a moment away!
Preguntas_ La ayuda es justa un momento Hejos!
Call: Pressure Washer Helpline
Uame: Linea Directa dei Lavador a Presi6n - m-800-743-411S H°F 8-5 CT
CHeanShot TM is a trademark of Briggs & Stratton Power Products.
CHeanShot TM es una marca registrada de Briggs & Stratton Power Products.
BRJGGS & STRATTON POWER PRODUCTS GROUP, LEe
JEFFERSON,WiSCONSiN, U.S.A.
ModeH No. 020244°0 (2050 PSI PressureVVasher) ManuaHNo. H95950GS Revision 0 (10/08/2004)
i

CHeanShot TM 2.050 PSI Pressure Washer
TABLE OF CONTENTS
Safety RuHes.................................... 2-4
Know Your Pressure _A/asher ........................ 5
AssemHy ...................................... 6-7
Operation .................................... 8- HH
Product Spedfications ............................ H2
Maintenance ................................. [2-[ 4
Storage ........................................ [5
Troubleshooting ................................. H6
V_/arranty ...................................... H7
EQUmPNENT
-1 Readthis manuamcarefummyand become famimiar
pressure washer. Know its
Jwith
...... your
applications, its limitations and any hazards
invomved.
This manuaHcontains information for a pressure washer
that operates at Z050 PSI at a flow rate of 1.9gallons per
minute.This high quality residential system features
7" wheels, axial cam pump with stainless steel pistons,
automatic cool down system, chemical iniection system,
adiustable spray nozzle. Includes safety goggles, heavy duty
25' hose, and more.
Every effort has been made to ensure that information in
this manual is accurate and current. However, we reserve
the right to change, alter or otherwise improve the product
and this document at any time without prior notice.
SAFETY RULES
This isthe safetyalertsymbol [tisused to
alertyou to potentiam personam iniuryhazards.
Obey all safety messages that follow this
symbol to avoid possible iniuryor death.
The safety alert symbol (_) is used with a signal word
(DANGER, CAUTION,WARNING), a pictorial and/or a
safety message to alert you to hazards. DANGER indicates
a hazard which, if not avoided, will result in death or serious
iniury. WARNmNG indicates a hazard which, if not avoided,
could result in death or serious iniury. CAUTmON
indicates a hazard which, if not avoided, might result in
minor or moderate iniury. CAUTmON, when used
without the alert symbol, indicates a situation that could
result in equipment damage. Follow safety messages to
avoid or reduce the risk of iniury or death.
[
Hazard Symbols and Meanings
Toxic Fumes
Slippery Surface
Fire
Electrical Shock
Fail FluidIniection
Explosion Hot Surface
Moving Parts Flying Obiects Kickback
2

DANGER
Operate pressure washer ONLY outdoors.
Keep exhaust gas from entering aconfined area through
windows, doors, ventilation intakes or other openings.
DO NOT operate pressure washer inside any building or
endosure.
Use a respirator or mask whenever there is a chance that
vapors may be inhaled.
Read all instructions with mask so you are certain the mask wilI
provide the necessary protection against inhaling harmful vapors.
WARNING
Keep spray nozzle between 8 to 24 inches away from cleaning
surface,
Operate this unit on a stable surface.
The cleaning area should have adequate slopes and drainage to
reduce the possibility of a fail due to slippery surfaces.
Be extremely careful if you must use the pressure washer from
a ladder, scaffolding or any other relativdy unstable Iocation_
Firmly grasp spray gun with both hands when using high
pressure spray to avoid injury if gun kicks back.
When starting engine, pull cord slowly until resistance is felt
and then pull rapidly to avoid kickback.
If engine starts and fails to continue to run or if increased
resistance is felt during starting pull attempts, squeeze trigger
on spray gun_
WARNING
WHEN ADDING FUEL
Turn pressure washer OFF and let it cool at least 2 minutes
before removing gas cap.
Fill fuel tank outdoors.
DO NOT overfill tank.Allow space for fuel expansion.
Keep fuel away from sparks, open flames, pilot lights, heat, and
other ignition sources.
DO NOT light a cigarette or smoke_
?HEN OPEBATING EQUIPMENT
• Transport/repair with furl tank EMPTY or with furl shutoff
valve OFE
WHEN STORING FUEL OR EQUIPMENT WiTH FUEL
iN TANK
Store away from furnaces, stoves, water heaters, clothes
dryers or other appliances that have pilot light or other
ignition source because they can ignite fuel vapors.
WARNING
NEVER aim spray gun at people, animals or plants.
DO NOT allow CHILDREN to operate pressure washen
NEVER repair high pressure hose. Replace it.
Keep high pressure hose connected to pump and spray gun
while system is pressurized,
Squeeze trigger on spray gun to relieve trapped pressure,
every time you stop engine. Engage trigger lock on spray gun.
WARNING
Keep water spray away from electric wiring or fatal electric
shock may result.
3

