Owner’s Manual
Manual del Propietario
Manual No. 191678GS
Revision 1 (03/03/2003)
01805
(2500 PSI)
01806
(2650 PSI)
01936
(2550 PSI)
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON,WISCONSIN, U.S.A.
Questions? Help is just a moment away!
Preguntas? La ayuda es justa un momento lejos!
Call: Pressure Washer Helpline - 1-800-743-4115 M-F 8-5 CT
Llame: Línea Directa del Lavador a Presión - 1-800-743-4115 M-F 8-5 CT
Model 01806 Shown

Pressure Washer
2
TABLE OF CONTENTS
Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-14
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
EQUIPMENT
DESCRIPTION
Read this manual carefully and become
familiar with your pressure washer. Know its
applications, its limitations and any hazards
involved.
Every effort has been made to ensure that information in this
manual is accurate and current. However, we reserve the
right to change, alter or otherwise improve the product and
this document at any time without prior notice.
SAFETY RULES
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
The safety alert symbol ( ) is used with a signal word
(DANGER, CAUTION,WARNING), a pictorial and/or a
safety message to alert you to hazards. DANGER indicates
a hazard which, if not avoided, will result in death or serious
injury. WARNING indicates a hazard which, if not avoided,
could result in death or serious injury. CAUTION
indicates a hazard which, if not avoided, might result in
minor or moderate injury. CAUTION, when used
without the alert symbol, indicates a situation that could
result in equipment damage. Follow safety messages to
avoid or reduce the risk of injury or death.
Hazard Symbols and Meanings
In the State of California a spark arrester is required by law
(Section 4442 of the California Public Resources Code).
Other states may have similar laws. Federal laws apply on
federal lands. If you equip the muffler with a spark arrester,
it must be maintained in effective working order.
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
WARNING
Fire Explosion
Toxic Fumes
Hot Surface
Moving Parts
Electrical Shock
Slippery Surface Fall
Kickback
Flying Objects
Fluid Injection

Pressure Washer
3
• Keep water spray away from electric wiring or fatal electric
shock may result.
Spray contact with electrical wiring can result in
electrocution.
WARNING
• Operate pressure washer ONLY outdoors.
• Use a respirator or mask whenever there is a chance that
vapors may be inhaled.
• Read all instructions with mask so you are certain the mask will
provide the necessary protection against inhaling harmful vapors.
Running engine gives off carbon monoxide, an
odorless, colorless, poison gas.
Some chemicals or detergents may be harmful if
inhaled or ingested, causing severe nausea,
fainting or poisoning.
Breathing carbon monoxide will cause nausea,
fainting or death.
DANGER
• Keep spray nozzle between 8 to 24 inches away from cleaning
surface.
• Operate this unit on a stable surface.
• The cleaning area should have adequate slopes and drainage to
reduce the possibility of a fall due to slippery surfaces.
• Be extremely careful if you must use the pressure washer from
a ladder, scaffolding or any other relatively unstable location.
• Firmly grasp spray gun with both hands when using high
pressure spray to avoid injury if gun kicks back.
Use of pressure washer can create puddles and
slippery surfaces.
High pressure spray could cause you to fall if
you are too close to the cleaning surface.
WARNING
WHEN ADDING FUEL
• Turn pressure washer OFF and let it cool at least 2 minutes
before removing gas cap.
• Fill fuel tank outdoors.
• DO NOT overfill tank.Allow space for fuel expansion.
• Keep fuel away from sparks, open flames, pilot lights, heat, and
other ignition sources.
• DO NOT light a cigarette or smoke.
WHEN OPERATING EQUIPMENT
• DO NOT tip engine or equipment at angle which causes fuel
to spill.
• DO NOT spray flammable liquids.
WHEN TRANSPORTING OR REPAIRING EQUIPMENT
• Transport/repair with fuel tank EMPTY or with fuel shutoff
valve OFF.
WHEN STORING FUEL OR EQUIPMENT WITH FUEL
IN TANK
• Store away from furnaces, stoves, water heaters, clothes
dryers or other appliances that have pilot light or other
ignition source because they can ignite fuel vapors.
Fuel and its vapors are extremely flammable and
explosive.
Fire or explosion can cause severe burns or
death.
WARNING
• NEVER aim spray gun at people, animals or plants.
• DO NOT allow CHILDREN to operate pressure washer.
• NEVER repair high pressure hose. Replace it.
• Keep high pressure hose connected to pump and spray gun
while system is pressurized.
The high pressure stream of water that this
equipment produces can pierce skin and its
underlying tissues, leading to serious injury and
possible amputation.
WARNING