CHeanShot TM 2050 PSI Pressure Washer
WARNING
DO NOT touch hot surfaces,
Allow equipment to coo[ before touching.
The pressure washer must be at least 5 feet from structures
having combustible wails and/or other combustible materials.
Keep at least S feet of clearance on all sides of pressure
washer for adequate cooling, maintenance and servicing.
In the State of California a spark attester is required by law
(Section 4442 of the California Public Resources Code). Other
states may have similar laws. Federal laws apply on federal
lands. If you equip the muffler with a spark arrester, it must be
maintained in effective working order:
WARNING
, DO NOT wear loose clothing, ieweIry or anything that may
be caught in the starter or other rotating parts.
Tie up long hair" and remove jeweir>;
WARNING
, Always wear eye protection when using this equipment or in
vicinity of where equipment is in use.
WARNING l
WHEN ADJUSTING OR MAKING REPAiRSTOYOUR
PRESSURE WASHER
Disconnect spark plug wire from spark plug and place wire
where it cannot contact spark plug.
CAUTION
DO NOT tamper with governed speed.
DO NOT operate pressure washer above rated pressure.
CAUTION
DO NOT secure spray gun in open position,
DO NOT leave spray gun unattended while machine is
running.
NEVER use aspray gun which does not have atrigger lock or
trigger guard in place and in working order:
Always be certain spray gun, nozzles and accessories are
correctly attached.
DO NOT point spray gun at glass when in jet spray mode.
NEVER aim spray gun at plants_
If you have questions about intended use, ask dealer or
contact Briggs & Stratton Power Products.
NEVER operate units with broken or missing parts, or
without protective housing or covers.
DO NOT by-pass an>, safety device on this machine.
Before starting pressure washer in coId weather, check all
parts of the equipment to be sure ice has not formed there.
NEVER move machine by pulling on high pressure hose. Use
handle provided on unit.
Check fuel system for leaks or signs of deterioration, such as
chafed or spongy hose, loose or missing damps, or damaged
tank or cap. Correct all defects before operating pressure
washerL
This equipment is designed to be used with Briggs & Stratton
Power Products authorized parts ONLY. If equipment is used
with parts that DO NOT comply with minimum specifications,
user assumes all risks and liabilities.
4

C eanShotPS,PressureWasher CleanShot
KNOWYOUR PRESSURE WASHER
Read this owner's manual and safety rules before operating your pressure washer,
Compare the ilhstrations with your pressure washer to familiarize yourself with the locations of various controls and
adjustments. Save this manual for future reference.
High Pressure Hose Spray Gun
Air Filter
Primer Bulb
Oil Fill/Dipstick
High Pressure Outlet
& Water Inlet
Fuel Tank
Adjustable Nozzle
Chemical Injection Pump equipped with
Automatic Cool Down System
Adiustabie Nozzle --Always attached to nozzle
extension.Adjustable nozzle allows you to adjust spray
pressure and spray pattern.
Air Filter -- Protects engine by filtering dust and debris
out of intake air.
Automatic Cool Down System -- Cycles water
through pump when water reaches 125°° 155°E VVarm
water will discharge from pump onto ground.This system
prevents internal pump damage.
Chemical [niection Siphon/Filter -- Use to siphon
detergent or other pressure washer chemicals into the low
pressure stream.
High Pressure Hose -- Connect one end to water
pump and the other end to spray gun.
High Pressure Outlet -- Connection for high pressure
hose.
DataTag (not shown, near rear of base plate) -
Provides model and serial number of pressure washer.
Please have these readily available if calling for assistance.
Oil FHl/Dipstick -- Check and fill with oH here.
PHmer Bulb -- Prepares a cold engine for starting.
Pump -- Develops high pressure.
Recoil Starter -- Used for starting the engine manually.
Spray Gun -- Controls the application of water onto
cleaning surface with trigger device. Includes trigger loci<.
Water inlet -- Connection for garden hose.
5

CleanShot TM 2050 PSI Pressure Washer
ASSEMBLY
mNPORTANT: Read entire owner's manual before you
attempt to assemble or operate your new pressure washer.
Remove Pressure Washer From
Carton
1. Remove the parts bag,accessories_ and inserts inchded
with pressure washer,
2. Ske two corners at the end of carton from top to
bottom so the panel can be folded down fiat.
3. Remove pressure washer from carton.
Carton Contents
ffems in the carton include:
Hain Unit
Handle
High Pressure Hose
Spray Gun
Adjustable Nozzle Extension
Safety Goggles
Oil Bottle
Parts Bag (which includes the following):
Owner's Manual
Engine Manual
Owner's Registration Card
Handle Fastening Hardware Kit (which includes):
Carriage Bolts (2)
"U' Hooks (2)
Plastic Knobs (4)
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged, call the
pressure washer helpline at 1-800-743-4115. If calling for
assistance, please have the model, revision, and serial
number from the data tag available.
To prepare your pressure washer for operation, you
wii[ need to perform these tasks:
I. Fill out and send in registration card.
2. Attach handle to main unit.
3. Add oil to engine crankcase.
4. Add fuel to fuel tank.
5. Connect high pressure hose to spray gun and pump.
6. Connect water supply to pump.
7. Attach nozzle extension to spray gun.
Attach Handle
I. Place handle assembly onto handle supports connected
to main unit. Hake sure holes in handle align with
holes on handle supports (Figure I).
Align Holes ___i_l__ _
_ Hande
l/ Supports /
NOTE: It may be necessary to move the handle supports
from side to side in order to align the handle so it will slide
over the handle supports.
2. Insert carriage bolts through holes from outside of
unit and attach a plastic knob from inside of unit
(Figure 2).Tighten by hand.
3. Insert one "U' hook through hole just above billboard
on left side of handle (viewing from rear of unit). Hold
hook in place and attach a plastic knob from inside of
unit (Figure 3).Tighten by hand.
Hose Hook
SprayGun Hook
Insert other "U' hook through hole just above
billboard on right side of handle (viewing from rear of
unit). Hold hook in place and attach a plastic knob
from inside of unit (Figure 3).Tighten by hand.
6