Pressure Washer
4
• DO NOT tamper with governed speed.
• DO NOT operate pressure washer above rated pressure.
Excessively high or low operating speeds increase risk
of injury and damage to pressure washer.
CAUTION
WHEN ADJUSTING OR MAKING REPAIRS TOYOUR
PRESSURE WASHER
• Disconnect spark plug wire from spark plug and place wire
where it cannot contact spark plug.
Unintentional sparking can result in fire or
electric shock.
WARNING
• DO NOT point spray gun at glass when in jet spray mode.
• NEVER aim spray gun at plants.
High pressure spray may damage fragile items including
glass.
CAUTION
• DO NOT wear loose clothing, jewelry or anything that may
be caught in the starter or other rotating parts.
• Tie up long hair and remove jewelry.
Starter and other rotating parts can entangle
hands, hair, clothing, or accessories.
WARNING
• Always wear eye protection when using this equipment or in
vicinity of where equipment is in use.
High pressure spray can cause paint chips or
other particles to become airborne.
WARNING
• DO NOT secure spray gun in open position.
• DO NOT leave spray gun unattended while machine is
running.
• NEVER use a spray gun which does not have a trigger lock or
trigger guard in place and in working order.
• Always be certain spray gun, nozzles and accessories are
correctly attached.
A pressure washer produces a high pressure spray
which increases risk of injury and damage to unit.
CAUTION
• If you have questions about intended use, ask dealer or
contact Briggs & Stratton Power Products.
• NEVER operate units with broken or missing parts, or
without protective housing or covers.
• DO NOT by–pass any safety device on this machine.
• Before starting pressure washer in cold weather, check all
parts of the equipment to be sure ice has not formed there.
• NEVER move machine by pulling on high pressure hose. Use
handle provided on unit.
• Check fuel system for leaks or signs of deterioration, such as
chafed or spongy hose, loose or missing clamps, or damaged
tank or cap. Correct all defects before operating pressure
washer.
• This equipment is designed to be used with Briggs & Stratton
Power Products authorized parts ONLY. If equipment is used
with parts that DO NOT comply with minimum specifications,
user assumes all risks and liabilities.
Improper treatment of pressure washer can damage it
and shorten its life.
CAUTION
• DO NOT touch hot surfaces.
• Stay clear of exhaust gases.
• Allow equipment to cool before touching.
Running engines produce heat and hot exhaust
gases.Temperature of muffler and nearby areas
can reach or exceed 150°F (65°C).
Fire or severe burns can occur.
WARNING

Pressure Washer
5
ASSEMBLY
IMPORTANT: Read entire owner’s manual before you
attempt to assemble or operate your new pressure washer.
Remove Pressure Washer From
Carton
1. Remove the parts bag, accessories, and inserts included
with pressure washer.
2. Slice two corners at the end of carton from top to
bottom so the panel can be folded down flat.
3. Remove pressure washer from carton.
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged, call the
pressure washer helpline at 1-800-743-4115. If calling for
assistance, please have the model, revision, and serial
number from the data tag available.
Perform these tasks to prepare unit for operation:
• Attach the handle to the main unit.
• Add oil to the engine.
• Add fuel to the fuel tank.
• Connect the high pressure hose to the spray gun and the
pump.
• Connect the water supply to the pump.
• Connect nozzle extension to spray gun.
• Select and install desired nozzle (if applicable).
Attach Handle to Unit
This manual describes assembly and use of three models
(01805, 01806 and 01936). Please see the appropriate
section for the handle instruction specific to your model.
To attach handle with accessory tray (Models 01805
and 01806):
NOTE: All assembly operations given in this section will
be described from the perspective of assembling the
pressure washer from the rear.
1. Slide plastic accessory tray onto handle and align holes
in accessory tray with holes on handle (Figure 1).
2. Secure tray to handle with self tapping screws using a
#2 phillips screwdriver. Ensure screws are tight but not
crushing the plastic accessory tray.
3. Place handle assembly onto handle supports connected
to main unit. Make sure holes in handle align with
holes on handle supports (Figure 2).
NOTE: It may be necessary to move handle supports
from side to side in order to align handle so it will slide
over handle supports.
Align Holes
Handle
Handle
Supports
Figure 2 — Attach Handle to Base
Figure 1 — Attach Accessory Tray

Pressure Washer
6
4. Insert “L” bolt through hole on left side of handle
(viewing from rear of unit) and attach plastic knob.
Tighten knob by hand (Figure 3).
5. Insert carriage bolt through right side hole from
outside of unit and attach plastic knob from inside of
unit (viewing from rear of unit).Tighten by hand
(Figure 3).
6. Insert “J” hook into second from left slot in accessory
tray (Figure 4).
7. Pinch chemical hose and slide it into metal clip as
shown in Figure 5.
8. Tilt unit up by handle and attach metal clip to rib on
center underside of accessory tray (Figure 6). Slide
chemical hose through metal clip so that it is tight but
not kinked.
Figure 3 — Secure Handle
Figure 4 — Install “J” Hook on Accessory Tray
Figure 5 — Slide Chemical Hose into Metal Clip
Figure 6 — Slide Metal Clip onto Accessory Tray Flange