C,eanShotPS,PressureWasher CleanShot
Add Engine Oil and Fuel
*Place pressure washer on a level surface.
i
•Refer to engine manuaI for oil and fuel fill information.
• Damage to equipment resulting from failure to foJJow this
instruction will void warrant)i.
•Refer to engine owner's manual and follow oil and fuel
recommendations and instructions.
NOTE: Check oil often during engine break-in. Refer to
engine owner's manual for recommendations.
Connect Hose and Water Supply to
mHPORTANT: To avoid pump damage, you must assemble
the nozzle extension to the spray gun and attach all hoses
before you start the engine.
NOTE: Remove and discard the shipping caps from the
pumps high pressure outlet and water inlet before
attaching hoses.
I. Uncoil high pressure hose and attach one end of hose
to base of spray gun (Figure 4).Tighten by hand.
hose here
2. Attach other end of high pressure hose to high
pressure outlet on pump (Figure S).Tighten by hand.
Before connecting garden hose to water inlet, inspect
inlet screen (Figure 6). Clean screen if it contains
debris or have it replaced if damaged. DO NOT RUN
PRESSUREWASHER IF INLET SCREEN IS DAMAGED.
_\ Inspect inlet
.... \\ screen, DO NOT
use if damaged;
clean if dirty.
4. Run water through your garden hose for 30 seconds
to clean out any debris.
mNPORTANT: DO NOT siphon standing water for the
water supply. Use ONLY cold water (less than 100°F).
S. Connect the garden hose (not to exceed S0 feet in
length) to the water inlet.Tighten by hand (Figure 6).
Damage to equipment resulting from failure to follow this
instruction wiJl void warranty,
6. Turn ON the water and squeeze the trigger on the
gun to purge the pump system of air and impurities.
WARNING
Always wear eye protection when using this equipment or in
vicinity of where equipment is in use.
Before starting the pressure washer, be sure you are wearing
adequate eye protection,
Checklist Before Startin ine
Review the unit's assembly to ensure you have performed
all of the following.
I. Make sure handle is in place and secure.
2. Check that oil has been added to proper level in the
engine crankcase.
3. Add proper gasoline to fuel tank.
4. Check for properly tightened hose connections.
S. Check to make sure there are no kinks, cuts, or
damage to high pressure hose.
6. Provide a proper water supply at an adequate flow.
7. Be sure to read "Safety Rules" and "HowTo UseYour
PressureVVasher" before using pressure washer.
7

CleanShotTM 2050 PSI Pressure Washer
HOWTO USEYOUR
PRESSURE WASHER
If you have any problems operating your pressure washer,
please call the pressure washer heIpline at m-800-743-4mmS.
Pressure Washer Location
Pressure Washer Cmearance
DANGEN
Operate pressure washer ONLY outdoors.
Keep exhaust gasfrom entering aconfined area through
windows, doors, ventilation intakes or other openings.
DO NC)T operate pressure washer inside any building or
encJosure.
The pressure washer must be at least 5 ft. (I 52 cm) from
structures having combustible walls and/or other
combustible materials. Leave at least 3 ft. (92 cm) all around
pressure washer including overhea& for adequate cooling,
maintenance and servicing.
Place pressure washer in a well ventilated area, which will
allow for removal of deadly exhaust gas. DO NOT place
pressure washer where exhaust gas could accumulate and
enter inside or be drawn into a potentially occupied
building. Ensure exhaust gas is kept away from any
windows, doors, ventilation intakes or other openings that
can allow exhaust gas to collect in a confined area
(Figure 7). Prevailing winds and air currents should be taken
into consideration when positioning pressure washer.
/
/
Typical Pressu_ e
Washe_ Shown
Exhaust Port
How to StartYour Pressure Washer
To start your pressure washer for the first time, follow
these instructions step-by-step.This starting information
also applies if you have let the pressure washer sit idle for
at least a day.
I. Place pressure washer near an outside water source
capable of supplying water at a flow rate greater than
2.9 gallons per minute and no less than 20 PSI at
pressure washer end of garden hose.
2. Check that high pressure hose is tightly connected to
spray gun and pump. See "Preparing Pressure _A/asher
for Use" for illustrations.
3. Hake sure unit is in a level position.
4. Connect garden hose to water inlet on pressure
washer pump. Turn ON water.
Damage to equipment resulting from failure to follow this
instruction will void warranty.
5. Attach adjustable nozzle extension to spray gun
(Figure 8).Tighten by hand.
\\
\
Position nozzle in low pressure mode (see "How to
Use the Adjustable Nozzle") and squeeze trigger on
spray gun to relieve air pressure caused by turning ON
water.Water will flow out of spray gun in a thin
stream. Continue to hold trigger until there is a steady
stream of water and no air remains in system.This will
make it easier to pull start engine. Release trigger.
Engage trigger lock on spray gun trigger (Figure 9).
8