Pressure Washer
7
To attach handle supplied with two “L” hooks
(Model 01936):
1. Place handle assembly onto handle supports connected
to main unit. Make sure holes in handle align with holes
on handle supports (Figure 7).
NOTE: It may be necessary to move the handle supports
from side to side in order to align the handle so it will slide
over the handle supports.
2. Insert carriage bolts through holes from outside of the
unit and attach a plastic knob from inside of unit
(Figure 8).Tighten by hand.
3. Insert one “L” hook through hole just under billboard
on left side of handle (viewing from rear of unit). Hold
hook in place with pliers and attach locknut with
7/16” wrench (Figure 9).
4. Insert other “L” hook through hole just above billboard
on right side of handle (viewing from rear of unit).
Hold hook in place with pliers and attach locknut with
7/16” wrench (Figure 9).
Add Engine Oil
IMPORTANT: Any attempt to crank or start the engine
before it has been properly serviced with the
recommended oil may result in an engine failure.
• Place pressure washer on a level surface.
• Refer to engine owners manual to add recommended oil
to engine.
NOTE: Check Oil Often During Engine Break–in.
Add Fuel
WARNING! NEVER fill fuel tank indoors. NEVER
fill fuel tank when engine is running or hot.Allow unit
to cool for two minutes before refueling. DO NOT
light a cigarette or smoke when filling the fuel tank.
WARNING! DO NOT overfill the fuel tank.
Always allow room for fuel expansion.
• Place pressure washer on a level surface.
• Refer to engine owners manual to add recommended
fuel to engine.
Hose Hook
Spray Gun
Hook
Figure 9 — Attach “L” Hooks to Handle
Align Holes
Handle
Handle
Supports
Figure 7 — Attach Handle to Base
Figure 8 — Secure Handle

Pressure Washer
8
Connect Hose and Water Supply to
Pump
IMPORTANT: To avoid pump damage, you must assemble
the nozzle extension to the spray gun and attach all hoses
before you start the engine.
1. Uncoil high pressure hose and attach one end of hose
to base of spray gun (Figure 12).Tighten by hand.
2. Attach other end of high pressure hose to high
pressure outlet on pump (Figure 13).Tighten by hand.
3. Before connecting garden hose to water inlet, inspect
inlet screen (Figure 14). Clean screen if it contains
debris or replace if damaged. Refer to “O-Ring
Maintenance” section on page 13 if inlet screen is
damaged. DO NOT run pressure washer if inlet screen
is damaged.
4. Run water through your garden hose for 30 seconds
to clean out any debris.
IMPORTANT: DO NOT siphon standing water for the
water supply. Use ONLY cold water (less than 100°F).
5. Connect garden hose (not to exceed 50 feet in length)
to water inlet.Tighten by hand (Figure 14).
CAUTION! There MUST be at least ten feet of
unrestricted garden hose between the pressure washer
inlet and any flow shut off device, such as a ‘Y’ shut-off
connector or other convenience-type water shut-off valve.
Damage to pressure washer resulting from disregarding this
warning will not be covered by the warranty.
6. Turn ON water and squeeze trigger on gun to purge
pump system of air and impurities.
CAUTION! Before starting the pressure washer,
be sure you are wearing adequate eye protection.
CHECKLIST BEFORE
STARTING ENGINE
Review the unit’s assembly to ensure you have performed
all of the following.
1. Make sure handle is in place and secure.
2. Check that oil has been added to proper level in
engine crankcase.
3. Add proper fuel to fuel tank.
4. Check for properly tightened hose connections.
5. Check to make sure that there are no kinks, cuts, or
damage to the high pressure hose.
6. Provide a proper water supply at an adequate flow.
7. Be sure to read “Safety Rules” and “How To Use Your
Pressure Washer” before using the pressure washer.
Figure 12 — Connect High Pressure Hose to Spray Gun
Figure 13 — Connect High Pressure Hose to Pump
OR
Figure 14 — Connect the Garden Hose to Water Inlet
Inspect inlet screen,
DO NOT use if
damaged, clean if dirty.
OR
Inspect inlet screen,
DO NOT use if
damaged, clean if dirty.
Model 01806
Model 01805
and 01806
Model 01806
Model 01805 and 01936