eanShotPS,PressureWasher CleanShot
8. Start engine according to instructions given in engine
owner's manuaLAHso see operating instructions tag
located on the pressure washer.
When starting engine, puJI cord slowly until resistance is fek
and then pull rapidly to avoid kickback.
If engine starts and fails to continue to run or if increased
resistance is fek during starting pull attempts, squeeze trigger
on spray gun.
NOTE: Always keep the throttle lever in the "Fast"
_osition when operating the pressure washer.
WANNING
DO NOT touch hot surfaces,
Allow equipment to cool before touching.
The pressure washer must be at least 5 feet from structures
having combustible wails and/or other combustible materials.
Keep at least 3 feet of clearance on all sides of pressure
washer for adequate cooling, maintenance and servicing.
[n the State of Caiifornia a spark arrester is required by law
(Section 4442 of the California Public Resources Code). Other
states may have similar laws. Federal laws apply on federal
lands, ff you equip the muffler with a spark arrester, it must be
maintained in effective working order.
1
Now to gtopYour Pressure Washer
I. Let engine idle for two minutes.
2. Turn engine off according to instructions given in
engine owner's manual
3. Squeeze trigger on spray gun to relieve trapped
pressure in hose to avoid iniury.
NOTE: A small amount of water will squirt out when
pressure is released.
WANNING
Keep high pressure hose connected to pump and spray gun
while system is pressurized.
Squeeze trigger on spray gun to relieve trapped pressure,
every time you stop engine, Engage trigger lock on spray gun,
4. Engage trigger lock on spray gun when not in use.
Now to Use the Adjustable Nozzle
You should now know how to START and STOP your
pressure washer.The information in this section will tell
you how to adjust the spray pattern and to apply detergent
or other cleaning chemicals.
CAUTION
NEVER adiust spray pattern when spraying.
NEVER put hands in front of nozzle to adjust spray pattern.
9

CHeanShot TM 2050 PSI Pressure Washer
H. SHidenozzHe forward when you wish to adjust spray to
How pressure mode (Figure H0). SHidenozzHe backward
to achieve high pressure.
Forward =Low Pressure Backward =High Pressure
and Detergent Mode Mode
Point nozzle down towards a firm surface and press
trigger to test spray pattern (Figure I I).
3. Twisting nozzHe adjusts spray pattern from a narrow
pattern to a fan pattern (Figure H2).
CountercHockwise =Fan CHockwise =Narrow Spray
Spray Pattern Pattern
UsageTips
o For most effective cHeaning, keep spray nozzHe from 8 to
24 inches away from cHeaning surface.
o If you get spray nozzHe too chose, especiaHHy using high
pressure mode,you may damage surface being cHeaned.
o DO NOT get cHoser than 6 inches when cHeaning tires.
Applying Detergent with the
Adjustable Nozzle
iMPORTANT: Use soaps designed specifically for
pressure washers. HousehoHd detergents couHd damage
the pump.
•Starting the engine without all the hoses connected and
without the water turned ON will damage the pump.
Damage to equipment resulting from faih_re to follow this
instruction will void warranty.
To apply detergent, follow these steps_"
H. Review use of adiustabHe nozzHes.
2. Prepare detergent soHution as required by iob.
3. PHace fiHter end of chemicaH iniection hose into
detergent container.
• When inserting the filter into a detergent solution bottle,
route the tube so as to keep it fl'om inadvertendy contacting
the hot muffler.
4. SHide adiustabHe nozzHeforward to How pressure mode.
Detergent cannot be appHied with nozzHe in high
pressure position.
5. Make sure garden hose is connected to water inHet.
Check that high pressure hose is connected to spray
gun and pump. Start engine.
6. AppHy detergent to a dry surface, starting at Hower
portion of area to be washed and work upward, using
Hong,even, overHapping strokes.
7. AHHowdetergent to "soak in" for 3-5 minutes before
washing and rinsing. F_eappHyas needed to prevent
surface from drying. DO NOT aHHowdetergent to dry
on (prevents streaking).
JMPORTAJ_T:You must flush the chemicaH iniection
system after each use by pHacing the fiHter into a bucket of
dean water, then run the pressure washer in How pressure
for Ho2 minutes.
H0