Pressure Washer
9
HOW TO USEYOUR
PRESSURE WASHER
If you have any problems operating your pressure washer,
please call the pressure washer helpline at 1-800-743-4115.
How to Start Pressure Washer
To start your pressure washer for the first time, follow
these instructions step-by-step.This starting information
also applies if you have let the pressure washer sit idle for
at least a day.
1. Place pressure washer near an outside water source
capable of supplying water at a flow rate greater than
1.0 gallons per minute more than pressure washer is
rated for and no less than 20 PSI at pressure washer
end of garden hose.
2. Check that high pressure hose is tightly connected to
spray gun and pump. See “Preparing Pressure Washer
for Use” for illustrations.
3. Make sure unit is in level position.
4. Connect garden hose to water inlet on pressure
washer pump. Turn ON water.
CAUTION! DO NOT run the pump without the water
supply connected and turned on.You must follow this
caution or the pump will be damaged.
5. Squeeze spray gun trigger until a steady stream of
water occurs.
6. For models 01806 and 01936, place quick connect
spray tips in slots on the holder attached to nozzle
extension (Figure 15).
7. On all models, attach nozzle extension to spray gun
(Figure 16).Tighten by hand.
8. Engage safety latch to spray gun trigger (Figure 17).
9. Start engine according to instructions given in engine
owner’s manual.
NOTE: Always keep the throttle lever in the “Fast”
position when operating the pressure washer.
How to Stop Pressure Washer
1. Let engine idle for two minutes.
2. Turn engine off according to instructions given in
engine owner’s manual.
3. Squeeze trigger on spray gun to relieve
pressure in hose.
NOTE: A small amount of water will squirt out when
pressure is released.
HOW TO USE NOZZLES
You now should know how to START your pressure
washer and how to STOP it.This section tells you how to
adjust the spray pattern.
WARNING! NEVER adjust spray pattern when
spraying. NEVER put hands in front of nozzle to test
spray pattern.
Figure 16 — Connect Nozzle Extension to Spray Gun
Safety Latch
Figure 17 — Spray Gun with Safety Latch Engaged
Figure 15 — Install Spray Tips in Holder
CAUTION
• Squeeze trigger on spray gun each time recoil starter is
pulled and engine fails to start.
Avoid injury from kickback.

10
Pressure Washer
If Unit is Equipped with Adjustable
Nozzle
If your pressure washer is equipped with an adjustable nozzle
(Model 01805 (2500 PSI)), adjust the spray pattern and spray
pressure as follows:
1. Slide nozzle forward to obtain low pressure mode
(Figure 18). Slide nozzle backward to achieve high
pressure.
2. Point nozzle towards firm surface and press trigger to
test spray pattern (Figure 19).
3. Twisting nozzle adjusts spray pattern from narrow
pattern to fan pattern (Figure 20).
4. For most effective cleaning, keep spray nozzle from
8 to 24 inches away from cleaning surface.
5. DO NOT get closer than 6 inches when cleaning
automobile tires.
If Unit is Equipped with
Quick-Connect Spray Tips
CAUTION! NEVER exchange nozzles without
locking the safety latch on the trigger.
NOTE: Model 01805 (2500 PSI) is NOT equipped with
quick connect spray tips.
The nozzle extension quick–connect allows the use of
several different spray tips. Each spray tip provides a
different spray pattern.
Follow these instructions to change spray tips:
1. Engage safety latch on spray gun.
2. Pull back collar on quick–connect and pull current
spray tip off.
3. Select desired spray tip:
• For gentle rinse, select white 40° spray tip.
• To scour surface, select yellow 15° or red 0° spray
tip.
• To apply chemical, select black spray tip.
4. Pull back on collar, insert new spray tip and release collar.
Tug on spray tip to make sure it is securely in place.
5. For most effective cleaning, keep spray tip from 8 to
24 inches away from cleaning surface. DO NOT get
closer than 6 inches when cleaning automobile tires.
Cleaning and Applying Chemical
IMPORTANT: Use soaps designed specifically for
pressure washers. Household detergents could damage
the pump.
To apply detergent follow these steps:
1. Review the use of nozzles.
2. Prepare detergent solution as required by manufacturer.
3. Place chemical injection siphon/filter into detergent
container.
CAUTION! Keep the chemical injection tube from
coming in contact with the hot muffler.
4A. For model 01805, slide adjustable nozzle forward to
low pressure mode. Detergent cannot be applied with
nozzle in high pressure position.
4B. For models 01806 and 01936, make sure black spray tip is
installed. Detergent cannot be applied with high pressure
quick-connect spray tips (White,Yellow, or Red).
Figure 18 — Adjusting Nozzle for Pressure
Slide nozzle backward
for High Pressure Mode
Slide nozzle forward for low
pressure mode and
detergent application
Figure 19 — Testing the Spray Pattern
Figure 20 — Adjusting the Nozzle for Spray Pattern
Rotate nozzle
counterclockwise for fan
spray pattern
Rotate nozzle clockwise
for narrow spray pattern
